JVC NX-PN7 User manual

JVC
COMPACT COMPONENT SYSTEM
NX-PN7
o Madefor
~ iPod
OWorks with
iPhone
INSTRUCTIONS
For customer use:
Enter below the Model No. and
Serial No. which are located
eitheron the rear, bottom or side
of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1864-001 A
[J]

Warnings, Cautions and Others
Mises en garde, precautions et indications diverses
CAUTION
The 0 II button in any position does not
disconnect the mains line.
Disconnect the mains plug to shut the power off
completely (the STANDBY lamp goes off).
The MAINS plug or an appliance coupler is used
as the disconnect device, the disconnect device
shall remain readily operable.
•When the system
is on standby, the STANDBY
lamp lights red.
•When the system is turned on, the STANDBY
lamp goes off.
The power can be remote controlled.
ATTENTION
La touche 0/1, dans n'importe quelle position, ne
deconnecte pas
Ie systeme du secteur.
Deconnectez la fiche de secteur pour mettre
I'appareil completement hors tension
(Ie temoin
STANDBY s'eteint).
La fiche secteurou un coupleur est utilise comme
dispositif de deconnexion de I'appareil, et
I'appareil deconnecte doit etre pret aetre utilise.
•Quand
Ie systeme est en attente, Ie temoin
STANDBY est allume en rouge.
•Quand
Ie systeme est sous tension, Ie temoin
STANDBY s'eteint.
L'alimentation peut etre telecommandee.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or
moisture.
ATTENTION
Afin d'eviter tout risque d'electrocution,
d'incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne
pas ouvrir
Ie coffret de I'appareil.
2. Ne pas exposer I'appareil a la pluie ni a
I'humidite.
Le point d'exclamation aI'interieur
d'un triangle equilateral est destine a
alerter I'utilisateur sur la presence
d'operations d'entretien importantes
au sujet desquelles des
renseignements se trouvent dans
Ie
manuel d'instructions.
Le symbole de I'eclairaI'interieurd'un
triangle equilateral est destine a
alerter I'utilisateur sur la presence
d'une "tension dangereuse" non
isolee dans
Ie boWer du produit. Cette
tension est suffisante pour provoquer
I'electrocution de personnes.
~ !~E D'ELECTRO~lu\! t
~ IRISQ
NE
PAS OUVRld
TION
! ~
The exclamation point within an
equilateral triangle
is intended to alert
the user to the presence of important
operating and maintenance
(servicing) instructions
in the literature
accompanying the appliance.
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated "dangerous
voltage" within the product's
enclosure that may
be of sufficient
magnitude to constitute arisk of
electric shock to persons,
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
ATTENTION: POUR EVITER TOUT RISQUE D'ELECTROCUTION,
NE PAS OUVRIR LE BoiTIER.
AUCUNE PIECE INTERIEURE N'EST AREGLER
PAR L'UTILISATEUR.
SE REFERER A UN AGENT QUALIFIE EN CAS DE PROBLEME.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
G-1

