Zline MWO-24 Assembly instructions

Microwave oven
Installation Guide
and Users Manual

REGISTERING YOUR PRODUCT
Please register your ZLINE appliance. Begin the simple registration
process by scanning the QR code.
By registering your appliance, you will have easy and accurate
access to:
• Technical Support
• Warranty Service
• Tracking your support inquiries
WARNING: This product can expose you to chemicals including nickel, which is known to the
State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
SCAN ME

ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your
dreams is never out of reach. Through our unique designs and unparalleled quality, we’re
dedicated to providing you an elevated experience in the heart of your home. With an
endless selection of features and finishes, our inspiration is your reality.
ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end
luxury designs and professional features into everyone’s homes. Because we continually strive
to improve our products, we may change specifications and designs without prior notice.

COVERAGE
ZLINE Kitchen and Bath microwave parts will be warrantied for two years from the
original purchase date for the original purchaser of the product.
TERMS
This warranty applies only to the original purchaser of the product installed for
normal residential use. This is defined as a single-family, residential dwelling in a
non-commercial setting. Commercial settings include but are not limited to: schools,
churches, hotels, restaurants, vacation rentals such as Airbnb, day care centers,
private clubs, fire stations, common areas in multi-family dwellings, nursing homes,
food service locations, and institutional food service locations such as hospitals or
correction facilities. This warranty is non-transferable and will not be extended based
on the date of installation. The warranty applies only to products installed in the
continental United States and the District of Columbia. Warranty shall not apply and
ZLINE Kitchen and Bath is not responsible for damage resulting from negligence,
improper maintenance, misuse, abuse, alteration of or tampering with the appliance,
accident, natural disaster, improper electric supply, unauthorized service or repair,
improper installation, or installation not in accordance with the instructions contained
in the manual or the local codes.
WHAT IS NOT COVERED
1. Installation or start-up damages or problems caused by improper installation or
use.
2. Damage related to unauthorized service or unauthorized parts.
3. Installation in any commercial or non-residential application.
4. Aesthetic damage, scratches, or natural wear caused by normal use.
5. Second-hand, open box products, or products purchased from an unauthorized
retailer.
WARRANTY

TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 1
BEFORE INSTALLATION 7
INSTALLATION 12
OPERATION 16
MAINTENANCE 43
TROUBLESHOOTING 45

1
General Safety
Read all instructions before using the appliance.
When using electrical appliances basic safety precautions
should be followed, including the following:
• Install or locate this appliance only in accordance with
the provided installation instructions.
• This appliance is intended to be used in household and
similar applications such as: staff kitchen areas in shops,
offices, and other working environments; by clients in
hotels, motels, and other residential type environments;
farm houses; bed and breakfast type environments.
WARNING
WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.
•
• Do not attempt to operate this oven with the door open.
This can result in harmful exposure to microwave energy.
It is important not to break or tamper with the safety
interlocks.
• Do not place any object between the oven front face and
the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
• Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that
there is no damage to the:
• Door (bent)
• Hinges and latches (broken or loosened)
• Door seals and sealing surfaces
• The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
• If the oven is not maintained in a good state of
cleanliness, its surface could be degraded and affect the
lifespan of the oven and lead to a dangerous situation.
SAFETY INSTRUCTIONS

2
General Safety
• Use this appliance only for its intended use as described
in the manual. Do not use corrosive chemicals or
vapors in this appliance. This type of oven is specifically
designed to heat, cook or dry food. It is not designed for
industrial or laboratory use.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
• Heavily soiled seal: If the seal is very dirty, the appliance
door will no longer close properly during operation. The
fronts of adjacent units could be damaged. Always keep
the seal clean.
• This appliance can be used by children if they have been
given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision. Keep the appliance and its
cord out of reach of children without supervision.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard. (For appliances with
type Y attachment.)
• Do not immerse cord or plug in water.
• Keep cord away from heated surface.
• Do not let cord hang over edge of table or counter.
• Do not cover or block any openings on the appliance.
• Do not store this appliance outdoors. Do not use this
product near water - for example, near a kitchen sink,
in a wet basement, near a swimming pool, or similar
location.
SAFETY INSTRUCTIONS

3
Fire Safety
• To reduce the risk of fire in the oven cavity:
• Do not overcook food. Carefully attend
appliance when paper, plastic, or other
combustible materials are placed inside the oven
to facilitate cooking.
• Remove wire twist-ties from paper or plastic bag
before placing bag in oven.
• If material inside of the oven ignites, keep oven
door closed, turn oven off, and disconnect
power cord or shut off power at the fuse or circuit
breaker panel.
• Do not use the cavity for storage purposes. Do
not leave paper products, cooking utensils, or
food in the cavity when not in use.
• If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
• Care should be taken not to displace the turntable when
removing containers from the appliance.
• Some products, such as whole eggs and sealed
containers - for example, closed glass jars - can explode
and should not be heated in this oven.
WARNING
WARNING: Liquids and other foods must not be
heated in sealed containers since they are liable to
explode.
SAFETY INSTRUCTIONS

