zSpace 200 User manual

www.zSpace.com
zSpace 200
User Manual

2 #770-00007-01
www.zSpace.com 08122014
Contents
The zSpace 200 System................................................................................................................................. 3
Contents of the zSpace System Box.......................................................................................................... 3
Parts of your zSpace.................................................................................................................................. 3
Side panel.................................................................................................................................................. 4
Rear panel ................................................................................................................................................. 5
Technical Specifications ................................................................................................................................ 5
How zSpace works ........................................................................................................................................ 6
Head tracked stereoscopic display ........................................................................................................... 6
Stylus Interaction ...................................................................................................................................... 6
System Requirements ................................................................................................................................... 7
Minimum................................................................................................................................................... 7
Recommended.......................................................................................................................................... 7
zSpace Graphic Card (GPU) requirements ................................................................................................ 7
Application Graphics Requirements ......................................................................................................... 8
Monitor stands.............................................................................................................................................. 9
Software for your zSpace system................................................................................................................10

3 #770-00007-01
www.zSpace.com 08122014
The zSpace 200 System
Congratulations on your purchase of the zSpace system, this manual reviews the features,
requirements to run the system and other system information.
Contents of the zSpace System Box
1. zSpace Display
2. Stylus
3. 1 Pair tracked polarized glasses
4. 1 Pair tracked polarized clip-ons
5. 1 Power supply for zSpace display
6. 1 DisplayPort cable
7. 1 USB Type A to Type B cable for connecting zSpace to the PC
8. 1 Pair non-Tracked 2D Conversion glasses (for partners)
9. 1 Quickstart guide
Parts of your zSpace
Tracked Eyewear:
In order to use your zSpace system in stereoscopic mode (3D) you will need to wear the tracked
eyewear. These eyewear include small reflectors to tell the system where your eyes are located
as well as polarized lenses.
Tracking Cameras
Stylus
Tracked Eyewear
Display
Integrated stand

4 #770-00007-01
www.zSpace.com 08122014
Stylus:
The stylus is used to control the system enabling six degrees of freedom of motion and
selection through the buttons.
Tracking Cameras:
The tracking cameras are necessary for the stylus and tracking to work. Please do not block the
cameras.
Integrated Stand:
The stand works by adjusting the angle then pulling it down to lock it in place. To release, push
it upwards from the base, then readjust to any of the preset angles (30°, 45°, 60°).
Side panel
On/Off switch
USB Ports

5 #770-00007-01
www.zSpace.com 08122014
Rear panel
The primary connections between the PC and the zSpace are the DisplayPort connector and the
USB Type B. A cable is included in the system for each of these.
Technical Specifications
Resolution
1920*1080 Full HD
Stand
30°, 45°, 60°, Variable with VESA
Display Area
20.5” H * 11.5” V, 23.6” D
VESA
100 mm * 100 mm
Rise Time/Fall
Time
Tr: 1.3 ms
Tf: 4.3 ms
Brightness
2D: 500 cd/m2
3D: 500 cd/m2
Contrast Ratio
2D: 1000:1
3D: 100:1
Operating
Environment
Temperature: 10-40° C
Humidity: 10-80% NC
Power
Requirements
12 VDC,
External Power Adapter:
100-240 VAC 50/60 Hz
Certifications
FCC B, WEEE, CE, RoHS,
VCCI, CB, UL,
C-Tick, PSE, SPRING
Package Includes:
USB Device to Computer
DisplayPort Cable
Power adapter
Stylus
Polarized Eyewear
Polarized Clip-ons
Connectors
Type B USB –1 port
Type A USB (Hub) –4 ports
DisplayPort (1.2)
DVI
Stylus *2
DC Power (12V)
DVI Port
DisplayPort
USB Type B
to computer
Power input
Stylus
inputs
USB for
peripherals

6 #770-00007-01
www.zSpace.com 08122014
How zSpace works
zSpace has many features to enable a compelling user experience.
Head tracked stereoscopic display
The head tracked display enables the left and right images of the display to focu on your eyes
wherever they move within the tracking zone. This capability ensures a comfortable virtual
experience.
Stylus Interaction
The tracking cameras enable the stylus to interact with virtual items anywhere within the
tracking zone.
Tracking Zone

