Zotac nForce 610i - ITX User manual

1
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with instructions
contained in this manual, may cause harmful interference to radio and television communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- REORIENT OR RELOCATE THE RECEIVING ANTENNA
- INCREASE THE SEPARATION BETWEEN THE EQUIPMENT AND THE RECEIVER
- CONNECT THE EQUIPMENT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM
THAT OF THE RECEIVER
- CONSULT THE DEALER OR AN EXPERIENCED AUDIO/TELEVISION TECHNICIAN
NOTE:
Connecting this device to peripheral devices that do not comply with Class B requirements, or
using an unshielded peripheral data cable, could also result in harmful interference to radio or
television reception.
The user is cautioned that any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
To ensure that the use of this product does not contribute to interference, it is necessary to use
shielded I/O cables.
Copyright
This manual is copyrighted with all rights reserved. No portion of this manual may be copied or
reproduced by any means.
While every precaution has been taken in the preparation of this manual, no responsibility for
errors or omissions is assumed. Neither is any liability assumed for damages resulting from the
use of the information contained herein.
Trademarks
All brand names, logos and registered trademarks mentioned are property of their respective
owners.
Electronic Emission Notices
WARNING!

2
NForce 610i/630i-ITX series Motherboard
Table of Contents
Motherboard Specifications ------------------------------------------------------------------- 4
Motherboard Layout------------------------------------------------------------------------------ 5
Hardware Installation ---------------------------------------------------------------------------- 7
Safety Instructions ----------------------------------------------------------------------------- 7
Preparing the Motherboard -------------------------------------------------------------------- 8
Installing the CPU------------------------------------------------------------------------------ 8
Installing the CPU Fan------------------------------------------------------------------------ 9
Installing Memory DIMMs -------------------------------------------------------------------- 9
Installing the Motherboard ------------------------------------------------------------------- 10
Installing the I/O Shield ----------------------------------------------------------------------- 10
Connecting Cables and Setting Switches ------------------------------------------------ 11
24-pin ATX Power (PW1)--------------------------------------------------------------------- 12
4-pin ATX 12V Power (PW2) ---------------------------------------------------------------- 12
Hard Disk Connector-IDE-------------------------------------------------------------------- 13
SPDIFOut Header(optional) ---------------------------------------------------------------- 13
SPK Connector --------------------------------------------------------------------------------- 13
Front Panel Header---------------------------------------------------------------------------- 14
USB Headers------------------------------------------------------------------------------------ 15
Serial Port Connector-COM ----------------------------------------------------------------- 15
Audio ---------------------------------------------------------------------------------------------- 16
Connecting Serial ATA Cables(optional)-------------------------------------------------- 17
Fan Connections ------------------------------------------------------------------------------- 17
Expansion Slots -------------------------------------------------------------------------------- 18
PCI Express x1 Slots(optional) ------------------------------------------------------------- 18
Jumper Settings -------------------------------------------------------------------------------- 19
Configuring the BIOS ---------------------------------------------------------------------------- 20
Enter BIOS Setup ------------------------------------------------------------------------------ 20
Main Menu ------------------------------------------------------------------------------------------- 21
Standard CMOS Features Menu-------------------------------------------------------------- 22
Date and Time ---------------------------------------------------------------------------------- 22
IDE Channel------------------------------------------------------------------------------------- 22
Drive A -------------------------------------------------------------------------------------------- 23
Halt On-------------------------------------------------------------------------------------------- 23
Memory ------------------------------------------------------------------------------------------- 23
Advanced BIOS Features----------------------------------------------------------------------- 24
CPU Features--------------------------------------------------------------------------------------- 25
Hard Disk Boot Priority ------------------------------------------------------------------------- 26

