1
•Built for the enterprise secure
converged network environment
•Efficient and streamlined single
code base
• Flexible and feature-rich
enterprise performance from
the LAN to the WAN
3Com Router 6000 Family
Overview
DATA SHEET
The 3Com®Router 6000 family offers
flexible, feature-rich resilient routing,
from the core to the edge of a secure
converged network, delivering WAN
connectivity at a competitive value. A
convenient hot-swappable modular design
allows easy installation and maintenance
and flexible expansion options. These
routers integrate seamlesslyinto existing
networks to facilitate keeping pace with
rapidly changing business needs.
Organizations gain easilymanaged, robust
networks for reliable support of their key
business applications.
Flexible and Resilient Design
The Router 6000 family offers an attractive
network solution for enterprises wanting
to maximize throughput and resiliency
from the core to the edge. The flexible
modular design of the 3Com Router 6040
and Router 6080 offers multiple configura-
tion options with a variety of LAN and
WAN interfaces that adhereto strict
industry specifications. Interface modules,
known as Flexible Interface Cards (FICs),
provide LAN and WAN support for high-
speed serial, T1/E1, T3/E3, ISDN PRI,
asynchronous transfer mode (ATM), and
asymmetric digital subscriber line (ADSL),
as well as a variety of Ethernet options.
The Router 6040 is housed in a 3U chassis
with four FIC slots; the Router 6080 comes
in a 5U chassis with eight FIC slots for
maximum flexibility and growth. For
maximum uptime, both routers offer two
embedded 10BASE-T/100BASE-TX ports,
hot-swappable FIC, and fan and power
supply modules. Powering down the
router is not necessary when changing
these components.
Feature-Rich, Full Routing
The Router 6000 family helps enhance
ROI—protecting the purchase investment
and eliminating hidden upgrade costs by
providing maximum operating memory, a
complete routing and security suite, and
robust applications set. The router is
designed to meet present and future needs
without system memory or software
upgrade purchases; no late-night upgrades
or unplanned downtime are needed.
The routers include the full complement of
SDRAMand FLASH memory* to support
dual software images. This feature assists
in recovery and provides rollback capabili-
ties. Also included as standard are: IP and
IPX Routing, OSPF, RIP V1/2, integrated
IS-IS, multicast routing,Quality of Service
(QoS), IEEE 802.1Q VLAN, IGMP v1, 2
and 3, stateful packet inspection firewall,
IPSec, BGP-4, and MPLS VPN.
Verified Interoperability
The 3Com Router 6000 family is “Tolly
Verified for Interoperability with Cisco‡”
and Tolly Verified for redundancy. This
functionality can reduce implementation
and testing time, as the question of multi-
vendor interoperability and router
resilience has been removed.
*Routers 6040 and 6080 supplied with currently available maximum of 512MB SDRAM.
‡See http://www.tolly.com/TVDetail.aspx?ProductID=172

3COM®ROUTER 6000 FAMILY DATA SHEET
2
Key Features
Enterprise-Class Design
The 3Com Router 6000 family supports
enterprise-level routing in a secure
converged network with:
· Advanced security and control
· Voice and data integration
·Standards-based interoperability
·Next-generation network readiness
·Sophisticated management capabilities
· World-class service, support, and training
· End-to-end solutions
Advanced Security and Control
Today’s enterprises can reduce operational
spending by utilizing a mix of public and
private high-speed WAN connections. By
deploying an Internet-based WAN strategy,
abusiness can take advantage of available
high-bandwidth, yet low-cost offerings.
However, using the public Internet can expose
an organization's network to numerous secu-
rity threats.
The 3Com Router 6000 family helps secure
sensitive client and company information
against unauthorized access byincorporating
3Com’s layered approach to security. These
security and control features include AAA,
RADIUS authentication support, stateful
packet inspection firewall, denial of service
blocking (DoS), Access Control Lists (ACLs).
L2TP and IPSec VPNs with 3DES and AES
encryption further help provide secure
networks.
