Zline Monument Series User manual

Installation Manual
MONUMENT DISHWASHERS
www.zlinekitchen.com

ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams
is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to
providing you an elevated experience in the heart of your home. With an endless selection of features
and finishes, our inspiration is your reality.
ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury
designs and professional features into everyone’s homes. Because we continually strive to improve our
products, we may change specifications and designs without prior notice.
WARNING: This product can expose you to chemicals including nickel, which is known to the
State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.

COVERAGE
ZLINE Kitchen and Bath dishwashers will be warrantied for one year from the original
purchase date for the original purchaser of the product.
TERMS
This warranty applies only to the original purchaser of the product installed for
normal residential use. This is defined as a single-family, residential dwelling in a
non-commercial setting. Commercial settings include but are not limited to: schools,
churches, hotels, restaurants, vacation rentals such as Airbnb, day care centers,
private clubs, fire stations, common areas in multi-family dwellings, nursing homes,
food service locations, and institutional food service locations such as hospitals or
correction facilities. This warranty is non-transferable and will not be extended based
on the date of installation. The warranty applies only to products installed in the
continental United States and the District of Columbia. Warranty shall not apply and
ZLINE Kitchen and Bath is not responsible for damage resulting from negligence,
improper maintenance, misuse, abuse, alteration of or tampering with the appliance,
accident, natural disaster, improper electric supply, unauthorized service or repair,
improper installation, or installation not in accordance with the instructions contained
in the manual or the local codes.
WHAT IS NOT COVERED
1. Installation or start-up damages or problems caused by improper installation or
use.
2. Damage related to unauthorized service or unauthorized parts.
3. Installation in any commercial or non-residential application.
4. Aesthetic damage, scratches, or natural wear caused by normal use.
5. Second-hand, open box products, or products purchased from an unauthorized
retailer.
WARRANTY

GENERAL SAFETY INSTRUCTIONS 1
BEFORE INSTALLATION 3
INSTALLATION 12
OPERATIONAL SAFETY INSTRUCTIONS 34
OPERATION 37
MAINTENANCE AND CLEANING 51
TROUBLESHOOTING 56
TABLE OF CONTENTS

CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
This symbol indicates that dangerous voltage constituting a risk of
electric shock is present within your refrigerator.
This symbol indicates that there are important operating and
maintenance instructions in the literature accompanying your
refrigerator.
WARNING
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT
• Observe all governing codes and ordinances.
• Note to Installer – Be sure to leave these instructions for the consumer’s and local
inspector’s use.
• Note to Consumer – Keep these instructions with your User Guide for future
reference.
• Skill Level – Installation of this dishwasher requires basic mechanical and
electrical skills. Proper installation is the responsibility of the installer. Product
failure due to improper installation is not covered under the appliance warranty.
• Completion Time – One to three hours. New installations require more time than
replacement installations.
IMPORTANT
• The dishwasher MUST be installed to allow for future removal from the enclosure
if service is required.
• If you received a damaged dishwasher, you should immediately call customer
service.
IMPORTANT SAFETY INSTRUCTIONS
1
General Safety

FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS shown throughout these
instructions. While performing installations described in this booklet, gloves and
safety glasses or goggles should be worn.
WARNING
This dishwasher comes with a heating element to heat the water. To avoid the risk of a
serious burn, don’t touch the heating element when the dishwasher is on.
WARNING
To reduce the risk of electrical shock, fire, or injury to persons, the
installer must ensure that the dishwasher is completely enclosed at
the time of installation.
2
General Safety
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS shown throughout these
instructions. While performing installations described in this booklet, gloves and
safety glasses or goggles should be worn.
WARNING
This dishwasher comes with a heating element to heat the water. To avoid the risk of a
serious burn, don’t touch the heating element when the dishwasher is on.
WARNING
To reduce the risk of electrical shock, fire, or injury to persons, the
installer must ensure that the dishwasher is completely enclosed at
the time of installation.
IMPORTANT SAFETY INSTRUCTIONS
SPECIFICATIONS
Dimensions
(W x D x H)
• Unit with decorated door and handle: 23.9 x 26.5 x 33.7 in.
• Unit without decorated door and handle: 23.9 x 24 x 33.7 in.
Basket Handle
SPECIFICATIONS
Dimensions
(W x D x H)
• Unit with decorated door and handle: 23.9 x 26.5 x 33.7 in.
• Unit without decorated door and handle: 23.9 x 24 x 33.7 in.
IMPORTANT SAFETY INSTRUCTIONS
Basket handle
2
Product Specifications