3
Table of Contents
Advanced Chipset Features ------------------------------------------------------------------- 28
Integrated Peripherals Menu ------------------------------------------------------------------ 29
Power Management Setup Menu ------------------------------------------------------------ 30
PnP/PCI Configuration -------------------------------------------------------------------------- 31
PC health status ----------------------------------------------------------------------------------- 33
Frequency/Voltage Control -------------------------------------------------------------------- 33
Load Optimized Defaults ----------------------------------------------------------------------- 34
Set Supervisor/User Password--------------------------------------------------------------- 35
Save & Exit Setup --------------------------------------------------------------------------------- 36
Exit Without Saving ------------------------------------------------------------------------------ 36
Installing Drivers and Software -------------------------------------------------------------- 37
Drivers Installing --------------------------------------------------------------------------------- 38
Flash Update Procedure ----------------------------------------------------------------------- 42
REALTEK HD AUDIO DRIVER SETUP ----------------------------------------------------- 43
Getting Started---------------------------------------------------------------------------------- 43
Sound Effect------------------------------------------------------------------------------------- 43
Environment Simulation ---------------------------------------------------------------------- 43
Equalizer Selection --------------------------------------------------------------------------- 44
Frequently Used Equalizer Setting -------------------------------------------------------- 44
Karaoke Mode ---------------------------------------------------------------------------------- 44
Mixer----------------------------------------------------------------------------------------------- 45
Playback control --------------------------------------------------------------------------- 45
Recording control-------------------------------------------------------------------------- 46
Audio I/O------------------------------------------------------------------------------------- 47
Speaker Configuration ------------------------------------------------------------------- 48
Connector Settings------------------------------------------------------------------------ 49
S/PDIF --------------------------------------------------------------------------------------- 49
Speaker Calibration----------------------------------------------------------------------- 50
Microphone---------------------------------------------------------------------------------- 51
Noise Suppression ------------------------------------------------------------------------ 51
Beam Forming ----------------------------------------------------------------------------- 51
Acoustic Echo Cancellation------------------------------------------------------------- 51
Audio Demo--------------------------------------------------------------------------------- 52
Information --------------------------------------------------------------------------------- 52
SATA RAID User Manual ------------------------------------------------------------------------ 53
Setting up the BIOS --------------------------------------------------------------------------- 53
Entering the RAID BIOS Setup ------------------------------------------------------------- 55
Installing the RAID Drives-------------------------------------------------------------------- 58

4
NForce 610i/630i-ITX series Motherboard
Motherboard Specications
qChipset
NVIDIA MCP73 Series
qSize
Mini-ITX form factor of 170mm x 170mm
qMicroprocessor support
Intel LGA 775 Celeron® , Pentium® 4, Pentium® D, CoreTM 2 Series
qOperating systems:
Supports Windows XP 32bit/64bit and Windows Vista 32bit/64bit
qSystem Memory support
Supports DDRII533/667(DDRII800 for NForce630i series). Supports up to 4GBs
DDRII memorys.
qUSB 2.0 Ports*
v Supports hot plug and play
v Eight USB 2.0 ports (four rear panel ports, four from onboard USB
headers)(For Ver:01,02 PCB)
v Ten USB 2.0 ports (six rear panel ports, four from onboard USB headers)(For
Ver:10,20 PCB)
v Supports wake-up from S1
v Supports USB 2.0 protocol up to 480 Mbps transmission rate
qOnboard Serial ATA II
v Independent DMA operation on two ports (optional).
vData transfer rates of 3Gb/s.
qOnboard LAN
vLAN interface built-in onboard
v Supports 10/100Mbps Ethernet
v Supports 1000Mbps Ethernet(Optional for Ver:10,20 PCB)
qOnboard Audio(optional)
v Azalia High-Definition audio
v Supports 6-channel
v Supports Jack-Sensing function
qGreen Function
v Supports ACPI (Advanced Configuration and Power Interface)
v RTC timer to power-on the system
v AC power failure recovery
v Supports suspend to RAM (STR)(For Ver:20 PCB only)
qOnboard Graphics support
v Integrated 300MHz DAC for external desktop display.
qExpansion Slots
v One PCI Express x1 slot(optional)

5
Motherboard Layout
Figure 1 shows the motherboard and Figure 2 shows the back panel connectors.
24-pin ATX Power Connector
IDE connector
Front Panel Header
SPK Header
Serial-ATA (SATA) Connectors
SYS Fan connector
COM Header
SPDIF-OUT Header
PCI Express x1 slot(optional)
Front Pannel Audio Header
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Clear CMOS Jumper
Backpanel connectors
P/S port 5V standby selection Power
4-pin ATX_12V power connector
CPU Fan connector
USB Header
CPU socket
Chipset
DDRII DIMM Sockets
11.
12.
13.
14.
15.
16.
17.
18.
19.
Motherboard Layout
Figure 1. Board Layout
120 240
121
120 240
121
+
LOTES
R E O EVM
Chiset
DDRII1 DDRII2
PW1
S FAN1_FP1
SATA1
SATA2
COM
PCIEX1
SPDIF
C FAN1_
FP S1
_
FP U2
_
FP U1
_
JP1
PW2
DVI
USBU_LAN
SD1
KB1
2
3
45
6
7
8
9
10
11
12
13 14
15 16
SPK
17
JP2
IDE
VGA
18 19

