Commercial Gas BoilersC
ACMSS00507
TOTAL HOT WATER SUPPLY SYSTEM USING VF™BOILERS
With Ac-U-Temp, A. O. Smith makes it as easy as possible to install a complete packaged hot
water supply system, combining high-efficiency VF™boilers with storage tanks up to 10,000
gallons. Each Ac-U-Temp system is custom-made to your specifications for each application
and shipped fully assembled, pre-piped and pre-wired. All the installer has to do is make the
flue, gas, electrical and water connections, so installations are easy.
Consult your A. O. Smith representative for more information
on the wide range of available boiler/storage tank combinations
using the Ac-U-Temp system.
VF MODULATING BOILERS
UP TO 88% THERMAL EFFICIENCY
•A. O. Smith’s most efficient hot water supply boilers
•Available inputs: 500,000, 750,000, 1,000,000 BTUs
•Flexible conventional-vent or sealed-combustion
direct-vent options
•For complete information on VF Hot Water Supply
Boilers, consult VF Specification Sheet
GLASS-LINED STORAGE TANKS
•Standardcapacities up to 1,000 gallons
•Custom tanks available up to 10,000 gallons
•Standard tanks are factory jacketed and insulated –
bareuninsulated tanks also available
•Optional cement or epoxy-lined tanks available
•For complete information on standard and optional
tanks, consult tank Specification Sheet
MULTIPLE BOILER SYSTEMS
•Ac-U-Temp systems can be designed with multiple
boilers to provide 50% to 100% back-up
•Multi-boiler systems can be sequenced to meet
changing system demands
•Sequenced multi-boiler systems with small storage
tanks are ideal for applications with relatively constant
hot water demands
•Optional sequenced control panel available
MULTIPLE TANK SYSTEMS
•Ac-U-Temp systems can be designed with multiple
tanks for applications with low ceiling heights or other
unique installation challenges
VWT-500
through
VWT-1000
April 2007
Page 1 of 4

ACMSS00507
Page 2 of 4
MODEL
NUMBER INCHES
OR
CM
DIMENSIONS
LENGTH
(C2) WIDTH (C1) HEIGHT (D) INLET SIZE GAS INLET
VW-500 Inches 30 30 60 2 1
CM 76.2 76.2 152.4 5.1 2.5
VW-750 Inches 30 30 66 2 1
CM76.2 76.2 167.6 5.1 2.5
VW-1000 Inches 3030752 1
CM 76.2 76.2 190.5 5.1 2.5
MODEL
NUMBER INCHES
OR
CM
DIMENSIONS
HEIGHT
(A) WIDTH (B1) INLET
HEIGHT (B2) INLET SIZE OUTLET SIZE
AJ-80A Inches 66-1/4 28 15 2 2
CM 168.3 71.1 38.1 5.1 5.1
AJV-120A Inches 66 28 15 2 2
CM 167.6 76.2 167.6 5.1 2.5
AJV-140A Inches 88 30 19-1/2 2-1/2 2-1/2
CM 223.5 76.2 49.5 6.4 6.4
AJV-200A Inches 84 36 21 2-1/2 2-1/2
CM 213.4 91.4 53.3 6.4 6.4
AJV-250A Inches 96 36 21 2-1/2 2-1/2
CM 243.8 91.4 53.3 6.4 6.4
AJV-350A Inches 99 42 22-1/2 2-1/2 2-1/2
CM 251.5 106.7 57.2 6.4 6.4
AJV-400A Inches 92 42 22-1/2 2-1/2 2-1/2
CM 233.7 106.7 57.2 6.4 6.4
AJV-500TA Inches 101 48 24 3 3
CM 256.5 121.9 61 6.4 6.4
AJV-500A Inches 86 54 25-1/5 3 3
CM 218.4 137.2 64.8 6.4 6.4
AJV-750A Inches 118 54 24-1/2 3 3
CM 299.7 137.2 62.2 6.4 6.4
AJV-1000A Inches 150 54 25-1/2 3 3
CM 381 137.2 64.8 6.4 6.4
BOILER DATA
VERTICAL STORAGE VESSEL DATA
MODEL
NUMBER INCHES
OR
CM
DIMENSIONS
LENGTH
(A1) OUTLET DIM (A2) WIDTH (B1) HEIGHT (B2) INLET
HEIGHT (B3) INLET SIZE OUTLET SIZE
AJH-200 Inches 77 59 36 41 11 2-1/2 2-1/2
CM 195.6 149.9 91.4 104.1 27.9 6.4 6.4
AJH-350 Inches 93 72-1/2 42 47 14 2-1/2 2-1/2
CM 236.2 184.2 106.7 119.4 35.6 6.4 6.4
AJH-350 Inches 99 72-1/2 42 47 14 3 3
CM 251.5 184.2 106.7 119.4 35.6 7.6 7.6
AJH-350 Inches 94 73 48 53 14 3 3
CM 238.8 185.4 121.9 134.6 35.6 7.6 7.6
AJH-350 Inches 79 56-1/2 54 59 14 3 3
CM 200.7 143.5 137.2 149.9 35.6 7.6 7.6
AJH-350 Inches 111 88-1/2 54 59 14 3 3
CM 281.9 224.8 137.2 149.9 35.6 7.6 7.6
AJH-350 Inches 143 120-1/2 54 59 14 3 3
CM 363.2 306.1 137.2 149.9 35.6 7.6 7.6
HORIZONTAL STORAGE VESSEL DATA

