A.R.I. K-060 Owner's manual

K060.IOM.ENG01
Installation, Operation & Maintenance
AIR & VACUUM AIR VALVE MODEL K-060
The following is a step-by-step narrated description of the A.R.I. K-060 Air & Vacuum valve installation,
operation and maintenance processes.
The K-060 Air & Vacuum valve is designed to automatically discharge or admit large volumes of air during the
filling or draining of a pipeline or piping system. This valve will open to relieve negative pressures whenever
water column separation occurs.

2
IOM
TABLE OFCONTENTS
1. SAFETY INSTRUCTIONS ............................................................................................................................... 3
Safety Instructions - General................................................................................................................................... 3
Safety Instructions - Handling ................................................................................................................................ 3
Safety Instructions - Installation ............................................................................................................................. 3
Safety Instructions - Commissioning and Operation ............................................................................................ 4
Safety Instructions - Maintenance.......................................................................................................................... 4
Safety Instructions - Before returning to regular operation.................................................................................. 4
2. INSTALLATION............................................................................................................................................ 5
2.1
.
Installation Recommendations ..................................................................................................................... 5
2.2. Conventions and Measurements.................................................................................................................. 6
2.3. Installation Instructions ............................................................................................................................... 7
2.4. Directions for Discharge Outlet..................................................................................................................... 7
3. OPERATION ................................................................................................................................................ 8
4. PERIODIC MAINTENANCE ........................................................................................................................... 9
4.1. Preparation ................................................................................................................................................... 9
4.2 Maintaining the Air & Vacuum valve ......................................................................................................... 9
5. TROUBLESHOOTING ..................................................................................................................................11
6. A.R.I. LIMITED WARRANTY ........................................................................................................................12
Disclaimer
ThisdocumentisanInstallation,OperationandMaintenance(IOM)manualforA.R.I.FlowControlAccessoriesLtd.(A.R.I.)products.Theinformationenclosedherein
containsrestricted,privileged,proprietaryandconfidentialinformation,intendedonlyforusagebyauthorizedA.R.I.technicians.Ifyouarenotaqualifiedtechnician, you
must not take any action in reliance uponthis document, unless otherwise permitted in writing by A.R.I.
A.R.I. has made every effort to ensure that this document is accurate; A.R.I. disclaims liability for any inaccuracies or omissions that may have occurred.
All the procedures, drawings, pictures and/or any other information provided in this document are presented as general information only; they can be altered,
removedorchangedwithoutA.R.I.'spriorwrittenapproval.A.R.I.makesnocommitmenttoupdateor keeptheinformationin thisdocumentcurrentand/orup-to-
date, and reserves therightto make improvements, alterations and/or modifications to this document and/orto the products described in this document, atany time
without providing any notice with respectthereto. Nothing in this Disclaimer derogates in any way whatsoever from theconfidentialnatureof any document enclosed
hereto, including for avoidanceof doubt, any mistake orclericalerroror other error. None oftheprocedures providedin this Disclaimer and/orin any document
enclosed hereto may be used in any form or by any means without the prior written consent from A.R.I. If you received this Disclaimer and/or in any document
enclosed heretoin error or by mistakeorif this Disclaimer and/orin any document enclosed heretois not intendedforyou, pleasenotify A.R.I. in writing immediately.
A.R.I. assumes that all users understand the risks involved within this Disclaimer and/or in any document enclosed hereto.
A.R.I. accepts/assumes noliability whatsoever, whether caused by: accessing and/or relying upon this Disclaimer and/or in any document enclosed hereto including
withoutlimitationanylinks,proceduresormaterials.
A.R.I. shallNOT assume any liability for any costs, director indirect, including loss ofincome, loss ofprofits and/or goodwill, legal actions and/ordamages ofany kind
whatsoever including any, damages accidents, equipmentdamage orbodily injury resulting from and/or related toany of the following:
• producthas not beendulyinstalledandthereaftermaintainedin strictcompliance with its designated Maintenance Instructions and/or any other installation and
operationmanualsprovidedby A.R.I.forthe productand/orapplicableordinancesand/orcodes;
• Repairs madein and to the products by personnelnot authorizedby A.R.I.
• Maintenanceor repairs usingparts orcomponents other thanthosespecified byA.R.I. and in theiroriginalcondition.
• Operating theproducts in ways other than theoperating procedures described in themanuals provided by A.R.I., or resulting fromnot following the
cautionary remarks and warnings in the productmanual.
• Improper storage, workplace conditions and environmental conditions which do not conform to those statedin theProduct manual.
• Fires,earthquakes,floods,lightning,naturaldisasters,oractsofGod.
A.R.I. does notwarrant and hereby disclaims any express or implied warranties that theproduct will work properly in environments and applications otherthan its original
designpurpose,andmakesnowarrantyandrepresentation,eitherimpliedorexpressed,withrespecttothequality,performance,merchantability,orfitness foranyother
particularpurpose.
Exceptas providedhereinand to the fullextentpermittedby law,A.R.I. shallnot be responsibleand/orliablefor direct,special, incidental orconsequentialdamages or
loss resulting from any breach ofthe aboveor under any otherlegal theory.
Thisdocumentdoesnotreplaceanycertifieddrawing,procedureorinformationprovidedbyA.R.I.inreferencetoaspecificcustomer,siteor project. All
rights reserved.

