A.S.HELSINGO Lalax User manual

Wardrobes Mounting Instructions /
Lalax
Before you begin
Please read these instructions carefully before you start assembling your new wardrobe:
– Our wardrobes are easy to assemble, but you need to have basic skills in using tools such as an electric
screwdriver and clamps.
– Make sure you have assembled the IKEA PAX cabinet frames correctly, according to IKEA’s instructions.
– Do check carefully that the cabinet frames are straight to ensure a beautiful result.
–Assemble the wardrobe on a smooth and even surface, preferably on a thin carpet close to the area you
are planning to place it. We also recommend having help, to minimize the risk of damaging any of the parts.
Tools needed
Electric screwdriver Bits(T20) 2 x Clamps Tape measure Flat head screwdriver

Disclaimer
Suggestions in these mounting instructions are provided for informational purposes only. A.S.Helsingö does
not guarantee the ecacy of the instructions, as unforeseen variables, such as the existing wall, ceiling and
ooring conditions, and alternative designs, may render these suggestions moot. Equally, A.S.Helsingö does
not guarantee that this information is up to date. For questions concerning IKEA products, specications, or
utilizations, please refer to IKEA’s manuals and instructions.

General Safety Guidelines
– Read all IKEA’s and A.S.Helsingö’s assembly instructions carefully before beginning the installation.
Failure to follow the instructions may result in property damage, bodily injury, or loss of life.
– Read all safety instructions carefully for the tools that you use in the installation.
– Be aware of water and power lines when drilling into walls.
– Lift all items carefully, especially heavy parts.
– Keep children away.

1. Attach the IKEAcabinet frames using three screws.
Drill three screws in between the holes of the frame
in the front.
2. Install the side panels. They should stand out of the front of
the cabinet frame by 25mm. Drill six screws in between the
holes of the frame in the back and front.
How it will look
Contents
Front view Back view
Front side of
the cabinet frame
Side panel
25 mm
Please note that the design varies slightlydepending on the
size of your wardrobe.
Safety
Please always follow the safety instructions that apply to yourIKEA
products,especially when securing the cabinet to the wall. It’s
essential as the weight distribution changes when the doors are
open. Use the anchor brackets provided with the IKEAcabinets.
Lalax
Width
Screws (4 x 30 mm)
Handle screws (3,5 x 30mm)
Doors
75 cm
16
8/10
2
100 cm
16
16/20
2
150 cm
23
16/20
4
Side panels
Top panels
Handles
2
1
2
2
1
2
2
1
4
Width
Screws (4 x 30 mm)
Handle screws (3,5 x 30mm)
Doors
200 cm
23
16/20
4
225 cm
30
24/30
6
300 cm
30
24/30
6
Side panels
Top panels
Handles
2
1
4
2
1
6
2
2
6

IKEA PAX
25 mm
6. Install the handles with the brass screws through the
pre-drilled holes (4 or 5 screws depending on height)
with a at head screwdriver. Do not use a power drill.
IKEA
KOMPLEMENT
3. Install the top panel with four screws per frame from the inside
of the cabinet. In the front drill the screw in between the two holes.
In the back drill the screw in front of the hole in the back. The top
panel should stand out of the front of the cabinet frame by 25mm.
4. Secure the wardrobe to the wall using brackets and
mounting screws, according to IKEA's instructions.
5. Install the hinges following IKEA’s instructions.
Then attach the doors.
Front side of
the cabinet frame
Top panel

[e-mail]
[phone]
If you need support, you can always get in touch – we are happy to help!