If you have an installation problem, contact your dealer or installer. You are
responsible for providing adequate electrical, plumbing, and other connecting
facilities.
PREPARING TO INSTALL YOUR DISHWASHER
PARTS SUPPLIED
• Screws A - #8, 3/4”, Flat Head sheet
Metal Screw (4)
• Screws B - #8, 1/2”, Flat Head Sheet
Metal Screw (8)
• Screws C - #6, 7/8”, Flat Head Sheet
Metal Screw (2)
• Screws D - #6, 1 3/4”, Flat Head
Sheet Metal Screw (4)
• Top mounting clips (2)
• Hose clamp
• Drain hose
• Brackets (2)
• Top Hook Mounting Seats (2)
TOOLS NEEDED
• Phillips screwdriver
• 1/4” and 5/16” nut driver
• Level
• Flashlight
• Gloves
• Bucket
• Adjustable wrench
• Carpenters square
• Measuring tape
• Safety glasses
MATERIALS NEEDED (KIT PURCHASE SEPARATELY)
• 90° Elbow, ferrule and compression nut. (3/8” NPT external thread on one end. Other
end sized to fit water supply line
• Teflon thread seal tape
• Three wire nuts (UL listed) (two included in kit)
Not included in kit
• Hand shut-off valve
• Waste tee for house plumbing (if applicable)
• Screw-type hose clamps
• Coupler for extending drain line (if applicable)
• Air gap (if required)
PACKAGE CONTENTS
• Dishwasher
• Hose
• Installation Kits
• User Guide
• Installation Guide
BEFORE INSTALLATION
3
Tools

ENCLOSURE REQUIREMENTS
• The dishwasher must be installed so that the drain hose is no more than 10 ft. in
length, for proper drainage.
• This dishwasher is designed to be enclosed on the top and on both sides by a
standard residential kitchen cabinet unit.
• The installation enclosure must be clean and free of any obstructions.
• The enclosure must be at least 24 in. wide, 25 in. deep, and 34 in. high.
• For the front door of the dishwasher to be flush with the front edge of the counter
top, the counter top must be 25 in. deep.
If installing into a corner, allow 2 in. min. clearance between dishwasher and
adjacent cabinet, wall, or other appliances. Allow 25.63 in. min. clearance from the
front of the dishwasher for opening the door.
BEFORE INSTALLATION
4
Enclosure Dimensions

DRAIN REQUIREMENTS
• Follow all local codes and ordinances.
• Do not exceed 10 ft. of drain hose.
• Do not connect the drain lines from other devices to the dishwasher drain hose.
• The dishwasher must be connected to a waste line with an air gap (not provided)
or a 32 in. high (min.) drain loop, depending on local codes and ordinances, to
prevent back flow into the dishwasher.
• An air gap must be used if the waste tee or garbage disposal connection is less
than 18 in. above the floor, to prevent siphoning.
BEFORE INSTALLATION
5
Drain Requirements

DRAIN PREPARATION
The type of drain installation required depends on the answers to the following questions:
• Do local codes or ordinances require an air gap?
• Will the waste tee or garbage disposal connection be less than 18 in.
above the floor?
• Will installation have a drain loop less than 32 in. above the floor?
If the answer to ANY of these questions is YES, Method 1 MUST be used. Otherwise,
either Method 1 or Method 2 may be used.
Install the waste tee or garbage disposal connection and air gap according to
manufacturer’s instructions.
An air gap MUST BE USED if the drain hose is connected to a waste
tee or garbage disposal lower than 18 in. above the floor.
Failure to provide the proper drain connection height with an air
gap or 32 in. (min.) high drain loop will result in improper draining
of the dishwasher.
WARNING
Method 1 - Air gap with a waste tee or garbage disposal connection
Method 2 - High drain with a waste tee or garbage disposal connection
You must provide a method to attach the drain hose to the underside of the countertop.
BEFORE INSTALLATION
6
Drain Preparation

ELECTRICAL REQUIREMENTS
• This appliance must be supplied with 120V, 60 Hz, and it must be connected to
its own, properly grounded branch circuit that is protected by a 15 or 20 ampere
circuit breaker or time delay fuse.
• Wiring must be two wire with ground.
• If the electrical supply does not meet the above requirements, call a licensed
electrician before proceeding.
SPECIFICATIONS
Power requirements 120 V~60 Hz
Current 8.4 A
Water pressure Between 20 and 120 psi
Noise (dB) 45 dB
WARNING
Remove the house fuse or open the circuit breaker before beginning
the installation. Do not use an extension cord or adapter plug with
this appliance.
BEFORE INSTALLATION
7
Electrical Requirements