4
Food Safety
• Liquids, such as water, coffee, or tea may be heated
beyond the boiling point without appearing to be
boiling. Visible bubbling or boiling when the container
is removed from the microwave oven is not always
present. THIS COULD RESULT IN VERY HOT LIQUID
SUDDENLY BOILING OVER WHEN THE CONTAINER
IS DISTURBED OR A UTENSIL IS INSERTED INTO THE
LIQUID. To reduce the risk of injury to persons:
• Do not overheat the liquid.
• Stir the liquid both before and halfway through
heating it.
• Do not use straight-sided containers with narrow
necks.
• After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
• Use extreme care when inserting a spoon or
other utensil into the container.
• Do not operate any heating or cooking appliance
beneath the appliance. (Exception: A microwave oven
made for use above another heating appliance.)
• Do not mount unit over or near any portion of heating or
cooking appliance. (Exception: A microwave oven made
for use above another heating appliance.)
• Do not mount over sink.
• Do not store anything directly on top of the appliance
surface when the appliance is in operation.
• Oversized food or oversized metal utensils should not
be inserted in a microwave/ toaster oven as they may
create a fire or risk of electric shock.
• The appliance shall not be cleaned with a steam cleaner.
• Do not clean with metal scouring pads. Pieces can burn
off the pad and touch electrical parts involving a risk of
electric shock.
SAFETY INSTRUCTIONS

5
• Do not use paper products when appliance is operated in
the toaster mode.
• Do not store any materials, other than manufacturer’s
recommended accessories, in this oven when not in use.
• Do not cover racks or any other part of the oven with
metal foil. This will cause overheating of the oven.
• When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
• Only use utensils that are suitable for use in microwave
ovens.
• The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
• The oven should be cleaned regularly and any food
deposits removed since they may explode, even after
microwave heating has ended.
• The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth, and similar
may lead to risk of injury, ignition, or fire.
WARNING
WARNING: The appliance and its accessible parts
become hot during use. Surface of a storage drawer
can get hot. Care should be taken to avoid touching
heating elements. Metallic containers for food and
beverages are not allowed during microwave
cooking.
• The appliance is intended to be used built-in.
• The appliance must not be installed behind a decorative
door in order to avoid overheating.
• Using metal with the microwave function can cause
sparks. Metal - e. g. a spoon in a glass - must be kept at
least 1 in. from the oven walls and the inside of the door.
Sparks could irreparably damage the glass on the inside
of the door.
Cooking Safety
SAFETY INSTRUCTIONS

