Aaeon FES-5120 User manual

Flexible Embedded
System FES-5120
FES-5120
Flexible Embedded System
2.5” SATA Hard Disk Drive Bay
1 Gigabit Ethernet Port/
4 COM/ 6 USB2.0
HD Audio Codec (2CH Audio)
FES-5120 Manual 2nd Ed.
February 2012

Flexible Embedded FES-5120
System
i
Copyright Notice
This document is copyrighted, 2012. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Flexible Embedded FES-5120
System
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
Award is a trademark of Award Software International, Inc.
CompactFlash™is a trademark of the Compact Flash
Association.
Microsoft Windows®is a registered trademark of Microsoft
Corp.
Intel®, Atom™ are trademarks of Intel Corporation.
PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

Flexible Embedded FES-5120
System
iii
Packing List
Before you begin operating your PC, please make sure that the
following materials are enclosed:
1 FES-5120
1 CD-ROM for manual (in PDF format) and drivers
1 60W AC-DC Power Adapter
1 Wallmount Kit
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.

Flexible Embedded FES-5120
System
iv
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a firm surface during installation. Dropping
it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.

Flexible Embedded FES-5120
System
v
d. The equipment does not work well, or you cannot get it
to work according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT INAN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE IS BELOW -20°C
(-4°F) OR ABOVE 65°C (149°F). IT MAY DAMAGE THE
EQUIPMENT.
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received including
interference that may cause undesired
operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.

Flexible Embedded FES-5120
System
vi
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Boxer/ Industrial System
有毒有害物质或元素
部件名称 铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件 ×○○○○○
外部信号
连接器及线材 ×○○○○○
外壳 ×○○○○○
中央处理器
与内存 ×○○○○○
硬盘 ×○○○○○
电源 ×○○○○○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、电源为选购品。

Flexible Embedded FES-5120
System
vii
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
1.4 General System Information .....................................1-6
Chapter 2 Hardware Installation
2.1 Location of Jumpers and Connectors .......................2-2
2.2 Mechanical Drawing ................................................2-3
2.3 List of Jumpers ........................................................2-4
2.4 List of Connectors .....................................................2-5
2.5 Setting Jumpers .......................................................2-6
2.6 Clear CMOS (JP1) ...................................................2-7
2.7 LVDS Power Selection (JP3) .................................... 2-7
2.8 LVDS Inverter Voltage Selection (JP4).....................2-7
2.9 CFD Voltage 3.3V/5V Selection (JP5) ......................2-7
2.10 Auto Power Selection (JP6) .................................... 2-7
2.11 COM1 Port Power/Ring Selection (JP10)...............2-8
2.12 COM2 Port Power/Ring Selection (JP11)...............2-8
2.13 COM2 Port Power Selection (COMV1)...................2-8
2.14 COM1 Port Power Selection (COMV2)...................2-8
2.15 Front Panel Connector (FP1) ................................2-8
2.16 RS-232 Serial Port Connector (COM1, COM3, COM4)
.........................................................................................2-9

Flexible Embedded
System FES-5120
viii
2.17 RS-232/422/485 Serial Port Connector (COM2).....2-9
2.18 LPT Port Connector (LPT1) ....................................2-9
2.19 LVDS Inverter (CN1)...............................................2-10
2.20 LVDS (CN2) ............................................................2-10
2.21 Audio Pin Header (Right Channel) (CN4)............... 2-11
2.22 Audio Pin Header (Left Channel) (CN5)..................2-11
2.23 USB Connector (CN6).............................................2-11
2.24 Digital I/O (CN7) (Address: 802h, 803h, 804h).......2-11
2.25 PS/2 Keyboard/Mouse Connector (CN8)................2-12
2.26 SATA Power Connector (PWR1, 2)........................2-12
2.27 Audio Connector (AUDIO1).....................................2-12
2.28 Installing The Hard Disk Drive.................................2-13
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup....................................................3-3
Chapter 4 Driver Installation
4.1 Installation.................................................................4-3
Appendix A Programming The Watchdog Timer
A.1 Programming ........................................................A-2
A.2 ITE8718 Watchdog Timer Initial Program ............A-5
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-3
B.3 IRQ Mapping Chart................................................B-4
B.4 DMA Channel Assignments.……………………….B-4

Flexible Embedded
System FES-5120
Chapter 1 General Information 1- 1
General
Chapter
1
Information

Flexible Embedded
System FES-5120
1.1 Introduction
FES-5120 adopts the Intel®AtomTM N270 Processor, up to 1.6GHz.
The chipset is equipped with Intel®945GSE & ICH7M. Moreover,
the system memory features 200-pin DDRII 400/533 SODIMM
socket up to 2GB. It deploys one RJ-45 port that features
10/100/1000Base-TX Ethernet LAN. FES-5120 condensed
appearance features desktop and wallmount form factor that fits
nicely into a space-limited environment.
This compact FES-5120 equipped with one internal 2.5” Hard
Disk Drive with SATA interface. In addition, it features three
RS-232/ one RS-232/422/485 COM ports and six USB2.0 ports.
Furthermore, the VIA HD VT-1708B supports optional 5.1 audio
channel and 2W amplifier for speaker out.
Chapter 1 General Information 1- 2