Note to CATV system installer:
This reminder is provided to call the CATV
system installer's attention to Section 820-40 of
the NEC which provides guidelines for proper
grounding and, in particular, specifies that the
cable ground shall be connected to the
grounding system of the building, as close to
the point of cable entry as practical.
For U.S.A.
This equipment has been tested and found to
comply with the limits for aClass Bdigital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in aresidential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur
in a
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try tocorrect the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radiofTV
technician for help.
CAUTION
Changes or modifications notapproved by JVC
could void the user's authority to operate the
equipment.
CAUTION:
Excessive sound pressure from earphones or
headphones can cause hearing loss.
ATTENTION:
Une pression acoustique excessive des
ecouteurs ou du casque d'ecoute peut
entrainer une perte auditive.
For Canada/pour Ie Canada
THIS DIGITAL APPARATUS DOES NOT
EXCEED THE CLASS BLIMITS FOR RADIO
NOISE EMISSIONS FROM DIGITAL
APPARATUS AS SET OUT
IN THE
INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED
"DIGITAL APPARATUS," ICES-003
OF THE
DEPARTMENT
OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE
LES L1MITES DE BRUITS
RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMIRIQUES DE CLASSE B
PRESCRITES DANS LA NORME SUR LE
MATERIEL BROUILLEUR; "APPAREILS
NUMERIQUES", NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
CAUTION
•Do not block the ventilation openings or
holes.
(If the ventilation openings or holes are
blocked by anewspaper or cloth, etc., the
heat may not be able to get out.)
•Do not place any naked flame sources, such
as lighted candles, on the apparatus.
•When discarding batteries, environmental
problems must be considered and local rules
or laws governing the disposal of these
batteries must be followed strictly.
•Do not expose this apparatus to rain,
moisture, dripping or splashing and that no
objects filled with liquids, such as vases, shall
be placed on the apparatus.
ATTENTION
•Ne bloquez pas les orifices ou les trous de
ventilation.
(Si les orifices ou les trous de ventilation sont
bloques par un journal
un tissu, etc., la
chaleur peut ne pas etre evacuee
correctement de I'appareil.)
•Ne placez aucune source de flamme nue,
telle qu'une bougie, sur I'appareil.
•Lors de la mise au rebut des piles, veuillez
prendre en consideration les problemes de
I'environnement et suivre strictement les
regles et les lois locales sur la mise au rebut
des piles.
•N'exposez pas cet appareil ala pluie, a
I'humidite, a un egouttement ou ades
eclaboussures et ne placez pas des objets
remplis de liquide, tels qu'un vase, sur
I'appareil.
6-2

Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. SidesfTop/Back: No obstructions should be placed in the areas shown by the dimensions below.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a
stand with aheight of 10 cm (3-15/16") or more.
Attention: Aeration correcte
Pour prevenirtout risque de decharge electrique ou d'incendie et evitertoute deterioration, installez
I'appareil de la maniere suivante:
1. Avant: Bien degage de tout objet.
2. Cotes/dessus/dessous: Assurez-vous que rien ne bloque les espaces indiques sur Ie schema ci-
dessous.
3. Dessous: Posez I'appareil sur une surface plane et horizontale. Veillez ace que sa ventilation
correcte puisse se faire en
Ie playant sur un support d'au moins dix centimetres de hauteur.
1
15 cm
(5-15/16")
Side
Cote
,+10 cm
+(3-15/16")
u
u
u
u
• • Q
15 cm
(5-15/16")
Front
Face
15 cm 15 cm
(5-15/16")1~5~~~~;?J(5-15/16")
~ .10 cm
t(3-15/16")
-[European Union only]
[Union europeenne seulement]
6·3

Introduction 2
Precautions 2
Getting Started 3
Connections 4
Canceling the Display Demonstration 5
Basic Operations 6
Main Unit 6
Remote Control 8
Playing Back from iPod 11
Connecting iPod Devices 12
Operations 13
Listening to FMlAlVI Broadcasts 15
Playing Back from Other Equipment 17
Connecting Other Equipment.. 17
Operations 17
Setting the Clock and Timer 18
Setting the Clock 18
Setting the Timer.. 19
Troubleshooting 21
Specifications
2,2
1

Thank you for purchasing a lVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and
to obtain the best possible performance from the unit.
Precautions
o Installation
•Install in aplace which is level, dry and neither too hot nor too cold-between 5°C and 35°C (41°F
and 95°F).
•Install the unit in alocation with adequate ventilation to prevent internal heat buildup inside the
unit.
DO NOT install the unit in alocation near heat sources, or
in aplace subject to direct
sunlight, excessive dust or vibration.
•Leave sufficient distance between the unit and the TV.
•Keep the unit away from the TV to avoid interference with TV.
o Power Sources
•When unplugging the unit from the wall outlet, always pull on the plug, not the AC power cord.
... : 1,:;.....
DO NOT handle the AC power cord with wet hands.
~
o Internal Heat
For safety, observe the following carefully:
•Make sure there
is good ventilation around the unit. Poor ventilation could overheat
and damage the unit.
•DO NOT block the ventilation openings or holes.
If they are blocked by anewspaper
or cloth, etc., the heat may not be able to get out.
o Others
•Should any metallic object or liquid fall into the unit, unplug the AC powercord and consult your
dealer before operating any further.
~{ DO NOT disassemble the unit since there are no user serviceable parts inside.
•
If you are not going to operate the unit for an extended period of time, unplug the AC power cord
from the wall outlet.
If anything goes wrong, unplug the AC power cord and consult your dealer.
2

