ZyWALL (ZLD) VPN Troubleshooting
L2TP VPN will not connect
No traffic flow through L2TP VPN tunnel
Client-to-Site (RoadWarrior) VPN will not connect
No traffic flow through client-to-site IPSec VPN tunnel (RoadWarrior)
Site-to-Site VPN will not establish
No traffic flow through site-to-site IPSec VPN tunnel
SSL VPN connection will not establish
Connection issues with SSL VPN
L2TP VPN will not connect
Please verify your VPN rule setup with the example provided on the
“ZyWALL_L2TP_VPN_Setup.pdf” walkthrough. If your setup is similar to
the example provided please check the following:
Is the ZyWALL behind a NAT (another router)? The L2TP function
will not work if the ZyWALL is behind another router. This is a
limitation on the devices L2TP capability, the ZyWALL needs direct
communication with the public network (internet).
If the L2TP client is behind a router please make sure that VPN
pass-through is enabled or create port forwarding rules so it does
not block the L2TP communication to the ZyWALL.

2/26
www.zyxel.com
Does the client have any other VPN clients installed? Only one
application can use the IKE/IPSec services at a time, if there is
another VPN client installed on the computer (and running) such
as Cisco IPSec client, TheGreenBow, ShrewSoft, etc., you will
need to close the application completely and restart the
IKE/IPSec services so that the L2TP client can use them.
[Windows]
To restart the services on your computer open a RUN dialog box.
You can access this by pressing the Windows + R keys on the
keyboard.
Type “services.msc” and click OK or hit the Enter/Return key.

3/26
www.zyxel.com
Scroll down the list to find the ‘IKE and AuthIP IPsec Keying
Modules’ and ‘IPsec Policy Agent’ to restart these services.
Please check your L2TP clients settings against our setup
example(s) [link to Windows, macOS, iOS, etc., setup guides]
Disable your computers firewall to make sure it is not blocking the
VPN connection attempt.
Windows: To disable the Windows firewall, open a RUN dialog
box. You can access this by pressing the Windows + R keys on the
keyboard.

4/26
www.zyxel.com
Type “firewall.cpl” and click OK or hit the Enter/Return key.
Select the option to “Turn Windows Firewall on or off” on the left.
Disable the firewall by selecting the “Turn off Windows Firewall”
and click the OK button to save the settings.
Note: If you’re using a third party software firewall, Trend Micro, Norton, McAfee,
etc., please open the softwares control panel and disable the firewall feature.
macOS: To disable the firewall on macOS open System
Preferences Security & Privacy, click the Firewall tab and press
the “Turn Off Firewall” button to disable.

5/26
www.zyxel.com
Update your computers NIC drivers.
Note: For updates to your computers NIC cards please visit the computer
manufacturer or the NIC cards chipset manufacturer.
Bypass your router (if possible) to make sure it is not blocking the
attempt to connect/establish the L2TP VPN.
Check the ZyWALL’s IKE logs to make sure it is receiving a request
to establish the VPN. By default the ZyWALL is programmed to
allow VPN traffic, if the IKE logs on the ZyWALL do not show any
IKE connection attempts try disabling the ZyWALL’s Firewall/Policy
Control. If still no luck, check with your ISP to make sure they are
not blocking ports on the service end.
To disable the ZyWALL’s firewall/policy control, go to:
Configuration Firewall OR Configuration Security
Policy Policy Control

6/26
www.zyxel.com
Verify the firmware is up to date and contact tech support for
further assistance. To check the current version of firmware on
the ZyWALL go to Maintenance File Manager Firmware
Package

7/26
www.zyxel.com
No traffic flow through L2TP VPN tunnel
Please follow the instructions below if you have successfully established
an L2TP VPN connection but cannot pass traffic through the tunnel.
By default L2TP clients are programmed to send all traffic through
the L2TP connection once established. If you have disabled this
option you will need to manually create routes on your devices
operating system to route traffic through the tunnel accordingly.
Make sure there are no IP conflicts. The ZyWALL’s internal (LAN)
IP scheme and the L2TP IP pool should be on different subnets,
using the same IP scheme can cause routing issues.
Create a policy route on the ZyWALL to specify that any traffic
destined for the L2TP IP Pool needs to take a hop (Next-Hop) at
the L2TP VPN tunnel. Configuration Network Routing 
Policy Route
Disable the ZyWALL’s Firewall/Policy Control.
To disable the ZyWALL’s firewall/policy control, go to:

