Abocom SAS2800 User manual

SAS2800 Hi-Gain WiFi
MIMO Signal Booster
Description
Hi-Gain WiFi MIMO Signal Booster (SAS2800) is a Smart
Antenna design that attaches directly to an IEEE 802.11
b
/g
Access Point (AP) over a coaxial cable. Through the use o
f
adaptive beamforming, SAS2800 simultaneously enhances the
AP’s overall range and throughput.
The SAS2800 is designed for 802.11 b/g (11/54Mbps)
dualband applications operating in the 2.4 GHz ISM band.
The SAS2800 allows an 802.11 b/g transceiver to employ up to
four antenna elements for adaptive antenna
p
rocessing which
results in increased RF receiver sensitivity, extended range and
more uniform coverage. The combination of a standard AP and
a SAS2800 device significantly improves the system
performance over the AP alone, which incorporates advanced
combining algorithms that eliminate the need for additional AP
processing resources.
Features
 2.4 GHz ISM Band
 IEEE 802.11 b/g operation
 Completely Standards Compliant
 Supports Most Proprietary Modes including
Atheros SuperG, Static Turbo and Dynamic Turbo
 Up to 12 dB of beamforming gain
 Improves 802.11 b/g Access Points
 Expands Overall Range
 Increases Throughput
 Prolongs Laptop Battery Life
 Provides Uniform Coverage
 Simple Single Cable to AP Connection
 No Software Required

Standards
 802.11g
 802.11b
Dimensions (including case)
 Length 5 in (12.70 cm)
 Width 1 in (2.54 cm)
 Height 4 in (10.16 cm)
Weight
 0.11 lbs (49.90 g)
Humidity

95% non
-
condensing
The SAS2800 is compliant to FCC standards when
tested with a compliant AP unit. Retesting of the final
packaging is required.
The SAS2800 is compliant to UL safety certifications.
Retesting of the final packaging is required.
RF Parameter Unit Min Typ Max
Frequency GHz 2.3 2.4 GHz
ISM
band
2.5
TX Input from AP
to SAS2800 dBm 15 18 19
I/O
 4 SMA Type Antenna Connectors
 1 SMA Type RF Cable Connector
 DC Adapter Voltage 7.5 V
 4 LED Indicators
Indicator LEDs
 Power
 TX
 Channel Number
 Channel Scanning
Parameter Rating
Operating Temperature 0o C to 50 o C
Storage Temperature -40 o to 50 o C
DC Voltage 8.0 V
RF Input from AP to
SAS2800
23dBm
 Specification
 Compliancy  Absolute Maximum Rating