t~~ting'Sla rled
In this manual, operations using the remote
control are mainly explained; however, you
can use the buttons and controls on the unit if
they have the same (or similar) name and
Imarks.·
o Supplied Accessories
After unpacking, check to be sure that you have
all the following items. The number
in
parentheses indicates the quantity of each piece
supplied.
•Remote control
(l)
•Lithium coin battery CR2025 (1) (The battery
has been installed when shipped from the
factory.)
•FM antenna (1)
•AM loop antenna (1)
If anything is missing, consult your dealer
immediately.
o Prepare the Remote Control
When you use the remote control for the first
time, pull out the insulation sheet.
Front side
8B1
Ou .. ~
QJJt
Insulation sheet
Replacing the battery in the remote control
Insert the battery into the remote control by
matching the polarity (+ and -) correctly.
• If the range or effectiveness of the remote
control decreases, replace the battery.
Rear side
CAUTION:
Battery shall not be exposed to excessive heat
such
as sunshine, fire or the like.
WARNINGS:
•Store the battery in aplace where children
cannot reach.
If achild accidentally swallows
the battery, consult adoctor immediately.
•Do not recharge, short, disassemble or heat
the battery or dispose
of it in afire. Doing any
of these things may cause the battery to give
off heat, crack,
or start afire.
•Do not leave the battery with other metallic
materials. Doing this may cause the battery to
give offheat, crack,
or start afire.
•When throwing away or saving the battery,
wrap it in tape and insulate; otherwise, the
battery may start to give off heat, crack, or
start afire.
•Do not poke the battery with tweezers or
similar tools. Doing this may cause the battery
to give off heat, crack, or start afire.
•Dispose
of battery in the proper manner,
according to federal, state, and local
regulations.
CAUTION:
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent
type.
For USA-California only
This product contains a CR Coin Cell Lithium
Battery which contains Perchlorate
Material-
special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/
perchlorate
Lithium coin battery
(product number:
CR2025)
3

Connections
Do not connect the AC power cord until all other connections have been made.
o Connecting the Antennas
NTENN
FM antenna (supplied):
Extend it so that you can obtain
the best reception.
To connect the AM loop antenna
FM 750
COAXIAL
E)
Left side
For better FM reception
Disconnect the supplied FM antenna, and
connect to an outdoor
FM antenna using a 75 Q
wire with coaxial type connector.
AM loop antenna (supplied):
Turn it until the best reception is obtained.
NOTES:
•Make sure the FM antenna does not touch any other terminals, connecting cords or the AC power
cord. Also, keep the antenna away from metallic parts of the unit, connecting cords, and the AC
power cord. This could cause poor reception.
•Keep the
AM loop antenna cable wrapped around the AM loop antenna frame, otherwise the
effectiveness and sensitivity
of the AM loop antenna may be reduced.
4

J
L_
- -
o Connecting the Video Cord to View a Video/Picture from iPod
When viewing avideo/picture from your iPod on your TV, use acomposite video cord (not
supplied)
to connect the VIDEO OUT jack on the unit and the composite video input on your TV.
AUDIO IN
©Video cord (not supplied)
~'--cCJ::lm>ol-t~"
Right side
o Connecting the Power Cord
To awall outlet
Plug in the AC power cord
only after all connections are
complete.
Right side
Canceling the Display Demonstration
When you connect the AC power cord for the first time, the display demonstration starts
automatically.
•When you operate the unit, the display demonstration stops temporarily.
If no operation is done
for 2minutes, the unit starts the display demonstration again.
COLOR
o
DEMO
Hold down until "DEMO OFF" appears on the display.
•
To activate again, hold down DEMO until "DEMO ON" appears on the display.
•When the ECO mode is activated (P.9), the display demonstration does not function.
5

