ZyXEL Communications NBG-419N User manual

NBG-419N
Wireless N Home Router
Quick Start Guide
Version: 1.00
Wireless N RouterWireless N Router
Copyright © 2009 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered
trademarks of ZyXEL Communications Corp.All other brands, product names, or trademarks mentioned
are the property of their respective owners. All specifications are subject to change without notice.
This product is designed for the 2.4 GHz WLAN network throughout the EC region.
http://www.zyxel.com/index.php
A6 105(W) x 150(H) mm

www.zyxel.com
NBG-419N
Wireless N Home Router
Version 1.00
Edition 2, 4/2009
QUICK START GUIDE
DEFAULT LOGIN DETAILS
LAN Port LAN1 ~ LAN4
IP Address http://192.168.1.1
Password 1234
CONTENTS
ENGLISH 5
DEUTSCH 15
ESPAÑOL 27
FRANÇAIS 39
ITALIANO 51
SVENSKA 63
NEDERLANDS 75
2009 ZyXEL Communications Corporation
C

[Document Title]
4
LED and Rear Panel
WLAN RESET
LAN 1 ~ LAN 4
POWER
ON/OFF
WPS
WAN
WPS
POWER
WLAN
WAN
LAN 1 ~ LAN 4

ENGLISH
5
Overview
The NBG-419N is a wireless router that lets you set up
both wired and wireless networks. Its built-in firewall is
enabled by default to protect your network.
The Quick Start Guide shows you how to:
•Set Up a Wired Network with Internet Access
•Set Up a Wireless Network with WPS
•Set Up Wired and Wireless Networks using the Wizard
ENGLISH

ENGLISH
6
Set Up a Wired Network with
Internet Access
1. Make the following hardware connections to your
NBG-419N:
C
D
B
A

ENGLISH
7
• Connect the antennas (A) to the antenna sockets,
ensuring it is screwed in firmly and angled upwards.
• Connect the Ethernet port on your computer to a LAN
port (B) on the NBG-419N using an Ethernet cable.
• Connect the WAN port (C) on your NBG-419N to the
Ethernet port on the device with which you are
accessing the Internet (for example, a modem) using
the cable that came with your modem.
• Use the power adapter (D) from the package to
connect the POWER socket to an appropriate power
source.
2. Check your Internet connection. Open a web
browser on your computer and enter www.zyxel.com
in the address bar.
 If you cannot access the Internet, restart your
NBG-419N. If you were given a user name and
password for Internet connection, you will have to
use the wizard. Skip the next section and go to
Set Up Wired and Wireless Networks using the
Wizard.

ENGLISH
8
Set Up a Wireless Network with
WPS
Use Wi-Fi Protected Setup (WPS) to let wireless
devices, such as notebooks and computers, securely
access the NBG-419N wirelessly.
Check if your wireless device has the
WPS logo and follow these steps to
set up your wireless network using
WPS.
2 minutes
A
B
C
D

ENGLISH
9
1. Make sure your NBG-419N is turned on (A). Place
your wireless device within range of the NBG-419N.
2. Enable wireless on the NBG-419N by turning on the
WLAN switch (B).
3. Press the WPS button on the NBG-419N and your
notebook (C). It doesn’t matter which button is
pressed first. You must press the second button
within two minutes of pressing the first one.
The WPS LED ( ) on the NBG-419N blinks during
the WPS process, then shines steadily when the WPS
process is finished.
If your WPS connection is successful, you should
now be able to access the NBG-419N.
4. Connect the WAN port (D) on your NBG-419N to your
broadband modem. You are now ready to connect to
the Internet wirelessly through your NBG-419N.
 If your wired Internet connection is fine but your
wireless connection is not, repeat step 3. If WPS
is not working or your wireless device does not
support WPS, go to the next section.

ENGLISH
10
Set Up Wired and Wireless
Networks using the Wizard
Enter the information in the wizard exactly as given by
your ISP. If no information was given for a field in the
wizard, leave it to the default.
1. Open a web browser on the computer connected to
the NBG-419N. Type "http://192.168.1.1" as the
website address. Enter "1234" (default) as the
password and click Login.
2. The Welcome screen opens. Choose your
Language and click Connect to Internet.
