4-noks Power Reducer User manual

POWER REDUCER
- Technical Manual -
4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
1 Product Overview
2 System Requirements
3 Main Features
4 Installation
4.1 General instructions
4.2 Positioning
4.3 Ventilation
4.4 Mounting
5 Wiring
5.1 Wiring Power Reducer (SA ONLY)
5.2 Wiring Power Reducer (E4U ONLY)
5.3 Wiring the “supply” connections
5.4 Wiring the “control” connections
6 Elios4you Installation (Power Reducer E4U ONLY)
7 Settings (Power Reducer E4U ONLY)
8 User Operation (Power Reducer E4U ONLY)
9 Control Parameters (Power Reducer E4U ONLY)
10 Advanced Settings (Power Reducer E4U ONLY)
11 LED and Push-button
12 Switching from SA version to E4U (0-10V) version
13 Troubleshooting
14 CE Norms
15 Disposal
16 Template
17 Notes
Pag 3
Pag 4
Pag 4
Pag 5
5
5
6
6
Pag 7
7
9
11
12
Pag 13
Pag 14
Pag 15
Pag 16
Pag 16
Pag 17
Pag 17
Pag 18
Pag 18
Pag 18
Pag 19
Pag 20
INDEX
Pag 2
WARNING: This manual is meant to provide general information about Power Reducer. Some
pargraphs and sentences might refer ONLY to one specic version of Power Reducer
(Stand Alone or Elios4you ).
Check carefully the documentation and take note of possible suggestions!
SA E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
Product Overview
Power Reducer is a load diverter designed to automatically divert the excess energy produced from a PV system to a
resistive load, such as an immersion tank, rather than exporting to the GRID.
There are 2 different versions of Power Reducer, which provide 2 distinct modes of controlling the diversion of the
surplus generated energy.
Stand Alone
The Stand Alone version comprises of the Power Reducer SA and a Current Transformer (CT). The CT detects the en-
ergy exchange with the GRID and in particular the energy ow directions. Thus it distinguishes when the household is
drawing energy to satisfy consumption or exporting when the PV system is generating surplus to requirement.
Elios4you
This second version of the Power Reducer provides the measurements and commands that are managed through Eli-
os4you and its mobile application interface with dedicated graphics.
Elios4you features 2 Current Transformers (CT), one to detect the energy exchanged with the GRID and the other to
monitor the energy generated by the PV installation. The mobile application interface allows detailed understanding of
the PV system and a more rened control over the generated power by means of the Power Reducer (E4U)
Both versions of the Power Reducer perform the same basic functionality, which is to divert surplus generated power to
a resistive load such as the immersion tank even when this surplus power is less than the rated power required by the
resistive load. The Power Reducer accomplishes this feat by modulating the load to force it to operate at the lower rating
in a continuous manner over time, thus avoiding the need to import energy for this load from the GRID.
Example: Supplying a 1700W resistive load with say a 400W surplus from the PV system. In this case the Power Re-
ducer will warm the resistive load with just 400W avoiding any drawing of the 1300W of power from the GRID which
would normally take place without the Power Reducer.
1
Pag 3
Stand Alone version Elios4you version
SA
E4U
SA E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
Main features
Suply Voltage: 230V ±15%
Supply Frequency: 50 Hz
Load Size: 3 kW - Max 3,2 kW
Load Current: 13 A - Max 16 A
Analog Input (0-10Vdc): 0-10Vdc directly supplied by Power Reducer - max current 40 mA
Reading accuracy: ±1%
Input impedence:~5 KOhm
Power: PWM a 19,2 KHz
Working Temperature: from -5°C to 40°C
Protection rate: IP 20
Weight: 3,9 Kg
Dimensions:
3
Pag 4
24 19
70,5
277
294309
15
System Requirements
The electrical load (immersion) connected to a Power Reducer has to be a pure resistive load that does not exceed the
related power of Power Reducer itself (3kW).
(E4U ONLY) The rmware version installed on the Elios4you TOP must be V1054 build 72 or higher. The
system can not work properly with older rmware versions. Check the version from the App in the “Update” menu. If
necessary, update the App by clicking “Update App via 4-Cloud”. It is then suggested to select “Install Firmware” to
update the device with the latest rmware version from App.
(E4U ONLY) It is necessary that the installation of Elios4you is completed correctly before proceeding with
the installation of Power Reducer. Verify the orientation of CTs (Current Transformer) and the correct wiring of Elios4you.