The embedded stateful packet inspection
firewall also includes support for ACLs,
GRE (generic routing encapsulation), NAT
(network address translation), and NAT
traversal and application-specific firewalls,
allowing mission-critical business applica-
tions to operate through the firewall and
across the VPN.
Voice and Data Integration
The Router 6000 family delivers advanced
Quality of Service (QoS), including DiffServ
support for traffic management capabilities.
Utilizing IP differentiated services for
applications, the routers are equipped to
handle the most demanding voice and data
networking, helping assure the level of
service required for business operations.
Bundled with IEEE 802.1p prioritization
and IEEE 802.1Q VLAN support, the routers
help provide the service levels required to
maintain expected quality and productivity;
for example, just the right bandwidth and
frame latency for delay-sensitive traffic and
applications such as voice over IP or video.
The network is enabled to effectively
expedite application and data delivery—
even during times of heavy network use.
Voice modules deliver versatile support of
analog and digital voice. This lets enterprises,
managed service providers, and service providers
directly connect the public switched telephone
network (PSTN) and traditional telephony
equipment—private branch exchange (PBX),
key system, analog telephones, fax machines,
etc.—to the Router 6000.
Standards-Based Interoperability
3Com routerscan be confidentlyused in a
mixed-vendor network, as they have been
designed to be standards-compliant and
interoperable. Independent third party
testing by The Tolly Group enables these
routers to display the “Tolly Verified” mark
of distinction.
Next-Generation Network Readiness
Utilizing Multiprotocol Label Switching
(MPLS) in the Router 6000, larger enterprises
can simplify the routing configuration of
an existing network infrastructure and
provide scalable Layer 2 or Layer 3 VPNs
throughout their corporate network. This
benefit can increase network efficiency in
delivering services that utilize MPLS.
Sophisticated Management Capabilities
GUI management of the router is supported
by the 3Com Enterprise Management Suite
orby the 3Com Router Manager that is
included with 3Com Network Director.
These applications provide sophisticated
router management, including bulk-updating
of remote router code and configuration
backup, auto-trap setup and monitoring,
router system status, and historical reporting.
An intuitive and easy-to-use CLI interface
can be accessed directly, or remotely via
Telnet, Secure Shell, or Rlogin; other
management applications may also be used.
In addition, the Info Center diagnostic tool,
available through the CLI interface, quickly
diagnoses trouble spots and reports back for
quick and immediate action.
World-Class Service, Support, and Training
The 3Com Router 6000 family is backed
by 3Com Global Services and its authorized
partners’ expertise in network assessment,
implementation, and maintenance. Trained
personnel—competent in a variety of
network environments—provide assistance
through all phases of the network lifecycle
with services that include, but are not limited
to, project management, troubleshooting,
and training.
End-to-End Solutions
The Router 6000 family complements a broad
portfolio of 3Com enterprise and small office
secureconverged network solutions:
TippingPoint™Intrusion Prevention Systems;
the 3Com Router 3000 and 5000 families,
SuperStack®switches, 3Com Switch 8800,
7700, and 5500, and VCX™and NBX®IP
telephony solutions for enterprises; and
OfficeConnect®routers, firewalls and switches
for small offices.

