ABA FMC30RF User manual

FMC30RF User Manual r1.3
UM015 www.abaco.com - 1 -
FMC30RF
User Manual
Abaco Systems, USA
Support Portal
This document is the property of Abaco Systems and may not be copied nor communicated
to a third party without the written permission of Abaco Systems.
© Abaco Systems 2015

FMC30RF User Manual r1.3
UM015 www.abaco.com - 2 -
Revision History
Date Revision Revision
2012-05-30 Draft 0.1
2012-05-30 Release after review 1.0
2012-10-05 Additional info on LNA and reference oscillator 1.1
2014-06-11 Update voltage monitoring section
Additional info in Figure 5 and pin out. 1.2
2015-02-12 Added RF input analog line-up description,
updated RF in/out characteristics. 1.3

FMC30RF User Manual r1.3
UM015 www.abaco.com - 3 -
Table of Contents
1Acronyms and related documents ............................................................................. 4
1.1 Acronyms................................................................................................................ 4
1.2 Related Documents................................................................................................. 4
2General description..................................................................................................... 5
3Installation ................................................................................................................... 5
3.1 Requirements and handling instructions.................................................................. 5
4Design .......................................................................................................................... 5
4.1 Phycisal specifications ............................................................................................ 6
4.1.1 Board Dimensions............................................................................................ 6
4.1.2 Front panel coax inputs.................................................................................... 6
4.2 Electrical specifications........................................................................................... 6
4.2.1 EEPROM ......................................................................................................... 6
4.2.2 JTAG................................................................................................................ 7
4.2.3 FMC connector................................................................................................. 7
4.2.4 RF input ........................................................................................................... 7
4.3 Main characteristic .................................................................................................. 9
5Modes of operation.....................................................................................................10
5.1 Time-Division Duplex (TDD)...................................................................................10
5.2 Frequency-Division Duplex (FDD)..........................................................................10
5.3 Multiple-Input Multiple-Output (MIMO)....................................................................10
6Controlling the FMC30RF...........................................................................................11
6.1 Guidelines for controlling the RF path ....................................................................11
6.2 Guidelines for controlling the CDCE62005.............................................................11
6.3 Guidelines for controlling the TRF3765 ..................................................................12
6.4 Guidelines for controlling the TRF3711 ..................................................................12
6.5 Guidelines for controlling the TRF3720 ..................................................................12
6.6 Guidelines for controlling the AFE7225 ..................................................................12
6.7 Guidelines for controlling the AMC7823 .................................................................13
7Power supply..............................................................................................................13
8Environment................................................................................................................14
8.1 Temperature ..........................................................................................................14
8.2 Monitoring..............................................................................................................15
8.3 Cooling...................................................................................................................15
8.3.1 Convection cooling..........................................................................................15
8.3.2 Conduction cooling..........................................................................................15
9Safety...........................................................................................................................16
10 EMC .............................................................................................................................16
11 Ordering information..................................................................................................16
12 Warranty......................................................................................................................16
Appendix ALPC pin-out FMC30RF...............................................................................17

FMC30RF User Manual r1.3
UM015 www.abaco.com - 4 -
1 Acronyms and related documents
1.1 Acronyms
ADC
Analog to Digital Converter
DDR
Double Data Rate
EPROM
Erasable Programmable Read-Only Memory
FBGA
Fineline Ball Grid Array
FMC
FPGA Mezzanine Card
FPGA
Field Programmable Gate Array
JTAG
Join Test Action Group
LED
Light Emitting Diode
LVTTL
Low Voltage Transistor Logic level
LSB
Least Significant Bit(s)
LVDS
Low Voltage Differential Signaling
MGT
Multi-Gigabit Transceiver
MSB
Most Significant Bit(s)
PCB
Printed Circuit Board
PLL
Phase Locked Loop
PSSR
Power Supply Rejection Ratio
Table 1: Glossary
1.2 Related Documents
•FPGA Mezzanine Card (FMC) standard ANSI/VITA 57.1-2010
•CDCE62005 datasheet, TI, August 2011
•TRF3765 datasheet, TI, November 2011
•TRF371109 datasheet, TI, May 2011
•TRF371125 datasheet, TI, December 2010
•TRF372017 datasheet, TI, August 2010
•AMC7823 datasheet, TI, January 2010

