Aztech Kyla User manual

User Guide

Smart IP Camera Smart Zigbee
Hub
Smart Door/
Window Sensor
Smart Motion
Sensor
Thanks for using Aztech Kyla product
If you need support or help, please visit www.kyla.aztech.com
Smart Starter Bundle
01

02
Scan and download the APP
Aztech Kyla App
Motion Sensor Base x1
Motion Sensor Holder x1
Micro USB Power cord x2
Power Adapter (5V/1A) x2
CR2032 Battery x2
User Guide x1
Network Cable x1
Steel Plate x1
AA Battery x2
Screwx4
Packing List - Accessories
Note: Please confirm that your router is connected to the internet and the
WiFi frequency is 2.4GHz before using this product kit.
Initial Setup
How to download the Aztech Kyla App.
Download the free Aztech Kyla App from the App Store / Google Play to get
the app on your smartphone or tablet.

Notes
a) Use the security kit properly under the requested working condition
b) Please make sure the Smart Zigbee Hub’s power is off during the installation
c) For indoor use only. Keep away from moisture and water
d) Keep the product from devices with strong interference signal such as
microwave oven and TV sets
a
Adaptor DC 5V/1A
b
LAN Port
c
Reset Button
03
STA Indicator Light
Zigbee Indicator
Light Reset Button
1. Smart Zigbee Hub
The Smart Zigbee Hub is the centre of
your smart home. Connect wirelessly
with hundreds of compatible smart
devices, allowing you to monitor, control
and secure your home from anywhere.
STA Indicator Light ON: Working
STA Indicator Light blink: Data transmission
STA Indicator Light Flashing: The device is ready to be searched by
Aztech Kyla App
Launch the Aztech Kyla App
a) Plug the Smart Zigbee Hub to power outlet
b) Connect the Smart Zigbee Hub to the router’s LAN port with attached
network cable
c) Press and hold the reset button for 5s until the Smart Zigbee Hub is
ready to be searched by Aztech Kyla App
d) Login to Aztech Kyla App, then add “Smart Zigbee Hub” to device list to
enable the Smart Zigbee Hub
e) Follow the Aztech Kyla App instruction to complete the setup

04
Setup
a) Open the bottom cover and insert the attached AA battery to enable
the Smart Motion Sensor
b) Fix the motion sensor bracket on the wall. The recommended
installation height is approximately 7 feet (2 meters)
c) Align the groove at the back of the Smart Motion Sensor with the
bracket, adjust the sensor bracket angle manually to achieve the optimal
detection range
Launch the Aztech Kyla App
a) Plug the Smart Motion Sensor into a power outlet. Press and hold the
reset button until the green light is OFF, then short-press the reset button
to make the green light slowly blink. The Motion sensor is connected to
network and ready to set up
b) Login to Aztech Kyla App, add “Smart Motion Sensor” to device list to
enable the motion sensor
c) Follow the Aztech Kyla App instruction to complete the setup.
d) How to disconnect the Motion sensor: The motion sensor will disconnect
from the internet by pressing and holding the reset button until the green
light is off
Notes
a) Make sure to finish the Smart Zigbee Hub setup first before proceeding
with the Smart Motion Sensor setup above
b) Smart Motion Sensor works best when the intruder walks directly toward the sensor
c) To avoid false alarms:
Don't mount the Smart Motion Sensor in direct sunlight/ air condition/
heater/refrigerator (as moving heat sources would trigger the sensor) or
in a place affected by wind. When installing outside, mounting it in a
shady, protected place with minimal changing temperatures is most ideal.
Avoid vibration or mounting on metal doorframe surfaces which may
reduce the transmission range
Wall
Steel Plate
Steel Plate
Smooth and Flat Wall
2. Smart IP Camera
The Smart IP Camera is a High-Definition camera with 2-way audio and
night-vision function, allowing you to see what's happening in your home
wirelessly on your smartphone or tablet - anytime, anywhere.
Setup
a) Mount your camera (optional), fix the plate on a clear and flat wall
with 3M tape or attached screws
b) Attach screws to wall and hang plate onto screws, then adjust the angle
manually
LED Status
indicator lamp
Microphone
Lens
Support available
for 360°rotation
Magnetic
Base
Storage Card
Power
Supply Port
Reset Settings
Red Indicator Light ON：Power On
Red Indicator Light Flashing：Airlink Configuration Status
Blue Indicator Light Flashing：Network Connecting
Red Indicator Light ON：Network is successfully connected
Red and Blue Indicator Light Flashing: System upgrading, do not power off