6
NForce 610i/630i-ITX series Motherboard
6. Port 2-Channel 4-Channel 6-Channel
Blue Line-In Rear Speaker Out Rear Speaker Out
Green Line-Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Center/Subwoofer
7. LAN Connector
Lan Port with LEDs to indicate status.
· Yellow/Light Up/Blink = 10 Mbps/Link/Activity
· Yellow and Green/Light Up/Blink = 100 Mbps/link/Activity
Figure 2: Backpanel connectors
6
11
5
10
15
23456
7
6
11
5
10
15
23456
7
For Ver:01,02 PCB
For Ver:10,20 PCB
1. PS/2 Mouse Port
2. PS/2 Keyboard Port
3. VGA Connector
4. DVI Connector(optional for NForce630i-
ITX)
5. USB Connectors*
The bottom side of motherboard PCB
shows “136-0AAF3-0D001”
Motherboard PCB Version:01
The bottom side of motherboard PCB
shows “136-0AAF3-0D002”
Motherboard PCB Version:02
The bottom side of motherboard PCB
shows “136-0AAF3-0D010”
Motherboard PCB Version:10
The bottom side of motherboard PCB
shows “236-D0AF3-XXB0F”
Motherboard PCB Version:20
Note:
* Different motherboard PCB version could carry slightly different features and components
placement . Please refer to the following diagram to identify PCB version:
* How to identify PCB Versionto identify PCB VersionPCB Version
236-D0AF3-0JBOF

7
Hardware Installation
This section will guide you through the installation of the motherboard. The topics
covered in this section are:
q Preparing the motherboard
v Installing the CPU
v Installing the CPU fan
v Installing the memory
q Installing the motherboard
qConnecting cables and setting switches
Safety Instructions
To reduce the risk of fire, electric shock, and injury, always follow basic safety precations.
Remember to remove power from your computer by disconnecting the AC main source
before removing or installing any equipment from/to the computer chassis.
Hardware Installation

8
NForce 610i/630i-ITX series Motherboard
Preparing the Motherboard
The motherboard shipped in the box does not contain a CPU and memory. You need
to purchase these to complete this installation.
Installing the CPU
Be very careful when handling the CPU. Make sure not to bend or break any pins on
the back. Hold the processor only by the edges and do not touch the bottom of the
processor.
Use the following procedure to install the CPU onto the motherboard.
1. Unhook the socket lever by pushing down and
away from the socket.
2. Lift the load plate. There is a protective socket
cover on the load plate to protect the socket
when there is no CPU installed.
3. Remove the protective socket cover from the
load plate.
4. Remove the processor from its protective cover,
making sure you hold it only by the edges.
It is a good idea to save the cover so that
whenever you remove the CPU, you have a
safe place to store it.
5. Align the notches in the processor with the
notches on the socket.
6. Lower the processor straight down into the
socket with out tilting or sliding it into the socket.
Note: Make sure the CPU is fully seated and
level in the socket.
7. Close the load plate over the CPU and press
down while you close and engage the socket
lever.

9
Installing the CPU Fan
There are many different fan types that can be used with this motherboard. Follow the
instruction that came with your fan assembly. Be sure that the fan orientation is correct
for your chassis type and your fan assembly.
Installing Memory DIMMs
Your new motherboard has two 1.8V 240-pin slots for DDR2 memory. These slots
support 256 Mb, 512 Mb, 1Gb and 2Gb DDR2 technologies. There must be at least
one memory bank populated to ensure normal operation. Use the following the rec-
ommendations for installing memory. (See Figure 1 on page 5 for the location of the
memory slots.)
q One DIMM: Install into slot 1 or 2. You can install the DIMM into any slot,
however, slot 1 is preferred.
q Two DIMMs: Install into slots 1 and 2. The idea is to not have the DIMMs in
adjacent slots.
120 240
121
120 240
121
+
LOTES
R E O EVM
Hardware Installation
DDRII-1
DDRII-2