3
IOM
1. SAFETY INSTRUCTIONS
Safety Instructions - General
1. A.R.I.productsalwaysoperate ascomponentsin alargersystem.Itisessentialforthesystemdesigners,installers,operators
and maintenance personnel to comply with all the relevant safety standards.
2. Installation, operation or maintenance of the product should be done only by qualified workers, technicians and/or
contractors using only good engineering practices, complying with and observing all conventional safety instructions in
order to minimize risk and/or danger and/or hazard to workers, the public or to property in the vicinity in accordance with all
relevant local standards.
3. Extra safety considerations should be taken with hot and hazardous liquids or in hazardous environments' applications to
avoid bodily/physical harm and damage to public or private property.
4. All individuals installing operating and/or handling the products including all workers should at all times adhere to the
occupational safety and health (OSH) instructions and wear safety helmets, goggles, gloves, and any other personal safety
equipment required by the local standards and regulations.
5. Use only appropriate standard tools and equipment operated by qualified operators when installing, operating and
maintaining theproduct.
6. Priortoinstallation, operation, maintenance orany other typeofaction carriedoutontheproduct, readcarefullythesafety,
installation and operationinstructionsoftheproduct.
7. Please note:
- Pressurized fluid and/or gas may be discharged from the product without prior warning. Make sure that the product's outlet
port isnot directed toward electrical elements (pumps) or people.
- The pressurized fluid and/or gas that can be discharged from the product may create high noise levels. Take this into
consideration when installing the product in areas sensitive tonoise.
8. Always open and close valves slowly and gradually.
9. Please note that the maximum working pressure indicated at the product’s specifications table doesn't include pressure
changes caused by water hammer and pressure surge effects. Use the product only according to its designated pressure rate
specifications.
10. Use the product only for its intended use as designed by A.R.I. Any misuse of the product may lead to undesired damages and
may affect your warranty coverage. Please consult with A.R.I. prior to any non-regular use of this product and make no change
ormodificationtotheproduct without apriorwrittenconsent to beprovidedbyA.R.I.atA.R.I.'ssolediscretion.
11. Please note that A.R.I. shall NOT assume any liability with respect to any damage losses and/or expenses caused to any person
and/or property whatsoever unless the product has been duly installed and thereafter maintained in strict compliance with its
designated maintenance Instructions and/or any other installation and operation manuals provided by A.R.I. for the product
and/or applicableordinancesand/or codes.
Safety Instructions - Handling
1. Shipping and handling the product must be done in a safe and stable manner and in accordance with the relevant standards
and regulations.
2. Storage should be in the original delivery crates or cases. Storage should be off the ground in a clean, dry indoor area.
3. For lifting and positioning the product, use only approved lifting equipment operated by authorized employees and
contractors.
4. Prior to the installation visually verify that the product was not damaged during shipment to the installation site.
Safety Instructions - Installation
1. Install the product according to the detailed Installation Instructions provided with it by A.R.I. and according to the description
given in this manual.
2. The user should install a manual Isolation Valve under the product's inlet port.
3. In all installation sites, the user should enable good visibility and verify that the work and auxiliary equipment used are
done in accordance with the relevant local authorized standards. Extra safety considerations should be taken on hazardous
environment sites.
4. Check and re-tighten the bolts connecting the product to the pipeline during commissioning and before operating the
productforthefirsttime.