FMC30RF User Manual r1.3
UM015 www.abaco.com - 5 -
2 General description
The FMC30RF is an FMC Daughter Card which is fully compliant with the VITA 57.1-2010
standard. The FMC30RF offers in a small footprint a low power and fully featured Rx/Tx signal
path for the development and deployment of advanced RF solutions. With a frequency range
coverage from 400MHz to 3.0GHz (two ranges) and up to 60MHz bandwidth the FMC30RF
provides flexibility and reconfigurability to a host of applications.
Based on Texas Instruments RF technology the FMC30RF comprises of a dual DAC Tx IQ
modulator, a dual ADC Rx IQ demodulator with PGA and LNA front-end and on-board clocking
with integrated PLL/VCO. The FMC30RF allows flexible control on sampling frequency through
serial communication busses. Furthermore the card is equipped with power supply and
temperature monitoring and offers several power-down modes to switch off unused functions.
TRF372017
TRF3765
TRF371109
TRF371125
AFE7225
CDCE62005
FMC
LPC
REF OUT
REF IN
RX CLK
TX CLK
LO
REF
REF
RF I/O
RF IN
ATT
LNA_OUT
TCXO
30.72MHz
* not avalable from front panel
TX VCO IN
TX LO OUT
RX VCO IN
RX LO OUT
LNA_BYPASS_CTRL
TRX_SWITCH_CTRL
TX_VCO_CTRL
RX_VCO_CTRL
CDCE65005_REFEN
SEC_REF
PRI_REF
Figure 1: FMC30RF block diagram
3 Installation
3.1 Requirements and handling instructions
•The FMC30RF daughter card must be installed on a carrier card compliant to the FMC
standard.
•The FMC carrier card must support the low-pin count connector (LPC 160-pins). High
pin count is permitted.
•The FMC carrier card must support VADJ/VIO_B voltage between +1.65V and +5.5V.
•Do not flex the card and prevent electrostatic discharges by observing ESD precautions
when handling the card.
4 Design

FMC30RF User Manual r1.3
UM015 www.abaco.com - 6 -
4.1 Phycisal specifications
4.1.1 Board Dimensions
The FMC30RF card complies with the FMC standard known as ANSI/VITA 57.1. The card is
a single width conduction cooled mezzanine module (with region 1 and front panel I/O). A
front rib on the carrier hardware is not supported. The stacking height is 10mm.
AFE
7225
TRF
3720
TRF
3711
TRF
3765
CDCE
62005
AMC
7823
REF IN
REF OUT
RF IN
RF I/O
TX CLK
RX CLK
Figure 2: FMC30RF dimensions
4.1.2 Front panel coax inputs
The FMC30RF can be ordered with MMCX or SSMC connector type. Six connectors are
available on the front panel.
TX
CLK
RF
I/O
RF
IN
RX
CLK
REF
OUT
REF
IN
Figure 3: FMC30RF bezel layout
4.2 Electrical specifications
The FMC30RF card uses a mix of LVDS and LVCMOS signals. According to the FMC standard
VADJ should be +2.5V to support LVDS, but the FMC30RF is designed to accept any level on
VADJ ranging between 1.65V and 5.5V. VIO_B_M2C connections are connected to VADJ on
the FMC30RF. Level translators are implemented to guarantee VADJ level on the FMC
connector for all single ended communication and control signals.
4.2.1 EEPROM
The FMC30RF card carries a 2Kbit EEPROM (24LC02B) which is accessible from the carrier
card through the I2C bus. The EEPROM is powered by 3P3VAUX. The standby current is only

