Abocom WCM5202 User manual

802.11b/g MIMO XR®Wireless MiniPCI Card
The WCM5202 is an IEEE802.11b/g standard mini PCI card
that connects your notebook to a wireless local area. With
MRC (Maximal Ratio Combining) technique, The WCM5202
better expands the transmitting distance and efficiently
eliminates wireless connection dead spots compared with
normal 802.11b/g products. Moreover, the Burst
transmission mode also accelerates the throughput and
improves the actual transmission rate.
The WCM5202 is a very small card that can fit into any
notebook, handheld or desktop computer equipped with a
Mini PCI (Type III B slot) interface for wireless network
applications. It allows you to take full advantage of your notebook’s mobility with access to real-
time information and online services anytime and anywhere. It slides easily into the MINI PCI
expansion slot to enable a wireless connection to your network.
FEATURES
 III-b MiniPCI form factor
 Support 802.11b/g
 1T2R Architecture, with extended range
and dead spot eliminated
 Complete Security Feature - WEP 64/128,
WPA, WPA2, 802.1x and 802.11i
 Cisco CCX V1.0, V2.0 and V3.0
Compliance
 Advanced Quality of Service (QoS) -
802.11e, WMM
 International Regulatory Compliance -
802.11d+h
 Bluetooth Co-existence
 Comprehensive OS support:Win98/SE/ME,
Win2000, WinXP, WinCE, Linux, MAC OSX
 Linux AP Driver Available
 WiFi and WHQL Certification

SPECIFICATIONS
Standard IEEE 802.11b/g Standard
Host Interface MiniPCI Interface 1.0
Operating Voltage 3.3V ± 5%
Power Requirement Power consumption at 11g TX: 455mA
RX: 317mA
RF Connector Type 3
Frequency Range 2.412GHz-2.4835GHz
Number of Selectable
Channels
USA, Canada (FCC): 11 channels (2.412GHz~2.462GHz)
Europe (CE): 13 channels (2.412GHz~2.472GHz)
Japan (TELEC): 14 channels (2.412GHz~2.4835GHz)
Modulation Technique 802.11b: Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
802.11g: Orthogonal frequency division multiplexing
Data Rate
802.11b (11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)
802.11g (54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9
Mbps, 6 Mbps)
802.11b: Both Short and Long preamble
Preamble 802.11g: Long preamble only
Modulation
11g: Orthogonal Frequency Division Multiplexing (OFDM)
54Mbps/48Mbps:QAM-64
36Mbps/24Mbps:QAM-16
18Mbps/12Mbps:QPSK
9Mbps/6Mbps:BPSK
11b: Direct Sequence Spread Spectrum (DSSS)
11Mbps/5.5Mbps:CCk
2Mbps:DQPSK
1Mbps:DBPSK
Security Hardware-Based Encryption/Decryption Using WEP 64/128, WPA,
WPA2, 802.1x and 802.11i
Output Power 54Mbps OFDM: 18~20dBm
11Mbps CCK: 21dBm
Receiver Sensitivity -79dBm at 54Mpbs, 10% PER
<-90dBm at 11Mpbs, 8% PER
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Physical Specifications Weight: 10g
Dimension: 59.75 (L) x 44.6(W) mm
Environment Specifications
Operating Temperature: 0~60°C ambient temperature
Storage Temperature: -20~70°C ambient temperature
Operating humidity: 90% maximum (non-condensing)
Storage humidity: 90% maximum (non-condensing)
EMC Certification FCC Part 15.247 in US
