ZyXEL Communications P-2608HWL-D1 Manual

P-2608HWL Series
Support Notes
Version 3.40
August. 2006

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 2
Index
Application Notes ........................................................................................... 9
General Application Notes.....................................................................................9
Internet Connection................................................................................................9
Set up the Prestige as a DHCP Relay...........................................................13
Configure an Internal Server Behind The Prestige......................................15
Configure a PPTP server Behind SUA........................................................17
Using NAT / Multi-NAT..............................................................................21
Introduction to Filter & Filter Examples .....................................................42
Using the Dynamic DNS (DDNS)...............................................................65
Network Management Using SNMP ...........................................................68
Using syslog.................................................................................................74
Using IP Alias ..............................................................................................78
Using Call Scheduling .................................................................................80
Using IP Multicast .......................................................................................85
Using traffic redirect....................................................................................87
Using Universal Plug n Play (UPnP)...........................................................89
Wireless Application Notes..................................................................................95
Infrastructure mode......................................................................................95
Wireless MAC address filtering.................................................................100
WEP (Wired Equivalent Privacy)..............................................................103
Site Survey.................................................................................................111
PSTN Lifeline Application Notes......................................................................115
Usage of PSTN Lifeline.............................................................................115
Lifeline configuration ................................................................................116
Relay to PSTN ...........................................................................................116
How to connect Lifeline and DSL connection...........................................117
VoIPApplication Notes......................................................................................118
SIPAccount Setup .....................................................................................118
Peer to Peer call .........................................................................................121
Phone Port Settings....................................................................................126
Configuring Advanced Voice Settings.......................................................130
Speed dial Phone book...............................................................................132
Voice - QoS setup.......................................................................................135
Call Forwarding Setup...............................................................................136
Voice – Common Settings..........................................................................139

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 3
Group Ring.................................................................................................140
FAQ............................................................................................................... 145
ZyNOS FAQ ......................................................................................................145
What is ZyNOS?........................................................................................145
How do I access the embedded web configurator?....................................145
What is the default LAN IP address and Password? And, how do I change
it?................................................................................................................145
How do I upload the firmware via the web configurator?.........................145
How do I upgrade/back up the firmware using an FTP client program
through the LAN?......................................................................................146
How do I upload or back up the configuration file (the ROM file) via the
web configurator? ......................................................................................146
How do I back up/restore configurations using an FTP client program
through the LAN?......................................................................................147
Why can't I Telnet into the Prestige from the WAN?.................................147
What should I do if I forget the system password?....................................147
What is SUA? When should I use SUA?...................................................147
What is the difference between NAT and SUA?........................................148
How many network users does SUA/NAT support?..................................148
What are Device and Protocol filters?.......................................................148
Why can't I configure device filters or protocol filters?............................149
Product FAQ ......................................................................................................149
What is the Prestige Integrated Access Device?........................................149
Will the Prestige work with my Internet connection?................................149
What do I need to use the Prestige?...........................................................149
What is PPPoE? .........................................................................................149
Does the Prestige support PPPoE?.............................................................150
How do I know I am using PPPoE?...........................................................150
Why does my provider use PPPoE?...........................................................150
Which Internet Applications can I use with the Prestige? .........................150
How can I configure the Prestige?.............................................................150
What network interface types does the Prestige have?..............................150
What can we do with Prestige?..................................................................151
Does Prestige support dynamic IP addressing? .........................................151
What is the difference between the internal IP and the real IP from my ISP?
....................................................................................................................151
How does e-mail work through the Prestige?............................................151

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 4
Is it possible to access a server running behind the Prestige with SUAfrom
the Internet? If possible, how?...................................................................151
What DHCP capability does the Prestige support?....................................152
How to use the reset button? And which parameter will be reset by the
reset button?...............................................................................................152
What network interface does the new Prestige series have?......................152
How does the Prestige support TFTP?.......................................................152
Does the Prestige support TFTP over the WAN?.......................................152
How fast is the DSL connection?...............................................................152
What is Multi-NAT? ..................................................................................153
When do I need Multi-NAT? .....................................................................154
What IP/Port mapping does Multi-NAT support? .....................................154
What is the difference between SUA and Multi-NAT? .............................155
What is BOOTP/DHCP?............................................................................156
What is DDNS?..........................................................................................156
When do I need the DDNS service?..........................................................156
What DDNS servers does the Prestige support?........................................156
What is DDNS wildcard?...........................................................................157
Does the Prestige support DDNS wildcard?..............................................157
Can VPN tunnels still work on a Prestige using SUA?.............................157
How do I set up my Prestige to route IPsec packets over SUA?...............157
PSTN Lifeline FAQ ...........................................................................................157
What is P2608 and what is the meaning of L in the model name (for
example P2608HWL-D1)? ........................................................................157
What is the Lifeline feature?......................................................................158
Do I need Lifeline? ....................................................................................158
Can I connect more than one phone to the phone port?.............................158
Can I receive incoming PSTN call through P2608HWL?.........................158
Can I make a PSTN call through P2608HWL ? ........................................158
VoIP FAQ...........................................................................................................158
What is Voice over IP?...............................................................................158
How does Voice over IP work?..................................................................159
Why use VoIP?...........................................................................................159
What is the relationship between codec and VoIP? ...................................159
What advantage does Voice over IP provide?............................................159
What is the difference between H.323 and SIP?........................................159
Can H.323 and SIP interoperate with one another?...................................160