Flexible Embedded
System FES-5120
1.2 Features
zIntel®Atom™ N270 1.6 GHz
zIntel®945GSE + ICH7M Chipset
z200-Pin Non-ECC DDRII 400/533 SODIMM x 1, Up To 2 GB
zVGA Single View
zRealtek PCI-Express 10/100/1000Base-TX Ethernet x 1
z2.5” SATA Hard Disk Drive Bay x 1
zUSB 2.0 x 6, COM x 4, CompactFlash™ x 1, 8-bit Digital I/O
zCost-Effective and Fanless Solution
Chapter 1 General Information 1- 3

Flexible Embedded
System FES-5120
1.3 Specifications
System
Form Factor Compact size for Desktop/Wallmount
Main Board IMBE-945G
Processor Onboard Intel®Atom N270 1.6GHz
System Memory 200-pin DDRII 400/533 SODIMM Socket x
1, Max. 2GB
Chipset Intel®945GSE & ICH7M
Ethernet 10/100/1000Base-TX Ethernet x 1
BIOS Award BIOS 4Mb Flash EEPROM
Audio VIA HD codec VT1708B
2W amplifier for speaker out
I/O Chip ITE 8712F I/O Controller
Hard Disk Drive 2.5” Hard Disk Drive bay x 1 (SATA II
interface)
Solid Storage Disk CompactFlash™ Type II socket x 1
LED Two indicators for Power and HDD
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1
min./step
H/W Status Monitor Monitoring system temperature, voltage,
and cooling fan status
Power Supply Single DC 12V input
Dimension (WxHxD) 9.4” x 1.77” x 5.7” (240mm x 45mm x
145mm)
Chapter 1 General Information 1- 4

Flexible Embedded
System FES-5120
Weight 3.6 lb (1.62 Kg)
External I/O
Serial Port RS-232 x 3
RS-232/422/485 x 1
KB & Mouse Keyboard /Mouse x 1
Universal Serial Bus USB2.0 x 6 (2 on the front panel and 4 at
I/O)
Audio Audio jack x 2 (Mic-in, Line-out)
Ethernet RJ-45 x 1
Display VGA x 1
Environment
Operating
Temperature 32oF~113oF (0oC ~45oC) (Industrial grade
SSD only)
Storage
Temperature
4oF~140oF (-20oC ~60oC)
Operating Humidity 10~80%
Storage Humidity 10~80%, non-condensing
Vibration 0.5 gms/ 5~500Hz/ Random Operation
(2.5” HDD)
Shock 15G peak acceleration (11 m sec.
duration), operation
Chapter 1 General Information 1- 5

Flexible Embedded
System FES-5120
1.4 General System Information
Front Panel
Rear Panel
Chapter 1 General Information 1- 6

Flexible Embedded
System FES-5120
Chapter2HardwareInstallation2-1
Hardware
Installation
Chapter
2

Flexible Embedded
System FES-5120
2.1 Location of Jumpers and Connectors
Main board
Chapter 2 Hardware Installation 2-2

Flexible Embedded
System FES-5120
2.2 Mechanical Drawing
DIO Pin Definition
Chapter 2 Hardware Installation 2-3

Flexible Embedded
System FES-5120
2.3 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP1 Clear CMOS
JP3 LVDS Power Selection
JP4 LVDS Inverter Power Selection
JP5 CFD Voltage 3.3V/5V Selection
JP6 Auto Power on Selection
JP10 COM1 Port Power/Ring Selection
JP11 COM2 Port Power/Ring Selection
COMV1~2 COM1, 2 Port Power Selection
Chapter 2 Hardware Installation 2-4

Flexible Embedded
System FES-5120
2.4 List of Connectors
The board has a number of connectors that allow you to configure
your system to suit your application. The table below shows the
function of each board's connectors:
Label Function
FP1 Front Panel Connector 1
VGA1 VGA Display Connector
COM1、3、4 RS-232 Serial Port Connector
COM2 RS-232/422/485 Serial Port Connector
CFD1 Compact Flash Slot (Master)
LPT1 LPT Port Connector
USB1~2 USB Connector
LAN1 10/100 or 100/1000Base-TX Ethernet Connector
DIMM1 DDRII SODIMM Slot
CN1 LVDS Inverter Power Connector
CN2 LVDS Connector
CN4 Audio Pin Header (right channel)
CN5 Audio Pin Header (left channel)
CN6 USB Pin Header
CN7 Digital I/O Connector
CN8 PS2 Keyboard/Mouse Connector
ATX1 +12V Power Connector
PWR1~2 SATA POWER Connector
SATA1~2 Serial ATA Connector
AUDIO1 Audio Connector
Chapter 2 Hardware Installation 2-5
