Abit SI-1NS User manual

SI-1Ns
Socket 478 Server Board
User’s Manual
4200-0353-02
Rev. 1.00

Copyright and Warranty Notice
The information in this document is subject to change without notice and does not
represent a commitment on part of the vendor, who assumes no liability or
responsibility for any errors that may appear in this manual.
No warranty or representation, either expressed or implied, is made with respect to the
quality, accuracy or fitness for any particular part of this document. In no event shall
the manufacturer be liable for direct, indirect, special, incidental or consequential
damages arising from any defect or error in this manual or product.
Product names appearing in this manual are for identification purpose only and
trademarks and product names or brand names appearing in this document are
property of their respective owners.
This document contains materials protected under International Copyright Laws. All
rights reserved. No part of this manual may be reproduced, transmitted or transcribed
without the expressed written permission of the manufacturer and authors of this
manual.
SI-1Ns

Table Of Contents
Chapter 1. Introduction .................................................... 1-1
1.1. Features & Specifications....................................................... 1-1
1.2. Layout Diagram...................................................................... 1-3
1.3. Jumpers & Connectors Description........................................ 1-4
Chapter 2. Hardware Setup.............................................. 2-1
2.1. Precautions ............................................................................. 2-1
2.2. Installing the Server Board..................................................... 2-2
2.3. Install Pentium®4 CPU and Heatsink Supporting-Base........ 2-3
2.4. System Memory ..................................................................... 2-4
2.4.1. Memory Configuration Table...................................2-4
2.4.2. Installing and Removing Memory Modules............. 2-5
2.5. Connectors, Headers, and Switches ....................................... 2-6
2.5.1. ATX Power Connectors............................................ 2-6
2.5.2. FAN Connectors ....................................................... 2-7
2.5.3. CMOS Memory Clearing Header............................. 2-8
2.5.4. Auto-Reboot Switch ................................................. 2-9
2.5.5. Parallel Port Connector............................................. 2-9
2.5.6. Front Panel Switches & Indicators Headers ........... 2-10
2.5.7. IDE Connector ........................................................ 2-11
2.5.8. COM Port Header ................................................... 2-12
2.5.9. Additional USB Ports Header................................. 2-13
2.5.10. Additional VGA Port Header ................................. 2-14
2.5.11. External I/O Panel Connectors ............................... 2-14
Chapter 3. BIOS Setup...................................................... 3-1
3.1. Standard CMOS Features....................................................... 3-2
3.2. Advanced BIOS Features ....................................................... 3-5
3.3. Advanced Chipset Features.................................................... 3-8
3.4. Integrated Peripherals........................................................... 3-10
3.5. Power Management Setup.................................................... 3-13
User’s Manual

3.6. PnP/PCI Configurations ....................................................... 3-15
3.7. PC Health Menu ................................................................... 3-17
3.8. Load Fail-Safe Defaults........................................................ 3-18
3.9. Load Optimized Defaults ..................................................... 3-18
3.10. Set Supervisor Password ...................................................... 3-18
3.11. Set User Password ................................................................ 3-18
3.12. Save & Exit Setup ................................................................ 3-18
3.13. Exit Without Saving ............................................................. 3-18
Chapter 4. Driver Installation .......................................... 4-1
4.1. Setup Items ............................................................................. 4-2
Appendix A. How to Get Technical Support ..................... A-1
SI-1Ns

Introduction 1-1
Chapter 1. Introduction
1.1. Features & Specifications
Processor
• Supports single Pentium 4 478-pin processor up to 3.06GHz and higher.
(Based on 533/400MHz FSB)
Chipset
• Intel845GV Chipset Memory Controller Hub (MCH)
• Supports PCI 2.2, Ultra DMA100 IDE protocol (ICH4)
Memory
• Two 184-pin DIMM sockets support PC1600/PC2100 un-buffered low
profile memory
• Up to 2GB, none ECC memory capacity
LAN
• Intel82550EY
• Dual 10/100Mbps LAN ports
• Support IPsec feature
Security & Acceleration
• Onboard Cavium CN-1005S supporting SSL
Graphics
• Integrated graphics support featured by 845GV
PCI Extension Slot
• 1 PCI 32bit/33MHz extension slot
Storage
• 1 Ultra DMA 33/66/100 IDE channel connector (by ICH4)
Internal I/O Headers
• 2 USB headers (support 4 USB ports)
• 1 VGA pin header
• 1 COM port pin header (for COM2)
• 1 Parallel port pin header
• ATX12V PSU connector
User’s Manual

1-2 Chapter 1
External I/O Panel
• PS/2 keyboard connector
• 2 RJ-45 LAN connectors
• 1 COM port connector (for COM1)
• 1 VGA connector
System BIOS
• Phoenix/Award Plug and Play BIOS
• 4M-bit Flash ROM
Form Factor
• 9.6” x 9.6”
Miscellaneous
• Hardware monitoring, ACPI, Wake on LAN
• Support both 3.3V and 5V PCI Riser Card
 Specifications and information contained herein are subject to change
without notice.
SI-1Ns

Introduction 1-3
1.2. Layout Diagram
User’s Manual

1-4 Chapter 1
1.3. Jumpers & Connectors Description
Jumpers Description Default Setting
CCMOS1 CMOS Clear Pins 1-2 (Normal)
JP1 Auto-Reboot Switch Open (Enabled)
Connectors Description
ATX12V1 4-pin ATX12V Power Connector
ATXPWR1 20-pin ATX12V Power Connector
COM2 External COM2 Bracket Connector
FAN1/FAN2 Fan Connector with monitoring Support
FAN4/FAN5 Fan Connector without monitoring Support
FPIO1 Front Panel Switch Headers
IDE0 Hard Disk Drives Connector
J2/J3 DDR DIMM Slots
J6 PCI 32bit/33MHz
LPT1 Parallel Port Connector
USB1/USB2 Additional USB Ports Connectors
VGA2 Additional VGA Port Connector
SI-1Ns

Hardware Setup 2-1
Chapter 2. Hardware Setup
2.1. Precautions
Please pay attention to the following precautions before setting up any hardware.
1. Always switch off the power supply and unplug the power cord from the wall
outlet before installing the board or changing any settings.
2. Ground yourself properly by wearing a static safety wrist strap before removing
the board from the antistatic bag.
3. Hold the board by its edges. Avoid touching any component on it.
4. Avoid touching module contacts and IC chips
5. Place the board on a grounded antistatic surface or on the antistatic bag that came
with the board.
User’s Manual

2-2 Chapter 2
2.2. Installing the Server Board
Before installing the server board, exam your chassis to ensure this server board fits
into it. Your chassis should support micro ATX form factor.
1. Face the side of the I/O ports toward the rear part of the chassis.
2. Locate the screw holes on the server board and the chassis base.
3. Place all the studs or spacers needed on the chassis base and have them tightened.
4. Line up all the screw holes on the board with those studs or spacers on the chassis.
5. Tightens all the screw holes.
ATTENTION: To prevent shorting the PCB circuit, please REMOVE the metal studs
or spacers if they are already secured on the chassis base and are without
mounting-holes on the server board to align with.