FMC30RF User Manual r1.3
UM015 www.abaco.com - 7 -
0.01µA when SCL and SDA are kept at 3P3VAUX level. These signals may also be left floating
since pull-up resistors are present on the card.
4.2.2 JTAG
The FMC30RF card TDO pin is connected to the TDI pin (through an SN74LVC1G126 buffer)
to ensure continuity of the JTAG chain. TCK, TMS and TRST are left unconnected on the
FMC30RF.
4.2.3 FMC connector
The low-pin count connector has only bank LA available and two dedicated LVDS clock pairs.
The recommendations from AV57.1-2010 Table 14 have been taking into account resulting in
the following arrangement:
•The ADC data clock pair (ADC_DCLKOUT) and ADC frame clock pair
(ADC_FCLKOUT) are connected to clock capable pins LA00_CC and LA01_CC
respectively. The ADC data pairs are mapped to LA02 to LA05.
•The DAC clock, frame and data pairs are mapped to LA06 to LA12. Since all pairs are
outputs as seen from the FPGA, there is no need to have the clock and frame pair on
clock capable pins.
•LA13 to LA31 are used for low speed single ended communication and control signals.
•The remaining connections (LA32-LA33) are used left unconnected.
•An LVDS output of the CDCE62005 is connected to a dedicated LVDS connections on
the FMC (CLK0_M2C). The other dedicated LVDS connection is not used.
Refer also to the appendix for the detailed LPC connector pinout.
4.2.4 RF input
The RF input circuit comprises tuneable and fixed gain stages. The analog line-up is depicted
in Figure 4.
TRF371109
TRF371125
AFE7225
RF I/O
RF IN
ATT
LNA_BYPASS_CTRL
LNA1
+18dB
LNA2
+18dB
SW2
-0.5dB SW1
-0.5dB
SW3
-0.5dB
ATT:
-1dB to
-32dB
BB Gain:
0dB to
+24dB
Figure 4: RF input analog line-up

FMC30RF User Manual r1.3
UM015 www.abaco.com - 8 -
Guidelines of controlling tuneable gain and attenuators are provided in section 6. The
maximum input level at the RF input is +3dBm and can be applied to the board when the total
gain of the analog line-up is set to minimum. This is done by:
- Bypass LNA2
- Set the stepped attenuator to 32dB attenuation
- Set the BB gain of the TRF3711 to 0dB (default setting is 15dB, refer to the
datasheet of the TRF3711)
Applying a signal of +3dBm to the first stage LNA drives the LNA close to its input 1dB
compression point.

FMC30RF User Manual r1.3
UM015 www.abaco.com - 9 -
4.3 Main characteristic
RF IN
LO Range Low range option: 400MHz – 1200MHz
High range option: 1200MHz – 3000MHz
Bandwidth 60MHz (when LPF in TRF3711xx bypassed)
Input Impedance 50Ω
Maximum Input Level +3dBm1
RF OUT
LO Range 300MHz – 4800MHz
Bandwidth 70MHz
Output Impedance 50Ω
Full Scale Maximum Output Level +3dBm (depending on LO frequency)
Receiver LO (RX CLK)
Output Frequency Range Programmable trough fractional PLL (TRF3765):
300MHz to 4800MHz
Output Impedance 50Ω
Output Level -0.5dBm typ.
Input Frequency Range 300MHz to 4800MHz
Input Impedance High-impedance
Input Level 0dBm
Transmitter LO (TX CLK)
Output Frequency Range Programmable trough fractional PLL (TRF372017):
300MHz to 4800MHz
Output Impedance 50Ω
Output Level -0.5dBm typ.
Input Frequency Range 300MHz to 4800MHz
Input Impedance High-impedance
Input Level 0dBm
External Reference Input (REF IN)
Input Level 0.2VPP - 3.3VPP
Input Frequency 10MHz – 250MHz
Input Impedance 50Ω
External Reference Output (REF OUT)
Output Level 3.3VPP (AC coupled LVCMOS)
Output Frequency 10MHz – 250MHz
Table 2: FMC30RF daughter card main characteristics
1Make sure minimum gain is configured, refer to section 4.2.4.

FMC30RF User Manual r1.3
UM015 www.abaco.com - 10 -
5 Modes of operation
The FMC30RF support different modes of operation; TDD and FDD.
TRF372017
TRF3765
TRF371109
TRF371125
AFE7225
CDCE62005
FMC
LPC
REF OUT
REF IN
RX CLK
TX CLK
LO
REF
REF
RF I/O
RF IN
ATT
LNA_OUT
* not avalable from front panel
TX VCO IN
TX LO OUT
RX VCO IN
RX LO OUT
LNA_BYPASS_CTRL
TRX_SWITCH_CTRL
TX_VCO_CTRL
RX_VCO_CTRL
TCXO
30.72MHz
CDCE65005_REFEN
SEC_REF
PRI_REF
Figure 5: Signal Path
5.1 Time-Division Duplex (TDD)
The FMC30RF supports TDD using the RF I/O connector. The RF I/O connector is either
receiving (TRX_SWITCH_CTRL=0) or transmitting (TRX_SWITCH_CTRL=1). The
TRX_SWITCH_CTRL signal should be driven by the FPGA trough the FMC connector.
5.2 Frequency-Division Duplex (FDD)
The FMC30RF supports FDD using the RF I/O connector for transmitting and the RF IN
connector for receiving. The TRX_SWITCH_CTRL signal should be driven high by the FPGA
trough the FMC connector.
5.3 Multiple-Input Multiple-Output (MIMO)
With two FMC30RF boards a 2x2 MIMO setup can be realised.

