Abroco Atom GT Black Edition User manual

GT & RS BLACK EDITION
USER GUIDE
www.abroco.com

CONTENTS
4D ARMREST
RECLINE
ROCKING TILT
HEIGHT ADJUSTMENT
LUMBAR & NECK SUPPORT CUSHIONS
HOW TO ADJUST YOUR CHAIR TO SIT COMFORTABLY
CHAIR MAINTENANCE
3
4
5
5
6
7
7
DIMENSIONS

Lifting lever (A) on the outer side of each
armrest will enable the height to be adjusted,
once you find the desired position release & the
height will be fixed in position.
The armrests can be positioned left, right or
centrally, simply use slight force to manoeuvre in
place. The mechanism inside provides enough
resistance to ensure it remains fixed in place
once the preferred angle is chosen.
HOW IT WORKS
The button (B) found on the inside front end,
allows for the surface area to be shifted forward
& back. Press & hold button to adjust & release
to lock in place.
Button (C) found further back on the inside
allows for the armrest surface to be shifted
from right to left for width adjustment. Press &
hold button to adjust & release to lock in place.
Warning: Be careful when adjusting, keep
fingers clear of underside to avoid injury on
moving parts.
AN ESSENTIAL COMPONENT TO
OPTIMISE YOUR POSITION...
Multi directional with eight ways of
adjustment.
Refined cured foam surface improving
comfort & grip.
Streamline ergonomic design to find the
perfect position for your arms.
A
B
C
3
4D ARMREST

When seated pull lever (A) & gently lean backwards.
Once you have found the perfect position release the
lever & the backrest will fix in place. To return to the
upright position pull the lever & sit upright, the
backrest will automatically return to the default
position.
Warning: Be careful to recline backwards slowly to
prevent any accident.
HOW IT WORKS
A
4
RECLINER
DELIVERING 180 DEGREES OF
RELAXATION...
90° - 180° full length recliner.
Multiple settings for work, rest & play.
Maximising comfort for long periods in
the chair.

CREATE MOTION & EASE TENSION
AT YOUR DESK...
90°-135° rocking tilt mechanism with
multiple lock settings & tension control.
Enable rocking motion, a great way to
ease tension for long sessions.
Fully height adjustable 130 -137cm.
A
5
ROCKING TILT & HEIGHT ADJUSTMENT
HOW IT WORKS
Operated using two paddle levers (A,B) located
on either side of the mechanism. The right hand
paddle (A) is for height adjustment. Lift the
paddle & either apply weight to lower, or use
your feet to semi stand to increase height. Once
the desired height is found release lever to lock
in place.
Pushing down on the left hand paddle (B),
releases the mechanism enabling the
rocking function. Using your feet & body you
can gently push backwards to create the
rocking motion. To lock simply lift paddle (B)
when the desired angle of tilt is found. The
chair can be locked in various settings from
90∞-135∞. The tension of the mechanism
can be controlled by using the cog found
underneath the seat.
Warning: Do not use the rocking tilt with an
extreme recline angle. Reclining back too
far & rocking can be dangerous.
B

Both support cushions can be easily
adjusted using the attached straps.
Simply adjust higher or lower or
unc lip & r emo v e a l tog ethe r
depending on preference.
GOOD POSTURE PREVENTS LONG
TERM DAMAGE...
Improves comfort helping to
maintain correct posture.
Supports your neck & back through
extended sessions.
Fully adjustable & detachable.
6
LUMBAR & NECK SUPPORT CUSHIONS

CHAIR MAINTENANCE
SEAT HEIGHT
Adjust the height so that your feet are flat on the
floor & your knees are slightly lower than your
hips.
Pro Tip: adjust the chair height in combination
with armrest height so that you can use the
keyboard with your wrists & forearms straight
(level with the floor).
4D ARMRESTS
Adjust armrests height so that you can
comfortably use your keyboard with your wrist &
forearms straight. Customise your seating
position further using: left / right, forward /
backward, width inside / outside to fully benefit
from this feature & optimise your position.
BACKREST & RECLINE
When gaming or working at your desk, aim to sit
in the upright position to maintain good posture &
support your spine. To ease tension you can
recline back slightly or lay back completely flat to
rest.
Pro Tip: for the ultimate seating experience
combine the recline setting with rocking function
& lumbar support.
Warning: Be careful to recline backwards slowly
to prevent any accident.
LUMBAR & NECK SUPPORT
Adjust the height of lumbar & neck cushions to
support your lower back & head. Promoting good
posture, the support cushions help to reduce the
temptation to slouch forwards when sitting for
long periods.
MULTI SETTING ROCKING TILT
Use rocking function whilst maintaining an
upright seating position. Gently rock to ease
tension or in combination with the recline feature
when looking to take a break & relax. Use multi
setting lock function to customise tilt angle.
Enable rocking function, lean back & lock at your
desired angle. Use the tension control cog under
the seat to adjust the amount of tension on the
mechanism. This will adjust the amount of
resistance / weight required to rock back &
forth.
Warning: Do not use the rocking tilt with an
extreme recline angle. Reclining back too far &
rocking can be dangerous.
In order to fully benefit from ATOM's ergonomic features its important
you adjust your seating position correctly.
CLEANING
Avoid using any chemicals as this may damage
the PU leather. Use a damp cloth to remove dirt
& stains.
Pro Tip: Periodically checking & tightening all
bolts that connect the backrest, armrests &
mechanism will maintain the chairs structural
integrity, preventing noise associated with loose
fittings.
7
HOW TO ADJUST YOUR CHAIR

www.abroco.com