Make sure that the App shows the proper values of the system energy ows, making sure that the Elios4you LEDs diagno-
sis conrms the ows of energy represented by the graphics. For further information, check the Elios4you documentation.
2
E4U
E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
Installation4
Warning: The wiring MUST be carried out by a qualied technician.
Warning: Connect the device to a line adequately protected against short circuits and heat overloads in excess of
the applicable maximum rated power.
Warning: Connect the device as set out by local regulations.
Warning: Do not perform any wiring while the device is powered up.
4.1 General instructions
4.2 Positioning
When choosing where to install Power Reducer, you must consider the following factors:
a) location of the power cable of the immersion
b) recirculating air
c) (E4U ONLY) distance between Power Reducer and Elios4you
The length of the 0-10V connection cables between Power Reducer and Elios4you must not exceed 10 meters.
0-10 V max 10m
230 V ~ 230 V ~
Power Reducer shares the same power source as the resistive load. Install the Power Reducer along the path
followed by the cable of the immersion.
Power Reducer must be positioned in an area with adequate ventialtion, in order to have a an efcient cooling
system. As far as possible, choose open areas with windows, avoiding closets or narrow spaces.
Pag 5
230 V ~ 230 V ~
Stand Alone version
Elios4you version
SA
E4U
E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
4.3 Ventilation
It is very important to provide good ventilation to the
Power Reducer to facilitate effective control of the
operating temperature of the device. To do this, it is
necessary to install Power Reducer vertically, posi-
tioning the cable downwards.
Ensure that there is adequate spacing around the
Power Reducer (minimum of 7cm) in particular the
top and bottom for adequate ow of air.
MIN 7 cm
MIN 7 cm
4.4 Mounting
Power Reducer can be mounted xing it to the wall with 4 screws (not supplied). The size and type of screws have
to be suited to the weight of the Power Reducer and the type of wall.
WARNING: Do NOT use the Power Reducer directly as a template for the holes. This use may damage the device
beyond repair. Utilise the template attached at the end of this document.
Pag 6
Pantone 368C
C=57 M=0 Y=100 K=0
Pantone 158C
C=0 M=61 Y=97 K=0
Grigio 70%
C=0 M=0 Y=0 K=70
Nero
C=0 M=0 Y=0 K=0
!

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
Wiring5
Household
L
N
L
LN
Generation
meter
Mains meter
Switchboard
Pantone 368C
C=57 M=0 Y=100 K=0
Pantone 158C
C=0 M=61 Y=97 K=0
Grigio 70%
C=0 M=0 Y=0 K=70
Nero
C=0 M=0 Y=0 K=0
N
Power Reducer
Immersion
16A
power supply
GRID
PV inverter
5.1 Wiring Power Reducer (SA ONLY) - Example
Pag 7
power supply
Towards the
mains meter
Green point
Towards the
residual-current
circuit breaker
WARNING: CT orientation
K
L
Arrow and “L”
pointing towards the
residual-current
circuit breaker
SA

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
Power Reducer (SA ONLY) - General wiring
Towards the immersion
16A
circuit breaker
Towards power
supply
WARNING:
3-core cable
Minumum dimension:
2,5 mm2
Terminal 1 Terminal 2
+10 V
Ctrl
L
GND
N
Fuse 16A
Categ. FF
L
GND
N
Terminal 3
Current Transformer Bypass switch
for system
override
(optional)
TA +
TA -
WARNING:
label reporting the rmware
version uploaded:
it must be 1.2 o bigger
!
!
Power Reducer - Terminals
Terminal 1 - Towards the resistive load (up to 3 kW)
Terminal 3 - Power supply
Terminal 2 - CT wiring
Terminal 2 bis - clean contact - OPTIONAL
1
2
3
1
2
1
2
L (phase)
GND
N (neutral)
TA + (red or white wires)
TA - (black or brown wires)
N (neutral)
GND
L (phase @ 230V)
+10V
Ctrl
SA

SECONDARY
SwitchBoard
4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
Household
L
N
L
LN
Generation
meter
Mains meter
Green point Switchboard
Mains CT
Pantone 368C
C=57 M=0 Y=100 K=0
Pantone 158C
C=0 M=61 Y=97 K=0
Grigio 70%
C=0 M=0 Y=0 K=70
Nero
C=0 M=0 Y=0 K=0
Generation CT
N
Power Reducer
Immersion
16A
0-10V connection
between Elios4you
and Power Reducer
(max 10 meters)
1A
power supply
GRID
PV inverter
ALTERNATIVE installation example
Main Switchboard
Towards the generation
meter
0-10V Connection
Towards the
Power Reducer
5.2 Wiring Power Reducer E4U (ONLY) - Example
If the space in the main consumer unit is already full, you
can install a secondary panel enclosure.
