4xem 4X-FD7131 User manual
Indoor Day/Night
Fixed Dome PoE
IP Network Camera
4X-FD7131
Need more information?
Visit www.4XEM.com or call 1-866-999-4XEM
3-axis Mechanical Design allows lens adjustment for wall or•
ceiling installation
Wide Angle 2-4mm Variable focus Lens•
Multi-window Motion Detection•
Built-in PIR Sensor for Thermal Detection•
Built-in White-light Illuminators•
Real-time MPEG-4 and MJPEG Compression (Dual Codec)•
Supports Simultaneous Dual Streams•
Up to 30fps in VGA Resolution – 640x480•
3GPP Mobile Surveillance Support•
Built-in 802.3af Compliant PoE (Power over Ethernet)•
Includes 32 camera Monitoring & Recording Software•
Features:
Supports
3GPP
FREE
32 Camera
Monitoring & Recording
Software
The 4XEM 4X-FD7131 features a 2-4mm variable focus lens oering a wide
viewing area, and includes PoE for easy installation utilizing a single Ethernet cable.
The sophisticated 3-axis design oers the exibility of mounting the camera on
wall or ceiling locations as the lens is easily adjusted for any desired view. This high
performance camera delivers superb image quality and is perfect for any indoor
surveillance requiring low light and a discrete prole. Two-way audio capabili-
ties allow real time audio and video recording as well as real time two-way
communication.
The 4X-FD7131 is equipped with a PIR (Passive Infrared) sensor, which
detects motion causing temperature changes in the infrared range emitted
by surrounding objects.This means the built-in motion detection will alert
you to what you want, thereby avoiding false alarms.The built-in white-light
illuminators can be automatically or manually activated for monitoring or
recording in complete darkness. Dual streaming of MPEG-4 and MJPEG are
simultaneously delivered oering dierent resolutions to two dierent devices.
Users can therefore view and record on a PC at 30 fps inVGA resolution as well
as remotely view through a 3GPP device such as a PDA or cell phone at another
resolution at the same time.
The support for 3GPP mobile surveillance allows you to view live video from your
Internet capable PDA or cellular equipped with a 3GPP player. Video surveillance
on the go! Built-in 802.3af compliant PoE makes the 4X-FD7131 a powerful, cost-
eective IP surveillance system solution for various indoor applications.
Built-in
PoE
DAY
NIGHT
Camera Specications
Image Sensor MICRON 1/4”CMOS sensor
withVGA resolution
LensType Vari-focal board lens,
f=2mm~4mm, F1.4~1.8,
focus range: 50cm to innity
Electronic Shutter Speed 1/5 sec. to 1/15000 sec.
Auto Electronic Shutter Supported
Auto Gain Control Supported
AutoWhite Balancing Supported
Dimensions 143mm (D) x 106mm (H)
Weight Net: 575.5g
System
CPU VVTK-1000 SoC
RAM 64MB SDRAM
ROM 8MB Flash ROM
Embedded OS: Linux 2.4
System Requirements
Operating System MicrosoftWindows 2000/XP
Browser Internet Explorer 6.x or above
Cellphone 3GPP player
Real Player 10.5 or above
QuickTime 6.5 or above
PacketVideo Player 3.0 or above
Networking
Protocol TCP/IP, HTTP, UPnP, RTSP/RTP/
RTCP, IGMP, SMTP, FTP,Telnet,
DHCP, NTP, DNS, DDNS, PPPoE
10/100 Mbps Ethernet, RJ-45
Security Triple-level user access with
password protection
IP address ltering
Video Specications
Frames/Second 640x480 up to 30fps
Streaming Simultaneous dual-stream
MPEG-4 streaming over UDP,TCP, or
HTTP MPEG-4 multicast streaming
MJPEG streaming over HTTP
Features Adjustable image size, quality and
bit rate
Supports 3GPP mobile surveillance
Time stamp and text overlay
Flip & mirror
Congurable brightness, contrast,
saturation, sharpness, and white
balance
Up to 3 congurable motion
detection windows
3-axis mechanism for exible ceiling
and wall mount installation
Alarm & Event Management
Triple-window video motion detection
One D/I and one D/O for external sensor and alarm
Passive infrared sensor (PIR) for human detection
White-light illuminators for low light condition when
event triggered
Event notication using HTTP, SMTP, or FTP
Miscellaneous
Audio
Compression: GSM-AMR speech encoding, bit rate:
4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate:
16 kbps to 128 kbps
Interface: Built-in microphone
External microphone input Audio
output
Supports audio mute
LED Indicators: System power and status indicator
System activity and network link
indicator
Power
Output 12V DC
Consumption: Max 3.6W
802.3af compliant Power over Ethernet
EMI & Safety
Certication CE, FCC,VCCI, C-Tick
Operating Environment
OperatingTemp. 0~55˚C (32~131˚F)
Operating Humidity 20% - 80% RH
Indoor Fixed Dome PoE
IP Network Camera
Need more information? Visit www.4XEM.com or call 1-866-999-4XEM
4X-FD7131
Bundled Software
IPNV32 Security & Remote Monitoring Software:
Remote conguration and control of up to 32 devices
Fast/slow forward, replay, and pause
Scheduled backup
Event-triggered, scheduled, and manual recording
Instant search with preview windows
Hard disk quota warning
AVI format export
