Zokop SF311-36G User manual

Table of Contents
Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Pre-installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Care And Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2

3

36in.x4.3in.x17in.
120V
60Hz
1400W
4
Rated Power

4
2+extra2
2+extra2
5

6
Electric Firebox (A) to the pre-drilled holes with Wall Anchor (CC) and Large Screw (BB) by using Phillips screw driver.
Attention: At least 23.6 in. of free space is required at the top of the product and at least 7.9 in. of free space at left, right and bottom side.
Note: Please observe that the power plug must still be able to be reached after installation of the electric fireplace insert.
25 in.

7
USING THE MANUAL AND REMOTE CONTROLS
Note: This panel contains the buttons to properly operate the electric fireplace.
The buttons on the control panel on the side of the electric fireplace and the remote control function in the same way. The remote control has an
effective range of up to 13 feet.
1. Digital display unit
2. Function indicator
3. Timer button
4. Thermostat button
5. Flame control button
6. Power ON/OFF button
7. Week timer
8. Week timer adjustment
USING THE POWER ON/OFF BUTTON
1. Pressing the Power on/off button (6) once to turns the unit on.
2. Pressing the Power on/off button (6) again will turn the unit off.
3. If you find that none of the other buttons appear to work, check
to make sure that the Power on/off button (6) is turned on.
USING THE FLAME CONTROL BUTTON
Pressing the flame control button (5) to turn on the flame effect. To press the flame control button (5) to adjust the flame brightness,
there are 3 levels of flame brightness, L3-L2-L1-L3.
USING THE THERMOSTAT CONTROL BUTTON
1. Pressing the thermostat control button (4) to turn on the heating function.
2. Pressing the thermostat control button (4) to cycle through the different heat settings, 17°C-18°C-19°C-.…-26°C-27°C-0N-OFF
3. To display the temperature setting in either Fahrenheit or Celsius, press the thermostat button (4 ) of control panel once,
then press and hold the power on/off button (6) of the control panel for 5 seconds.
4. The display will switch between Fahrenheit or Celsius.

USING THE TIMER CONTROL BUTTON
Pressing the timer control button (3) will set the timer. This interval period is shown in the display (1) on the control panel on the side
of the electric fireplace. There are total 8 levels timer settings, from 0.5hf-1hf-2hr-3hf-4hr-5hr-6hr-OFF.
USING THE WEEK TIMER CONTROL BUTTON
Note: Besides a regular timer function, this unit also equipped with week timer function,
to setup the time when to turn on and off the heater with desired temperature, one group each day and max.
7 days/group available, if stop pressing any of those buttons for more than 5 seconds,
will quite the week timer function and confirm the previous setting.
USING THE REMOTE CONTROL TO SETUP THE WEEK TIMER
Press the week timer button (7) 1st time to activate the function and set up the current local time
by pressing week timer adjustment buttons (8) “+”/"-” and repress the week timer button (7) to enter the adjustment mode
and the digital display showing “--", then press the week timer adjustment buttons (8) "+"/"-" to setup the time to
turn on and turn off the unit, and press the week button (7) 4th times to set up the temperature.
Repeat the actions above to setup the time and temperature for other groups and different days.
USING THE TIMER BUTTON 13 ON CONTROL PANEL TO SETUP THE WEEK TIMER
Press and hold the timer button (3) on control panel for 5 seconds to input current local time (01, 02.03,... 21,22, 23)
by pressing flame button (5) or thermostat control button (4), then press timer button (3) again to confirm previous setup
and the digital display will show"1d” to start set up 1st group and re-press the timer button (3) again
and after digital display showing "--" to setup UNIT-OFF-TIMER by pressing flame button (5) or thermostat control button (4),
then press the timer button (3) once to confirm the previous settings and after the digital display showing “--” to set up the temperature desired,
and repeat to set up 2d, 3d, ...,7d, to skip a specified day/group, by continue pressing timer button (3) .
8

9