05
LED Indicator Light
Reset Button Battery Position
MagnetTransmitter
Base
Setup
a) Open the transmitter base and put in the attached button cell and enable
the transmitter
b) Stick the transmitter on a doorframe, window frame, or the fixed part of a
cabinet or drawer, and place the magnet part next to it on the door, window,
or part that opens. The Door/Window sensor works best if the installation
distance is less 1cm .
Launch the Aztech Kyla App
a) Plug the Smart IP Camera into a power outlet
b) Press and hold the Reset button 8 sec to reset to factory default setting
c) Login to Aztech Kyla App, add “Smart IP Camera” to device list to enable
the Smart IP Camera
d) Follow the Aztech Kyla App instruction to complete the setup
Notes
a) Restore to factory default setting when switching the Smart IP Camera to
a new WiFi network
b) A router with strong WiFi signal is necessary
c) Turn off the camera before inserting or removing the SD card
3. Smart Door/Window Sensor
The Smart Door/Window Sensor can be installed on a door, window and
any other open/close object. Working with Smart Zigbee Hub and Aztech
Kyla App, it provides your home a security defense and creates scene with
other devices.
LED Slowly Blinks Once per Second: Attempting to connect the Internet
LED Blinks Once: Detection and alarm
LED Blinks Once per 3 Seconds: Battery low-voltage need replace the
battery as soon as possible

06
LED Indicator
Light
Sensing Window
Reset Button
LED Slowly Blinks Once per Second: The device is searching for network
LED Blinks Once: Detection and alarm
LED Blinks Once per 3Ssec: Battery low-voltage alert need replace the
battery as soon as possible
Launch the Aztech Kyla App
a) Press and hold the reset button until the green light is off, then
short-press the reset button to make the green light slowly blink. The
Smart Door/Window Sensor is connected to network and ready to set up
b) Login to Aztech Kyla App, add “Smart Door/Window Sensor” to device
list to enable the Smart Door/Window Sensor
c) Follow the Aztech Kyla App instruction to complete the setup
d) How to disconnect the Door/Window sensor: The Smart Door/Window
Sensor will disconnect from the internet by pressing and holding the reset
button until the green light is off
Notes
a) Make sure to finish the Smart Zigbee Hub setup first before proceeding
with the Smart Motion Sensor setup above
b) The Smart Door/Window sensor works best if the installation distance is
less than 1cm
c) When the Smart Door/Window Sensor is mounted on a metal door &
window frame, make sure to put a non-metal object between the sensor
and the frame to avoid shielding the signal
d) Mount the Smart Door/Window Sensor on a doorframe, window frame, or
the fixed part of a cabinet or drawer
4. Smart Motion Sensor
The Smart Motion Sensor is based on the human body’s infrared spectrum
detection technology. It can detect heat and movement in the surrounding
areas, creating a protective "grid". If a moving object blocks too many grid
zones and the infrared energy levels change rapidly, the sensor is triggered.
Pair with the Smart Zigbee
Hub and Aztech Kyla App
for an easy home security
defense system.

07
110°
2m 4m 6m 10m0m
2m
Detection range schematic diagram
Setup
a) Open the bottom cover and insert the attached AA battery to enable
the Smart Motion Sensor
b) Fix the motion sensor bracket on the wall. The recommended
installation height is approximately 7 feet (2 meters)
c) Align the groove at the back of the Smart Motion Sensor with the
bracket, adjust the sensor bracket angle manually to achieve the optimal
detection range
Launch the Aztech Kyla App
a) Plug the Smart Motion Sensor into a power outlet. Press and hold the
reset button until the green light is OFF, then short-press the reset button
to make the green light slowly blink. The Motion sensor is connected to
network and ready to set up
b) Login to Aztech Kyla App, add “Smart Motion Sensor” to device list to
enable the motion sensor
c) Follow the Aztech Kyla App instruction to complete the setup.
d) How to disconnect the Motion sensor: The motion sensor will disconnect
from the internet by pressing and holding the reset button until the green
light is off
Notes
a) Make sure to finish the Smart Zigbee Hub setup first before proceeding
with the Smart Motion Sensor setup above
b) Smart Motion Sensor works best when the intruder walks directly toward the sensor
c) To avoid false alarms:
Don't mount the Smart Motion Sensor in direct sunlight/ air condition/
heater/refrigerator (as moving heat sources would trigger the sensor) or
in a place affected by wind. When installing outside, mounting it in a
shady, protected place with minimal changing temperatures is most ideal.
Avoid vibration or mounting on metal doorframe surfaces which may
reduce the transmission range

