3Dconnexion®CadMouse Compact
Driver Version: 3DxWare 10.8.0 and higher

3Dconnexion CadMouse Compact | 2
Table of Content
QuickStart Guide................................................................................................................ 3
Desktop Setup...................................................................................................................................................................................3
Installation........................................................................................................................................................................................3
Feature Guide .................................................................................................................... 4
3Dconnexion CadMouse Compact.......................................................................................................................................................4
3Dconnexion Settings......................................................................................................... 6
Advanced Settings.............................................................................................................................................................................7
Buttons .............................................................................................................................................................................................8
Assigning Quick Macros to buttons....................................................................................................................................................8
Assigning Commands using the flyout window...................................................................................................................................9
Creating Macros................................................................................................................................................................................9
Creating Radial Menus.....................................................................................................................................................................10
3Dconnexion Home............................................................................................................11
Technical Specifications....................................................................................................12

3Dconnexion CadMouse Compact | 3
QuickStart Guide
Desktop Setup
Place your CadMouse Compact on the right side of the keyboard.
Installation
1. Connect
Connect your 3Dconnexion CadMouse Compact to an USB port of your computer.
2. Download the latest 3Dconnexion software
Before starting the installation, make sure you have the latest 3Dconnexion software (3DxWare), which can be downloaded at
3dconnexion.com/drivers.
3. Install the 3Dconnexion software
Install the 3Dconnexion software by following the instructions.
4. Register your product
Register your product after the installation to benefit from 3Dconnexion services.

3Dconnexion CadMouse Compact | 4
Feature Guide
3Dconnexion CadMouse Compact
Middle Mouse Button
The CadMouse Compact features a dedicated Middle Mouse Button that helps you quickly access important
application functions. It instantly recognizes the applications you are using, as well as their environments, and
automatically assigns commands to the Button.
Functionality of the Middle Mouse Button in the following applications and environments:
CAD applications: Use the Middle Mouse Button to navigate (pan, zoom, orbit) within your drawings or 3D models.
Windows: Middle click an application icon on the Windows taskbar to open the application in a new window. To close the
application, simply hover over the it’s icon and then middle-click the appearing thumbnail.
Internet browsers: Use the Middle Mouse Button to open a link in a new tab. To close a tab, simply click on it with the Middle
Mouse Button.
Other applications: Use the 3Dconnexion Settings to assign your most frequently used commands to the Middle Mouse Button.
You can, for example, assign the Format Painter command to the Middle Mouse Button in Microsoft Word or the Enter command
in Microsoft Excel.
Note: The 3Dconnexion driver (3DxWare) is needed to utilize all the functions of the CadMouse Compact.

3Dconnexion CadMouse Compact | 5
Thumb Buttons
Your CadMouse Compact comes with two Thumb Buttons, which help you navigate in CAD as well as in other
applications. The CadMouse instantly recognizes the applications you are using, as well as their environments,
and automatically assigns commands to the Thumb Buttons.
Functionality of the Thumb Buttons in the following applications and environments:
CAD applications: Press the Thumb Buttons to zoom in and out of the cursor’s position in your drawing or 3D model; fine tune
the zoom level by continuing to keep the corresponding button pressed.
Text or spreadsheet applications:Use the Thumbs Buttons to quickly jump to the beginning or end of a document.
Internet browsers: While browsing you can easily jump forward or backward between web pages with the Thumb Buttons.
Other applications: Facilitate your work and use the 3Dconnexion Settings to assign your most frequently used commands to
the Thumb Buttons.
Note: The 3Dconnexion driver (3DxWare) is needed to utilize all the functions of the CadMouse Compact.
On-Screen Display
The On-Screen Display (OSD) provides a convenient visual reminder of the commands assigned to the Middle Mouse Button
and the Thumb Buttons. After installing the driver, the OSD of the CadMouse Compact is hidden by default. To enable the OSD,
open the 3Dconnexion Settings, select the CadMouse Compact, click on Buttons, and activate the checkbox Always show
On-Screen Display. You can easily drag and drop the OSD to a different position, where it is more convenient (e.g., on the
taskbar near the systray). A click on the OSD opens the button mapping panel.
Radial Menu Button
Located between the Mouse Wheel and the status LED you will find the Radial Menu Button of your CadMouse
Compact. Clicking it opens an application or environment-specific radial menu, giving you access to your
favourite commands with a simple mouse gesture. Learn in the section Creating Radial Menus how to easily
create your own radial menus for any application.
Mouse Wheel
The Mouse Wheel allows for both precise click-by-click zooming in CAD applications, as well as adjustable
smart scrolling speed with inertia for fast but precise skimming of long documents or web pages.
The Mouse Wheel provides two scrolling modes:
High Speed Mode: Flick the mouse wheel once to scroll quickly across multiple pages (approximately 3 pages). Simply flick
the mouse wheel again immediately afterwards, to increase the scrolling speed.
Low Speed Mode: To smoothly scroll through a document and read it at the same time, first flick the mouse wheel once, then
rotate it (click by click) before the document stops to continue scrolling.
Move the mouse wheel by one increment in the oppositive direction to stop scrolling.