3
3COM®ROUTER 6000 FAMILY DATA SHEET
Ports and slots
Router 6040:
Four FIC slots
Router 6080:
Eight FIC slots
Both models:
One Router Processing Unit slot
One sparepower supplyslot
Router Processing Unit:
Two 10BASE-T/100BASE-TX ports
One Console Port
One AUX Serial Port
Processor
733 MHz
Memory
Boot ROM: 512 KB
SDRAM: 512 MB
Flash: 32 MB
Dimensions
Router 6040:
Height: 130.5 mm (5.1 in)
Width: 436.2 mm (17.2 in)
Depth: 420.0 mm (16.5 in)
Weight: 17.5 kg (38.6 lb)
Router 6080:
Height: 219.5 mm (8.6 in)
Width: 436.2 mm (17.2 in)
Depth: 420.0 mm (16.5 in)
Weight: 27.5 kg (60.6 lb)
Power Supply
Input Voltageand Maximum Power Consumption:
Router 6040: 100 to 240 V
AC, 240W
Router 6080: 100 to 240 VAC, 320W
AC Line Frequency 50/60 Hz
Environmental Requirements
Storage temperature: -40°C to +70°C
Operation temperature: 0°C to +40°C
Humidity Range: 5% to 90%
MTBF
Router 6040: 1,520 years (13,324,000 hours)
Router 6080: 2,212 years (19,390,000 hours)
Router 6000 RPU: 75 years (657,000 hours)
Router 6000 PSU: 57 years (500,000 hours)
FICs:
3C13860: 151 years (1,323,000 hours)
3C13861: 389 years (3,413,000 hours)
3C13862: 136 years (1,191,000 hours)
3C13821: 119 years (1,042,000 hours)
3C13823: 112 years (984,000 hours)
3C13863: 157 years (1,376,000 hours)
3C13864: 95 years (832,000 hours)
3C13866: 112 years (985,000 hours)
3C13870: 119 years(1,042,000 hours)
3C13872: 143 years (1,252,000 hours)
3C13876: 211 years (1,850,000 hours)
3C13877: 217 years (1,902,000 hours)
3C13882: 255 years(2,239,000 hours)
3C13884: 126 years (1,108,000 hours)
3C13886: 126 years (1,108,000 hours)
3C13888: 199 years (1,744,000 hours)
3C13889: 192 years(1,681,000 hours)
3C13890: 359 years (3,147,000 hours)
3C13891: 260 years (2,279,000 hours)
3C13893: 280 years (2,454,000 hours)
3C13894: 187 years(1,639,000 hours)
3C13895: 207 years(1,815,000 hours)
3C13896: 136 years (1,192,000 hours)
3C13897: 183 years (1,604,000 hours)
3C13898: 175 years(1,534,000 hours)
Regulatory Compliance
CE Mark for European Union, Council Directive
99/5/EC
Safety
UL 60950 3rd Edition
CAN/CSA-C22.2 #60950
EN 60825-1, 60825-2, 60950
IEC 60950
AS/NZS60950: 2000
Emissions
CISPR 22 Class A
EN55022 Class A
FCC Part 15, CFR 47 Class A
ICES-003 Class A
AS/NZS CISPR22 Class A
VCCI V-3 Class A
Immunity
CISPR 24
EN 55024; 61000-3-2, -3-3, -4-2, -4-3,
-4-4, -4-5, -4-6, -4-8, -4-11
Warranty Terms
Hardware: 1 year
Software: 90 days
See www.3Com.com/warranty for details.
Management
3Com Enterprise Management Suite
3Com Network Director
3Com NetworkSupervisor
3Com Router Manager†
SNMP management
Specifications
†Included with 3Com Network Director
FEATURE BENEFIT 3COM ROUTER 6000 FAMILY
3Com Router 6000
Family Highlights •Serial, E1/E3, T1/T3, ATM, ISDN, ADSL,
Frame Relay, X.25, PPP, Ethernet, Fast
Ethernet
•Copper and optical interfaces
•IP, IPX, OSPF, BGP-4, IS-IS (IP), Static
Routing
•VPN: L2TP, GRE, IPSec
•MPLS VPN: L2 and L3
•Stateful packet inspection firewall, ACLs,
NAT, DoS blocking
•AAA, RADIUS, PAP/CHAP
•3Com Enterprise Management Suite,
3Com Router Manager†,CLI
•SNMP v 1, 2 and 3, Telnet, SSH, Rlogin
•Info Center (diagnostic tool)
•IP QoS (CAR, LAR, GTS, FIFO, PQ, CQ,
WFQ, WRED, LLQ); IEEE 802.1p
•Multicast routing protocols (IGMP, PIM-
SM, PIM-DM)
•IEEE 802.1Q VLAN, Inter-VLAN Routing
•H.323 and H.323 Gatekeeper support,
SIP compatibility, G.729/G.711/G.723
compression
•Telephony Interface Signaling support
•Hot-swap power,fan and FIC modules
•N+1 power supply module backup
•VRRP (Virtual Router Redundancy)
•Backup Center (Configuration / Port)
•Dial Control Center
WAN Routing • Comprehensive support for standards-
based WAN and LAN interfaces and
protocols ensures easy integration with the
widest variety of public and private
networks
Security • Protection of corporate data, assets and
resources
•Security from unauthorized access
•Secure access for authorized entities
Management • Ability to securely manage and control
across the enterprise
•Remote diagnostics and reporting
Voice/Data Support • Effective management of voice and real-
time traffic delivers top-quality transmission
•Assured availability of bandwidth for key
applications
•Voice network modules deliver versatile
combination of analog and digital voice and
data capabilities in a single network module
Resilience • Minimize downtime
•Redundant links, routers and extra band-
width ensure resilience in the face of
potential service disruptions

3Com Corporation, Corporate Headquarters, 350 Campus Drive, Marlborough, MA 01752-3064
To learn more about 3Com solutions, visit www.3com.com. 3Com Corporation is publicly traded on NASDAQ under the
symbol COMS.
