ZyXEL Communications ARMOR G1 User manual

Default Login Details
User’s Guide
ARMOR G1
AC2600 Multi-Gigabit Security WiFi Router
Model: NBG6818
Copyright © 2020 Zyxel Communications Corporation
LAN IP Address http://zyxelwifi.com
OR
http://zyxelwifi.net
Version 1.00 Edition 2, 08/2020

NBG6818 User’s Guide
2
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
Screenshots and graphics in this book may differ slightly from your product due to differences in your
product firmware or your computer operating system. Every effort has been made to ensure that the
information in this manual is accurate.
Related Documentation
•QuickStartGuide
The Quick Start Guide shows how to connect the NBG6818 and access the Web Configurator wizards.
It contains information on setting up your network and configuring for Internet access.
•MoreInformation
Go to support.zyxel.com to find other information on the NBG6818.

NBG6818 User’s Guide
3
Document Conventions
Warnings and Notes
These are how warnings and notes are shown in this guide.
Warnings tell you about things that could harm you or your device.
Note: Notes tell you other important information (for example, other things you may need to
configure or helpful tips) or recommendations.
Syntax Conventions
• Product labels, screen names, field labels and field choices are all in bold font.
• A right angle bracket ( > ) within a screen name denotes a mouse click. For example, Setting >
Internet > Internet Connection means you first click Setting in the navigation panel, then the Internet
sub menu and finally the Internet Connection tab to get to that screen.
Icons Used in Figures
Figures in this user guide may use the following generic icons. The NBG6818 icon is not an exact
representation of your device.
NBG6818 Wireless Device Laptop Computer
Switch Firewall Server
Internet Desktop Computer Smartphone

Contents Overview
NBG6818 User’s Guide
4
Contents Overview
User’s Guide ......................................................................................................................................10
Introduction ........................................................................................................................................... 11
Wizard .................................................................................................................................................... 17
The Web Configurator ......................................................................................................................... 27
NBG6818 Modes ................................................................................................................................... 34
Standard Mode .................................................................................................................................... 36
................................................................................................................................................................ 38
Bridge Mode ......................................................................................................................................... 39
Tutorials .................................................................................................................................................. 42
Technical Reference ........................................................................................................................55
Applications .......................................................................................................................................... 56
WAN ....................................................................................................................................................... 77
Wireless LAN ........................................................................................................................................ 102
LAN ....................................................................................................................................................... 113
Security ................................................................................................................................................ 123
System .................................................................................................................................................. 130
Troubleshooting .................................................................................................................................. 141

Table of Contents
NBG6818 User’s Guide
5
Table of Contents
Document Conventions ......................................................................................................................3
Contents Overview .............................................................................................................................4
Table of Contents.................................................................................................................................5
Part I: User’s Guide..........................................................................................10
Chapter 1
Introduction ........................................................................................................................................11
1.1 Overview ......................................................................................................................................... 11
1.2 Applications .................................................................................................................................... 11
1.3 Ways to Manage the NBG6818 .................................................................................................... 12
1.4 Good Habits for Managing the NBG6818 ................................................................................... 12
1.5 Resetting the NBG6818 .................................................................................................................. 13
1.5.1 How to Use the RESET Button ................................................................................................ 13
1.6 The WPS Button ............................................................................................................................... 13
1.7 LEDs .................................................................................................................................................. 14
1.8 Desk Mounting ................................................................................................................................ 15
1.9 Wall Mounting ................................................................................................................................. 15
Chapter 2
Wizard .................................................................................................................................................17
2.1 Overview ......................................................................................................................................... 17
2.2 Accessing the Wizard ..................................................................................................................... 17
Chapter 3
The Web Configurator........................................................................................................................27
3.1 Overview ......................................................................................................................................... 27
3.2 Accessing the Web Configurator ................................................................................................. 27
3.3 Navigation Panel ............................................................................................................................ 29
3.3.1 Standard Mode Navigation Panel ...................................................................................... 30
3.3.2 Bridge Mode Navigation Panel ........................................................................................... 32
Chapter 4
NBG6818 Modes.................................................................................................................................34
4.1 Overview ......................................................................................................................................... 34
4.2 Modes .............................................................................................................................................. 34