FMC30RF User Manual r1.3
UM015 www.abaco.com - 11 -
TRF372017
TRF3765
TRF371109
TRF371125
AFE7225
FMC
LPC
REF OUT
REF IN
RX CLK
TX CLK
LO
REF
REF
RF I/O
RF IN
ATT
LNA_OUT
* not avalable from front panel
TX VCO IN
TX LO OUT
RX VCO IN
RX LO OUT
LNA_BYPASS_CTRL
TRX_SWITCH_CTRL
TX_VCO_CTRL
RX_VCO_CTRL
TCXO
30.72MHz
CDCE65005_REFEN
U0P/N
U4P
CDCE62005
SEC_REF+
PRI_REF+
U3P
U2P
U1P/N
CLK_M2C_P/N
Figure 6: Clock paths
6 Controlling the FMC30RF
Good knowledge of the internal structure and communication protocol of relevant on-board
devices is required for controlling the FMC30RF. This document only provides guidelines for
programming the devices. For detailed information it is recommended torefer to the datasheets
listed in the related documents section of this document.
6.1 Guidelines for controlling the RF path
The following control signals controls the RF frontend;
•TRX_SWITCH_CTRL
•LNA_BYPASS_CTRL
•RF_ATT_V[1..5]
Refer to Appendix A for a description of these signals.
The LNA in the RX path depends on the RF coverage specified at the time of order:
- RF coverage option 1 (400MHz – 1200MHz): SKY67101-396LF
- RF coverage option 2 (1200MHz – 3000MHz): SKY67100-396LF
The gain is 18-20dB for each LNA stage.
6.2 Guidelines for controlling the CDCE62005
The following control signals connect from the FMC connector to the CDCE62005;
•SCLK (shared with other devices)
•SDATA (shared with other devices)
•CDCE62005_CS#
•CDCE62005_SDOUT
•CDCE62005_PD#
•CDCE62005_SYNC#

FMC30RF User Manual r1.3
UM015 www.abaco.com - 12 -
•CDCE62005_LOCK
•CDCE62005_REFEN
Refer to Appendix A for a description of these signals.
6.3 Guidelines for controlling the TRF3765
The following control signals connect from the FMC connector to the TRF3765;
•SCLK (shared with other devices)
•SDATA (shared with other devices)
•TRF3765_CS#
•TRF3765_SDOUT
•TRF3765_LOCK
•RX_VCO_CTRL
Refer to Appendix A for a description of these signals.
6.4 Guidelines for controlling the TRF3711
The following control signals connect from the FMC connector to the TRF3711;
•SCLK (shared with other devices)
•SDATA (shared with other devices)
•TRF3711_CS#
•TRF3711_SDOUT
•TRF3711_PD#
•TRF3711_GAIN_B[0..2]
Refer to Appendix A for a description of these signals.
6.5 Guidelines for controlling the TRF3720
The following control signals connect from the FMC connector to the TRF3720;
•SCLK (shared with other devices)
•SDATA (shared with other devices)
•TRF3720_CS#
•TRF3720_SDOUT
•TRF3720_PS
•TRF3720_LOCK
•TX_VCO_CTRL
Refer to Appendix A for a description of these signals.
6.6 Guidelines for controlling the AFE7225
The following control signals connect from the FMC connector to the AFE7225;
•SCLK (shared with other devices)
•SDATA (shared with other devices)
•AFE7225_CS#
•AFE7225_SDOUT