10
NForce 610i/630i-ITX series Motherboard
Use the following procedure to install memory DIMMs into the slots on the
motherboard. Note that there is only one gap near the center of the DIMM slot. This
slot matches the slot on the memory DIMM to ensure the component is installed
properly.
1. Unlock a DIMM slot by pressing the module clips outward.
2. Align the memory module to the DIMM slot, and insert the module vertically into
the DIMM slot. The plastic clips at both sides of the DIMM slot automatically lock
the DIMM into the connector.
Installing the Motherboard
The sequence of installing the motherboard into the chassis depends on the chassis
you are using and if you are replacing an existing motherboard or working with an
empty chassis. Determine if it would be easier to make all the connections prior to this
step or to secure the motherboard and then make all the connections. It is normally
easier to secure the motherboard first.
Use the following procedure to install the I/O shield and secure the motherboard into
the chassis.
Note: Be sure that the CPU fan assembly has enough clearance for the
chassis covers to lock into place and for the expansion cards. Also
make sure the CPU Fan assembly is aligned with the vents on the
covers.
Installing the I/O Shield
The motherboard kit comes with an I/O shield that is used to block radio frequency
transmissions, protects internal components from dust and foreign objects, and
promotes correct airflow within the chassis.
Before installing the motherboard, install the I/O shield from the inside of the chassis.
Press the I/O shield into place and make sure it fits securely. If the I/O shield does
not fit into the chassis, you would need to obtain the proper size from the chassis
supplier.

11
Connecting Cables and Setting Switches
This section takes you through all the connections and switch settings necessary on
the motherboard. This will include:
q Power Connections
v 24-pin ATX power (PW1)
v 4-pin ATX 12V power (PW2)
q Internal Headers
v Hard Disk Connector - IDE
v SPDIF Out Header(Optional)
v SPK Connector
v Front panel Header
v USB Headers
v Serial Port Connector-COM
v Audio
q Serial ATA II
q Chassis Fans
q Expansion slots
q Jumper settings
See Figure 1 to locate the connectors and jumpers referenced in the following
procedure.
Hardware Installation

12
NForce 610i/630i-ITX series Motherboard
24-pin ATX Power (PW1)
PW1 is the main power supply connector located along the edge of the board next to
the DIMM slots. Make sure that the power supply cable and pins are properly aligned
with the connector on the motherboard. Firmly plug the power supply cable into the
connector and make sure it is secure.
Table 1. PW1 Pin Assignments
Connector Pin Signal Pin Signal
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 GND 15 GND
4 +5V 16 PS_ON
5 GND 17 GND
6 +5V 18 GND
7 GND 19 GND
8 PWROK 20 -5V
9 +5V_AUX 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 GND
120 240
121
120 240
121
+
LOTES
R E O EVM
1
12
1324
4-pin ATX 12V Power (PW2)
PW2, the 4-pin ATX 12V power con-
nection, is used to provide power to
the CPU. Align the pins to the connec-
tor and press firmly until seated.
1
2
3
4
PIN Assignment
1 GND
2 GND
3 +12V
4 +12V
PW2 - Pin Definition

13
Hard Disk Connector - IDE
The motherboard has a 32-bit Enhanced PCI IDE and Ultra DMA 66/100/133 control-
ler that provides PIO mode 0~4, Bus Master, and Ultra DMA 66/100/133 function. You
can connect up to two hard disk drives, CD-ROM, 120MB Floppy (reserved for future
BIOS) and other devices.
120 240
121
120 240
121
+
LOTES
R E O EVM
PIN Assignment
1 VCC
2 NC
3 NC
4 SPK-
SPK - Pin Definition
Hardware Installation
SPK
1
SPK Connector
IDE
1
SPDIF Out Header(optional)
This header provides a SPDIF (Sony/Philips
Digital Interface)output to digital multimedia
device through coaxial connector.
CN7 - Pin Definition
PIN Assignment
1 SPDIF-out
2 +3.3V
3 NC
4 GND
SPDIF
1

