ZyXEL Communications PLA4215 User manual

High Priority
Low Priority
Voice
1
Video
2
Others
3
Noise
PLA4215
Noise Reduce interference
for better HD video
streaming experiences
PLA4215
500 Mbps Powerline
Pass-Thru Gigabit
Ethernet Adapter
PLA4215
500 Mbps Powerline
Pass-Thru Gigabit
Ethernet Adapter
Benefits
Enjoy stable HD video and gaming
Powered by the latest IEEE 1901 technology and a Gigabit Ethernet port, the ZyXEL PLA4215,
500 Mbps Powerline Pass-Thru Gigabit Ethernet Adapter,provides a stable, high-performance
network for users to enjoy multiple HD streaming, multiplayer gaming and Web surfing
simultaneously.With a pair of plug-and-play installed PLA4215, you can easily extend home
networks through any electrical outlet for Internet access with HDTVs, Blu-ray™ players, DVRs,
PCs and game consoles.The embedded noise filter enables the PLA4215 to suppress noise from
all electronic equipment plugged into it and enhance the network environment for multimedia
streaming.
QoS enhances media streaming quality
The advanced QoS features on the PLA4215 improve the quality of multimedia streaming
applications such as Triple Play services, HD video streaming,high-speed Internet access and VoIP.
Green product saves energy consumption
When there is no Ethernet link, the PLA4215 will enter a power-saving mode to reduce energy
consumption by over 80% comparing to adapters without this function.
Easy security setup
Data transmission is protected by 128-bit Advanced Encryption Security (AES) security to provide
a secure connection to the Internet. As a simple button press on both PLA4215 is all it takes to
configure the encryption feature, there’s no need for complicated setup or extra software.
500 Mbps Powerline Adapter with
Extra Plug for Convenient Multiple HD
Video Streaming
■ Plug-and-play for quick data
transfer rates of up to 500 Mbps*
■ AC pass-through design with an
extra power outlet
■ Compliant with IEEE 1901 and
compatible with HomePlug AV
■ Gigabit Ethernet port provides
faster wired connection
■ Embedded noise filter for
reduced power interference
■ QoS enhances media streaming
quality
■ Power-saving mode reduces
energy waste
■ Encrypt button for easy security
setup
■ 128-bit AES encryption for
secure network
■ Multi-colored LED identifies
powerline network quality

5-100-00211027 10/11
For more product information, visit us on the web at www.ZyXEL.com
Copyright © 2011 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of
ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their
respective owners. All specifications are subject to change without notice.
Powerline
Ethernet
AV/HDMI Cable
IP Set-Top Box
Game Console
Blu-ray Player
HDTV
PLA4225
500 Mbps
Powerline 4-Port
Gigabit Switch
Internet
NBG5715
Simultaneous
Dual-Band Wireless
N Media Router
PLA4205
500 Mbps
Powerline Gigabit
Ethernet Adapter
xDSL/Cable
Modem
PLA4215
500 Mbps Powerline
Pass-Thru Gigabit
Ethernet Adapter
NSA320
2-Bay Power
Media Server
PLA4215
500 Mbps Powerline
Pass-Thru Gigabit
Ethernet Adapter
PLA4215
500 Mbps Powerline
Pass-Thru Gigabit
Ethernet Adapter
System Specifications
Standard
• Compliant with IEEE 1901 with data transfer rate
of up to 500 Mbps*
• Compatible with HomePlug AV standard
Access Methods
• CSMA/CA channel-access schemes
Range
• Up to 300 meters over power line
Power Saving Mode
• If link is inactive for a period (default setting: 60
seconds)
Security
• 128-bit AES encryption
Quality of Service (QoS)
• ToS
• Support up to 4-level type QoS
• Support up to 8-level VLAN priority field
Frequency Band
• 2 MHz ~ 67.5 MHz
Dynamic Neighbor Network Support
IGMP
• IGMP snooping for multicast to multiple
unicast mapping
System Requirements
• Deployment requirements:
■
Devices with 10/100 or 10/100/1000 Mbps
Ethernet port
■
Operating system independent
• Utility software OS support :
■
Microsoft Windows XP/Vista/7
Hardware Specifications
• Ethernet interface: One 10/100/1000 Mbps RJ-45
connector with auto MDI/MDIX support
• LED indicators:
■
Power on/off
■
Powerline link/quality
- Green: Best, Amber: Better, Red: Good
■
Ethernet link/activity
• Buttons:
■
Encrypt button
■
Reset button
• Power rating: 100-240 V AC, 50/60 Hz
• Power consumption:
■
Full operations: 5 Watt max.
■
Power-saving mode: 1 Watt max.
• Socket:
Physical Specifications
• Item dimensions (WxDxH):
67 x 73 x 127 mm (2.63”x 2.87” x 4.99”)
• Item weight: 235 g (0.52 lb.)
• Packing dimensions (WxDxH):
■
Single pack:
178 x 94 x 134 mm (7.01”x 3.7” x 5.27”)
■
Starter kit pack:
247 x 101 x 156 mm (9.73”x 3.98” x 6.14”)
• Packing weight:
■
Single pack: 483 g (1.07 lb.)
■
Starter kit pack: 825 g (1.82 lb.)
Environmental Specifications
Operating Environment
• Temperature: 0°C to 45°C (32°F to 113°F)
• Humidity: 20% to 95% (Non-condensing)
Storage Environment
• Temperature: -20°C to 70°C (-4°F to 158°F)
• Humidity: 20% to 95% (Non-condensing)
Certification
Safety
• CE-LVD
EMC
• CE, FCC
Package Contents
• Powerline Pass-Thru Ethernet Adapter
• Ethernet cable
• Quick start guide
• Support CD
• Warranty card
* The theoretical maximum channel data transfer rate is derived from
IEEE 1901 specifications.Actual data transfer rate will vary from
network environment including: distance, network traffic,noise on
electrical wires,quality of electrical installation and other adverse
conditions.
Specifications
Application Diagram
EU Outlet
(16 A Max.)
FR Outlet
(16 A Max.)
CH Outlet
(10 A Max.)
UK Outlet
(13 A Max.)
US Outlet
(15 A Max.)
■
Type E (CEE 7/7):FR, BE, PL
■
Type J (SEV 1011): CH
■
Type G (BS 1363):UK, CY, HK
■
Type B (NEMA 5-15):TW, US
■
Type F (CEE 7/4): DE, NL, ES, PT,
AT, SE, FI, NO, GR, HU, LU