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 5
What is voice quality?................................................................................160
How are voice quality normally rated?......................................................160
What is codec?...........................................................................................160
What is the relation between codec and VoIP?..........................................160
What codec types does the Prestige support?............................................160
Which codec should I choose?...................................................................161
What do I need in order to use SIP? ..........................................................161
I am unable to register to a SIP server. ......................................................161
I can register to the SIP server but cannot establish a call?.......................162
I can receive a call but the voice traffic only goes one way, not both way?162
I have tried all the troubleshooting steps, but still cannot register to the SIP
server. What should I do next?...................................................................162
What should I do if there may be a hardware problem with my Prestige?162
Firewall FAQ .....................................................................................................163
What is a network firewall?.......................................................................163
Why is the Prestige firewall secure?..........................................................163
What are the basic firewall types? .............................................................163
What advantages does the Prestige firewall provide?................................164
Why do you need a firewall when your router has built-in packet filtering
and NAT features?......................................................................................164
What is a Denial of Service (DoS) attack? ................................................164
What is a Ping of Death attack?.................................................................165
What is a Teardrop attack?.........................................................................165
What is a SYN Flood attack?.....................................................................165
What is a LAND attack?............................................................................165
What is a Brute-force attack?.....................................................................165
What is an IP Spoofing attack?..................................................................166
What are the default ACL firewall rules on the Prestige?..........................166
How can I protect against IP spoofing attacks?.........................................166
Content Filter FAQ ............................................................................................167
IPSec FAQ .........................................................................................................168
What is VPN? ............................................................................................168
Why do I need a VPN? ..............................................................................168
What are the most commonly used VPN protocols? .................................169
What is PPTP? ...........................................................................................169
What is L2TP? ...........................................................................................169
What is IPSec?...........................................................................................169

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 6
What secure protocols does IPSec support? ..............................................170
What are the differences between the 'Transport mode' and 'Tunnel mode’?170
What is SA? ...............................................................................................170
What is IKE?..............................................................................................170
What is a Pre-Shared Key? ........................................................................170
What are the differences between IKE and manual key VPN? .................170
What is the use of a Phase 1 ID?................................................................171
What are Local ID and Peer ID?................................................................171
When should I use FQDN?........................................................................172
Is my Prestige ready for IPSec VPN?........................................................172
How do I configure VPN on the Prestige?.................................................172
How many VPN connections does the Prestige support?..........................172
What VPN protocols are supported on the Prestige?.................................172
What VPN encryption types are supported on the Prestige?.....................172
What VPN authentication types does the Prestige support?......................173
I am planning my Prestige-to-Prestige VPN configuration. What do I need
to know?.....................................................................................................173
Does the Prestige support dynamic secure gateway IP?............................174
Which VPN gateways have been tested to work with the Prestige?..........174
Which VPN client software has been tested to work with the Prestige?...174
Will ZyXEL support Secure Remote Management?..................................175
Does the Prestige VPN support NetBIOS broadcast?................................175
Are hosts behind NAT allowed to use IPSec? ...........................................175
Why does VPN throughput decrease when my SMT screen stays at menu
24.1?...........................................................................................................175
Where can I configure Phase 1 ID on the Prestige?...................................175
If I have a NAT router between two VPN gateways, and I would like to
use IP type as Phase 1 ID, what information do I need?............................176
How can I keep a tunnel alive?..................................................................177
Which IP address types (Single, Range or Subnet ) does the Prestige
VPN/IPSec support ? .................................................................................177
Does the Prestige support IPSec passthrough?..........................................177
Can the Prestige work as a NAT router with IPSec passthrough and an
IPSec gateway at the same time?...............................................................177
Wireless FAQ.....................................................................................................178
What is a Wireless LAN ?..........................................................................178
What are the advantages of Wireless LANs ?............................................178