Table of Contents
NBG6818 User’s Guide
6
Chapter 5
Standard Mode..................................................................................................................................36
5.1 Overview ......................................................................................................................................... 36
5.2 What You Can Do .......................................................................................................................... 36
5.3 Standard Mode Status Screen ...................................................................................................... 36
.............................................................................................................................................................38
Chapter 6
Bridge Mode.......................................................................................................................................39
6.1 Overview ......................................................................................................................................... 39
6.2 What You Can Do .......................................................................................................................... 39
6.3 Setting your NBG6818 to Bridge Mode ........................................................................................39
6.3.1 Accessing the Web Configurator in Bridge Mode ............................................................ 40
6.4 Bridge Mode Status Screen ........................................................................................................... 41
Chapter 7
Tutorials...............................................................................................................................................42
7.1 Overview ......................................................................................................................................... 42
7.2 Run a Speed Test ............................................................................................................................ 42
7.3 Configure the NBG6818’s WiFi Networks ......................................................................................43
7.4 Enable or Disable a WiFi Network ................................................................................................. 45
7.5 Add Clients to a Profile .................................................................................................................. 46
7.6 Set a Profile’s WiFi Schedule .......................................................................................................... 47
7.7 Pause or Resume Internet Access on a Profile ............................................................................ 49
7.8 Turn on or off the NBG6818’s LED (Light) ...................................................................................... 50
7.9 Change Your NBG6818 Operating Mode ................................................................................... 51
7.10 Configure a Port Forwarding Rule .............................................................................................. 52
Part II: Technical Reference...........................................................................55
Chapter 8
Applications .......................................................................................................................................56
8.1 Overview ......................................................................................................................................... 56
8.1.1 What You Can Do ................................................................................................................. 56
8.1.2 What You Need To Know ..................................................................................................... 56
8.1.3 Before You Begin ................................................................................................................... 57
8.2 Parental Control ............................................................................................................................. 57
8.2.1 Device Screen ....................................................................................................................... 57
8.3 OpenVPN Server/Client ................................................................................................................. 61
8.3.1 OpenVPN Server Screen ...................................................................................................... 61
8.3.2 OpenVPN Account Screen .................................................................................................. 63

Table of Contents
NBG6818 User’s Guide
7
8.3.3 OpenVPN Client Screen ....................................................................................................... 65
8.4 USB Application .............................................................................................................................. 67
8.4.1 SAMBA Server Screen ........................................................................................................... 67
8.4.2 FTP Server Screen .................................................................................................................. 69
8.4.3 USB Media Sharing Screen ................................................................................................... 71
8.5 Access Your Shared Files From a Computer ............................................................................... 73
8.5.1 Using Windows Explorer ........................................................................................................ 73
8.5.2 Using FTP Program ................................................................................................................. 74
Chapter 9
WAN ....................................................................................................................................................77
9.1 Overview ......................................................................................................................................... 77
9.2 What You Can Do .......................................................................................................................... 77
9.3 What You Need To Know .............................................................................................................. 78
9.3.1 Configuring Your Internet Connection ............................................................................... 78
9.4 Internet Connection Screen .......................................................................................................... 79
9.4.1 IPoE Encapsulation ................................................................................................................ 79
9.4.2 PPPoE Encapsulation ............................................................................................................ 82
9.4.3 PPTP Encapsulation ............................................................................................................... 85
9.5 NAT & Port Forwarding Screen ...................................................................................................... 87
9.5.1 Add Port Forwarding Rule Screen ....................................................................................... 89
9.6 Passthrough Screen ........................................................................................................................ 91
9.7 Port Trigger Screen ......................................................................................................................... 92
9.7.1 Add Port Trigger Rule Screen ............................................................................................... 94
9.8 Dynamic DNS Screen ..................................................................................................................... 95
9.9 UPnP Screen .................................................................................................................................... 96
9.9.1 Turning On UPnP in Windows 7 Example ............................................................................ 97
9.9.2 Turning on UPnP in Windows 10 Example .......................................................................... 99
Chapter 10
Wireless LAN .....................................................................................................................................102
10.1 Overview ..................................................................................................................................... 102
10.1.1 What You Can Do ............................................................................................................. 102
10.1.2 What You Should Know ....................................................................................................103
10.2 Main WiFi Screen ........................................................................................................................ 106
10.3 Guest WiFi Screen ....................................................................................................................... 108
10.4 MAC Filter Screen ...................................................................................................................... 108
10.4.1 Add MAC Address Screen ............................................................................................... 109
10.5 WPS Screen ................................................................................................................................. 110
10.6 Scheduling Screen ..................................................................................................................... 112
Chapter 11
LAN....................................................................................................................................................113