8/26
www.zyxel.com
Configuration Firewall OR Configuration Security
Policy Policy Control
Make sure the L2TP connection has a higher priority than any
other route on your computer. On macOS you need to change
the service order to give the VPN connection a higher priority
than the Ethernet or Wi-Fi connections.
Windows: All routes for the L2TP interface should have a higher
metric than the standard routes. Open command prompt or
PowerShell and type route print to view the routing table.
macOS: Open System Preferences Network, click the
configuration icon at the bottom of the network
interface list and “Set Service Order”.

9/26
www.zyxel.com
Verify that the device you are trying to contact across the VPN is
pointing to the ZyWALL for its default gateway. If the device is
pointing to a different default gateway the traffic will not get sent
back through the L2TP VPN tunnel.
Verify the firmware is up to date and contact tech support for
further assistance. To check the current version of firmware on
the ZyWALL go to Maintenance File Manager Firmware
Package

10/26
www.zyxel.com
Client-to-Site (RoadWarrior) VPN will not connect
Please use the walkthrough “Dynamic_VPN_Setup_CR.pdf” as an
example to verify the setup on your ZyWALL, to make sure all necessary
settings and rules have been created on the router.
If the ZyWALL is behind a NAT (another router) make sure the first
NAT is forwarding the VPN ports to the ZyWALL. IKE UDP:500 and
NAT-T UDP:4500
Make sure your network router is allowing the IPSec ports through
(UDP:500 and UDP:4500) or be sure to enable VPN pass-through if
the router supports this option. Bypass the router if possible to
make sure it is not causing the problem.
Make sure your ISP is not blocking VPN ports, some providers will
block the VPN ports on their end.
Verify that your computers firewall is allowing communications
from the VPN client.
Update your NIC drivers (Ethernet and/or Wi-Fi).
Note: For updates to your computers NIC cards please visit the computer
manufacturer or the NIC cards chipset manufacturer.

11/26
www.zyxel.com
Check the VPN settings on the ZyWALL and make sure they
match the software client configuration.
Check the ZyWALL’s IKE logs to make sure it is receiving a request
to establish the VPN. By default the ZyWALL is programmed to
allow VPN traffic, if the IKE logs on the ZyWALL do not show any
IKE connection attempts try disabling the ZyWALL’s Firewall/Policy
Control. If still no luck, check with your ISP to make sure they are
not blocking ports on the service end.
To disable the ZyWALL’s firewall/policy control, go to:
Configuration Firewall OR Configuration Security
Policy Policy Control
Verify the firmware is up to date and contact tech support for
further assistance. To check the current version of firmware on
the ZyWALL go to Maintenance File Manager Firmware
Package

12/26
www.zyxel.com
No traffic flow through client-to-site IPSec VPN tunnel
(RoadWarrior)
If you have successfully established a VPN connection to the ZyWALL
but cannot get traffic across, please try the following:
Login to the ZyWALL’s WebGUI and disable the “Use Policy Route
to control dynamic IPSec rules” in the VPN menu. Configuration
VPN IPSec VPN VPN Connection
Disable the ZyWALL routers Firewall.
Configuration Firewall OR Configuration Security
Policy Policy Control
Disable the firewall on the remote host (computer/device) to
make sure it is not blocking the request.
Windows: To disable the Windows firewall, open a RUN dialog
box. You can access this by pressing the Windows + R keys on the
keyboard.

13/26
www.zyxel.com
Type “firewall.cpl” and click OK or hit the Enter/Return key.
Select the option to “Turn Windows Firewall on or off” on the left.
Disable the firewall by selecting the “Turn off Windows Firewall”
and click the OK button to save the settings.
Note: If you’re using a third party software firewall, Trend Micro, Norton, McAfee,
etc., please open the softwares control panel and disable the firewall feature.
macOS: To disable the firewall on macOS open System
Preferences Security & Privacy, click the Firewall tab and press
the “Turn Off Firewall” button to disable.