FMC30RF User Manual r1.3
UM015 www.abaco.com - 13 -
•AFE7225_RESET
•AFE7225_PD
Refer to Appendix A for a description of these signals.
6.7 Guidelines for controlling the AMC7823
The following control signals connect from the FMC connector to the AMC7823;
•SCLK (shared with other devices)
•SDATA (shared with other devices)
•AMC7823_CS#
•AMC7823_SDOUT
•AMC7823_GALR#
•AMC7823_RESET#
Refer to Appendix A for a description of these signals.
7 Power supply
Power is supplied to the FMC30RF card through the FMC connector. The pin current rating is
2.7A, but the overall maximum as specified by the FMC standard is limited according to Table
3.
Voltage
# pins
Max Amps
Max Watt
+3.3V
4
3 A
10 W
+12V
2
1 A
12 W
VADJ (+2.5V)
4
4 A
10 W
VIO_B (+2.5V)
2
1.15 A
2.3 W
Table 3: FMC standard power specification
The power provided by the carrier card can be very noisy. Special care is taken with the power
supply generation on the FMC30RF card to minimize the effect of power supply noise on clock
generation, (de-)modulation, and data conversion.
Clean supply is derived from +3.3V and 12Vin two steps for maximum efficiency. The first step
uses a high efficient switched regulators to generate +3.8V and +5.5V power rails. From these
power rail the analog and digital supplies are derived with a low dropout, low noise, high PSRR,
linear regulator. At several stages in the power supply there is additional noise filtering with
beads and capacitance. Power supplies for different devices are isolated where necessary.

FMC30RF User Manual r1.3
UM015 www.abaco.com - 14 -
Power plane
Typical
Maximum
VADJ
100mA
200mA
3P3V
1.3A
1.6A
12P0V
0.5A
0.6A
3P3VAUX (Operating)
3P3VAUX (Standby)
0.1 mA
0.01 µA
3 mA
1 µA
Table 4: Typical/Maximum current drawn from FMC carrier card
TPS7A8001 (60mA)
3.8V à1.8V
VDD1_1p8
3.8V
5.5V
TPS7A8001 (60mA)
3.8V à1.8V
VDD2_1p8
TPS7A8001 (40mA)
5.5V à5.0V
5V0A_DAC
TPS7A8001 (132mA)
3.8V à3.3V
3V3A_DAC
TPS7A8001 (580mA)
3.8V à3.3V
CDCE_3p3
TPS7A8001 (201mA)
5.5V à4.0V
RF_4p0
TPS7A8001 (360mA)
5.5V à5.0V
TRF3711_5p0
TPS74401(148mA)
5.5V à5.0V
TRF3720_5p0
TPS74401 (250mA)
3.8V à3.3V
TRF3720_3p3
TPS74401 (190mA)
3.8V à3.3V
TRF3765_3p3
TPS63020 (0.75A)
3.3V à5.5V
TPS5430 (1.30A)
12V à3.8V
TPS7A8001 (30mA)
3.8V à3.3V
TCXO_3p3
1.4A @ 3.3V
0.5A @ 12V
Typical power
consumption:
10 Watt
Figure 7: FMC30RF Power Supply Architecture
8 Environment
8.1 Temperature
Operating temperature:
•-40°C to +85°C (Industrial)
Storage temperature:

FMC30RF User Manual r1.3
UM015 www.abaco.com - 15 -
•-40°C to +120°C
8.2 Monitoring
The AMC7823 device may be used to monitor the voltage on the different power rails as well
as the temperature. It is recommended that the carrier card and/or host software uses the
power-down features in the devices in the case the temperature is too high. Normal operations
can resume once the temperature is within the operating conditions boundaries.
Parameter: Voltage Formula
Channel 0 5.0V Analog DAC 2 * ADC0
Channel 1 3.3V Digital/Clock 2 * ADC1
Channel 2 1.8V Analog/Digital 2 * ADC2
Channel 3 4.0V RF 2 * ADC3
Channel 4 5.0V Analog 2 * ADC4
Channel 5 3.3V Analog 2 * ADC5
Channel 6 3.3V TCXO 2 * ADC6
Channel 7 VADJ 2 * ADC7
Temperature (Ch 8)
Table 5: Temperature and voltage parameters
8.3 Cooling
Two different types of cooling will be available for the FMC30RF.
8.3.1 Convection cooling
The air flow provided by the chassis fans the FMC30RF is enclosed in will dissipate the heat
generated by the on board components. A minimum airflow of 300 LFM is recommended.
For stand alone operations (such as on a Xilinx development kit), it is highly recommended to
blow air across the FMC and ensure that the temperature of the devices is within the allowed
range. Abaco’s warranty does not cover boards on which the maximum allowed temperature
has been exceeded.
8.3.2 Conduction cooling
In demanding environments, the ambient temperature inside a chassis could be close to the
operating temperature defined in this document. It is very likely that in these conditions the
junction temperature of power consuming devices will exceed the operating conditions
recommended by the devices manufacturers (mostly +85°C).
The FMC30RF is designed for maximum heat transfer to conduction cooled ribs. A customized
cooling frame that connects directly to the surface of the devices is allowed (contact Abaco for
detailed mechanical information).