3Dconnexion CadMouse Compact | 6
3Dconnexion Settings
You can access the 3Dconnexion Settings panel either via 3Dconnexion Home (on your desktop), the icon in your
notification area (systray), or the Windows start menu.
The name of the active application is displayed at the top of the panel. Any setting change is relevant to this application only.
If multiple 3Dconnexion devices are connected, you can select the desired product to configure by clicking on the flyout button
at the top left of the panel.
Speed
This slider sets the speed for your CadMouse Compact on the screen.
Note: The CadMouse Compact speed slider sets speed globally for all applications.

3Dconnexion CadMouse Compact | 7
Advanced Settings
Settings that can be configured in the Advanced Settings panel are not application-specific but are the same for all
applications system-wide.
Mouse Motion
Enable Acceleration: If the mouse moves slow or fast, the cursor will move even slower or faster across the screen.
Note: Recommended setting is disabled.
Sensor Polling Rate
Select the frequency at which the CadMouse Pro communicates with your PC. A higher frequency results in more accurate
tracking and smoother movement of the cursor.
Mouse Wheel Speed
Lines: Select the number of lines scrolled when the mouse wheel is moved 1 increment.
One page / one screen: Moving the mouse wheel 1 increment will scroll to the next/previous page.
Smart Scrolling
Adjustable smart scrolling speed with inertia in documents and browsers is ideal for working in many-paged documents,
allowing the user to find specific pages quickly and easily.

3Dconnexion CadMouse Compact | 8
Buttons
The Buttons panel within 3Dconnexion Settings allows you to assign commands, macros or radial menus to the programmable
CadMouse Buttons. The name of the active application is displayed at the top of the panel. Any changes you make to CadMouse
Compact settings are relevant to this application only.
While you are working in an application, the On-Screen Display always shows you the current assignment of the buttons for
this app. To hide the OSD, uncheck Always show On-Screen Display.
You have the option to swap the right mouse button and the middle mouse button by checking Swap Middle / Right Mouse
Buttons.
A note about Environment sensitivity: Some applications feature environment sensitive key mapping. In those applications you
can have different key assignments depending on the current active environment.
Assigning Quick Macros to buttons
Click on the text in the key field and press the required key or key combination to quickly assign a keystroke or macro to a
CadMouse button.
When a macro is created, it always sends a press and release command. If you want to assign a press and hold command
instead (for example Ctrl or Shift), you should use the Keyboard command category in the flyout window.

3Dconnexion CadMouse Compact | 9
Assigning Commands using the flyout window
Clicking on the >arrow on the right-hand side of the button field opens a flyout window for that CadMouse button:
The category of the command that it is currently assigned to is highlighted in bold. The flyout window allows you to browse or
search for commands in different categories such as 3Dconnexion or application commands. When you select a command by
clicking on it, it is automatically assigned to the CadMouse button.
Creating Macros
First click on the >arrow on the right-hand side of the key field, then expand the Macro category and click on New Macro.
This opens the macro editor where you can assign a name for your macro and a sequence of keystrokes in the corresponding
fields. Clicking on Save will automatically assign the new macro to the button from where you opened the panel.

3Dconnexion CadMouse Compact | 10
Creating Radial Menus
First click on the >arrow on the right-hand side of the button field, then expand the Radial Menu category and click on New
Radial Menu.
This brings up the radial menu editor where you can assign a name and commands to the different sections. Your new radial
menu will be automatically assigned to the button from where you opened the panel.

3Dconnexion CadMouse Compact | 11
3Dconnexion Home
Once you have successfully installed the latest 3Dconnexion driver, 3Dconnexion Home gives you access to various
3Dconnexion apps:
Trainer:
Learn how to quickly use the 3Dconnexion SpaceMouse.
Manual:
Here you can find the manuals for all 3Dconnexion products.
Settings:
Open the settings panel to customize your 3Dconnexion devices.
Viewer:
Use the 3Dconnexion Viewer to review 3D models.
Collage:
3Dconnexion Collage lets you create high resolution picture collages with your SpaceMouse.
Demo:
Test and practice your skills by assembling the landing gear of an aircraft.
Registration:
Register your product after the installation to benefit from 3Dconnexion services.
Videos:
Find instructive videos for your 3Dconnexion devices.

3Dconnexion CadMouse Compact | 12
Technical Specifications
Dimensions & Weight
Length: 115 mm / 4.5’’
Width: 71 mm / 2.8’’
Height: 41 mm / 1.6’’
Weight: 96 g / 0.21 lb / 3.39 oz
Supported Operating Systems
Microsoft®Windows, macOS
More information
Supported Software
More information
Package Contents
3Dconnexion CadMouse Compact
Certifications and Registrations
CE, FCC, KC, RCM, BSMI, RoHS, WEEE, LUCID
More information
Warranty
2-year limited hardware warranty
Support
3dconnexion.com/support
