ZyXEL Communications ZyAIR G-200 User manual

ZyAIR G-200
Wireless LAN USB Adapter
User's Guide
Version 1.00
November 2003

ZyAIR G-200 User’s Guide
ii Copyright
Copyright
Copyright ©2003 by ZyXEL Communications Corporation
The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a
retrieval system, translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without the prior written
permission of ZyXEL Communications Corporation.
Published by ZyXEL Communications Corporation. All rights reserved.
Disclaimer
ZyXEL does not assume any liability arising out of the application or use of any products, or software
described herein. Neither does it convey any license under its patent rights nor the patents' rights of others.
ZyXEL further reserves the right to make changes in any products described herein without notice. This
publication is subject to change without notice.
Trademarks
Trademarks mentioned in this publication are used for identification purposes only and may be properties
of their respective owners.

ZyAIR G-200 User’s Guide
ZyXEL Limited Warranty iii
ZyXEL Limited Warranty
ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials
or workmanship for a period of up to one (1) year from the date of purchase. During the warranty period
and upon proof of purchase, should the product have indications of failure due to faulty workmanship
and/or materials, ZyXEL will, at its discretion, repair or replace the defective products or components
without charge for either parts or labor and to whatever extent it shall deem necessary to restore the product
or components to proper operating condition. Any replacement will consist of a new or re-manufactured
functionally equivalent product of equal value, and will be solely at the discretion of ZyXEL. This warranty
shall not apply if the product is modified, misused, tampered with, damaged by an act of God, or subjected
to abnormal working conditions.
NOTE
Repair or replacement, as provided under this warranty, is the exclusive remedy of the purchaser. This
warranty is in lieu of all other warranties, express or implied, including any implied warranty of
merchantability or fitness for a particular use or purpose. ZyXEL shall in no event be held liable for
indirect or consequential damages of any kind of character to the purchaser.
To obtain the services of this warranty, contact ZyXEL's Service Center for your Return Material
Authorization (RMA) number. Products must be returned Postage Prepaid. It is recommended that the unit
be insured when shipped. Any returned products without proof of purchase or those with an out-dated
warranty will be repaired or replaced (at the discretion of ZyXEL) and the customer will be billed for parts
and labor. All repaired or replaced products will be shipped by ZyXEL to the corresponding return address,
Postage Paid. This warranty gives you specific legal rights, and you may also have other rights that vary
from country to country.
Online Registration
Register online at www.zyxel.com.for free future product updates and information.

ZyAIR G-200 User’s Guide
iv Information for Canadian Users
Information for Canadian Users
The Industry Canada label identifies certified equipment. This certification means that the equipment meets
certain telecommunications network protective operation and safety requirements. The Industry Canada
does not guarantee that the equipment will operate to a user's satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities
of the local telecommunications company. The equipment must also be installed using an acceptable
method of connection. In some cases, the company's inside wiring associated with a single line individual
service may be extended by means of a certified connector assembly. The customer should be aware that
compliance with the above conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated
by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions,
may give the telecommunications company cause to request the user to disconnect the equipment.
For their own protection, users should ensure that the electrical ground connections of the power utility,
telephone lines, and internal metallic water pipe system, if present, are connected together. This precaution
may be particularly important in rural areas.
Caution
Users should not attempt to make such connections themselves, but should contact the appropriate
electrical inspection authority, or electrician, as appropriate.
Note
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus
set out in the radio interference regulations of Industry.

ZyAIR G-200 User’s Guide
FCC Statement v
Federal Communications Commission
(FCC) Interference Statement
The device complies with Part 15 of FCC rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired
operations.
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
If this equipment does cause harmful interference to radio/television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and the receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Notice 1
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Caution
1. The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment, under 47 CFR 2.1093 paragraph (d) (2).
2. This Transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Certifications
Refer to the product page at www.zyxel.com.

ZyAIR G-200 User’s Guide
Customer Support vii
Customer Support
When contacting your Customer Support Representative, please have the following information ready:
 Product model and serial number.
 Warranty Information.
 Date you received your product.
 Brief description of the problem and the steps you took to solve it.
METHOD
LOCATION
E-MAIL
SUPPORT/SALES
TELEPHONE/FAX WEB SITE/ FTP SITE REGULAR MAIL
[email protected]m.tw [phone] www.zyxel.com
www.europe.zyxel.com
WORLDWIDE
[e-mail] [phone] ftp.europe.zyxel.com
ZyXEL Communications
Corp., 6 Innovation Road II,
Science-Based Industrial Park,
Hsinchu 300, Taiwan
[email protected]m [phone] www.us.zyxel.comNORTH
AMERICA
[e-mail] ftp.zyxel.com
ZyXEL Communications Inc.,
1130 N. Miller St.
Anaheim, CA 92806, U.S.A.
[email protected] [phone] www.zyxel.dkSCANDINAVIA
[e-mail] [phone] ftp.zyxel.dk
ZyXEL Communications A/S,
Columbusvej 5, 2860
Soeborg, Denmark
[email protected] [phone] www.zyxel.deGERMANY
[e-mail] [phone]
ZyXEL Deutschland GmbH.
Adenauerstr. 20/A2 D-52146
Wuerselen, Germany