4
IOM
Safety Instructions - Commissioning and Operation
1. Read carefully theoperation instructions prior toany attempt tooperatetheproduct.
2. Observe the safety stickers on the product and never perform any operation contradicting the instructions given.
3. In order to achieve maximum performance and smooth operation of the product, it is crucial to perform the startup and first
operation procedures exactly asdescribed in this manual.
4. In cases where formal commissioning procedure isrequired, it should be done by an authorized A.R.I. technician prior to the
firstoperation oftheproduct.
Safety Instructions - Maintenance
Before any maintenance or non-regular operation, please read the following:
1. Servicing the product should be done only by qualified technicians for this type of work.
2. Make sure that you know the exact type of the system fluid. Act accordingly and comply with all the relevant standards and
regulations set for handling this type of fluid.
3. Before disconnecting the product from the system and before releasing the residual pressure doNOT:
- loosen or unscrew the product bolts;
- removeanyprotectioncover;
- open any service port.
4. Beforeanymaintenanceornon-regularoperation, shutofftheIsolationvalveandreleasetheresidual pressure:
A. Forair valves with a pressure release outlet, slowly open the pressure release plug or the ball valve and make sure that all
pressure is released. Please note that some air release valves, especially the waste water models, may contain a significant
volume of compressed gas with accumulated energy!
B. Forair valves without a pressure release outlet, slowly unscrew the flange bolts until all the pressure is released from the
valve.
5. Make sure the air valve is empty of all liquid prior to commencing maintenance.
6. Remove the product from the line only after ensuring that internal pressure has been released.
7. Place warning signs around the work area as required by the local standards and procedures.
8. Inspectthe product’ssafety stickers and replace anydamaged orfaded sticker.
9. Manual cleaning of the product and/or its components using high water pressure or steam should be performed in
accordance with its specific cleaning instructions, the local standards and regulations and without endangering the operator
or thevicinity
10. Manual cleaning of product and/or its components using acid or other chemical agents should be performed in accordance
with the specific cleaning instructions, the relevant safety instructions for using that chemical as given by its supplier, the local
standards and regulations and without endangering the operator or his vicinity.
11. For products used in potable water systems, if it is required to disinfect the product, do so according to the local water
authority standards and regulations before putting the product into service.
Safety Instructions - Before returning to regular operation
1. Re-assemble any protection covers or protection mechanisms removed during service or maintenance operations.
2. Make sure thatall the tools, ladders, lifting devices, etc. used during the maintenance procedures are takenaway from the
productareaandstored.
3. Remove grease and fat material residues in order to avoid slipping.
4. In order to return the product to regular operation, follow the First Start-up Operation instructions as detailed in your user
manual.

5
IOM
2. INSTALLATION
Important: Before performing any work on the air valve make sure that all workers on site are familiar with
the safety instructions and the relevant local and general safety instructions and workregulations.
2.1. Installation Recommendations
Single Air Valve on an Isolating Valve at 45° to Air Valve outlet
Two Air Valves on an Air Trap with separate Isolating Valves. Air
Valve outlets face outward and the Isolating Valves at 45° to Air
Valve outlets
Two Air Valves on a shared Isolating Valve. Air Valves outlets face
outward and the Isolating Valve at 45° to Air Valve outlets
Underground Installations
Underground installations require a venting pipe from the
manhole
Use an angular installation to bypass an obstacle directly
above the pipeline.

6
IOM
2.2. Conventions and Measurements
This paragraph presents and explains the terms and
measurements used for the Installation process.
D = Diameter of pipeline
d = diameter of riser
H = Height of riser on the pipeline
(Measured from crown of pipeline)
•For pipelines up to 12" (300mm) in diameter (D), the Air
Trap diameter (d) should be the same as the pipeline
diameter.
•For larger pipelines of up to 60" (1500mm) in diameter
(D), the Air Trap diameter (d) should be 60% of the
pipeline diameter.
•For larger than 60" (1500mm) pipelines (D), the Air Trap
diameter (d) should be 35% of the pipeline diameter.
•The Air Trap length (H) should allow easy access to the air
valve from below and should be at least 6" (150mm).
D
Isolation
Valve
Air Trap
Raiser
H
d
D

7
IOM
2.3. Installation Instructions
1. Flush the system before installing the air valve to avoid any debris or sharp objects getting into the air
valve.
2. Carefullyremovethe air valvefromtheshippingpackage.Unloadallairvalvescarefullytoasturdylevel
surface taking care not to dropthem.
3. Air valves fitted with hoist rings should only be lifted and conveyed using these hoist rings.
4. Install an isolating valve below the air valve, connected by a Riser to the crown of the pipe.
5. Mount the air valve carefully on the rubber gaskets of the isolating valve.
6. Place washers on each of the bolts & nuts that connect the air valve flange to the isolating valve flange.
7. Tighten all the bolts and nuts using the crossover method.
8. The closure tightness of the bolts and nuts shall be according to the standard torque for their specific
size.
9. Use ring wrench keys for the closing and opening of all bolts of the air valve (including the flange bolts).
2.4. Directions for Discharge Outlet
1. Recommended to leave the discharge outlet completely open andunhindered:
2. Avoid directing the discharge outlet opening in the direction of workers, bystanders or animals.
3. Avoid directing the discharge outlet opening in the direction of vulnerable equipment that can be
damaged, such as electrical equipment, unstable structures, etc.