WARNING:
Current Transformers have to be installed inside the main
consumer unit and positioned in the correct direction: the
green dot should be pointing towards the residual-current
circuit breaker.
Pag 9
power supply
Towards the
mains meter
Green point
and letter “L”
towards the
residual-current
circuit breaker
KL
E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
Terminal 1 Terminal 2
Terminal 3
Terminal 4
E4U supply
OPTIONAL
Towards the
immersion
+10 V
Ctrl
GND
16 A
circuit
breaker
Towards power
supply
+10 V
Ctrl
GND
WARNING: 3-core cable
MIN dimension: 2,5 mm2
V
0
Earth
V0
Earth
V
0
Earth
Towards
E4U 0-10V
input
- Max 10 m -
Firmware
version
Power Reducer - Terminals
Terminal 1 - Towards the immersion
Terminal 3 - Supply
Terminal 2 - Connections E4U
Terminal 4 - E4U supply (OPTIONAL)
1
2
3
V (phase)
0 (neutral)
Earth
1
2
3
+10V
Ctrl
GND
1
2
3V (phase) 230V
Earth
0 (neutral)
1
2
3
V (phase) 230V
Earth
0 (neutral)
Power Reducer (E4U ONLY) - General wiring
Fuse
16A
Cat FF
Pag 10
- Serial Number from 1 to 99 -
Terminal 2
Towards the
immersion
+10 V
Ctrl
GND
16 A
circuit
breaker
+10 V
Ctrl
GND
WARNING: 3-core cable
MIN dimension: 2,5 mm2
Towards
E4U 0-10V
input
- Max 10 m -
Firmware
version
Fuse
16A
Cat FF
- Serial Number from 100 onwards -
Terminal 3
Terminal 4
E4U supply
OPTIONAL
L
GND
N
L
GND
L
N
N
GND
Terminal 1
1
2
3
L (phase)
GND
N (neutral)
1
2
3
+10V
Ctrl
GND
1
2
3N (neutral)
GND
L (phase) 230V
1
2
3
L (phase) 230V
GND
N (neutral)
Terminal 1 - Towards the immersion
Terminal 3 - Supply
Terminal 2 - Connections E4U
Terminal 4 - E4U supply (OPTIONAL)
Power Reducer - Terminals
Towards power
supply
E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
The wiring of Power Reducer is composed of 2 distinct areas: “supply” connections and “control” connections
Pag 11
L
N
GND
- Power Reducer version with Serial Number from 1 to 99 -
5.3 Wiring the supply connections and
from the
power supply
Towards the immersion
Live-phase cable
Power Reducer
WARNING:
16 A
Circuit
Breaker
Towards the
power supply
Towards the
immersrion
Terminal 1 V0
Earth
V
0
Earth
The power supply is carried by the same cable that feeds the load itself. Cut the cable of the immersion
(or replace the old cable with a new one) so that the two ends can be connected to terminals 1 and 3 of
Power Reducer, as shown below.
WARNING: before you cut the immersion cable, make sure it is switched OFF.
WARNING: the power supply cable must be a three-core cable. Each single wire must have a minumum cross
section of 2,5 mm2
WARNING: protect the cable that supplies the Power Reducer with a 16A circuit breaker or with an appropriate fuse
N
L
GND
- Power Reducer version with Serial number over 100 -
possible measurements made with amperometric clamps must be detected on the live-phase cable that
connects the power source to the Power Reducer. Measurements detected on the wire directed towards
the resistive load (immersion) will be inaccurate, due to the inuence generated by high-frequency
energy modulation signals.
Towards the
immersrion 16 A
Circuit
Breaker
Towards the
power supply
Terminal 1
!
!
!
!