6
• Water in the hot cooking compartment: Never pour water
into the hot cooking compartment. This will cause steam.
The temperature change can cause damage.
• Moist food: Do not store moist food in the closed cooking
compartment for long periods.
• Do not use the appliance to store food. This can lead to
corrosion.
• Cooling with the appliance door open: Only leave the
cooking compartment to cool with the door closed. Do
not trap anything in the appliance door. Even if the door
is only slightly ajar, the fronts of adjacent units may be
damaged over time.
• Operating the microwave without food: Operating the
appliance without food in the cooking compartment may
lead to overloading. Never switch on the appliance
unless there is food in the cooking compartment.
• Using the appliance door for standing on or placing
objects on: Do not stand or place anything on the open
appliance door. Do not place ovenware or accessories
on the appliance door.
• Transporting the appliance: Do not carry or hold the
appliance by the door handle. The door handle cannot
support the weight of the appliance and could break.
ENVIRONMENTALLYFRIENDLY DISPOSAL
Energy and environment tips
Here you can findtips on how to save energy when baking and
roastingand how to dispose of your appliance properly.
Saving energy
■Only preheat the oven if this is specified in the recipe or in the
operating instruction tables.
■Use dark, black lacquered orenamelled bakingtins. They
absorb the heat particularly well.
■Open the oven door as infrequently as possible while you are
cooking, baking or roasting.
■It is best to bake several cakes one after the other. The oven is
still warm. This reduces the baking time for the secondcake.
You can also place two loaf tins next to each other.
■For longer cooking times, you can switch the oven off
10 minutes before the end of the cooking time and use the
residual heat to finish cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly manner.
This appliance complies with European Directive 2002/
96/EC on Waste Electrical and Electronic Equipment
(WEEE). The directive gives a framework for the
collection and recycling of old appliances, which is valid
across the EU.
Expert Cooking Guide
The charts can be used as a guide. Follow package or recipe directions.
Broil
Place pan of food on the wire rack with the recess facing
up.
Food Oven tem-
perature
Cooking time
(minutes)
Internal tem-
perature
Cooking tip / Procedure
Hamburgers,
_" to 1", medium
High Side 1: 9 - 11
Side 2: 10 - 12
160°F
(71°C)
Use pan that allows fat to drain away from the
food.
High fat meat causes more spattering.
Lamb chops,
1", medium
High Side 1: 9 - 11
Side 2: 10 - 12
160°F
(71°C)
Use pan that allows fat to drain away from the
food.
Slit fat to prevent curling.
Sausage, fresh High Side 1: 9 - 11
Side 2: 8 - 10
160°F
(71°C)
Use pan that allows fat to drain away from the
food.
Steaks, _ " to 1",
medium rare
High Side 1: 9 - 11
Side 2: 10 - 12
145°F
(63°C)
Use pan that allows fat to drain away from the
food.
Slit fat to prevent curling.
Steaks, _ " to 1",
medium
High Side 1: 9 - 11
Side 2: 10 - 12
160°F
(71°C)
Use pan that allows fat to drain away from the
food.
Slit fat to prevent curling.
Toasting bread Low 3 - 5 - Check at minimum time.
Top browning cas-
seroles
Low 3 - 5 - Use only metal or glass ceramic dishes such as
Corning Ware®
Convection Broil
Place pans of food on the wire rack with the recess
facing up.
Food Oven
temperature
Cooking time
(minutes)
Internal
temperature
Cooking tip / Procedure
Chicken breasts,
bone-in
Low Side 1: 9 - 11
Side 2: 10 - 12
170°F
(76°C)
Start breast side down.
Fish filets,
_ " to 1"
Low 11 - 15 145°F
(63°C)
No turning of fish.
Turn thin ends under.
Brush with olive oil or butter to prevent sticking.
Dispose of packaging in an environmentally-friendly
manner. This appliance complies with European
Directive 2002/ 96/EC on Waste Electrical and
Electronic Equipment (WEEE). The directive gives a
framework for the collection and recycling of old
appliances, which is valid across the EU.
SAFETY INSTRUCTIONS
Environmental Safety

7
48”
21”
22 “
1
16
17 “
3
4
24 “
3
16
22 “
3
16
13 “
1
8
23 “
7
16 17 “
7
8
MWO-24 Appliance Dimensions
MWO-30 Appliance Dimensions
48”
19”
27 “
13
16
24 “
7
8
21 “
3
8
22 “
3
8
13 “
3
4
29 “
3
4 19 “
5
8
BEFORE INSTALLATION
PRODUCT SPECIFICATIONS
MWO-30
MWO-24
Product Specifications

8
Tools Needed
Gather the required tools before starting installation. Read and follow the instructions
provided with any tools listed here.
TOOLS AND PARTS NEEDED
• Philips head screwdriver
• 1/8” drill bit and drill
• Measuring tape
• Knife
PARTS PROVIDED
• Philips head screws
BEFORE INSTALLATION

9
Electrical Connection
ELECTRIC SHOCK HAZARD
• Before you plug in an electrical cord or turn on power supply, make sure all
controls are in the OFF position.
• This appliance must be grounded. Connect only to properly grounded outlet.
• Improper grounding can result in a risk of electric shock. Consult a qualified
electrician if the grounding instructions are not completely understood, or if doubt
exists as to whether the appliance is properly grounded.
• Do not cut or remove the ground prong. It must be plugged into a matching
grounding type receptacle to avoid electrical shock. If there is any doubt as to
whether the wall receptacle is properly grounded, the check with a qualified
electrician.
• Before installing, turn power OFF at the service panel. Lock service panel to
prevent power from being turned ON accidentally.
• Be sure your appliance is properly installed and grounded by a qualified
technician. Installation, electrical connections and grounding must comply with all
applicable codes. This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by providing an escape
wire for the electric current. This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must be plugged into an outlet
that is properly installed and grounded. The outlet must be properly grounded in
accordance with all applicable codes.
WARNING: Improper use of the grounding can result in a risk of
electric shock.
• Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood, or if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use only a 3-wire extension
cord that has a 3-blade grounded plug, and 3-slot receptacle that will accept the
plug on the appliance. The marked rating of the extension cord shall be equal to
or greater than the electrical rating of the appliance.
WARNING
WARNING
BEFORE INSTALLATION