14/26
www.zyxel.com
If you are attempting to access resources using computer
hostname, try using the IP address assigned to the
computer/device instead. Using a computer hostname requires
the NetBIOS broadcast protocol to resolve the computers IP
address, broadcasts are not supported by the IPSec standard.
Because broadcasts are not supported by the IPSec VPN
standard we cannot guarantee that using hostnames instead of
IP’s will work. A work around for this limitation of the IPSec
standard would be to use a WINS server.
Make sure there are no IP conflicts, if the ZyWALL network is
configured to use the 192.168.1.0/24 network and the remote user
is also using the same IP scheme, traffic will not route through the
VPN tunnel properly.
Make sure your network router is allowing the IPSec ports through
(UDP:500 and UDP:4500) or be sure to enable VPN pass-through if
the router supports this option. Bypass the router if possible to
make sure it is not causing the problem.

15/26
www.zyxel.com
Verify that the device you are trying to contact is pointing to the
ZyWALL for its default gateway. If the device is pointing to a
different default gateway the traffic will not get sent back
through the VPN tunnel.
Verify the firmware is up to date and contact tech support for
further assistance. To check the current version of firmware on
the ZyWALL go to Maintenance File Manager Firmware
Package

16/26
www.zyxel.com
Site-to-Site VPN will not establish
If you have configured an IPSec VPN rule for site-to-site (router-to-router)
connection and the tunnel is not being established, please try the
following:
Reboot/Restart the ZyWALL appliance to reload the VPN
daemon.
Check the ZyWALL logs to verify that IKE connection attempts are
being sent and received. If the logs show one way IKE traffic,
send only for example, check the internet connection to make
sure traffic is not being blocked/stopped on the service end.
Double check the VPN rules on both ends to make sure all
settings are matching.
If using DDNS hostname or domain name to dial the connection
instead of the public IP address, please make sure there are DNS
servers programmed on the ZyWALL and that they can resolve
the DDNS hostname/domain name. To check if the ZyWALL can
resolve the name you will need to open a terminal session using
SSH/Telnet/Console and run a ping command to the DDNS
hostname/domain name.
Router> ping hostname/domain (ex: Router> ping
www.google.com)
If the ping test fails double check the ZyWALL’s DNS settings and
try again. If your internet service is DHCP the ZyWALL would
have automatically obtained the DNS server settings from your ISP.
To check this go to Configuration System DNS.

17/26
www.zyxel.com
If your WAN IP was statically assigned the DNS settings will show
“N/A” for the Default entry (the Default entry is for the WAN ports
DHCP client capability only), click the Add button to manually
enter your ISP provided or public (OpenDNS, Google DNS, etc.)
DNS servers.
Verify the firmware is up to date and contact tech support for
further assistance. To check the current version of firmware on
the ZyWALL go to Maintenance File Manager Firmware
Package

18/26
www.zyxel.com
No traffic flow through site-to-site IPSec VPN tunnel
Tunnel established but can’t get traffic across:
Make sure there are no IP conflicts between the two sites.
Disable the ZyWALL routers firewall.
To disable the ZyWALL’s firewall/policy control, go to:
Configuration Firewall OR Configuration Security
Policy Policy Control
Verify that the host you are attempting to reach is pointing to the
ZyWALL for the default gateway.
Check for conflicting policy/static routes. A misconfigured or
out of order route can cause problems. To verify the
policy/static route rules go to, Configuration Network 
Routing.
Verify that the host you are attempting to reach is listening for the
traffic you are sending to it. Example: If you’re sending a ping
request to a device, make sure it is set to respond to ping/icmp
requests.
Windows: Open command prompt or powershell and type
netstat -an for a list of listening ports.

19/26
www.zyxel.com
macOS: Open terminal and type sudo lsof -i -n -P for a printout
of the listening ports.
Manually create a route (Configuration Routing) to stipulate
that traffic destined for the remote network should take its
Next-Hop on the appropriate VPN tunnel.

20/26
www.zyxel.com
Verify the firmware is up to date and contact tech support for
further assistance. To check the current version of firmware on
the ZyWALL go to Maintenance File Manager Firmware
Package