14
NForce 610i/630i-ITX series Motherboard
Front Panel Header
The front panel header on this motherboard is one connector used to connect the
following four cables:
q PWRLED
Attach the front panel power LED cable to these two pins of the connector. The
Power LED indicates the system’s status.
Note: Some chassis do not have all four cables. Be sure to match the name on
the connectors to the corresponding pins.
q PWR SW
Attach the power button cable from the case to these two pins. Pressing the
power button on the front panel turns the system on and off rather than using the
power supply button.
q HDD LED
Attach the hard disk drive indicator LED cable to these two pins. The HDD
indicator LED indicates the activity status of the hard disks.
q RST SW
Attach the Reset switch cable from the front panel of the case to these two pins.
The system restarts when the RESET switch is pressed.
120 240
121
120 240
121
+
LOTES
R E O EVM
FP1
7
KEY
PWR_SW
NC
RESET 9
GND 5
3PW_LED+
HDD_LED-
HDD_LED+ 1
6
8
10
2
4
GND
PW_LED-
Front Panel Header Pin Definition

15
Hardware Installation
120 240
121
120 240
121
+
LOTES
R E O EVM
PIN Assignment
1 VCC
2 VCC
3 USBP0-
4 USBP1-
5 USBP0+
6 USBP1+
7 GND
8 GND
9 KEY
10 OC#
USB - Pin Definition
1 2
9
10
USB Headers
This motherboard contains four(For Ver:01,02 PCB) or six(For Ver:10,20 PCB) USB
2.0 ports that are exposed on the rear panel of the chassis(Figure 2). The mother-
board also contains two 10-pin internal header connectors onboard.
1. Secure the bracket to either the front or rear panel of your chassis (not all chassis
are equipped with the front panel option).
FP_U1
Serial Port Connector - COM
COM - Pin Definition
PIN Assignment
1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
10 NC
1 2
9 10
COM
1 2
9
10
FP_U2

16
NForce 610i/630i-ITX series Motherboard
120 240
121
120 240
121
+
LOTES
R E O EVM
Audio
The audio connector supports HD audio standard and provides two kinds of audio
output choices: the Front Audio, the Rear Audio. The front Audio supports re-tasking
function.
Note:
In order to utilize the front audio header, your chassis must have front audio connector.
Also please make sure the pin assignment on the cable is the same as the pin assignment
on the mainboard header. To find out if the chassis you are buying supports a front audio
connector, please contract your dealer.
PIN Assignment
1 MIC2(L)
2 GND
3 MIC(R)
4 -ACZ-DET
5 Front Audio(R)
6 Reserved
7 FAVDIO - JD
8 Key (No pin)
9 Front Audio(L)
10 Reserved
FP - S1 Pin Definition
1 2
9
10
FP_S1

17
Hardware Installation
120 240
121
120 240
121
+
LOTES
R E O EVM
PIN SIGNAL
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
SATA-1/SATA-2- Pin Definition
Connecting Serial ATA Cables(Optional)
The Serial ATA II connector is used to connect the Serial ATA II device to the
motherboard. These connectors support the thin Serial ATA II cables for primary
storage devices. The current Serial ATA II interface allows up to 3Gb/s data transfer
rate.
There are two serial ATA connectors on the motherboard that support AHCI and RAID
configurations.
1
SATA-1
1
SATA-2
Fan Connections
There are two fan connections on the
motherboard. The fan speed can be
detected and viewed in the PC Health
Status section of the CMOS Setup.
SYS FAN Connector
Sense
+12V
GND
CPU FAN Connector
GND
+12V
Sense
Control

18
NForce 610i/630i-ITX series Motherboard
Expansion Slots
The NVIDIA MCP73 motherboard contains one PCI Express x1 slot.
120 240
121
120 240
121
+
LOTES
R E O EVM
PCI Express x1 Slots(optional)
There is one PCI Express x1 slot that is designed to accommodate less bandwidth-
intensive cards, such as a modem or LAN card. The x1 slot provides 250 MB/sec
bandwidth.
PCI Express x1 Slot

19
Jumper Settings
This chapter explains how to configure the motherboard’s hardware. Before using your
computer, make sure all jumpers and DRAM modules are set correctly. Refer to this
chapter whenever in doubt.
Notice:
1. Be sure to save the CMOS setting when exit the CMOS.
2. If the CPU is frequency multiplier locked, no CPU speed change will be seen
even if the frequency multiplier setting in CMOS setup is changed.
Hardware Installation
JP1-CMOS Clear Jumper
JP1 Selection
1-2* Normal*
2-3 CMOS Clear
1
1
JP2 Selection
1-2* 5V standby power input*
2-3 5V power input
Close Open * = Default setting.
1
1
JP2-P/S Port 5V Standby Power Selection(Optional)
If you want to clear the system configuration,use the JP1(Clear CMOS Jumper) to clear date
