5Core Pro Series User manual

O P E R A T I O N A L M A N U A L
®
• Thank you for purchasing 5CORE PA Column.
• Please read this manual thoroughly before making connection and turning on the power. Following
the instructions in this manual will enable you to obtain optimum performance from your new 5CORE
PA Column.
• Please retain this manual for future reference.
MADE IN INDIA
Specifications
Input Power
Configuration
Frequency Response
Low Frequency Speaker
Dynamic Horn
Max Rated SPL
Input Connector
Dimension
Weight
300W RMS
Two Way
35-18,000Hz
2X12” LF Speaker
7”x3” with Piezo Tweeter
130dB
Speakon
L397 X H876 X D400 (mm)
29.0Kgs
Page 1Page 4
5C-WC-12x2
E 300DX
Comprises of dual 12”
high performance LF and
for best HF response
one titanium diaphragm
compressor driver
www.5core.com
Thanks for using columns.
For any assistance/suggestion
visit us at www.5core.com
Est. Est.
1984 1984
ISO 9001:2015
M5400913IN
CERTIFICATE NO.: 16RQ07AY

BACK PANEL CONTROLS & FEATURES
Guideline to Operate the Column
Safety Instructions
Page 3Page 2
K
C
O
L
IN/OUT
±1 LF
Impedance : 4W
±2 HF
Impedance : 8W
BI-AMP
K
C
O
L
IN/OUT
±1 Full Range
Impedance : 4W
±2 NC
PASSIVE
MADE IN INDIA
www.5core.com
5C-WC-12x2
E 300DX
• Place the Column in dry and well ventilated place. Considerable heat is generated
inside the Column during continuous use, therefore do not block the top cover
ventilation holes by placing anything on top of the Column.
• Connect column with amplier near about 300W for proper audio output.
• WATER AND MOISTURE: In order to prevent any re or shock hazard, do not
expose this equipment to rain or moisture.
• VENTILATION: The Column should be situated so that its location or position
does not interfere with its proper ventilation, Also do not insert or drop anything
into the ventilation holes.
• PREVENTION OF LOSS IN SPEAKER CABLES: Always use thick cables for low
impedance speakers connections, Use of cable type 23/38 or thicker is
recommended as heavy current ow through the cables.
• EQUIPMENT TO BE USED: Please use a amplier of near about 300W for proper
output.
ISO 9001:2015
M5400913IN
CERTIFICATE NO.: 16RQ07AY
Speakers and Compressor Drivers used in Column
Frame: MS, 12”
Cone: Paper body with cotton edge
Impedance: 8W
Power Output: 150W R.M.S.
Magnet: 135X57X20 (mm)
Voice Coil: 1.5” Voice coil with Aluminium heat sink
FR 12135 DC
Diaphragm: 1.35" with aluminum heat sink
Material: Titanium Diaphragm
Hise 7x3
with Piezo Tweeter
