AAON RZ Series Owner's manual

RZ SERIES
(45-240tons)
Packaged Rooftop Units & Outdoor Air Handling Units
Installation, Operation,
& Maintenance
oDo not store gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance
oWHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.

Do not touch any electrical switch; do not
use any phone in your building.
Leave the building immediately.

Immediately call your gas supplier from a
phone remote from the building. Follow the
gas supplier’s instructions.

If you cannot reach your gas supplier, call
the fire department.
oStartup and service must be performed by a
Factory Trained Service Technician.
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings
exactly could result in serious
injury, death or property damage.
Be sure to read and understand
the installation, operation and
service instructions in this manual.
Improper installation, adjustment,
alteration, service or maintenance
can cause serious injury, death or
property damage.
A copy of this IOM mustbe kept
with the unit.