SA E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
Terminal 2
+10 V
Ctrl
GND
IN 0-10V (16)
OUT 0-10V (17)
GND 0-10V (18)
IN 0-10V (13)
OUT 0-10V (15)
GND 0-10V (14)
Elios4you single-phase Elios4you PRO three-phase
relay -
relay +
fan -
fan +
ntc
ntc
TA
TA
+10V
GND
Ctrl
A
B
GND
Power Reducer - Details of Terminal 2
Connection 0-10V
MAX lenght: 10 m
5.4.2) connection between Power Reducer and Elios4you (Power Reducer E4U ONLY)
The connection between Power Reducer and Elios4you is via a shielded three-core cable (3 x 0.5 or
2 x 0.25 + braid). The maximum cable lenght is 10 meters. The wiring must be carried out taking care to
match the terminals between Elios4you and Power Reducer.
Pag 12
Power Reducer E4U single-phase E4U three-phase Ref cable
+10V
Ctrl
GND
IN 0-10V (16)
OUT 0-10V (17)
GND 0-10V (18)
IN 0-10V (13)
OUT 0-10V (15)
GND 0-10V (14)
Cable matching
L
N
GND
Terminal 2
+10 V
Ctrl
Fuse 16A
Categ. FF
Terminal 3
Current Transformer
Bypass switch
for system
override
(optional)
TA +
TA -
WARNING:
label reporting the rmware
version uploaded:
it must be 1.2 o bigger
!
Morsetto 1
5.4 Wiring the “control connections”
5.4.1) connection between Power Reducer and Current Transformer + Bypass switch (Power Reducer SA ONLY)
SA
E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
6.5) Check the LEDs on the front panel of Elios4you and make sure they report the correct feed-back
from the device
6.3) Repeat the procedure for the Live-phase from the Mains electrical meter
WARNING: place the CT making sure that the green point is directed towards the Residual-Current Circuit Breaker
WARNING: make sure that all the household electrical appliances are connected to the electrical system in between
the 2 CTs and the related meters. Otherwise, the resulting measurements will not be reliable.
WARNING: any change to the CT cable length would lead to an increased error rate in data collection. 4-noks does
not recommed such alteration of the device.
6.4) Power Elios4you measuring device as shown on the wiring scheme, paying attention to the
phases sequence
b) Grab the GENERATION CT c) Securely clamp the CT over the Live-
phase cable
from RCCB to the meter
6.2) Carry out the connections
a) Identify the Live-phase that comes from
the GENERATION meter
Mains
Generation
Household
N
N
L
L
N
L
Generation - WHITE
Exchange - YELLOW
Pag 13
Elios4you Installation - (Power Reducer E4U ONLY)6
6.1) Mount Elios4you on DIN rail within the consumer unit
1
A
Before mounting Elios4you, remove the sticker / label stating USER
and PASSWORD. Store it in a safe place to access the dashboard.
WARNING: the device must be installed inside an electrical panel. Use the appro-
priate caution to let the the Radio Transmitter inaccessible to the end
user, ensuring at the same time the possibility of operation by skilled
personnel during technical assistance.
- if it is not possible to t Elios4you inside the general switchboard, you will need to use an additional panel enclo-
sure -
WARNING:
E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
Click “Peripherals” To activate Power Reducer it
necessary to activate DAC-
mode. Pressing the indicated
area, a drop-down menu ap-
pears, allowing the selection
of 2 different options. To con-
gure the device, select “Pow-
er Reducer” and confirm
with “OK”
Pag 14
Settings (Power Reducer E4U ONLY)7
Before using and managing Power Reducer properly, it is necesary to set the parameters needed to ensure it functions
correctly.
To set these parameters, the Elios4you app must be previously downloaded and installed on a smartphone or tablet and
the system conguration must have been completed successfully. Once the Wizard procedure is nished, follow the steps
below.
Press the “MENU” button Select “Parameter Settings”
12
3 4
E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
User operation (Power Reducer E4U ONLY)8
When the “Power Reducer” mode is activated, you can select between 3 different modes of operation through the Eli-
os4you App ( Menu / System Settings / Peripherals - DAC Mode - Power Reducer ).
Find below a brief description of the modes:
Automatic (recommended):
Power Reducer activates after passing the “Set Point” value
Off:
The immersion connected to the Power Reducer is turned off.
Boost:
The load connected to Power Reducer is forced to operate according to the parameters set (% of power and
duration) without considering the actual energy generated from the PV system and the energy exchanged
with the GRID.
Pag 15
Set the value of the “load” con-
nected to the Power Reducer.
Set the “Set Point”
Press the “Ok” button and
then the house-shaped button
left to return to the main page
of the app (System Activity)
Now the App home page “En-
ergy Performance” shows the
Power Reducer widget.
Click the button to open
the context menu.
