Zubr V1 User manual

KV
Voltmeter
PE
PE
N
N
L
L
Input
С16
16А
QF1
40 А
QFinput
63 A
300 mA
QD
ZUBR V1
12
INPUT
РЕL N
ZUBR V1
max
min
reset
~
V digital -phase voltmeter1 single (
) is designed to monitor the voltage
of a single-phase network.
hereinafter referred
to as the device
The device stores the maximum and minimum mains
voltage in non-volatile memory. Stored values can
be reset.
23
The appliance is intended for installation inside residences.
The risk of moisture or humidity in the installation site
should be minimal. When installing in the bathroom, toilet,
kitchen, pool appliance must be located in a shell with
protection degree not below IP55 per GOST 14254 (partial
protection from dust and waterproof in any direction).
The ambient temperature during installation should
be within –5...+45 °С.
The appliance is installed in a special box, which allows
to conduct the easy installation and operation. Cabinet
should be equipped with standard mounting rail 35 mm
width (DIN rail). The appliance takes in width of three
standard module on 18 mm. The height of the appliance
should be in the range 0,5...1,7 m from the floor.
s
To connect your device:
— take a wire;
Necessarily need to set in front of the appliance,
the automatic circuit-breaker (QF) (see schemes 1, 2).
To protect person from electric shock leak is set safety
shutdown device (QD).
— make the connection according to the passport.
— fix the appliance on the mounting rail (DIN);
Terminals of the device designed for wire cross section
up to 16 mm . To reduce mechanical load on the terminals
it is desirable to use soft wire. Clean the end wires
of 10 ±0,5 mm. If end is longer, it can cause a short circuit,
and if short — cause unreliable connection. Use the cable
lugs. Undo the screws of the terminals and insert tipped
end of the wire in terminal. Tighten terminal with derived
average 2,4 Н·m. Low tight may lead to low contact and
overheating terminals and wires and over tight — damage
terminals and wires. Wires protracted in terminals with
a screwdriver with a shank width not more than 6 mm.
Screw with shank width more than 6 mm may apply
mechanical damage to terminals. This could result in loss
of warranty.
²
Power Volt
Device weight 0,1 ±10 %4 kg
Overall dimensions
( × × )w h d
Degree of protection
GOST14254
IP20
53 85 66 х х mm
not less than 100
420
V
not more than V
Scheme 1. Option of wiring diagram
Scheme . Option of the connection diagram 2
Before the installation and operation
of the device, PLEASE READ BY THE END
OF THIS DOCUMENT. This will help to avoid
possible danger, mistakes and
misunderstandings
.
NON-VOLATILE STORAGE
saves all settings in the event of a power outage.
VOLTMETER
output voltage is not a sine wave. Long operation
(more than 5 minutes) from the following sources
voltage may damage ZUBR and lead to not
warranty repair.
IT IS FORBIDDEN TO POWER THE DEVICE
FROM SOURCES WITH A MODIFIED SINE
WAVE, uninterruptible power supplies whose
When turned on, the voltmeter immediately begins
to measure and display the value of the mains voltage.
To view the maximum voltage stored
in the memory, press the top button and
to view minimum voltage, press lower
button. The display of voltage values
is accompanied by the glow of dots
in the rightmost category of the screens.
Five seconds after the last pressing of the buttons,
the voltmeter will return to displaying the mains voltage.
Viewing the minimum and maximum
voltage
Resetting the stored maximum and
minimum voltage
Five seconds after the last pressing of the buttons,
the voltmeter will return to displaying the mains voltage.
A short press on the middle button will
display on the screen. When
the button is released, the voltmeter will
erase all stored voltage values from
memory.
«rSt»
To view the firmware version, hold
the middle button for 12 seconds.
Viewing of firmware version
/not more than 1,5 monthkWt*hPower consumption
not more than 16 mm2
Connection Please see the full text of the warranty and the data you
need to send to your Service Center on the website
https://www.ds-electronics.company. If you have
a warranty case, please, contact the General distributor
in your area.