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 7
What are the disadvantages of Wireless LANs ?.......................................179
Where can I find wireless 802.11 networks ?............................................179
What is an Access Point ?..........................................................................179
What is IEEE 802.11 ?...............................................................................179
What is IEEE 802.11b ?.............................................................................179
How fast is IEEE 802.11b ?.......................................................................180
What is IEEE 802.11a ?.............................................................................180
What is IEEE 802.11g ?.............................................................................180
Is it possible to use products from a variety of vendors ?..........................180
What is Wi-Fi ?..........................................................................................181
What types of devices use the 2.4GHz Band ?..........................................181
Does the IEEE 802.11 interfere with Bluetooth devices ?.........................181
Can radio signals pass through walls ? ......................................................181
What factors may cause interference among WLAN products ?...............181
What's the difference between a WLAN and a WWAN ? .........................182
What is Ad Hoc mode ?.............................................................................182
What is Infrastructure mode ?....................................................................182
How many Access Points are required in a given area ? ...........................182
What is the Direct-Sequence Spread Spectrum (DSSS) Technology ? .....182
What is the Frequency-hopping Spread Spectrum (FHSS) Technology?..183
Do I need the same kind of antenna on both sides of a link?.....................183
Why use the 2.4 Ghz Frequency range ? ...................................................183
What is a Server Set ID (SSID) ?...............................................................183
What is an ESSID ?....................................................................................183
How do I secure data transmitted to/from an Access Point over the
wireless connection?..................................................................................184
What is WEP?............................................................................................184
What is the difference between 40-bit and 64-bit WEP keys?...................184
What is a WEP key ?..................................................................................184
AWEP key is a user-defined string of characters used to encrypt and
decrypt data?..............................................................................................184
Can the SSID be encrypted? ......................................................................185
By turning off SSID broadcasting, can someone still sniff the SSID?......185
What are Insertion Attacks?.......................................................................185
What is a Wireless Snifter?........................................................................185
What is the difference between Open System and Shared Key
Authentication Types ?...............................................................................185

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 8
What is the difference between No authentication required, No access
allowed and Authentication required? .......................................................186
What is AAA?............................................................................................186
What is RADIUS?......................................................................................186
What is WPA?............................................................................................186
What is WPA-PSK? ...................................................................................186
Troubleshooting.......................................................................................... 187
Using Embedded Packet Trace ..........................................................................187
Debugging PPPoE Connection..........................................................................202
CLI Command List...................................................................................... 213

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 9
Application Notes
General Application Notes
Internet Connection
The following figure shows a typical Internet access application using the Prestige. Before accessing the
Internet in an office environment, you must configure the Prestige as outlined below.
•Before you begin
•Setting up the Windows
•Setting up the Prestige router
•Troubleshooting
•Before you begin
The Prestige is shipped with the following factory defaults:
1. IP address = 192.168.1.1, subnet mask = 255.255.255.0 (24 bits)
2. DHCP server enabled with client IP address pool starting from 192.168.1.33
3. Default SMT login password = 1234
•Setting up your Windows computer(s)
1. Ethernet connection
Your computer(s) must have an Ethernet card installed.

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 10
•If you have only one computer, connect the computer to the LAN port on the Prestige using a
crossover Ethernet cable (red).
•If you have more than one computer, you must use a hub or switch to connect the computers to the
LAN port on the Prestige using a straight-though Ethernet cable.
2. TCP/IP Installation
You must first install the TCP/IP software on each computer before you can use it for Internet access. If you
have already installed TCP/IP, skip to the next section; otherwise, follow these steps to install the software:
•In the Control Panel/Network window, click the Add button.
•In the Select Network Component Type windows, select Protocol and click Add.
•In the Select Network Protocol windows, select Microsoft from the manufacturers, then select
TCP/IP from the Network Protocols and click OK.
3. TCP/IP Configuration
Follow these steps to configure Windows TCP/IP:
•In the Control Panel/Network window, click the TCP/IP entry to select it and click the
Properties button.
•In the TCP/IP Properties window, select obtain an IP address automatically.
Note: Do not assign an arbitrary IP address and subnet mask to your computers. O otherwise, you will not be
able to access the Internet.
•Click the WINS configuration tab and select Disable WINS Resolution.
•Click the Gateway tab. Highlight any installed gateways and click the Remove button until there
are none listed.
•Click the DNS Configuration tab and select Disable DNS.
•Click OK to save and close the TCP/IP properties window
•Click OK to close the Network window. You will be prompted to insert your Windows CD or disk.
When the drivers are updated, you will be asked if you want to restart the computer. Make sure
your Prestige is powered on before clicking Yes. Repeat the above steps for each computer on
your network.
•Setting up the Prestige router

