2N SIP Mic
Microphone console
Configuration Manual
Firmware:
Version: 1.0

The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of
telecommunications equipment.
The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways,
private branch exchanges (PBX), and door and lift communicators. 2N
TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years
and represented a symbol of stability and prosperity on the telecommunications
market for almost two decades. At present, we export our products into over 120
countries worldwide and have exclusive distributors on all continents.
2N is a registered trademark of 2N TELEKOMUNIKACE a.s. Any product and/or other
®
names mentioned herein are registered trademarks and/or trademarks or brands
protected by law.
2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find
information and to answer your questions about 2N products and services. On www.
faq.2n.cz you can find information regarding products adjustment and instructions for
optimum use and procedures „What to do if...".
2N TELEKOMUNIKACE a.s. hereby declares that the 2N product complies with all
®
basic requirements and other relevant provisions of the 1999/5/EC directive. For the
full wording of the Declaration of Conformity see the CD-ROM (if enclosed) or our
website at www.2n.cz.
The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All
development, production and distribution processes of the company are managed by
this standard and guarantee a high quality, technical level and professional aspect of
all our products.

2N TELEKOMUNIKACE a.s., www.2n.cz 3/76
Content:
1. Product Overview
1.1 Components and Associated Products
1.2 Terms and Symbols
2. Description and Installation
2.1 Before You Start
2.2 Electric Installation
2.3 Product Description
3. Function and Use
3.1 Configuration
3.1.1 System Status
3.1.2 Network
3.1.3 VoIP
3.1.4 Audio
3.1.5 Buttons
3.1.6 Zones
3.1.7 Action Scheduler
3.1.8 System
3.1.9 Voice Messages
3.2 Setting Examples
3.2.1 Express Settings
3.2.2 Announce to Zone – VAPIX
3.2.3 Voice Message Loading
3.2.4 HTTP Request
3.3 Downloads
4. Technical Parameters
5. Supplementary Information
5.1 Troubleshooting
5.2 Directives, Laws and Regulations
5.3 General Instructions and Cautions

2N TELEKOMUNIKACE a.s., www.2n.cz 4/76
1. Product Overview
Here is what you can find in this section:
1.1 Components and Associated Products
1.2 Terms and Symbols

2N TELEKOMUNIKACE a.s., www.2n.cz 5/76
Basic Properties
2N SIP Mic
® is an IP microphone console playing live or pre-recorded announcements
to up to 12 zones. Together with the 2N SIP speakers, provides a 2N SIP Mic
®
complete voice announcement distribution system. However, is more 2N SIP Mic
®
than that. For example, it can accept calls from the 2N intercoms, listen to the zone
traffic, schedule announcements and/or load own messages. This makes it an ideal
solution for places where identical announcements are played several times a day,
such as schools, amusement parks, stores or public transport terminals. Easy power
supply via PoE and programming via a web interface are additional bonuses. With
integrated VAPIX , is capable of playing announcements to AXIS audio
®2N SIP Mic ® ®
systems and cameras.

2N TELEKOMUNIKACE a.s., www.2n.cz 6/76
Advantages of Use
Clear and loud speech
Announcement planner
VAPIX support
®
Easy control
Easy one-cable installation (Ethernet + PoE)
VoIP PBX support (SIP)
Remote control via DTMF or HTTP commands
Integrated administration web server
Streamed audio support
Applicable as a standard VoIP phone/communicator
DTMF detection according to RFC2833, in-band and SIP-INFO

2N TELEKOMUNIKACE a.s., www.2n.cz 7/76
Basic Features
10/100Base-TX LAN interface
12 – 30 V DC / 2 A or PoE 802.3af supply
Integrated speakers and top-quality microphone in package
Caution
This product, its installation and configuration are not intended for
persons with physical, sensory or mental disabilities or persons with
limited experience and skills unless expert supervision or relevant
instructions are provided to them by a person responsible for their
safety.

2N TELEKOMUNIKACE a.s., www.2n.cz 8/76
1.1 Components and Associated Products
Main Unit
Part No. 914431E
2N SIP Mic
®

2N TELEKOMUNIKACE a.s., www.2n.cz 9/76
Power Supply
Part Numbers:
91378100
91378100E
91378100US
PoE injector – without cable
PoE injector – with EU cable
PoE injector – with US cable
For power supply of intercom via ethernet cable when PoE
switch is not available.
Part No. 914102x Stabilised 12 V / 2 A power supply (E – Europe, GB – Great
Britain, US – USA) needs to be used when no PoE is
available.
Tip
For more accessories and particular advice please contact your local
distributor of 2N products.

2N TELEKOMUNIKACE a.s., www.2n.cz 10/76
1.2 Terms and Symbols
The following symbols and pictograms are used in the manual:
Safety
Always abide by this information to prevent persons from injury.
Warning
Always abide by this information to prevent damage to the device.
Caution
Important information for system functionality.
Tip
Useful information for quick and efficient functionality.
Note
Routines or advice for efficient use of the device.