ZyAIR G-200 User’s Guide
Table of Contents ix
Table of Contents
Copyright.......................................................................................................................................................ii
ZyXEL Limited Warranty ..........................................................................................................................iii
Information for Canadian Users.................................................................................................................iv
Federal Communications Commission (FCC) Interference Statement.................................................... v
Customer Support.......................................................................................................................................vii
List of Figures...............................................................................................................................................xi
List of Tables ...............................................................................................................................................xii
Preface.........................................................................................................................................................xiii
Chapter 1 Getting Started.........................................................................................................................1-1
1.1 ZyAIR Hardware and Utility Installation.....................................................................................1-1
1.2 Disable Windows XP Wireless LAN Configuration Tool ...........................................................1-1
1.3 Accessing the ZyAIR Utility........................................................................................................1-4
Chapter 2 Using the ZyAIR Utility...........................................................................................................2-1
2.1 About the Wireless LAN Network...............................................................................................2-1
2.1.1 SSID.....................................................................................................................................2-1
2.1.2 Channel ................................................................................................................................2-1
2.1.3 Transmission Rate................................................................................................................2-1
2.2 Wireless Network Application .....................................................................................................2-1
2.2.1 Ad-Hoc (IBSS).....................................................................................................................2-1
2.2.2 Infrastructure ........................................................................................................................2-2
2.3 Roaming.......................................................................................................................................2-3
2.4 The Link Info Screen ...................................................................................................................2-4
2.5 The Site Survey Screen ................................................................................................................2-6
2.5.1 Connecting to a Wireless Network.......................................................................................2-7
2.6 The Configuration Screen ............................................................................................................2-7
2.7 Wireless LAN Security ................................................................................................................2-9
2.7.1 Data Encryption with WEP ................................................................................................2-10
2.8 The Encryption Screen ...............................................................................................................2-10
2.9 The About Screen.......................................................................................................................2-13
Chapter 3 Maintenance .............................................................................................................................3-1
3.1 Removing the ZyAIR Utility........................................................................................................3-1
3.2 Upgrading the ZyAIR Utility .......................................................................................................3-1
3.3 Disconnecting the ZyAIR.............................................................................................................3-2
Chapter 4 Troubleshooting .......................................................................................................................4-1
4.1 Problems Using the ZyAIR..........................................................................................................4-2
4.2 Problems Starting the ZyAIR Utility Program.............................................................................4-1

ZyAIR G-200 User’s Guide
x Table of Contents
4.3 Problems Communicating With Other Computers ......................................................................4-1
4.4 Problem with the Link Status.......................................................................................................4-2
Appendix A Product Specifications............................................................................................................ A
Index ............................................................................................................................................................. C

ZyAIR G-200 User’s Guide
List of Figures xi
List of Figures
Figure 1-1 Windows XP: System Tray Icon.................................................................................................1-1
Figure 1-2 Windows XP: System Tray Icon.................................................................................................1-1
Figure 1-3 Windows XP: Wireless Network Connection Status ..................................................................1-2
Figure 1-4 Windows XP: Connect to Wireless Network..............................................................................1-3
Figure 1-5 Windows XP: Wireless Network Connection Properties............................................................1-4
Figure 1-6 ZyAIR Utility: System Tray Icon ...............................................................................................1-4
Figure 2-1 Ad-hoc Network Example ..........................................................................................................2-2
Figure 2-2 BSS Example..............................................................................................................................2-2
Figure 2-3 Infrastructure Network Example ................................................................................................2-3
Figure 2-4 Roaming Example ......................................................................................................................2-4
Figure 2-5 ZyAIR Utility: Link Info............................................................................................................2-5
Figure 2-6 Site Survey .................................................................................................................................2-6
Figure 2-7 Configuration .............................................................................................................................2-8
Figure 2-8 Encryption ................................................................................................................................2-11
Figure 2-9 About ........................................................................................................................................2-13
Figure 4-1 ZyAIR Utility: Exit ....................................................................................................................3-2
Figure 4-2 Removable Device System Tray Icon: Windows XP .................................................................3-2
Figure 4-3 Safely Remove Hardware: Windows XP....................................................................................3-3
Figure 4-4 Problem Ejecting Message: Windows XP ..................................................................................3-3
Figure 4-5 Stop a Hardware device: Windows XP.......................................................................................3-4
Figure 4-6 Safe To Remove Hardware Message: Windows XP...................................................................3-4