Main Unit
Dock A(P.12)
Illumination bars
(P.1 0)
o Operating on the Main Unit
Dock B(P.12)
iPod GJ I-+C .... , _ VOLUME + COMPACT COMPONENT SYSTEM
e C:JC3 (J NXPN'
~~ ~ ~ f---------
Remote control sensor
@Turns
on or off (standby) the power.
OJ
COlOR
Changes the color of the illumination bars. (P.lO)
rn
0•For DEMO button, see page
5.
DEMO
SOUND
Activates Sound Turbo. (P.IO)
rn
TURBO
0
FM/AM~
Changes the source to FM, AM (P.IS), LM
~AM.=J
[±]
AUDIO Ior AUDIO IN (P.I?).
0AUDIO
IN
6

iPod~ iPodla •Changes the source to iPod rJliPod 1]. (P.13)
f5l ~ ~ •Starts playback and pauses for iPod. (P.13)
~ \~/I~) \~/I~)
~ ~
I .... _I
« ))
- VOLUME +
« 0))
•iPod (P.13):
Press: Reverse skip/forward skip
Hold down: Reverse search/forward search
•FM/AM (P.l5): Tunes in to astation.
Adjusts the volume level (VOL
MINNOL Ito VOL 29NOL MAX).
o Display Information
iPod~m
S.TURBO
FMAMTUNED
STMONO
A.STBY
0123 SLEEP
iPod rJ
iPod I]
S.TURBO
FM
AM
TUNED
ST
MONO
A.STBY
e> 1/213
SLEEP
Lights up when an iPod is connected to dock A.
Lights up when an iPod is connected to dock B.
Lights up when Sound Turbo is activated. (P.IO)
Lights up when FM
is selected as the source.
Lights up when AM is selected as the source.
Lights up when astation
of sufficient signal strength is tuned in.
Lights up when FM stereo broadcast is received.
Lights up when FM monaural reception mode is activated.
•Lights up when Auto Standby
is activated. (P.IO)
•Flashes for about 3minutes before Auto Standby turns off the unit. (P.IO)
•Lights up when the Timer is set. (P.20)
• e> 1/2/3 icon flashes while the Timer is working.
Lights up when the Sleep Timer is activated. (P.IO)
7

o Using Headphones
Be sure to tum down the volume before connecting headphones.
•Connecting headphones will deactivate the speakers.
Stereo mini plug
......-rRl--p~~-Es.::.1 b;-----~
II Headphones (not supplied)
Right side
Remote Control
II!,P.10
P.9
P.10
!~~~ II
@Ej"
t I] ffiJ
"-
,
AUDIO IN
@~
83
"III "III
,
------
rI Jl
P.10 II .. AUTtSTBY 1 II
P.18-20 II 1@ e~~EEP. @\.IIIT]
P.13,P.18,P.20 II : cl?y~ r"~11_1IJ_2
film ~ fp~ R II P.14
P.13, P.15, P.16,
P.18 -20
P.14, P.15
LL~
P.14, P.16-20--1 i--=-
P.10--·-
w
e _1
P.10 II
JVC
Operating on the Remote Control
• Basic operations
OJ •Turns on or
off (standby) the power.
8

eChanges the display information.
•For iPod AJiPod B/AUDIO IN:
•ForFM/AM:
r- Frequency ~ Clock ~
IDay of the week.. I
•When the unit is turned off:
Clock ~ Day of the \veek
~
'C/
AUDIO IN
e•Changes the source to iPod
rJ/iPod (]. (P.13)
•Starts playback and pauses for iPod.
(P.l3)
Changes the source to FM, AM (P.15, P.16), or AUDIO IN (P.17).
Adjusts the volume level (VOL
MINNOL Ito VOL 29/VOL MAX).
Drops the volume in amoment.
•To restore the volume, press again, or adjust the volume level.
• To dim the display and the illumination bars-DIMMER
You can change the brightness of the display and illumination bars.
Press repeatedly while the unit is turned on. CDIM 1 - DIM 2
_DIM OFF
@---(CanCeled) ...... ---
DIM 1: Dims the display and the illumination bars.
DIM2: Dims the display much more than "DIM 1" and the illumination bars are turned off.
• To set the ECO mode
Setting the ECO mode allows you to reduce power consumption by turning offthe display while on
standby.
~ Press while the unit is on standby. "ECO ON" appears on the display for awhile.
e ·The clock is not shown on the display when the unit is on standby.
•To cancel this function, press ECO/DIMMER again. "ECO OFF" appears for awhile then the
clock
is shown on the display.
•The battery
of the iPod is not charged in ECO mode.
9