FMC30RF User Manual r1.3
UM015 www.abaco.com - 16 -
9 Safety
This module presents no hazard to the user.
10 EMC
This module is designed to operate from within an enclosed host system, which is build to
provide EMC shielding. Operation within the EU EMC guidelines is not guaranteed unless it is
installed within an adequate host system. This module is protected from damage by fast
voltage transients originating from outside the host system which may be introduced through
the system.
11 Ordering information
Part Number: FMC30RF-2-1-1-1
Temperature Range
Industrial (-40
o
C to +85
o
C) = 1
Commercial (0
o
C to +70
o
C) = 2
Connector Type
Standard Feature – MMCX (snap coupling) = 1
SSMC (screw coupling) = 2
RF coverage
400MHz – 1200MHz = 1
1200MHz – 3000MHz = 2
Mil-I-46058c Conformal Coating
No Conformal Coating = 1
Add Conformal Coating = 2
Card Type
FMC30RF
12 Warranty
Hardware Software/Firmware
Basic Warranty
(included) 1 Year from Date of Shipment 90 Days from Date of Shipment
Extended Warranty
(optional) 2 Years from Date of Shipment 1 Year from Date of Shipment

Appendix A LPC pin-out FMC30RF
FMC label FMC30RF Signal Description
CLK0_M2C_N
CLK_TO_FPGA_N Output from CDCE62005
CLK0_M2C_P
CLK_TO_FPGA_P Output from CDCE62005
LA00_N_CC ADC_DCLKOUT_N Connects to AFE7225
LA00_P_CC ADC_DCLKOUT_P Connects to AFE7225
LA01_N_CC ADC_FCLKOUT_N Connects to AFE7225
LA01_P_CC ADC_FCLKOUT_P Connects to AFE7225
LA02_N ADCB_DATA1_N Connects to AFE7225
LA02_P ADCB_DATA1_P Connects to AFE7225
LA03_N ADCB_DATA0_N Connects to AFE7225
LA03_P ADCB_DATA0_P Connects to AFE7225
LA04_N ADCA_DATA1_N Connects to AFE7225
LA04_P ADCA_DATA1_P Connects to AFE7225
LA05_N ADCA_DATA0_N Connects to AFE7225
LA05_P ADCA_DATA0_P Connects to AFE7225
LA06_N DAC_FCLKIN_N Connects to AFE7225
LA06_P DAC_FCLKIN_P Connects to AFE7225
LA07_N DACA_DATA1_N Connects to AFE7225
LA07_P DACA_DATA1_P Connects to AFE7225
LA08_N DACA_DATA0_N Connects to AFE7225
LA08_P DACA_DATA0_P Connects to AFE7225
LA09_N DACB_DATA0_N Connects to AFE7225
LA09_P DACB_DATA0_P Connects to AFE7225
LA10_N DAC_DCLKIN_N Connects to AFE7225
LA10_P DAC_DCLKIN_P Connects to AFE7225
LA11_N DAC_SYNCIN_N Connects to AFE7225
LA11_P DAC_SYNCIN_P Connects to AFE7225
LA12_N DACB_DATA1_N Connects to AFE7225
LA12_P DACB_DATA1_P Connects to AFE7225
LA13_N LNA_BYPASS_CTRL ‘0’ = 2nd LNA is excluded from the RX path
‘1’ = 2nd LNA is included in the RX path
LA13_P TRX_SWITCH_CTRL Behavior on RF I/O connector;
‘0’ = RF I/O connector is receiving (RX)
‘1’ = RF I/O connector is transmitting (TX)
Behavior on RF IN connector;
‘0’ = RF IN connector is disconnected
‘1’ = RF IN connector is receiving (RX)
LA14_N RF_ATT_V1 Connects to SKY12329-350LF V1
LA14_P RF_ATT_V2 Connects to SKY12329-350LF V2
LA15_N TRF3765_CS# Connects to TRF3765 STROBE