8
IOM
3. OPERATION
The Air & Vacuum component, with the large orifice, discharges air at high flow rates during the filling of the
system, and admits air into the system, at high flow rates, during system’s drainage and at water column
separation. High velocity air does not blow the float shut. Water lifts the float which seals the valve.
At any time during system operation, if the internal pressure of the system falls below the atmospheric
pressure, air enters the system.
The smooth discharge of air reduces pressure surges and other destructive phenomena.
The intake of air in response to negative pressure protects the system from destructive vacuum conditions,
and prevents damage caused by water column separation. Air entry is essential to efficiently drain the system.
As the system starts to fill, the valve functions according to the following stages:
1. Air in the pipeline is discharged by the air valve.
2. Liquid enters the valve, lifting the float to its sealing position.
When the internal pressure falls below the atmospheric pressure (negative pressure):
1. The floats drop down, immediately opening the Air & Vacuum orifices.
2. Air enters the system.

9
IOM
4. PERIODIC MAINTENANCE
Please note that the periodic maintenance of the air valve is an integral part of the proper pipeline
maintenance regime; it should be maintained at least once a year in accordance with the quality and
composition of the fluid in the system.
Important: Before performing any work on the air valve, make sure that all workers on site are familiar with the
safety instructions as appear chapter of this document and with all the relevant local and general safety
instructions, standards and work regulations.
4.1. Preparation
Releasing Pressure
Shut the isolating valve located on the riser under the air valve.
Option A:
Using two combination spanners, partially unscrew the bolts connecting the air valve to the riser in order
to release the pressure. Wait till the pressure is released.
Option B. –for air valves with Plug:
Use a ratchet box wrench to gradually release the Plug of the pressure release port, wait till the pressure
is released and then unscrew the Plug completely, remove it and drain the air valve.
4.2 Maintaining the Air & Vacuum valve
Refer to the drawing on the next page.
1. Shut the isolating valve below the air valve.
2. Unscrew the Bolts that connect the valve Cover to the valve Body.
3. Remove the Cover assembly from the valve Body
4. Wash and clean the following parts: Body including the groove of the O-ring, Screen, Float, and Cover
including the Orifice Seat and Orifice Seal under clean running water in order to remove coarse grime
and/or accumulated scale.
5. Check that the Orifice Seal is not damaged (torn and/or cracked).
6. In case the Orifice Seal is damaged, consult your dealer.
7. Reassemble the air valve in the reverse order:
8. First insert the Float, and then place the O-ring in the groove.
9. Place the Cover on the Body, insert the Bolts and Washers and tighten the Nuts.
10. Tighten all the Bolts and Nuts using the crossover method.
11. The closure tightness of the Bolts and Nuts shall be according to the standard torque for their specific
size.
12. Use ring wrench keys (Hand force only) for the closing and opening of all Bolts of the air valve (including
the flange bolts).

10
IOM
AIR & VACUUM VALVE - ASSEMBLY BOM TABLE AND DRAWING
1
Cover Assembly
2
Float
3
O-ring
4
Bolts & Nuts
5
Body

11
IOM
5. TROUBLESHOOTING
Symptom
Possible Causes
Remedy
Leakage from the Large Orifice
Dirt particles stuck on the Orifice Seal, Orifice
Seat, or on the Float
Shut the isolating valve, wait a minute,
and open it again, very fast.
If leaking continues, follow steps for:
4.2 Maintenance - Air & Vacuum Valve
Component

12
IOM
6. A.R.I. LIMITED WARRANTY
A.R.I. Standard International Warranty
A.R.I. manufactured products are guaranteed to be free from defect in material and/or
workmanship and to perform as advertised when properly installed, used and maintained in
accordance with current instructions, written or verbal.
Should any item prove defective within the time period set forth for that item(s), but in any case
not later than within 12 (Twelve) months of that product having left A.R.I.’s premises, and subject
to receipt by A.R.I. or its authorized representative, of written notice thereof from the purchaser
within 30 days of discovery of such defect or failure - A.R.I. will repair or replace or refund the
purchase price, at its sole discretion, any items proven defective in workmanship or material.
A.R.I. will not be responsible, nor does this warranty extend to any consequential or incidental
damages or expenses of any kind or nature regardless of the nature thereof, including without
limitation, injury to persons or property, loss of use of the products, loss of goodwill, loss of profits
or any other contingent liabilities of any kind or character alleged to be the cause of loss or
damage to the purchaser.
This warranty does not cover damage or failure caused by misuse, abuse or negligence, nor shall
it apply to products upon which repairs or alterations have been made byother than an authorized
A.R.I. representative.
This warranty does not extend to components, parts or raw materials used by A.R.I. but
manufactured by others, which shall be only to extent warranted by the manufacturer’s warranty.
THERE ARE NO WARRANTIES, EXPRESSED OR IMPLIED, EXCEPT THIS WARRANTY
WHICH IS GIVEN IN LIEU OF ANY OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING ANY IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
Guy Sagie
Chief Executive Officer