Commercial Gas Boilers
C
ACMSS00507
Page 3 of 4
The above are standard available configurations.Custom configurations designed to your specifications are available.Contact your local
A.O.Smith Sales Representative for assistance.
TOTAL HOT WATER SUPPLY SYSTEM USING VF™BOILERS
Configuration H
Configuration P
Configuration V

Commercial Gas Boilers
ACMSS00507
Page 4 of 4
DUAL-ENERGY SOURCE OPTION
•Storage tanks can be specified with an optional
heat exchanger for winter heating using on-site
hydronic heating boiler(s), switching to domestic
hot water boiler(s) for summertime operation
•Water-to-water or steam-to-water heat exchangers
available in single-wall or double-wall design
•Complete control packages can be factory-installed
for “hook up and run” simplicity
PROFESSIONAL START-UP SERVICE FURNISHED
•Assures optimum performance for each installation
MEETS ASHRAE/IESNA 90.1-1999
5 YEAR VF BOILER HEATEXCHANGER WARRANTY
5YEAR STORAGE TANK WARRANTY
•For complete information, consult written warranty or
contact A. O. Smith
OTHER FEATURES:
ASME TEMPERATURE AND PRESSURE RELIEF
VALVE #125
TANK TEMPERATURE SENSOR AND
THERMOMETER
ISOLATION VALVES (BALL VALVES)
125 PSI TANK WORKING PRESSURE
ALL-BRONZE CIRCULATING PUMP
LARGE SYSTEMS SHIPPED WITH SPLIT/
BOLT TOGETHER SKIDS FOR EASE OF
SHIPPING AND INSTALLATION
OTHER OPTIONS:
150 AND 160 PSI TANK WORKING PRESSURES
11˝ X 15˝ MANHOLES
Tank Type (A=Skid Mounted, J=Jacketed, V=Vertical, H= Horizontal)
TOTAL HOT WATER SUPPLY SYSTEM USING VF™BOILERS
SUGGESTED SPECIFICATION
Hot Water Supply System - shall consist of A. O. SMITH Ac-U-Temp factory assembled unit Model No. __________. System
shall be completely factory assembled and shall include the A.O. SMITH VF hot water supply boiler(s), with input
of ____ BTU/H for (natural/propane) ____ gas and recovery capacity of _______ gph, and the A.O. SMITH glass-lined
(cement/epoxy) hot water storage tank with ____ gallons capacity for ________ mounting (vertical-horizontal). System
shall include properly sized circulator, inlet and outlet thermometers, tank temperature thermometer, relief valve, and tank
temperaturecontrol. Entire system shall be rigidly mounted on welded steel skid base and shipped assembled to job site
(Ac-U-Temp systems employing tanks too large for shipping as an assembled unit, will be shipped with the tank mounted
on a split bolt-together skid). See VF Boiler Specification Sheet for boiler details. See A.O.Smith Storage Specification
sheets for storage tank details.
Hot water supply boiler(s) and storage tank(s) shall have a 5 year limited warranty against corrosion as outlined in the
written warranty
500 Tennessee Waltz Pkwy, Ashland City, TN 37015
For Technical Information and Automated Fax Service,call 800-527-1953.
A.O.Smithreserves theright tomake productchanges orimprovements withoutprior notice.
©2007 A. O. Smith Corporation Printed in U.S.A.
