2connect M930Z User manual

10.Scan mode
Auto Sense Mode
Continuous Scan
Trigger Scan
11.Terminator Suffix
Add suffix
No Terminator suffix
Set Terminator Suffix to 0x0D(CR)
Set Terminator Suffix to 0x0D 0x0A(CR+LF)
Dear users, thank you for choosing our products. we will provide you
with quality products and caring services.
12、Troubleshooting
Serial
number problems Possible reason Solution
1
Interface cable is
installed correctly,
but scanner not
started.
No power to scanner Ensure the scanner is
Powered On
Incorrect connection of
interface cable.
Ensure all cable connections
are secure
2Interface cable
connected but
Scanner not
decoding bar
code
The Bar code type is
disabled.
Enable that bar code type
Damaged barcode
Scan a test bar code of the
same bar code type
Distance between scanner
and bar code is incorrect Move scanner closer to or
further from bar code
The scanner is not high
enough to cover the
barcode completely
Point the reader at the target
and pull the trigger to enable
the illuminator (red beam) to
decode the bar code label.
3Scanned data
incorrectly
displayed on host
Input method error
Convert input method to
standard English input
method
Other settings were made
for the scanner
Restore the parameters of the
scanner to the factory settings
state, or contact the vendor
service center
，
4Scanned data
incorrectly
displayed on host
Region improperly
configured
Select appropriate country and
language encoding scheme
5
Other faults
Device conversion error
，
Turn off the device power,
connect the device and the
scanner correctly. Restore the
parameters of the scanner to
the factory settings state,
rescan the code
Quick Start Guide
V2.1

7.Common Setting
Restore to Factory Default
Note: please use the "restore factory default" function carefully. After reading this configuration
code, you will lose the current parameter setting and replace it with the factory default value.
Configuration Bar Code
9.Interface setting
Serial port
USB COM
HID-KBW
5.System Setting
1.Reading the "Enable configuration code" barcode enables the barcode scanner to open
and configure by reading a specific barcode (configuration code function). After the
function is turned on, the parameters of the barcode scanner can be modified by reading
one or more configure codes.
2.After reading the "Disable configuration code", most of the configuration code
processing functions will be disabled by the barcode scanner. In this state, only the "
Enable configuration code" code can be read and processed.
Enable Configuration Bar code
Disable configuration Bar code
6.Common settings
The content of the configuration code can be output. After reading the "output configuration
code content" and setting it successfully, the content will be output to the host when reading
the configuration code; after reading the "no output configuration code content" and setting
successfully, the barcode scanner will no longer output the configuration code content. After
the barcode scanner is restarted, no matter what the previous settings are, it will return to the
state of "no output of configuration code content".
Transmit Configuration Bar Code Data
Do not Transmit Configuration Bar Code
Data
8.User default settings
1.In addition to the factory default settings, you can save the settings you often use as user
default settings.
2.Reading the "save current settings as user default settings" code will save all parameters
of the barcode scanner as the user's default settings. If there is user default configuration
information on the barcode scanner, the current configuration information will replace the
original user default configuration information after this operation. Reading "restore to user
default settings" switches the module to the state of user default settings.
(Note: after restoring the factory default settings, the previously saved user default settings
will not be lost.)
Save current settings as user default Restore to user default
1.How to use
Maintain a 10-40° bevel angle in the horizontal direction of the scanner and
bar code for optimal scanning results.
2.Scanner Features
Scan Window
LED Indicator
Beeper
Data Port
Aiming - Wrong
Aiming - Correct
Scan Trigger
3.Interface cable's Installing and Removing
4.Packing List
Data cable connection:
1. The data cable on the bottom of the scanner is not allowed to be pulled
out;
2. Because the data cable is integrated with the scanner interface, the data
cable cannot be pulled out.
1* Scanner.
1* Interface Cable.
1* Quick Start Guide.
If you need to use the detailed manual, Please contact the bar code
scanner vendor.
How to use the parameter barcode: scan corresponding bar codes to set
up the scanner and the scanner will beep once.