7 #770-00007-01
www.zSpace.com 08122014
System Requirements
Minimum
Intel Core i3 processor, 4 GB RAM, Radeon R9 270 GPU
Recommended
Intel Core i5 Processor, 18 GB RAM, FirePro W5000
GPU Requirements:
zSpace Graphic Card (GPU) requirements
nVidia Quadro or Quadro K series and AMD Firepro V or W series, and AMD Radeon R9 or
better desktop or mobile GPU with the following support:
OpenGL quad buffered stereo
DVI-D (Dual Link) or DisplayPort output connections
1920x1080 resolution @ 120hz
2GB of on-board memory or better
There are a few key items that dictate what graphics cards can be used to drive your zSpace:
Quad-Buffer-Stereo
Minimum 2 GB Video RAM
OpenGL driver support
Optional support for Windowed Stereo (required for some applications)
Vendor & Model
Quad Buffer Stereo
Open GL Driver
Windowed Stereo
Nvidia Quadro
Yes
Yes
Yes
Nvidia GeForce
No
No
No
AMD FirePro
Yes
Yes
Yes
AMD Radeon
Yes
Yes
No
The following cards have been tested in-house and have been verified working with zSpace:
nVidia Desktop - Quadro 4000, 6000, K2000, K5000
nVidia Mobile - Quadro 4000m, 5010m, K3000m, k4000m, K5000m, k5100m
AMD Desktop - Firepro V5900, V7900, V8800, W5000, W7000, W8000, Radeon R7
260X
AMD Mobile - Firepro V8900m, 6000M, 6100M
If your card meets the above listed requirements it should work even if we have not tested or
extensively tested it.

8 #770-00007-01
www.zSpace.com 08122014
Current Models of zSpace compatible graphics cards with 2 GB RAM:
Nvidia Quadro, K6000, K5200, K4200, K2200, K620, K5100M, K4100M, K3100M,
K2100M, K1100M
AMD FirePro W5000, W5100, W5900, W7000, W7900, W8000, W8100, W9000, W9100
AMD Radeon, R9 Series 295X, 290X, 290, 280X, 280, 270X, 270
AMD Radeon, R7 Series 265, 260X, 260 (2GB RAM versions only)
Application Graphics Requirements
Independent of GPU and CPU capabilities some applications are certified on only certain brands
of graphics cards due to testing constraints.
Known application restrictions:
Nvidia Quadro only:
EON Software
Nvidia Quadro and AMD FirePro only:
EchoPixel
All other applications will work in full screen mode across all specified Radeon, FirePro and
Quadro GPUs, with varying performance.
For specific recommendations on hardware for a given application, please contact zSpace.

9 #770-00007-01
www.zSpace.com 08122014
Monitor stands
zSpace 200 is built with an integrated stand that supports 30, 45 and 60 degree viewing angles.
In addition, zSpace includes a 100*100 mm VESA mount that allows for attachment to a
monitor stand. This allows for zSpace to be mounted to a flexible monitor arm or stand that can
support any angle.
Be sure your monitor stand can support the weight of the zSpace display, as it is slightly
heavier than a conventional monitor of the same diagonal width (24”). The zSpace display
weighs 8.8 kg (17 lbs). The addition of a zView armature may also impact weight or angle, so
be sure to verify stability when using peripherals.
Using an arm or flexible mount allows
for the optimal positioning of zSpace.
This also allows for the easy transition
between 2D and 3D operation. A mount
at 90° might be preferred for 2D and an
angle of 55° might be preferred for 3D
usage. zSpace applications are typically
angle aware and will adjust the display
according to an angle between 0 and
90°.
The viewing
angle may also
be adjusted for
optimal user
height.

10 #770-00007-01
www.zSpace.com 08122014
Software for your zSpace system
A purchase of a zSpace system includes the purchase of a license to zSpace’s Core software.
This Core software enables a PC to control the zSpace hardware, along with providing various
base applications that enable you to use zSpace effectively.
The Core software consists of:
zSpace System –Display and tracking drivers
zSpace Zone –Virtual Reality desktop interface
zSpace Studio –A model viewing tool that allows the import and publishing of 3D
models from many environments
zSpace Gallery –A large volume of curated models for use in the zSpace Studio
application
zSpace Online Marketplace –Coming soon
In addition to these applications available as part of the Core software, there are many zSpace
and partner applications that can be downloaded and/or purchased for use with your zSpace
system.
Please visit www.zSpace.com to find additional software titles for use in zSpace