Copyright © 2005 3Com Corporation. All rights reserved. 3Com, the 3Com logo, SuperStack, OfficeConnect, and NBX are registered
trademarks, TippingPoint and VCX are trademarks, and Express is a service mark of 3Com Corporation or one of its subsidiaries.
All other company and product names may be trademarks of their respective companies. While every effort is made to ensure
the information given is accurate, 3Com does not accept liability for any errors or mistakes which may arise. Specifications and
other information in this document may be subject to change without notice. 400853-006 08/05
Ordering Information
3Com Router 6040 3C13840
3Com Router 6040 chassis, 4 FIC slots,
1power supply, fan module
3Com Router 6080 3C13880
3Com Router 6080 chassis, 8 FIC Slots,
1power supply, fan module
Router Processing Unit must also be ordered separately
for each chassis:
3Com Router Processing Unit 3C13804
2x10/100 ports
3Com Router 6000 Power Supply 3C13801
Spare / redundant power supply
LAN Flexible Interface Card (FIC) Modules
3Com Router 1-Port 100 Mbps FX MM FIC 3C13860
1-port 100BASE-FX interface module;
multi-mode fiber, SC connector
3Com Router 2-Port 10/100 Mbps FIC 3C13861
2-port 10BASE-T/100BASE-TX interface module
3Com Router 1-Port 100 Mbps FX SM FIC 3C13862
1-port 100BASE-FX interface module;
single-mode fiber, SC connector
WAN Flexible Interface Card(FIC) Modules
3Com Router 4-Port Fractional T1 FIC 3C13821
4-port Fractional T1 interface module
3Com Router 4-Port Fractional E1 FIC 3C13823
4-port Fractional E1 interface module
3Com Router 4-Port Enhanced Serial FIC 3C13863
4-port Sync/Async serial interface module
3Com Router 8-Port Enhanced Serial FIC 3C13864
8-port Sync/Async serial interface module
3Com Router 4-Port Channelized E1/PRI FIC 3C13866
4-port E1/CE1/PRI interface module
3Com Router 4-Port Channelized T1/PRI FIC 3C13870
4-port T1/CT1/PRI interface module
Com Router 1-Port ADSL (over POTS) FIC 3C13871
1-Port ADSL (over POTS) interface module
3Com Router 2-Port ADSL FIC 3C13872
2-port ADSL interface module
(ADSL over POTS – Annex A)
3Com Router 4-Port E1 IMA FIC 3C13874
4-Port E1 IMA interface module
WAN Flexible Interface Card (FIC) Modules,continued
3Com Router 4-Port T1 IMA FIC 3C13875
4-Port T1 IMA interface module
3Com Router 1-Port E3 ATM FIC 3C13876
1-Port E3 interface module
3Com Router 1-Port T3 ATM FIC 3C13877
1-Port T3 interface module
3Com Router 1-Port OC-3 ATM, MM FIC 3C13882
1-port OC-3 ATM interface module;
multi-mode, SC connector
3Com Router 1-Port OC-3 ATM, SM FIC 3C13884
1-port OC-3 ATM interface module;
single-mode (15km distance), SC connector
3Com Router 1-Port OC-3 ATM, SML FIC 3C13886
1-port OC-3 ATM interface module;
single-mode long reach (30km distance),
SC connector
3Com Router 1-Port Channelized E3 FIC 3C13888
1-port Channelized E3 interface module
