911 SIGNAL LURKER User manual

Your Innovative and Reliable Partner
INSTALLATION
INSTRUCTIONS
◎
◎
◎
◎
Easy module replacement
Modern and compact design
Full encapsulated for moisture, vibration and corrosion resistance
Excellent water resistance with waterproof modules and socket connectors
Hard-coated lenses and aluminum housing minimize environmental damage
Different lengths to choose from: 26'', 36'', 48'', 59'', 71''
Synchronize to other 911Signal products
◎
◎
◎

40mm
54mm
120mm
(645mm)
25.4 "
48"
(1205mm)
59"
(1485mm)
71"
(1765mm)
40mm
84mm
36"
(925mm)
Product Specifications
b. Bolt Mount
d. Rail Roof Mount
a. Gutter Mount
c. Magnetic Mount
Mounting
P1
Mounting Height with Magnets
Mounting Height with Gutters

Available in left-right sliding function
36” & 48” & 59” & 71”
25.4”
BATTERY
+10/33 V
RED
16AWG
22AWG
BL ACK
YELLOW Mode
Take Down
50% Power
Right Arrow Light
Left Arrow Light
BROWN
WHITE
GREEN
ORANGE
BLUE
ON/OFF
Wiring&Flash&
Flash Patterns
Maintenance
Random （default）
ECE R65 Rotator
ECE R65 single (ALL)
ECE R65 Double (ALL)
ECE R65 single (Split)
ECE R65 Double (Split)
Single (ALL)
Double (ALL)
Quad (ALL)
Quad (I/O)
Quint (I/O)
Single (Split1)
Double (Split1)
Quad (Split1）
Quint (Split1)
Single (Split2)
Double (Split2)
Quad (Split2）
Quint (Split2)
Wiring
Fuse @ 20A
BATTERY
+10/33 V
36” & 48” & 59” & 71”
RED
16AWG
22AWG
BL ACK
YELLOW Mode
WHITE ON/OFF
Fuse @ 20A
Model
25.4”
36”
48”
59”
71”
Voltage
DC 10-33V
DC 10-33V
DC 10-33V
DC 10-33V
DC 10-33V
Peak Current
8A
10.2A
13.2A
13.2A
13.2A
Specications
10A
15A
15A
15A
15A
Quint (ALL)
Single-Quad (ALL)
Single （Split）
Double （Split）
Quad （Split）
Quint （Split）
Single-Quad （Split）
Single （I/O）
Double (I/O)
WARNING: Power input end must be connected to the proper safety fuse.
P2

911 Signal T echnology Inc.
Add：Room 701-702, Hengwei Building, No.258, Tiangao Lane,
Shounan Subdistrict, Yinzhou Area, Ningbo City , Zhejiang, China.
Tel：[phone] [phone]
Fax：[phone]
E-mail：[email protected] m
Your Innovative and
Reliable Partner
www.911signal.co m
Scan QR Code and Get a Fre e
One-Year Extension
of Warranty