Select among the 3 available
modes the option that ts bet-
ter the end-user needs.
now the widget displays the
power that is diverted to the
Power Reducer.
When the “Boost” mode is
selected in the previous step,
then a new screen appears on
the display (Boost Setting).
“Power” allows to set the pow-
er to direct towards the resis-
tive load, expressed as a per-
centage (0-100%).
Set the duration of “Boost”
mode and click “OK” to con-
tinue.
There are some differences in
what is shown by the widget
according to the mode selected:
1. Value that shows the energy diverted to the Power Reducer
2. The colour of the bar is now yellow (Boost Mode) instead
of blu (Automatic Mode)
3. Progress indicator based on the parameter “Time”, availa-
ble when the “Time” option selected is “Automatic”
“Boost” mode
5 6
7
E4U

4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
www.4-noks.com [email protected]
Advanced settings (Power Reducer E4U ONLY)10
On the “Power Reducer Settings” page, it is possible to set the “Load” and “Set Point” values. It is also possible to tick the
option “Advanced settings”, enabling the access to the following regulations:
Integration time:
Integration time of the regulation algorithm
Proportional constant:
Proportional parameter of the regulation algorithm
Integral constant:
Integral parameter of the regulation algorithm
Derivative constant:
Derivative parameter of the regulation algorithm
Pag 16
Control Parameters (Power Reducer E4U ONLY)9
Accessing the Power Reducer Menu settings, from Eios4you App it is possible to set the following Control Parameters:
Immersion:
Load power controlled through the Power Reducer
Valid values: 0 - 3000 W. Default value: 1000 W
Set point:
Level of energy exchanged with the GRID acting on the controlled device
Valid values: - 30000 up to + 30000 W. Default value: 0 W
0 W: setting this value, the system tries to use only the energy generated from the PV system by varying the
power supplied to the immersion. This is the solution where self consumption is optimized.
E.g.: Set Point = 0 The system amends the power aiming at “0” exchanged energy
- xxxx W: setting a negative value, the system is forced to consume more energy than the amount of energy
generated. In this way, the lack of energy is compensated by energy purchased from the GRID and the im-
mersion operates at higher regimes.
E.g.: Set Point = - 200 The system adjusts the immersion power so that the system purchases 200 W
+ xxxx W: setting a positive value, the system reduces the energy consumed, so that is lower than the energy
generated. The excess energy is sold to the GRID and the immersion operates at lower regimes.
E.g.: Set Point = 100 The system adjusts the immersion power so that the system sells 100 W
!WARNING: Advanced parameters must be accessed for extra-ordinary and specic debugging operations ONLY.
The nal user MUST NOT alterate these parameters for any reasons, since they control the algorithm operations
and can cause system crashes.
E4U
E4U

GREEN LED is steady ON
GREEN LED is steady ON
GREEN LED ashing:
> frequency > energy read by CT
YELLOW LED ashing:
> frequency > energy to immersion
YELLOW LED is OFF
RED LED is OFF
RED LED is OFF
YELLOW LED is OFF
RED LED blinks quickly 3 times
alongside 3 quick beeps
4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
LED and push-button11
Power Reducer features 3 LEDs that provide status and mode of operation, plus a multi-function button.
Green
Yellow
Red
Push-button
LED behaviour Power Reducer behaviour
Push-button
GREEN light -steady ON Power Reducer is supplied properly
YELLOW light - blinking
Frequency of blinking depends on the amount of energy diverted.
- LED off: divertion 0% (Power Reducer NOT operating)
- LED steady on: divertion 100% (Power Reducer is supplying the immersion with
FULL power)
When on, the BOOST mode is active. BOOST option allows the immersion to receive
FULL power for 60 minutes, regardless of the energy generated by the photovoltaic
system
When pushed, the button manually enable / disable the BOOST mode
RED light - steady ON
Power Reducer is working properly, and
the resistive load is supplied with any
surplus energy
Installation successfully completed
Power Reducer is working in “0-10V
mode”: the device does not detect any
voltage variation out of the CT
Possible causes: CT wires not con-
nected; OR no electricity detected out
of the CT.
Check the correct installation / wiring of
the CT.
ERROR !