3Com Router 1-Port Channelized T3 FIC 3C13889
1-port Channelized T3 interface module
3Com Router 2-Port FXS FIC 3C13890
2-port FXS interface module
3Com Router 4-Port FXS FIC 3C13891
4-port FXS interface module
3Com Router 2-Port FXO FIC 3C13893
2-port FXO interface module
3Com Router 4-Port FXO FIC 3C13894
4-port FXO interface module
3Com Router 2-Port E&M FIC 3C13895
2-port E&M interface module
3Com Router 4-Port E&M FIC 3C13896
4-port E&M interface module
3Com Router Channelized E1 Voice FIC 3C13897
1-port Channelized E1 voice interface module
3Com Router Channelized T1 Voice FIC 3C13898
1-port Channelized T1 voice interface module
Cables (3meters in length, unless otherwise noted)
3Com Router T1 Cable, RJ45, 3m 3C13674
T1- RJ45 to RJ45
3Com Router E1 Cable, BNC, 20m 3C13675
E1 – 75 ohm/2.55 mm-DB-15M to 2 x
BNC 75 ohm; 20 meters
3Com Router E1 Cable, RJ45, 20m 3C13676
E1 – 120 ohm/0.32 mm-DB-15M to RJ-45;
20meters
3Com Router E1 Cable, RJ45, 3m 3C13677
G.703 – 120 ohm/0.32 mm-DB-15M to RJ-45
3Com Router X.21 DTE Cable- Enhanced 3C13681
X.21 DTE Cable – DB-28M to X.21M
3Com Router X.21 DCE Cable- Enhanced 3C13682
X.21 DCE Cable – DB-28M to X.21F
3Com Router V.24 DTE Cable- Enhanced 3C13683
V.24 DTE Cable – DB-28M to V.24M
3Com Router V.24 DCE Cable- Enhanced 3C13684
V.24 DCE Cable – DB-28M to V.24F
3Com Router V.35 DTE Cable- Enhanced 3C13685
V.35 DTE Cable – DB-28M to V.35M
3Com Router V.35 DCE Cable- Enhanced 3C13686
V.35 DCE Cable – DB-28M to V.35F
3Com Router T3/E3 Cable 3C13687
E3/T3 Cable – 75 ohm, SMB to BNC; 15 meters
3Com Router T1 Voice Cable 3C13688
T1 Voice Cable
3Com Router 4-Port E1 IMA Cable 3C13689
4-Port E1 IMA Cable
3Com Router 4-Port T1 IMA Cable 3C13690
4-Port T1 IMA Cable
3Com recommends a 3Com ExpressSMservice contract
for the Router 6000 family, which provides telephone
technical support, hardware replacement, and software
upgrades to ensurethat any technical issues are resolved
quickly and efficiently. Express support is available with
8x5 or 24x7 response time options for telephone
support. Choose next-business-day or 4-hour response
for advance hardware replacement. Availability may vary
by geographic location.
Order 3Com Router Installation service to ensure a
successful result, faster deployment, and minimize the
risk of disruption to your business.
3COM®ROUTER 6000 FAMILY DATA SHEET
PRODUCT DESCRIPTION SKU PRODUCT DESCRIPTION SKU PRODUCT DESCRIPTION SKU
SERVICE
The "Tolly Verified" certification, supported by intensive testing
by The Tolly Group, provides the opportunity for enterprise
network buyers to evaluate products on an objective basis and
gain the confidence that products support industry-accepted
protocols and features, and deliver interoperability. For details,
see http://www.tolly.com/TVDetail.Aspx?ProductID=172.