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 11
If you have a Single User Account (SUA), follow the procedure to configure the Prestige. You can use a web
browser (such as IE) to access the embedded web server on the Prestige for device management. Before you can
log into the web management interface, make sure that there is no one logging into the Prestige through Telnet
or the console port.
1. Accessing the Prestige Web Management Interface
Open your web browser (such as IE) and enter the LAN IP address of the Prestige in the Address field. The
default LAN IP address is 192.168.1.1.
2. First Login
A login screen displays. Enter the password and press Login. The default password is '1234' which is the same
as the one you use to log into the SMT.
3. Use the WIZARD SETUP screens to configure Internet access settings on the Prestige.

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 12
The Internet access configuration screen varies depending on the Internet connection type you select. The
following figure shows an example screen for PPPoE connection type.

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 13
Set up the Prestige as a DHCP Relay
•What is DHCP Relay?
DHCP (Dynamic Host Configuration Protocol) allows a network device to obtain IP settings from a server. You
can configure the P-2608 as a DHCP server or DHCP relay.

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 14
When the P-2608 is configured as a DHCP server, it assigns IP address to clients on the LAN. When the P-2608
acts as a DHCP relay, it forwards client DHCP requests to the DHCP server and forwards the responds from the
DHCP server to the DHCP clients. The following figure shows an example.
•Setup the Prestige as a DHCP Relay
1. In SMT menu 3.2, select Relay in the DHCP field and enter the IP address of the DHCP server in the Relay
Server Address field.
Menu 3.2 - TCP/IP and DHCP Setup
DHCP= Relay TCP/IP Setup:
Client IP Pool:
Starting Address= N/A IP Address= 192.168.1.1
Size of Client IP Pool= N/A IP Subnet Mask= 255.255.255.0
First DNS Server= N/A RIP Direction= None
IP Address= N/A Version= N/A
Second DNS Server= N/A Multicast= None
IP Address= N/A IP Policies=
Third DNS Server= N/A Edit IP Alias= No
IP Address= N/A
DHCP Server Address= 192.168.1.2
Press ENTER to Confirm or ESC to Cancel:

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 15
Configure an Internal Server behind The Prestige
•Introduction
SUA makes your LAN appear as a single machine to the outside world. However, you can make a server (such
as a web server, FTP server or mail server) behind the P-2608 assessable/visible to the outside world. A server
behind the P-2608 cannot be set to be a DHCP client. That is, the server must use a fixed IP address so outside
users can access the server using the static IP address.
A service is identified by its standard port number. You can allow public access to servers for specified services
based on the port number. In addition, you can also set a default server behind SUA. Thus service requests that
do not match any of the servers are forwarded to the default server. If you do not set a default SUA server, then
the unknown service requests are simply discarded.
•Configuration
To make an inside server visible to the outside world, specify the service port number and the IP address of the
server in SMT menu 15.2.1: NAT Server Setup. Users use the WAN IP address of the Prestige to access the
inside SUA servers. You can obtain the WAN IP address of the Prestige in SMT menu 24.1.
•The following figure shows a configuration example to allow public access to an internal Web
server

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 16
Menu 15.2 - NAT Server Setup
Rule Start Port No. End Port No. IP Address
---------------------------------------------------
1. Default Default 0.0.0.0
2. 80 80 192.168.1.10
3. 0 0 0.0.0.0
4. 0 0 0.0.0.0
5. 0 0 0.0.0.0
6. 0 0 0.0.0.0
7. 0 0 0.0.0.0
8. 0 0 0.0.0.0
9. 0 0 0.0.0.0
10. 0 0 0.0.0.0
11. 0 0 0.0.0.0
12. 0 0 0.0.0.0
Press ENTER to Confirm or ESC to Cancel:
•The following table lists some common service port numbers.
Service Port Number
FTP 21
Telnet 23
SMTP 25
DNS (Domain Name Server) 53
www-http (Web) 80