• To change the color of the illumination bars
You can change the color of the illumination bars.
•The color
is memorized for each source.
8
.s, '···'.····· '· .. '.:... Press repeatedly to change t~e color of the illumination bars.
:, COLOR, •You can select one of the nme colors.
:>;;:0,,,, .. :/
•When the source is iPod rJ or iPod [], you can set the color of each illumination bar separately:
the
bar below the source iPod.
• To turn off the unit after a certain period of time-Sleep Timer
Press repeatedly to specify the time (in minutes) as follows:
r10 ----.. 20 ----.. 30 - 60 - 90 _
L- OFF n...-J
(Canceled) .- 180 .-150.- 120
•To check the time remaining before the shut-offtime, press SLEEP once.
If you press the button repeatedly, you can change the shut-off time.
• Turning off the unit automatically-Auto Standby
Hold down until "A STBY" appears on the display.
¢A.STBY starts flashing after playback stops.
If no operation is done for about 3minutes while A.STBY flashing, the unit will be
turned off.
•
To cancel this function, hold down AUTO STBY until "OFF" appears on the display.
•This function does not work when
FM or AM is selected as the source.
• Emphasize the sound-Sound Turbo
This function emphasizes the sound.
Press to activate Sound Turbo.
¢"S-TURBO" appears for awhile and S.TURBO lights up on the display.
•
To cancel this function, press SOUND TURBO again. "OFF" appears on the display.
• To adjust the tone
You can adjust the bass and treble level.
1
2
10
Select the item you want to adjust.
BASS 4 • TREBLE
Adjust the bass or treble level (-5 to +5).

You can connect 2iPod devices to the unit and enjoy sound and video from the iPod.
o Compatible iPod Types:
i';~!J·.;,::':,,·'·-
iPod nano 1GB/2GB/4GB
iPod nano (2nd Generation) 2GB/4GB/8GB
iPod nano (3rd Generation) 4GB/8GB
iPod mini 4GB
iPod mini (2nd Generation)
4GB/6GB
iPod (4th Generation) 20GB/40GB
iPod photo (4th Generation) 20GB/30GB/40GB/60GB
iPod video (5th Generation) 30GB/60GB/80GB
iPod classic 80GBi160GB
iPod touch 8GB/16GB/32GB
iPhone 4GB/8GB/16GB
*Only for still picture.
If the iPod does not play correctly, update your iPod software to the latest version.
•For details about updating your iPod, check on the Apple web site <http://www.apple.com>.
iPod is atrademark
of Apple Inc., registered in the U.S. and other countries.
iPhone
is atrademark of Apple Inc.
11

Connecting iPod Devices
Connect the iPod to dock Aor Bon the unit.
You can have 2iPod devices connected at the same time.
•Make sure the unit is on standby when you connect an iPod.
1.
2.
~
[1J ,.'
~r.- Dock adapter (supplied with the
~.......... iPod or sold separately)
ITr~
To detach the dock adapter from the dock:
Pull up the dock adapter with your fingernail or asharp pointed tool using the slot.
•Be careful not to injure your fingertips or damage the terminal
of the dock.
NOTES:
•
Be careful not to damage the terminal on the dock when connecting/disconnecting the iPod.
•Close the cover
of the dock when you do not connect the iPod to the unit.
About the battery charge of the iPod
The battery
of the iPod is always charged through the unit except when the unit is in ECO mode
(see page 9).
•When 2iPod devices are connected, both batteries are charged at the same time.
•For details
of the battery charging, see the instruction manual for iPod.
12