Verify the correct installation of the Power
Reducer, checking:
- CT orientation,
- which cable is clamped by the CT,
- the sequence of colours / wires,
- the connections between terminals
TA+ and TA- on the Power Reducer side
LED behaviour Power Reducer behaviour Suggestions
Switching from SA version to E4U version (available if rmware is 1.2.2 or bigger)12
Providing that the installer has available the related material to complete the kit, it is possible to switch from version
Stand Alone (SA) to version Elios4you (E4U or 0-10V) and vice-versa. Follow the procedure:
1) turn off the Power Reducer and wait for 5 seconds;
2) press the push-button and switch on the Power Reducer. Keep the button pressed until you can hear the device
beeping (aprox 5 seconds).
TAKE NOTE THAT: 1 beep = from SA version to E4U version
2 beeps = from E4U version to SA version
Stand Alone (SA) version
Elios4you (E4U or 0-10V) version
SA
E4U
Push-button When pushed, the button manually en-
able / disable the BOOST mode

Disposal15
Packaging
The packaging delivered alongside the Power Reducer can be reused as long as it is kept in good conditions. As waste, the packaging is to be treated
as “urban waste”. Do not abandon the packaging but dispose it properly according to the national law.
INFORMATION
according to the Waste Electrical and Electronic Equipment Directive (WEEE Directive - European Community directive 2002/96/EC)
• The symbol adopted by the European Council, reported on the appliance, indicates that the item has been release on the market and
that it (Power Reducer and all its components) should not be dumped with normal household waste, but sorted and disposed of in appro-
priate authorised disposal facilities, such as those found at municipal waste sites.
• Get in touch with manufacturer / seller / supplier or other organizations registered with the National Register to know more about Local Authorised
Disposal Facilities. Waste originated from domestic use (or similar origin) can de disposed in regular domestic separate waste collection areas.
• Users of electrical and electronic equipment from private households have the possibility of returning WEEE free of charge to the supplier / retailer
when buying new devices with similar features than the older ones. Suppliers and retailers will then get in touch with the subject in charge for the
appliance withdrawal / disposal.
• A proper waste disposal allows the reuse, recycling and other forms of recovery of such wastes so as to reduce the disposal of waste (lower volume
of waste sent to incinerators or land-lls brings to natural resources will thus be conserved). It also allows to reduce the potential negative effect on
the environment and on the human health caused by the improper waste treatment.
•Unauthorised and illegal disposal carried by user brings to national penalities according to Directives 91/1567/CE and 91/689/CE.
CE Norms14
According to the European norms 2004/108/CE - Electro Magnetic Compliance e 2006/95/CE - Low Voltage Directive, 4-noks s.r.l. declares that the
device named Power Reducer is in compliance with the following norms:
EN 55014-1: Electromagnetic compatibility - Requirements for households appliances, eclectric tools and similar apparatus - Part 1: Emissions
EN 55014-2: Electromagnetic compatibility - Requirements for households appliances, eclectric tools and similar apparatus - Part 2: Immunity
- Product family standard
EN 61000-3-2: Electromagnetic compatibility - Part 3-2: Limits - Limits for harmonic current emissions (equipment input current <= 16 A per phase
EN 61000-3-3:2008 Electromagnetic compatibility - Part 3-3: Limits - Limitation of voltage changes, voltage uctuations and icker in public
low-voltage supply systems, for equipment with rated current <= 16 A per phase and not subject to conditional connection.
EN 60335-1: Household and similar electrical appliances - Safety - Part 1: General requirements
WARNING! This appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities or by people who do not have
the proper experience or qualication, unless under control or properly taught by a person who is responsible for their own safety.
WARNING! Power Reducer is not a toy. Children must be supervised to make sure they do not play with this device.
Troubleshooting13
PROBLEM DESCRIPTION SOLUTION
The protection of Power Reducer (16 A cir-
cuit breaker or installed between Power Re-
ducer and the power supply) has failed
The protection of immersion (fuse installed
between Power Reducer and immersion)
has burned out.
Do NOT reactivate the protection.
Technical assistance is required. Proper technical assistance can be provided only by qualified
personnel trained to manage possible short circuits on the device power supply elements
Technical assistance is required. Proper technical assistance can be provided only by qualified
personnel trained to change the blown fuse with another one with the same features:
16 A Cat FF
Any other kind of fuse will cause a damage beyond repair to the Power Reducer power control
4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617

Template16
4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
Download the template from www.4-noks.com/ftp and print it in A4 size.

Ver 1.8.1 122013
4-noks srl
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) ITALY
Tel +39 0434 768462 Fax +39 0438 694617
Notes17
Table of contents
Other 4-noks Home Automation manuals