GROUNDING INSTRUCTIONS
Grounding Instructions – Cable Direct
This appliance must be connected to a grounded metal, permanent wiring system, or
an equipment grounding conductor must be run with the circuit conductors and be
connected to the equipment grounding terminal or lead on the appliance.
Grounding Instructions – Power Cord Models
This appliance must be grounded. In the event of a malfunction or breakdown,
grounding will reduce the risk of electrical shock by providing a path of least
resistance for electric current. The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with local codes and ordinances.
Direct Wire Method
• The cable must be routed as shown in “Cabinet Preparation and Wire Routing”
on page 9, and extend a minimum of 24 in. from the rear wall.
• Use flexible, armored, or nonmetallic sheathed, copper wire with grounding
wire that meets the wiring requirements for your home and local codes and
ordinances.
• Use a UL Listed/CSA Approved strain relief.
Power Cord Method
• Install a 3-prong grounding type receptacle. The wall outlet can be installed in a
cabinet or on a wall adjacent to the undercounter space in which the dishwasher
is to be installed.
• Use power cord kit (part number 5304504505) under Smart Choice brand
marked with Dishwasher Install Kit With Power Cord, available for purchase
from an authorized store. The power cord and connections must comply with
local codes and ordinances.
• The recommended power cord length is 54 in. min. and 64 in. max.
WARNING
The improper connection of the equipment grounding conductor can
result in a risk of electric shock. Check with a qualified electrician
or service representative if you are in doubt that the appliance is
properly grounded.
BEFORE INSTALLATION
8
Electrical Requirements

CABINET PREPARATION AND WIRE ROUTING
• The wiring may enter the opening from either side, the rear, or the floor within the
shaded area.
• The electrical connection is on the front right of the dishwasher.
• Drill a 1.5 in. maximum diameter hole to run the electrical cable through the wall
of the cabinet.
• The hole must be free of sharp edges. If the cabinet wall is metal, the hole edge
must be covered with a bushing or rubber grommet.
• Cable direct connections may pass through the same hole as the drain hose and
hot water line, but power cords with plugs must pass through a separate hole.
BEFORE INSTALLATION
9
Electrical Requirements

PREPARING THE HOT WATER LINE
• The water connection is on the left side of dishwasher.
• The hot water line may enter the opening from either side, the rear, or the floor
within the shaded area.
• The hot water line may pass through the same hole as the electrical and drain
hose. Or, you can drill an additional 1.5 in. maximum diameter hole for the hot
water line.
• If a power cord with a plug is used, the hot water line may not pass through the
same hole as the power cord.
BEFORE INSTALLATION
10
Water Connection

CONNECTING THE WATER LINE TO THE WATER SUPPLY
1. Turn off the water supply.
2. Install a hand shut-off valve in an accessible location, such as under the sink. This
is optional, but strongly recommended, and may be required by local codes.
3. Install the hot water inlet line, using at least 3/8” tubing. Route the line as shown
in the figure above and extend it forward at least 18 in. from the rear wall of the
enclosure.
4. Adjust the water heater to a temperature of 120° F to 150° F.
5. Flush the water line to clean out any debris.
Note: The hot water pressure must be between 20 and 120 psi
(138 and 827 kPa).
BEFORE INSTALLATION
11
Water Connection

STEP 1: INSTALL THE DECORATION DOOR TO THE OUTER DOOR OF THE
DISHWASHER
1. Install the hook and brackets on the decoration door.
2. Install the handle to the outer door.
YOU’LL NEED
• Phillips screwdriver
• 1/4” and 5/16” nut driver
• Screws B - ST4 X 14 (8)
• Screws C - ST3.5 X 25 (2)
• Screws D - ST3.5 X 45 (4)
• Brackets (2)
• Top Hook Mounting Seats (2)
• Screws E - 5mm x 80 pitch, Metric
Screw (2)
C
C
E
E
INSTALLATION
12
Panel Installation

3. Put the hook into the slot of the outer door for the positioning.
Put the hook into the slot of the outer door, for the positioning.
3
Fix the decoration door onto the outer door by screws and bolts.4
You’ll need:
Phillips screwdriver
D
1/4 in. and 5/16 in.
Nut driver
Screws D
ST3.5 x 45 (4)
Screws C
ST3.5 x 25 (2)
Screws B
ST4 x 14 (8)
Top Hook
Mounting Seats (2)
Brackets (2)
11
ATTENTON: you need an assistant to hold the top of the machine to prevent it forward.
INSTALLATION
13
Panel Installation

4. Fix the decoration door onto the outer door by screws.
D
INSTALLATION
14
Panel Installation

STEP 2: CHECK THE DOOR BALANCE
CAUTION
Opening the door of your dishwasher before it is installed will cause
it to tip forward. Do not open the door until you are ready to install
your dishwasher.
If it is necessary to open the door, hold the top of the dishwasher
securely with one hand and hold the door with the other hand.
1. Hold the top of the dishwasher firmly.
2. Open the door slowly, then release it. If the door drops, increase the spring
tension. If the door closes, decrease the spring tension.
3. Continue moving the spring pin until the door is balanced. Adjust both springs to
the same tension.
Note: If you choose the wood decoration door (about 8 lbs), you can
choose the fifth groove from the top groove. If you choose the metal
decoration door (about 17 lbs), you need fix the springs to the third
groove in the same method.
Adjust to 0.25” less
than the installation
height
INSTALLATION
15
Door Balance