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 17
Configure a PPTP server Behind SUA
•Introduction
PPTP is a tunneling protocol defined by the PPTP forum that allows PPP packets to be encapsulated within
Internet Protocol (IP) packets and forwarded over any IP network, including the Internet itself.
In order to run the Windows 9x PPTP client, you must be able to establish an IP connection with a tunnel server
such as the Windows NT Server 4.0 Remote Access Server.
Windows Dial-Up Networking uses the Internet standard Point-to-Point (PPP) to provide a secure, optimized
multiple-protocol network connection over dial-up telephone lines. All data sent over this connection can be
encrypted and compressed, and multiple network level protocols (TCP/IP, NetBEUI and IPX) can be run
correctly. Windows NT Domain Login level security is preserved even across the Internet.
Window98 PPTP Client / Internet / NT RAS Server Protocol Stack
PPTP appears as new modem type (Virtual Private Networking Adapter) that can be selected when setting up a
connection in the Dial-Up Networking folder. The VPN Adapter type does not appear elsewhere in the system.
Since PPTP encapsulates its data stream in the PPP protocol, VPN requires a second dial-up adapter. This
second dial-up adapter for VPN is added during the installation phase of the Upgrade in addition to the first
dial-up adapter that provides PPP support for the analog or ISDN modem.

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 18
PPTP is already supported in Windows NT and Windows 98. For Windows 95, a software upgrade with
Dial-Up Networking 1.2 is required.
•Configuration
This application note explains how to establish a PPTP connection to a remote private network on the Prestige
with SUA enabled. In ZyNOS, all PPTP packets are forwarded to the internal PPTP Server (Windows NT
server) behind SUA. You must specify the PPTP port number in SMT menu 15 for the Prestige to forward the
packets to the intended Windows NT server using the private IP address.
•Example
The following example shows how to dial to an ISP via the Prestige and then establish a tunnel to a private
network. You need to configure the settings on the PPTP server (Windows NT server), the PPTP client
(Windows 9x) and the Prestige to set up the PPTP application. The following summarizes the setting for the
corresponding PPTP device.
oPPTP server setup (Windows NT)
Create a new VPN service in Control Panel > Network.
Create a new PPTP user account
Enable the RAS port
Select a network protocol (such as IPX or TCP/IP NetBEUI) for the RAS port
Set the Prestige as the Internet gateway
oPPTP client setup (Windows 9x)

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 19
In Dial-up Networking, create a secure VPN connection through the Prestige (using
the WAN IP address) and enter the correct user name and password to log into the
Windows NT RAS server.
Set the Prestige that connects to the ISP as the Internet gateway.
oPrestige Setup
•Before establishing a secure VPN connection from the PPTP client to the PPTP server, you must
first connect the Prestige to the ISP for Internet access.
•Enter the IP address and the port number of the PPTP server to allow public access to the server
behind the Prestige. The following shows a configuration example.
Menu 15.2 - NAT Server Setup
Rule Start Port No. End Port No. IP Address
---------------------------------------------------
1. Default Default 0.0.0.0
2. 80 80 192.168.1.10
3. 0 0 0.0.0.0
4. 0 0 0.0.0.0
5. 0 0 0.0.0.0
6. 0 0 0.0.0.0
7. 0 0 0.0.0.0
8. 0 0 0.0.0.0
9. 0 0 0.0.0.0
10. 0 0 0.0.0.0
11. 0 0 0.0.0.0
12. 0 0 0.0.0.0
Press ENTER to Confirm or ESC to Cancel:
After you have set the settings to allow public access to the PPTP server, test the connection from the
PPTP client to the PPTP server. You can use Ping to check that the PPTP client can reach the PPTP

P-2608HWL Series Support Notes
All contents copyright (c) 2005 ZyXEL Communications Corporation. 20
server over the Internet connection. For example, enter “ping 203.66.113.2＂ if the WAN IP address
of the Prestige is 203.66.113.2.
Once the connection is up, you can establish a secure VPN connection from the PPTP client to the ISP.
The default gateway is then used to route the traffic between the PPTP client and the server.
However, before you can establish a secure VPN connection from the PPTP client to the PPTP server,
you need to know the WAN IP address of the Prestige which is set to use the SUA feature. Depending
on your Internet account type and ISP, the Prestige WAN IP address is either fixed(static) or dynamic
(different each time). You need to enter the WAN IP address of the Prestige in the VPN dial-up
connection screen. You can check the WAN IP address of the Prestige in SMT menu 24.1.
The following figure shows an example VPN dial-up screen. The VPN Server field is 140.113.1.225
which is a dynamic IP address assigned to the Prestige by the ISP. Make sure you enter the WAN IP
address of the Prestige correctly; otherwise, the VPN connection will fail.