08
Technical Features
1. Smart Zigbee Hub
Power: DC 5V/1A Working Humidity: 10% ~ 90%RH
Working Temperature: 0 ~ 40°C Size: 88x90x27mm
2. Smart Door/Window Sensor
Power: CR2032 Battery Working Humidity: 10% ~ 90%RH
Wireless Standard: IEEE 802.15.4 Transmitter Size: 61.5×30.3×11.7mm
Communication Distance: 80m Magnet Size: 44.8×10.9×7.9mm
Working Temperature: -10~50°C
3. Smart Motion Sensor
Power: AA Battery x 2 Working Temperature: -10 ~ 50°C
Wireless Standard: IEEE 802.15.4 Working Humidity: 10% ~ 90%RH
Detection Range: Horizontal 110˚ Size: φ52.6×63.6mm
Communication Distance: 80m
4. Smart IP Camera
Power: 5V/1A Night-vision Distance: 6m
Wireless Standard: IEEE 802.11b/g/h Size: 68x68x125mm
Definition: 1280x720 Working Temperature: -20° ~ 50°C
Create Your Own Smart Home Defense System
1. Turn on light at night (Note: Needs to use the Smart Switch)
Install the motion sensor in the bedside corridor and setup the passing area as
trigger area
In the Aztech Kyla App, Select “Edit scene”and create the motion sensor linkage
trigger the smart switch
When someone walks through the trigger, area the light will be turn on automatically
2. Security defense triggering reminder
Install the door/window sensor or motion sensor in the mornitoring area
Install the camera in the area to be monitored and adjust it to the optimal
range to cover the area
Login to Aztech Kyla App, select the alarming mode. In case of unexpected
door/window opening/abnormal sound/movement is detected in the
monitoring area, the alarm will be triggered
Receive alerts, trigger actions, and communicate with your home no matter
where you are via the Aztech Kyla App

09
After-sales services
1. Warranty Statement
We appreciate your patronage of AZTECH KYLA products. Please read and
review this agreement before using this product. If you do not agree with
or wish to accept the terms of this agreement then please do not use the
product. By using this product, you agree to be bounded by this agreement
and represent that you satisfy all of the eligibility requirements below.
Always follow the instructions in the manual, especially concerning
devices that need to be assembled. This warranty card is the only voucher
for the company product warranty. Only this warranty card and related
sales invoice are valid to obtain free warranty.
2. Warranty Range And Duration
One year warranty applies to most AZTECH KYLA products unless otherwise
specified at the time of purchase. Accessories included with the main
device and batteries have a warranty of six months. When buying used
AZTECH KYLA products, the product warranty remains measured from the
time it was bought by the original owner. Any other promises made by
dealers beyond the guarantee of AZTECH KYLA, AZTECH KYLA will not
assume any liability. The following cases will not be covered by free repair
and will be subjected to paid services: failure to provide warranty card and
related sales invoices, cleaning of product and wear loss under normal
circumstances (such as natural loss of casing, inserting components, aging
and wear), any product failure or damage caused by installation, usage
maintenance, and storage that are not in accordance with usage
instructions, altered or torn up barcode on products or warranty card
without authorization, products beyond change or warranty period,
product serial number or type on warranty card not matching the product
itself, changing inherent structure circuit privately, or dismantling or
modifying without authorization from AZTECH KYLA.

31 Ubi Road 1, #01-05, Singapore 408694
www.aztech.com 丨[email protected]
Contact Us
Aztech Technologies Pte Ltd.
10

©2018 Aztech Technologies Pte Ltd. All rights reserved.