Table of Contents
NBG6818 User’s Guide
8
11.1 Overview ..................................................................................................................................... 113
11.2 What You Can Do ...................................................................................................................... 113
11.3 What You Need To Know .......................................................................................................... 113
11.4 LAN IP Screen .............................................................................................................................. 114
11.4.1 Static DHCP Table-Add/Edit Rule Screen ....................................................................... 117
11.4.2 Configure LAN Screen in Bridge Mode .......................................................................... 119
11.5 IPv6 LAN Screen .......................................................................................................................... 120
Chapter 12
Security .............................................................................................................................................123
12.1 Overview ................................................................................................................................... 123
12.1.1 What You Can Do ............................................................................................................. 123
12.1.2 What You Need To Know ................................................................................................. 123
12.2 IPv4 Firewall Screen ................................................................................................................... 124
12.2.1 IPv4 Firewall-Add Rule Screen ......................................................................................... 126
12.3 IPv6 Firewall Screen .................................................................................................................... 127
12.3.1 IPv6 Firewall-Add Rule Screen ......................................................................................... 128
Chapter 13
System...............................................................................................................................................130
13.1 Overview ..................................................................................................................................... 130
13.2 What You Can Do ...................................................................................................................... 130
13.3 Status Screen ............................................................................................................................... 130
13.4 General Setting Screen .............................................................................................................. 133
13.5 Remote Access Screen .............................................................................................................. 135
13.6 Maintenance Screen ................................................................................................................. 136
13.7 Operating Mode Screen ........................................................................................................... 137
13.8 Logs Screen ................................................................................................................................. 139
Chapter 14
Troubleshooting................................................................................................................................141
14.1 Overview ..................................................................................................................................... 141
14.2 Power, Hardware Connections, and LEDs ............................................................................... 141
14.3 NBG6818 Access and Login ...................................................................................................... 142
14.4 Internet Access ........................................................................................................................... 143
14.5 Resetting the NBG6818 to Its Factory Defaults ........................................................................ 144
14.6 Wireless Connections ................................................................................................................. 144
14.7 USB Device Problems ................................................................................................................. 146
Appendix A Customer Support ..................................................................................................... 147
Appendix B Setting Up Your Computer’s IP Address................................................................... 153
Appendix C Common Services .....................................................................................................172

Table of Contents
NBG6818 User’s Guide
9
Appendix D Legal Information ...................................................................................................... 175
Index.................................................................................................................................................181

10
PART I
User’s Guide

NBG6818 User’s Guide
11
CHAPTER 1
Introduction
1.1 Overview
This chapter introduces the main features and applications of the NBG6818, also called ARMOR G1.
The NBG6818 extends the range of your existing wired network without additional wiring, providing easy
network access to mobile users. You can set up a wireless network with other IEEE 802.11a/b/g/n/ac
compatible devices. The NBG6818 is able to function both 2.4GHz and 5GHz networks at the same time.
A range of services such as a firewall and content filtering are also available for secure Internet
computing.
There is an USB port on the side panel of your NBG6818. You can connect an USB memory stick, an USB
hard drive, or an USB device for file sharing. The NBG6818 automatically detects the USB device.
1.2 Applications
Your can have the following networks with the NBG6818:
•Wired. You can connect network devices via the Ethernet ports of the NBG6818 so that they can
communicate with each other and access the Internet.
Figure 1 Internet Access Application: Wired Connection
•Wireless. Wireless clients can connect to the NBG6818 to access network resources. You can use WPS
(Wi-Fi Protected Setup) to create an instant network connection with another WPS-compatible
device.

Chapter 1 Introduction
NBG6818 User’s Guide
12
Figure 2 Internet Access Application: Wireless Connection
•WAN. Connect to a broadband modem/router for Internet access.
Figure 3 Internet Access Application: Ethernet WAN
1.3 Ways to Manage the NBG6818
Use the following method to manage the NBG6818.
• Web Configurator. This is recommended for everyday management of the NBG6818 using a
(supported) web browser.
• Zyxel ARMOR. This is the app you can use to manage the NBG6818 on your cellphone. To install the
app, scan the QR code on the QSG.
1.4 Good Habits for Managing the NBG6818
Do the following things regularly to make the NBG6818 more secure and to manage the NBG6818 more
effectively.
• Change the password. Use a password that’s not easy to guess and that consists of different types of
characters, such as numbers and letters.
• Write down the password and put it in a safe place.
• Back up the configuration (and make sure you know how to restore it). Restoring an earlier working
configuration may be useful if the device becomes unstable or even crashes. If you forget your
password, you will have to reset the NBG6818 to its factory default settings. If you backed up an
earlier configuration file, you would not have to totally re-configure the NBG6818. You could simply
restore your last configuration.

