Abocom UBT2K1H User manual

Created on 8/18/2004
Revised on: 4/14/2006
AboCom System, Inc – RD5 division
Product Code: UBT 2K1H
Description
The UBT2K1H is specifically designed to plug
into an available Universal Serial Bus port
connecting to a desktop or laptop PC. It allows
you to make short-range wireless connections
between Bluetooth devices such as cellular
phones, personal digital assistants (PDA), and
desktop and notebook computers.
The UBT2K1H uses radio transmission; voice and data are transmitted almost
immediately. Bluetooth transmission ensures both protection from interference and
secure data transfers. It helps people to share and access the information that is
important to them more easily.
Link your notebook with your handheld, mobile phone, printer and other Bluetooth
devices within your personal area network (PAN) via a secure short-range wireless
radio link. Get rid of all those troublesome cables and automatically share documents,
browse the internet and synchronize calendars, address books and more.
FEATURE
zComplies with Bluetooth 1.2 specification.
zUses 2.4 GHz ISM frequency band.
zHigh-speed Wireless Transmissions, up to 723 Kbps Data Throughput.
zEnable wireless connectivity between a notebook computer and a cellular phone.
zConnections range up to 100 meters.
zProvides a high degree of security for communications between Bluetooth
devices.
zConnect with Bluetooth devices outside your PAN to quickly and easily share
data, files and information with a friend or co-worker
zSynchronize devices in your Personal Area Network to keep your data consistent.
zEase of use.
zPlug and play installation in Windows2000 / XP

Created on 8/18/2004
Revised on: 4/14/2006
AboCom System, Inc – RD5 division
Product Code: UBT 2K1H
SPECIFICATION
Standard Bluetooth 1.2
Host Interface USB1.1
Antenna Built in the card
LED Indicator Power LED
Frequency Range 2.4000-2.4835 GHz
Number of Selectable Channels 79 channels
Data rate Up to 723 Kbps
Typical Range Devices connect for access and data sharing ranges up to
100 meters
Security Data encryption up to 128-bits
RF Technology Frequency hopping spread spectrum(FHSS)
Topology 8 devices
point-to-multipoint
Transmitter Power Output power meets Class 1
Physical Specifications Weight: 10 g
Dimension: 69.53 (L) X 26.68 (W) X 9.19 (H) mm
Power Requirement Normal Operation: 5V DC, 100mA(Max)
Environment Specifications
Operating Temperature: 0~45℃ambient temperature
Storage Temperature: -20~45℃ambient temperature
Operating humidity: 90% maximum (non-condensing)
Storage humidity: 90% maximum (non-condensing)
Supported OS Windows 2000/XP
Sensitivity -80dBm
Distance 100 M
EMC Certification FCC CE BQB