Operations
For details, refer also to the instruction manual for iPod.
NOTES:
•Before viewing avideo/picture from your iPod on your TV, make the appropriate video setting
on the iPod. For details of the setting, see the instruction manual for iPod.
•For iPhone and iPod touch
Operate the iPod directly in the following cases:
-when operating the home button
-when selecting application icons
on the Home screen
-when dragging the slider
Control of
the iPod
iPod m iPod Ia
ee
~
\:.::I
~
\:.::I
Press:
-Selects iPod rJliPod
[] as the source and starts
playback.
-Starts playback/pauses.
Hold down*
I: iPod is in sleep mode.
~ II, ~, or
II
[, ))
C::J
8
8
~
~
Press: Forward skip
Hold down: Forward search
Press: Reverse skip
Hold down: Reverse search
(Press during playback
to back to the beginning of
the track.)
Goes back
to the previous menu/screen.
Selects
an item on the menu/screen.
-Press: Selects an item.
-Hold down: Scrolls through alist. To stop
scrolling, press either one
of the buttons.
•For iPhone and iPod touch: The buttons work
after starting "Music" or "Videos" by tapping
the corresponding application icon on the Home
screen
of the iPod.
•For iPod devices other than above: The buttons
work in the same way as operating the Click
Wheel
of the iPod counterclockwise/clockwise.
MENU*2
Click
Wheel*2
*INot available for iPhone and iPod touch.
*2 Not equipped with iPhone and iPod touch. Continued on the next page
13

e
TUNER /I/ODE
e
Confinns an item on the menu/screen.
Select the desired shuffle mode.
¢"SHUFFLE" appears on the display for a
while.
•The shuffle icon lights up on the display/screen
of the iPod.
•To cancel, press again until the shuffle icon
disappears.
•Shuffle play applies to the iPod selected as the
source.
Select the desired repeat mode.
¢"REPEAT" appears on the display for awhile.
•The repeat icon lights up on the display/screen
of the iPod.
•To cancel, press again until the repeat icon
disappears.
•Repeat play applies to the iPod selected as the
source.
Control of
the iPod
Center
button*
*Not equipped with iPhone and iPod touch.
NOTES:
• lVC is not responsible for any loss of or damage to iPod that might result from the use of this
product.
•Do not touch or hit the terminals
of the dock and of the iPod. It might cause damage to these
terminals.
•When you connect your iPod to the dock, make sure the terminal on the dock is fully inserted into
the iPod.
•Always set the volume to the minimum level when connecting
or disconnecting an iPod.
•Sound distortion may occur when playing back audio sources with ahigh recording level. When
distortion occurs, it is recommended
to tum offthe equalizer of the iPod. For infonnation on
operating the iPod, see the instruction manual for iPod.
•Do not carry the unit with iPod connected. You might drop it down or it might cause damage to
the connector part.
•Turn offthe unit when disconnecting an iPod.
•Remove the iPod from the dock when you do not use it.
•When you cannot operate the connected iPod through the unit
or using the remote control, operate
the iPod directly.
•After connecting an iPod, wait until the unit is ready for operation (about 3seconds).
14

o Basic Operations
Selects FM or AM as the source.
FM/AM/
AUOIOIN
o
I...... .-.,
(( ))
.i\UDIOIN
e
88
TUNER MODE
e
~FM ----AM~
~ AUDIO IN ----.J
When an FM programme is broadcast in stereo, ST (stereo)
lights up on the display (only when the reception is good).
Press: Changes the frequency.
Hold down and release: The unit starts searching for stations
and stops when astation
of sufficient signal strength is found.
•To stop searching, press again.
Tunes in to apreset station: Press repeatedly to select apreset
station number. (For presetting stations, see page 16.)
Changes the FM reception mode: When
an FM stereo
broadcast is hard to receive or noisy, press to improve
reception. MONO (monaural) lights up on the display.
Reception will improve though the stereo effect is lost.
•To restore the stereo effect, press again.
15

o Presetting Stations
You can preset 30 FM stations and 15 AM stations.
A;.! _:'~,~: 'I'.,
Select FM or AM as the source.
1Q
\::;J
2
88
Tune in to the station you want to preset.
•You can also store the monaural reception mode for FM preset stations if
selected.
3@Activate the preset number entry mode.
¢"SET" flashes on the display for afew seconds.
•Finish the following operations while the indication is flashing.
@Select apreset number for the station you want to store.
4
~
5@Store the station.
¢"STORED" appears on the display for awhile.
NOTES:
•When you unplug the AC power cord or if apowerfailure occurs, the preset stations will be erased
in afew days.
•
If you store anew station onto an occupied preset number, the station previously stored on that
number will be erased.
16
