Revised September 2010
AOSTT35100
Commercial Storage Tanks
FACTORY JACKETED AND
INSULATED STORAGE TANKS
These A. O. Smith storage tanks are designed for storing potable water. Fitting locations
are designed to meet the needs of normal installations plus those for the
A. O. Smith Cer-Temp 80® and Shure -Temp™ piping methods.
MODELS
TJ-80S, TJ-80A
TJV-120A, TJV-120M
& TJV-200M
120 Gallon Model
(FOR SELECT MODELS)
®
FEATURES
A. O. Smith storage tanks are ideal for
use with gas-fired copper heat exchanger
equipment for storage of any potable water
at temperatures up to 180°F.
GLASS-LINED TANK - Alkaline borosilicate
composition permanently fused to steel
by firing at a temperature of 1600°F,
providing years of corrosion protection and
dependable use.
HEAVY GAUGE STEEL JACKET - With
baked enamel finish.
THREADED OPENINGS - All tanks
furnished with threaded openings for
thermometer, relief valve, 2” recirculation
lines, tankstat, and drain valve.
INSULATION - Storage Tanks meet or
exceed R12.5 minimum thermal insulation
requirements of the U. S. Department
of Energy and current edition of
ASHRAE/IESNA 90.1
TJ-80S, TJ-80A, TJV-120M and TJV-120A
• Fits through 30” door
• Magnesium anode for anti-corrosion
protection
TJ-80A
• 80 gallons
• High density foam insulation saves energy,
helps reduce standby heat loss
• 160 psi ASME standard working pressure
TJV-120A
• 119 gallons
• High density foam insulation saves energy,
helps reduce standby heat loss
• 160 psi ASME standard working pressure
TJ-80S
• 80 gallons
• High density foam insulation saves energy,
helps reduce standby heat loss
• 160 psi working pressure
TJV-120M
• 119 gallons
• High density foam insulation saves energy,
helps reduce standby heat loss
• 160 psi working pressure
OPTIONS
Perfectly balanced manifold kits (120 gallon
models) allow installation where 240 to 480
gallons of stored water is required.
TJV-200-M - 175 GALLONS
• 160 psi ASME standard working pressure
• 2” foam insulation
• Handhole cleanout (Standard)
• Fits through 33” door
• Storage is downsized to 175 gallons for
a 32” x 77” envelope for space restrictive
installations. Model TJV-200 is available
with 200 gallons of storage.
• Magnesium anodes for extra
corrosion protection
5 YEAR WARRANTY
If the tank should leak any time during
the first 5 years, under the terms of the
warranty, A. O. Smith will repair or replace
the tank. Installation, labor, handling
and local delivery are extra. For complete
information, consult the written warranty
or contact A. O. Smith.
AOSTT35100 R August 2010 Storage Tank Spec.indd 1 9/1/10 12:13 PM

For Technical Information and Automated Fax Service, call 800-527-1953. A.O. Smith Corporation reserves the right to make product changes or improvements without prior notice.
Commercial Storage Tanks
Revised September 2010 Page 2 of 4
www.hotwater.com AOSTT35100
77 "
12 1/4"
17 1/4"
32 "
12 1/4"
17 1/4"
64"
1" NPT
ASME PLATE
LOCATED UNDER
COVER
2" NPT
3/4" NPT
3/4" NPT
(ANODES)
2" NPT
TJV-200M
4 1/8"
11"
42 1/4"
62"
3 1/2"
15"
54 1/4"
1" NPT
FRONT
2" NPT
FRONT
2" NPT
FRONT
CLEANOUT
2" NPT
FRONT & REAR
3/4" NPT
FRONT
2" NPT
3/4" NPT
(ANODE)
29 3/8"
TJV-120M
10 3/4"
17 3/4"
44 1/2"
61 3/4"
28"
9 3/4"
21 1/4"
50 1/2"
2" NPT FRONT
2" NPT FRONT
& REAR
3/4" NPT
1" NPT
ASME PLATE
LOCATED UNDER
COVER
1" NPT
1-1/4" NPT
(ANODE)
2" NPT
TJV-120A
®
AOSTT35100 R August 2010 Storage Tank Spec.indd 2 9/1/10 12:13 PM

11"
19 1/2"
32 1/4"
42 3/4"
54 7/8"
26 1/2"
9 3/4"
2" NPT
FRONT & REAR
3/4" NPT
REAR
ASME PLATE
UNDER COVER
3/4" NPT
FRONT
2" NPT
FRONT & REAR
3/4" NPT
REAR
3/4" NPT
(ANODE)
2" NPT
1" NPT
TJ-80A
7"
16"
47"
51 7/8"
63"
25 1/4"
3 3/4"
2" NPT
FRONT & REAR
3/4" NPT
REAR
3/4" NPT
FRONT
2" NPT
FRONT & REAR
3/4" NPT
REAR
2" NPT
3/4" NPT
(ANODE)
TJ-80S
For Technical Information and Automated Fax Service, call 800-527-1953. A.O. Smith Corporation reserves the right to make product changes or improvements without prior notice.
Commercial Storage Tanks
Revised September 2010 Page 3 of 4
www.hotwater.com AOSTT35100
®
FLOOR SPACE REQUIREMENTS
AOSTT35100 R August 2010 Storage Tank Spec.indd 3 9/1/10 12:13 PM

For Technical Information and Automated Fax Service, call 800-527-1953. A.O. Smith Corporation reserves the right to make product changes or improvements without prior notice.
Commercial Storage Tanks
Revised September 2010 Page 4 of 4
www.hotwater.com AOSTT35100
SUGGESTED SPECIFICATION
Storage tank shall be A. O. SMITH glass-lined storage tank. Tank shall be _______” x _______” and have a nominal
capacity of ____ gallons. Tank(s) shall have threaded openings as shown on drawings. Interior of tank(s) shall be
glasslined with an alkaline borosilicate composition which has been fused to the steel by ring at a temperature of 1600°F.
Glass coating shall be continuous over the entire inner surface of the tank. Outer jacket shall have a baked enamel
nish. Meets or exceeds R12.5 minimum thermal insulation requirements of the U. S. Department of Energy and current
edition of ASHRAE/IESNA 90.1. Cathodic protection shall be provided. Tank shall have a working pressure of ____ psi.
Tank shall have a ve year limited warranty as outlined in the written warranty.