ZyAIR G-200 User’s Guide
xii List of Tables
List of Tables
Table 1-1 ZyAIR Utility: System Tray Icon ................................................................................................1-5
Table 2-1 ZyAIR Utility: Link Info .............................................................................................................2-5
Table 2-2 Site Survey...................................................................................................................................2-7
Table 2-3 Configuration...............................................................................................................................2-8
Table 2-4 Encryption ................................................................................................................................. 2-11
Table 2-5 About .........................................................................................................................................2-14
Table 5-1 Troubleshooting Using the ZyAIR ..............................................................................................4-3
Table 5-2 Troubleshooting Starting ZyAIR Utility Program .......................................................................4-1
Table 5-3 Troubleshooting Communication Problems ................................................................................4-1
Table 5-4 Troubleshooting Link Quality......................................................................................................4-2

ZyAIR G-200 User’s Guide
Preface xiii
Preface
Congratulations on the purchase of your new ZyAIR G-200 Wireless LAN USB Adapter!
About This User's Guide
This guide provides information about the ZyAIR G-200 Wireless LAN Utility that you use to configure
your ZyAIR.
Syntax Conventions
• “Type” or “Enter” means for you to type one or more characters. "Select" or "Choose" means for
you to use one of the predefined choices.
• Mouse action sequences are denoted using a comma. For example, “click the Apple icon, Control
Panels and then Modem” means first click the Apple icon, then point your mouse pointer to
Control Panels and then click Modem.
• Window and command choices are in Bold Times New Roman font. Predefined field choices are
in Bold Arial font.
• The ZyXEL ZyAIR G-200 Wireless LAN USB adapter is referred to as the ZyAIR in this guide.
• The ZyAIR G-200 Wireless LAN Utility may be referred to as the ZyAIR Utility in this guide.
Related Documentation
 Support Disk
Refer to the included CD for support documents and device drivers.
 Quick Installation Guide
Our Quick Installation Guide is designed to help you get your ZyAIR up and running right away.
It contains a detailed easy-to-follow connection diagram and information on installing your
ZyAIR.
 ZyXEL Glossary and Web Site
Please refer to www.zyxel.com for an online glossary of networking terms and additional support
documentation.
User Guide Feedback
Help us help you! E-mail all User’s Guide-related comments, questions or suggestions for improvement to
[email protected] or send regular mail to The Technical Writing Team, ZyXEL Communications
Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 300, Taiwan. Thank you!

ZyAIR G-200 User’s Guide
Error! Reference source not found. 1-1
Chapter 1
Getting Started
This chapter prepares you to using the ZyAIR Utility.
1.1 ZyAIR Hardware and Utility Installation
Follow the instructions in the Quick Installation Guide to install the ZyAIR Utility and driver and make
hardware connections.
1.2 Disable Windows XP Wireless LAN Configuration Tool
Windows XP includes a configuration tool for wireless LAN devices.
DO NOT use the Windows XP configuration tool and the ZyAIR Utility at the same
time. It is recommended you use the ZyAIR Utility to configure the ZyAIR.
There are two methods to disable the configuration tool in Windows XP after you install the ZyAIR Utility.
From ZyAIR Utility
Right-click on the ZyAIR Utility system tray icon and click Turn off zero configuration.
Figure 1-1 Windows XP: System Tray Icon
From the Wireless Network Connection Status Screen
Step 1. Double-click on the network icon for the wireless connection in the system tray. If the icon is
not present, proceed to Step 2. Otherwise skip to Step 5.
Figure 1-2 Windows XP: System Tray Icon
Step 2. If the icon for the wireless network connection is not in the system tray, click Start, Control
Panel and double-click on Network Connections.

ZyAIR G-200 User’s Guide
1-2 Error! Reference source not found.
Step 3. Double-click on the icon for wireless network connection to display a status window as shown
next.
Figure 1-3 Windows XP: Wireless Network Connection Status
Step 4. Click Properties and click the Wireless Networks tab. Then skip to Step 6.

ZyAIR G-200 User’s Guide
Error! Reference source not found. 1-3
Step 5. When a Connect to Wireless Network window displays, click Advanced….
Figure 1-4 Windows XP: Connect to Wireless Network

ZyAIR G-200 User’s Guide
1-4 Error! Reference source not found.
Step 6. In the Wireless Network Connection Properties window, make sure the Use Windows to
configure my wireless network settings check box is not selected. Click OK.
Figure 1-5 Windows XP: Wireless Network Connection Properties
1.3 Accessing the ZyAIR Utility
After you installed the ZyAIR Utility, an icon for the ZyAIR Utility appears in the system tray.
When the ZyAIR Utility system tray icon displays, the ZyAIR is installed properly.
Figure 1-6 ZyAIR Utility: System Tray Icon
The color of the ZyAIR Utility system tray icon indicates the status of the ZyAIR. Refer to the following
table for details.

ZyAIR G-200 User’s Guide
Error! Reference source not found. 1-5
Table 1-1 ZyAIR Utility: System Tray Icon
COLOR DESCRIPTION
Red The ZyAIR is working properly but is not connected to any AP or wireless station.
Green The ZyAIR is connected to a wireless network.
Double click on the ZyAIR Utility icon in the system tray to open the ZyAIR Utility.