2N TELEKOMUNIKACE a.s., www.2n.cz 11/76
2. Description and Installation
Here is what you can find in this section:
2.1 Before You Start
2.2 Electric Installation
2.3 Product Description

2N TELEKOMUNIKACE a.s., www.2n.cz 12/76
2.1 Before You Start
Product Completeness Check
Before installing this product, check whether the product delivery includes:
1x 2N SIP Mic
®
Quick User Manual
Installation Conditions
2N SIP
®Mic is to be connected to the LAN.
2N SIP Mic
® is designed for indoor use.
2N SIP
®Mic may not be operated in damp environment.

2N TELEKOMUNIKACE a.s., www.2n.cz 13/76
2.2 Electric Installation
Electric Installation Step by Step
It is very easy to connect elec 2N SIP Mic
®trically. Just find the connectors and
controls for initial connection on the back panel :
connect the additional microphone to the upper connector,
connect the UTP cable,
connect a 12 V power supply to the back connector (unless PoE is used).
Caution
Be sure to connect the power supply as the last step. The SIP 2N®Mic
same applies to PoE supply from the LAN.
The device must be part of the electrical system of the building.
Insert the enclosed microphone into the DIN 3P connector on the upper 2N SIP Mic
®
side until its clicks into position. Press the locking button and pull out the microphone
to disconnect it.

2N TELEKOMUNIKACE a.s., www.2n.cz 14/76
Microphone Connection
LAN Connection
SIP Mic2N® can be connected to a standard local area network using a LAN interface
via the RJ-45 connector on the back panel. Always use CAT-5d or higher class cables
for reliability reasons. The interface supports 1 0/100 Mbps and can be PoE supplied
(IEEE 802.3af).

2N TELEKOMUNIKACE a.s., www.2n.cz 15/76
LAN Connection
The LAN interface is equipped with the Auto MDIX function for automatic straight or
cross-over cable detection.
The LAN interface can also be used for the power supply through active 2N® SIP Mic
network elements or injectors meeting the IEEE 802.3af standard.
Caution
We recommend the use of a LAN surge protection.
Power Supply Connection
SIP Mic2N® can be fed using active network elements or PoE injectors via the LAN
interface. In case this option is unavailable, use a 12 V DC / 2 A (Part No. 914102E)
power supply or another power supply on condition that you keep the nominal values
12 ~ 30 V DC included in the Mechanical and Electrical Parameters subsection. External
and PoE supplies can be combined as the device can be fed from both the supplies at
the same time. Thus, the other supply can be used for backup, for example.

2N TELEKOMUNIKACE a.s., www.2n.cz 16/76
Connect the device via the power jack on the back side as shown in the 2N SIP Mic
®
figure below.
Power Supply Connection
consumption with different power supplies: 2N SIP Mic
®
Power supply Consumption
PoE, IEEE 802.3af 8 W
12 V / 2 A 25 W
Warning
If you use an adapter other than the recommended one, do not exceed
the nominal supply voltage value of 30 V. Also make sure that the
supply voltage polarity is correct. Exceeding nominal values and/or
incorrect connection may lead to irreversible damage of the equipment.

2N TELEKOMUNIKACE a.s., www.2n.cz 17/76
2.3 Product Description
is an Ethernet SIP console designed for public sound distribution. 2N SIP Mic
®2N SIP ®
can be connected to a SIP Proxy and communicate with the server via phone calls. Mic
This guarantees compatibility with all the supported SIP-based systems.
Use an integrated web interface for configuration. Apply the 2N SIP Mic
®2N ®
to search all the units connected.Network Scanner 2N SIP Mic
®

2N TELEKOMUNIKACE a.s., www.2n.cz 18/76
Control Layout
Controls2N SIP Mic
®
Legend:
... call answer / mute buttonA
... call extension buttonB
... function buttons 1 to 12 for playing/announcing to zoneC
... bar graph – microphone drive indicatorD
... microphone DIN connectorE
... integrated speakerF

2N TELEKOMUNIKACE a.s., www.2n.cz 19/76
Controls2N SIP Mic
®
Button Function States
Each button is backlit. Different backlight colours signal different user states. See
below.
Call pick-up / Mute button
Colour Behaviour State Action upon press
White Shining At relax None
Green Flashing Incoming call ringing Answer call
Green Shining Active incoming call Mute microphone
White + (red hang-
up)
Shining Muted Turn up microphone
Yellow Shining Active message
recording
End recording
Blue Shining Active outgoing call Mute microphone

2N TELEKOMUNIKACE a.s., www.2n.cz 20/76
Call hang-up button
Colour Behaviour State Action upon press
White Shining At relax None
Red Shining Incoming / Outgoing call Hang up / Reject
Function Buttons
Colour Behaviour State Action upon press
White Shining At relax None
White Flashing Message playing End playing
Blue Flashing Outgoing call
ringing
End call
Blue Shining Active outgoing call
/ Zone
announcement
End call / End zone announcement
Green Flashing Outgoing ALARM
call ringing / DTMF
request
None (cannot be terminated) / End call
Green Shining Outgoing ALARM
call rigning / DTMF
request
None (cannot be terminated) / End call
Pink Shining HTTP request sent Return to relax
Yellow Shining Active relay
contact
As configured, refer to Buttons
Yellow
Flashing
Active message
recording
End recording
