The OCZ IBIS solid-state drive is a ground-breaking product on two levels—the storage level and interfacing
level. Unsatisfied with current storage interface options, OCZ developed High Speed Data Link or HSDL, to
eliminate the existing I/O bottlenecks and take SSD technology to new heights. As the first SSD to make
use of the proprietary HSDL interface, the IBIS is capable of delivering incredible, trailblazing performance
(740MBps read/write speeds and up to 120,000 random write IOPS). IBIS SSDs will be available in a
complete spectrum of capacities ranging from 100GB to 960GB. Each IBIS comes in a durable aluminum
3.5 inch housing and is bundled with a single port HSDL adapter card.
D e s i g n & T e c h n o l o g y :
A p p l i c a t i o n s :
Workstation PCs
Desktop PCs
AHigh Speed Data Link SSD for high-end systems & workstations
Part Numbers
UPC
IBIS 100GB
OCZ3HSD1IBS1-100G
842024019930
IBIS 160GB
OCZ3HSD1IBS1-160G
842024019947
IBIS 240GB
OCZ3HSD1IBS1-240G
842024019541
IBIS 360GB
OCZ3HSD1IBS1-360G
842024019954
IBIS 480GB
OCZ3HSD1IBS1-480G
842024019558
IBIS 720GB
OCZ3HSD1IBS1-720G
842024019961
IBIS 960GB
OCZ3HSD1IBS1-960G
842024019565
O C Z I B I S S e r i e s
H S D L 3 . 5 i n S o l i d - S t a t e D r i v e

©2010 OCZ Technology Group, Inc. OCZ reserves the right
to change prices, products, or specifications without notice.
IBIS 100 –160GB
IBIS 240 –960GB
P E R F O R M A N C E
Max Read¹
up to 740 MB/s
up to 740 MB/s
Max Write¹
up to 690 MB/s
up to 720 MB/s
Sustained Write²
up to 550 MB/s
up to 600 MB/s
4KB Random Write³
100,000 IOPS
120,000 IOPS
Seek Time
0.1 ms
0.1 ms
P H Y S I C A L
Usable Capacities (IDEMA)
100GB, 160GB, 240GB, 360GB, 480GB, 720GB, 960GB
NAND Components
Multi-Level Cell (MLC)
Interface
HSDL (High Speed Data Link) single channel
Form Factor
3.5 inch
Controller
4 x SandForce 1222
Dimensions (L x W x H)
146 x 101.6 x 25.4mm
Weight
339g (may vary slightly depending on capacity)
E N V I R O N M E N T A L
Power Consumption
Idle: 6.6 Watts Active: 9.5 Watts
Operating Temperature
0°C ~ +50°C
Storage Temperature
-45°C ~ +85°C
Shock Resistance
1500G
Certifications
RoHS, CE, FCC
R E L I A B I L I T Y
MTBF
2 million hours
ECC Recovery
Up to 24 bytes correctable per 512-byte sector
C O M P A T I B I L I T Y
HSDL
Fully compliant with the HSDL version 1.0 single channel (10 Gbps)
Operating System
Windows XP 32/64 Bit; Windows Vista 32/64 Bit; Windows 7 32/64 Bit
Power Requirements
Standard SATA power connector
A D D I T I O N A L F E A T U R E S
Performance Optimization
Onboard RAID 0
System Integration
Bundled with a single port HSDL adapter card; Bootable
Service & Support
3-Year Warranty, Toll-Free Tech Support, 24 Hour Forum Support
¹ Maximum Sequential Speeds are determined using ATTO
² Sustained transfer rate is measured using Iometer 2008, Queue Depth 32, 128KB
³ Small file I/O performance is measured using Iometer 2008, Queue Depth 32, 4KB Aligned