Chapter 1 Introduction
NBG6818 User’s Guide
13
1.5 Resetting the NBG6818
If you forget your password or IP address, or you cannot access the Web Configurator, insert a thin
object into the Reset hole on the side of the NBG6818 to reload the factory-default configuration file.
This means that you will lose all settings that you had previously saved.
1.5.1 How to Use the RESET Button
1Make sure the power LED is on.
2Locate the Reset hole.
3Insert a thin object into the Reset hole for longer than eight seconds to reset the NBG6818 back to its
factory-default configuration.
1.6 The WPS Button
Your NBG6818 supports Wi-Fi Protected Setup (WPS), which is an easy way to set up a secure wireless
network. WPS is an industry standard specification, defined by the Wi-Fi Alliance.
WPS allows you to quickly set up a wireless network with strong security, without having to configure
security settings manually. Each WPS connection works between two devices. Both devices must
support WPS (check each device’s documentation to make sure).
Depending on the devices you have, you can either press a button (on the device itself, or in its
configuration utility) or enter a PIN (a unique Personal Identification Number that allows one device to
authenticate the other) in each of the two devices. When WPS is activated on a device, it has two
minutes to find another device that also has WPS activated. Then, the two devices connect and set up
a secure network by themselves.
You can use the WPS button in the Web Configurator of the NBG6818 to activate WPS in order to quickly
set up a wireless network with strong security.
1Make sure the power LED is on (not blinking).
2Open the Web Configurator.
3Click Settings > WiFi > WPS, and the press the WPS button.
4Press the WPS button on another WPS-enabled device within range of the NBG6818.
Note: You must activate WPS in the NBG6818 and in another wireless device within two
minutes of each other.
For more information on using WPS, see Section 7.2 on page 42.

Chapter 1 Introduction
NBG6818 User’s Guide
14
1.7 LEDs
Figure 4 Front Panel
The following table describes the front panel LED.
Table 1 Front Panel LED
COLOR STATUS DESCRIPTION
White On The NBG6818 is receiving power.
Blinking The NBG6818 is booting.
Dark Blue On Blue tooth is ready.
Blinking Blue tooth configuration is in process.
Amber Blinking (Slow) The NBG6818 is upgrading firmware.
Blinking (Fast) The NBG6818 is resetting.
Purple Blinking WPS configuration is in process.
Purple
and Dark
Blue
Blinking The NBG6818 is receiving power and ready for use.
Red On The NBG6818 detects and error while self-testing, or there is a
device malfunction.

Chapter 1 Introduction
NBG6818 User’s Guide
15
Figure 5 Rear Panel
1.8 Desk Mounting
Place the side of the NBG6818 with rubber feet carefully on the desk.
1.9 Wall Mounting
You may need screw anchors if mounting on a concrete or brick wall.
Figure 6 Screw Specifications
1Select a position free of obstructions on a wall strong enough to hold the weight of the device.
2Mark two holes on the wall at the appropriate distance apart for the screws.
Be careful to avoid damaging pipes or cables located inside the wall when
drilling holes for the screws.
3If using screw anchors, drill two holes for the screw anchors into the wall. Push the anchors into the full
depth of the holes, then insert the screws into the anchors. Do not insert the screws all the way in - leave
a small gap of about 0.5 cm.
If not using screw anchors, use a screwdriver to insert the screws into the wall. Do not insert the screws all
the way in - leave a gap of about 0.5 cm.
Table 2 Wall Mounting Information
Distance between holes 10.50 cm
M4 Screws Two
Screw anchors (optional) Two

Chapter 1 Introduction
NBG6818 User’s Guide
16
4Make sure the screws are fastened well enough to hold the weight of the NBG6818 with the connection
cables.
5Remove the rubber feet.
6Align the holes on the back of the NBG6818 with the screws on the wall. Hang the NBG6818 on the
screws.
Figure 7 Wall Mounting- Rubber Feet

NBG6818 User’s Guide
17
CHAPTER 2
Wizard
2.1 Overview
In this chapter, you will learn how to:
• Go through NBG6818 (ARMOR G1) wizard steps
• Configure basic settings for your WiFi
• Create a myZyxel Cloud account.
2.2 Accessing the Wizard
Launch your web browser and type "http://zyxelwifi.com" or "http://zyxelwifi.net" as the website
address.
Note: The wizard appears automatically when the NBG6818 is accessed for the first time or
when you reset the NBG6818 to its default factory settings.
1Your NBG6818 will check the status of your Internet connection the first time you log in.

Chapter 2 Wizard
NBG6818 User’s Guide
18
2The following screen shows if you are connected to the Internet. Click Next to go to the next step in the
wizard.
The following screen shows if you are not connected to the Internet.
Note: You may need to turn off your network firewall if access to the Internet from the
NBG6818 is blocked.
You need to connect to the Internet to access your NBG6818. See Section 14.4 on
page 143 if you cannot connect to the Internet.

Chapter 2 Wizard
NBG6818 User’s Guide
19
3Enter 1-128 single-byte printable ASCII characters but not "''<>^$& as your 2.4G/5G WiFi Name and WiFi
Password. Select the check box Keep 2.4G & 5G name the same if you want to use the same name for
your 2.4G and 5G WiFi.

Chapter 2 Wizard
NBG6818 User’s Guide
20
4Wait a moment for your WiFi settings to be applied to your NBG6818.