10
Electrical Connection
• Only a qualified electrician who takes the appropriate regulations into account
may install the socket or replace the connecting cable. If the plug is no longer
accessible following installation, an all-pole isolating switch must be present on
the installation side with a contact gap of at least 1/8”. Contact protection must
be ensured by the installation.
• Touching some of the internal components can cause serious personal injury or
death. Do not disassemble this appliance. Improper use of the grounding can
result in electric shock. Do not plug into an outlet until appliance is properly
installed and grounded.
• A short power-supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
WARNING
WARNING: We do not recommend using an extension cord and if used
on this appliance, it will void warranty. If you are going to use an extension
cord, make sure the wire gauge and length are correct for use with a
microwave. The use of an extension cord can cause voltage drop, fire
hazard, and can cause permanent damage to the microwave if used.
• Longer cord sets or extension cords are available and may be used if care is
exercised in their use.
• If a long cord or extension cord is used:
• The marked electrical rating of the cord set or extension cord should be
at least as great as the electrical rating of the appliance.
• The extension cord must be a grounding-type 3-wire cord.
• The longer cord should be arranged so that it will not drape over the
counter top or tabletop where it can be pulled on by children or
tripped over unintentionally.
ELECTRICAL REQUIREMENTS:
• A three prong grounded outlet
• 120 V, 60 Hz, AC only
• 20 Amp electrical supply with a fuse or a circuit breaker
BEFORE INSTALLATION

11
Electrical Connection
ELECTRIC INSTALLATION
• This product must be connected to a supply circuit of the proper voltage and
frequency. Wire size must conform to the requirements of the National Electric
Code or the prevailing local code for this rating.
• The power supply cord and plug should be brought to a separate 20-amp
branch circuit single grounded outlet. The outlet box should be located inside the
cabinet above the appliance.
• The outlet box and supply circuit should be installed by a qualified electrician
and conform to the National Electrical Code or the prevailing local code.
• The voltage used must be the same as specified on this microwave oven. Using
a higher voltage is dangerous and may result in a fire or oven damage. Using a
lower voltage will cause slow cooking.
• The manufacturer is not responsible for any damages resulting from the use of the
oven with any voltage other than specified.
OUTLET AREA
• Anywhere within the shaded area the minimal distance between the appliance
and the wall is 1 3/4”.
• The outlet can be located anywhere within the shaded area.
BEFORE INSTALLATION
MWO-24 MWO-30

12
Cabinet Requirements
GENERAL CABINET REQUIREMENTS:
• 1⁄4” space between the side of the appliance and an adjacent wall or cabinet
door when installed at the end of a cabinet run.
• The cabinet base must be flat and capable of supporting the weight of your
appliance when in use.
• The appliance door will overlap the furniture below by approx 3/16” when
opened.
• There must be an air gap of at least 1/4” between the appliance and the
cabinet walls when the appliance is installed, i.e. 1/8” each side.
INSTALLATION
MWO-24
MWO-30

13
Cabinet Requirements
VENTILATION
This appliance is only intended to be fully fitted in a kitchen.
• This appliance is not designed to be used as a tabletop appliance or inside a
cupboard.
• The fitted cabinet must not have a back wall behind the appliance.
• A gap of at least 1 3/4” must be maintained between the wall and the base or
back panel of the unit above.
• The fitted cabinet must have a ventilation opening of 38 3/4 in² on the front. To
achieve this, cut back the base panel or fit a ventilation grill.
• Ventilation slots and intakes must not be covered.
• The safe operation of this appliance can only be guaranteed if it has been
installed in accordance with these installation instructions.
• The units into which the appliance is fitted must be heat-resistant up 194°F.
• Note: There should be a gap above the oven.
INSTALLATION
MWO-24
MWO-30

14
Cabinet Requirements
Flush installation also requires:
• Two side cleats to be attached inside the cabinet frame, recessed from the front
• A 5/16” baseplate underneath the unit body.
INSTALLATION
MWO-24
MWO-30

15
Cabinet Requirements
BUILDING IN
• Carefully push the microwave into the cabinetry, making sure that it is in the
center.
• Do not kink the connecting cable.
• Open the door and fasten the microwave with the screws that were supplied.
WARNING
WARNING: The gap between the worktop and the appliance must
not be closed by additional battens.
MOUNT TO CABINET
NOTE: The appliance is heavy. It is advisable to install it with a second person.
NOTICE
NOTICE: Before installing the appliance, be sure to verify the cabinet
dimensions and electrical connections.
1. Fully insert the appliance and center it. Do not kink the electrical cable.
2. Screw the appliance into place.
INSTALLATION
MWO-24
MWO-30