FMC30RF User Manual r1.3
UM015 www.abaco.com - 18 -
LA15_P AFE7225_RESET Connects to AFE7225 RESET
LA16_N AFE7225_CS# Connects to AFE7225 SEN
LA16_P AFE7225_PD Connects to AFE7225 PDN
LA17_N_CC RF_ATT_V4 Connects to SKY12329-350LF V4
LA17_P_CC RF_ATT_V3 Connects to SKY12329-350LF V3
LA18_N_CC AMC7823_CS# Connects to AMC7823 SS
LA18_P_CC AMC7823_RESET# Connects to AMC7823 RESET
LA19_N CDCE62005_LOCK Connects to CDCE62005 PLL_LOCK
LA19_P TRF3765_LOCK Connects to TRF3765 LD
LA20_N RF_ATT_V5 Connects to SKY12329-350LF V5
LA20_P TRF3720_LOCK Connects to TRF3720 LD
LA21_N SCLK Connects to:
- CDCE62005 SPI_CLK
- TRF3765 CLOCK
- TRF3720 CLK
- TRF3711 CLOCK
- AFE7225 SCLK
- AMC7823 SCLK
LA21_P TRF3720_CS# Connects to TRF3720 LE
LA22_N RX_VCO_CTRL Behavior on RX CLK connector;
‘0’ = RX CLK connector is VCO output from TRF3765 LO4_OUT
‘1’ = RX CLK connector is VCO input to TRF3765 EXTVCO_IN
LA22_P TRF3720_PS Connects to TRF3720 PS
LA23_N TX_VCO_CTRL Behavior on TX CLK connector;
‘0’ = TX CLK connector is VCO output from TRF3720 LO_OUT
‘1’ = TX CLK connector is VCO input to TRF3720 EXT_VCO
LA23_P TRF3711_PD# Connects to TRF3711 CHIP_EN
LA24_N TRF3711_CS# Connects to TRF3711 STROBE
LA24_P SDATA Connects to
- CDCE62005 MOSI
- TRF3765 DATA
- TRF3720 DATA
- TRF3711 DATA
- AFE7225 SDATA
- AMC7823 MOSI
LA25_N TRF3711_GAIN_B0 Connects to TRF3711 GAIN_B0
LA25_P TRF3711_GAIN_B1 Connects to TRF3711 GAIN_B1
LA26_N CDCE62005_REFEN Behavior on on-board reference clock;
‘0’ = the on-board reference clock is powered down
‘1’ = the on-board reference clock is enabled
LA26_P TRF3711_GAIN_B2 Connects to TRF3711 GAIN_B2
LA27_N CDCE62005_SDOUT Connects to CDCE62005 MISO
LA27_P AFE7225_SDOUT Connects to AFE7225 SDOUT
LA28_N CDCE62005_PD# Connects to CDCE62005 POWER_DOWN
LA28_P CDCE62005_SYNC# Connects to CDCE62005 SYNC
LA29_N TRF3720_SDOUT Connects to TRF3720 RDBK

FMC30RF User Manual r1.3
UM015 www.abaco.com - 19 -
LA29_P TRF3711_SDOUT Connects to TRF3711 READBACK
LA30_N AMC7823_SDOUT Connects to AMC7823 MISO
LA30_P CDCE62005_CS# Connects to CDCE62005 SPI_LE
LA31_N AMC7823_GALR# Connects to AMC7823 GALR#
LA31_P TRF3765_SDOUT Connects to TRF3765 READBACK
LA32_N Not connected
LA32_P Not connected
LA33_N Not connected
LA33_P Not connected
PRSNT_M2C_L
PRSNT_M2C_L
Connects to GND
PG_C2M
PG_C2M Connects to PS_EN