The warranty for ZUBR devices is valid for
from the date of sale, provided that the instructions
are followed. The warranty period for products without
a warranty certificate is counted from the date
of production.
60 months
If your device is not working properly, we recommend that
you first read the section «Possible problems». If you
cannot find an answer, contact Service Center. In most
cases, these actions resolve all issues.
If you continue to have issues with the device, please
send it to a Service Center or to the store where you
purchased the device. If your device is defective due
to our fault, we will repair or replace it under warranty
within 14 business days.
Voltage for measurement and supply (100–420 V, 50 Hz)
is applied to terminals 1 and 2.
V1
Voltmeter for professionals
Technical data sheet ,
installation and operation manual
1 piece
1 piece
1 piece
IN THE BOX
Digital single-phase voltmeter
ZUBR V1
Technical data sheet
installation and operation manual
and warranty card
,
The packing box
TECHNICAL DATA
SERVICE CENTER CONTACT
+38 (091) 481-91-81
Viber WhatsApp Telegram
WARRANTY CARD
place of a seal
a seller, a seal:
serial №: date of sale:
an owner contact
for a service center:
WARRANTY TERMS
CONNECTION SCHEMES
INSTALLATION
EXPLOITATION
V

5 6 7
If you think that the readings of the voltmeter V1 and your
reference device differ, the readings can be calibrated.
Correction of voltage indications on the
screen
To do this, enter the correction menu
by holding down the middle button
for 6 seconds until appears
on the screen.
«Cor»
After releasing the button, you will see
a blinking correction value, which can
be changed with the «max» button
to increase or «min» to decrease the value.
The range of variation corresponds
to ±20V.
Five seconds after the last pressing, the voltmeter will
return to displaying the mains voltage with the adjustment
made.
v _211201107
Low Voltage Directive 2014/35/E U
1 30 UEMC Directive 20 4/ /E
Manufacturer and vendor: DS ELECTRONICS, LTD
04136,
+38 (091) 1-91-8 , : +38 (091) 1-91-8
[email protected] www.ds-electronics.company
Ukraine, Kyiv region, Kyiv, 1–3 Pivnichno-Syretska str.
48 1 48 1Service Center
SAFETY INSTRUCTIONS
Do not connect the device to the network disassembled.
Do not expose the device to extreme temperatures (higher
than 40 ºС or below -5 °C) and high humidity.
Connection of the device must be done by a qualified
electrician.
Turning on and off or and configure the device should
be with dry hands.
Avoid hitting of water or moisture to the device.
Never clean the device with the use of chemicals such
as benzene, solvents.
Do not store the device and do not use it in areas with
the dust.
Do not exceed the landmarks value adaptor and power.
Carefully read and become aware of yourself these
instructions.
Before the installation (dismantling) and connection
(disconnection) of the device, turn off voltage supply and
also act according to the «Rules of an arrangement
of electric installations».
Do not attempt to disassemble and repair the device.
To protect against overvoltage caused by lightning
discharges, use a lightning protector.
Protect the children from games with the working device,
it is dangerous.
ADDITIONAL INFORMATION
Do not fire and do not throw away the device with
the household waste.
Transportation of goods carried in the package, ensuring
the safety of the product.
The deive is transported by any kind of transport (rail, sea,
motor, air transportation).
Date of manufacture is on the back side of device.
Application time is unlimited.
The device does not contain harmful substances.
If you have any questions or you something will not clear,
call the Service centre the telephone number listed below.
After the end of its service life, the product must
be disposed of in accordance with applicable law.
At turning on neither indicator nor screen do not shine
Possible cause: There is no power supply voltage.
It is necessary to: Ensure supply voltage presence.
POSSIBLE PROBLEMS, CAUSES
AND WAYS TO OVERCOME THEM
