24B1H VESA adapter
Assembly instructions
The VESA adapter is compatible with the following AOC (aoc.com) products:
24B1H, 27B1H
The VESA adapter allows you to conveniently mount your AOC brand monitor to a
monitor arm with a VESA hole pattern (75 x 75mm). Use the included screws and
nuts.
If you want to mount your VESA adapter directly to the wall, use suitable screws
and dowels.(not included in the scope of delivery).

2
Assembly instructions
Important Safeguards
Please read these instructions carefully and keep them for future reference.
If you pass the product on to third parties, these instructions should always
be included. Failure to follow these instructions may result in injury or
damage to persons or the product, for which we cannot accept any liability.
IMPORTANT - KEEP FOR FUTURE REFERENCE.
• This product should always be used in accordance with the specified safety instructions.
• Do not install your VESA adapter in combination with the monitor in places where there are people
below.
• Do not exceed the maximum weight of the compatible monitor models as this may result in serious
injury or damage to property.
• Observe the maximum ambient temperature of 35°C when using the product.
• Do not mount the VESA adapter near a heat source or in direct sunlight, as this could heat up the
adapter.
• Check whether your mounting point (e.g. monitor arm) can withstand the weight of the monitor with
VESA adapter.
• The product is designed exclusively for mounting with a hole pattern of 75x75 mm.
• After installing the VESA adapter, the position of the monitor must be readjusted to ensure correct
ergonomics.
⚠ CAUTION
Ensure that the device is switched off and disconnected from the power supply before
installation to avoid possible injury or damage.
1. Before First Use
Check the product carefully for possible transport damage and for the absence of accessories, such as
screws, which should be included in the scope of delivery.
⚠ CAUTION
Make sure that packaging materials and small screws and parts contained therein are
inaccessible to children to minimize the risk of choking and other risks.
2. Maintenance and Cleaning
2.1 Maintenance
- It is recommended to check every three months that all screws are still tight. Also, regularly check the
condition of all components of the product.
- Store the product in a cool and safe place, ideally at a maximum storage temperature of 40°C. For
additional safety, keep the product away from children and preferably in its original packaging.
- Avoid any vibrations and shocks so as not to affect the life and functionality of the product.

3Assembly instructions
2.2 Cleaning
- No corrosive or hot cleaning agents should be used to clean the product. Likewise, wire brushes, metal
or other sharp materials are unsuitable for cleaning and should not be used.
- For gentle and effective cleaning, the use of a soft, damp cloth is recommended.
3. Waste Disposal
For the disposal of this product we recommend to contact the responsible local authorities or disposal
services. They can provide you with detailed information on available disposal options and recycling
centers in your area.
4. Manufacturer Information
3idee Technologies S.à r.l.
5 Um Lenster Bierg
L-6125 Junglinster
Luxembourg
5. Help and Feedback
If you need help with your article, we are here for you. We also appreciate any feedback.
https://help.3idee.eu/en/contact

4
Assembly instructions
Scope of Delivery Accessories
4x M4x14 Phillips Head Screw
(SP2)

5Assembly instructions
Horizontal / Vertical Alignment
Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This
limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information,
as the load limit of the adapter can quickly be exceeded if not installed properly.
We are continuously working on developing monitors and adapters that are also suitable for vertical
orientation.
However, monitors are designed for horizontal alignment by default.
Horizontal
Mounting: YES
Vertical
Mounting: NO

6
Assembly instructions
Assembly Instruction
Step 1
Figure 1
Lay your AOC monitor flat on a safe and soft surface and
remove the stand. (Figure 1)
Step 2
Figure 2
Now take the 3idee VESA adapter and "lever" it onto the
base of your AOC monitor as shown. (Figure 2)
Step 3
Figure 3
This is how the adapter should now hang on your AOC
monitor. (Figure 3)
In the next step, we will screw the adapter to the monitor.
Step 4
Figure 4
Now you can use the screw you just removed from your AOC
stand to connect the VESA adapter to the monitor.
(Figure 4)

7Assembly instructions
Step 5
Figure 5
Please check if the adapter is properly connected to the
monitor. (Figure 5)
Step 6
Figure 6
For optical reasons you can fold down the lever of the screw
so that it is not visible later. (Figure 6)
Step 7
Figure 7
For this step we recommend a 2nd person.
Now lift the monitor and hold it to your monitor mount.
Fasten the VESA adapter with the 4 included M4x14 screws
(screw bag: SP2).
It is best to fasten 2 screws diagonally first, so that the
monitor cannot fall down and you can fasten the remaining
screws without any effort.
ATTENTION: Pay attention to the right screws!
(Figure 7)
Step 8
Figure 8
Please make sure that all 4 screws are tight. (Figure 8)
