PSBBCB1ADJ
ASSEMBLED VIEW
WRENCH
ALLEN KEY
HANGBAR
QTY. 1
TOP UPRIGHT
QTY. 2
ADJUSTABLE
CONNECTOR
QTY. 2
BOTTOM
UPRIGHT
QTY. 2
CASTER (WITH
FLAT WASHER
AND LOCK
WASHER)
QTY. 4 SETS
BASE
QTY. 1
EXPLODED VIEW
FACEOUT QUANTITY
VARIES WITH ITEM
A
STEP 2A
STEP 2B
CASTER
LOCK WASHER
FLAT WASHER
PSBBCB2ADJ
ASSEMBLED VIEW
TOOLS INCLUDED
ASSEMBLY
INSTRUCTIONS FOR:
PSBBCB1ADJ,
PSBBCB2ADJ
SCREW IN THE CASTERS TO THE BASE AS SHOWN USING PROVIDED WRENCH.
STEP 2A
BY HAND, SCREW IN BOTTOM UPRIGHTS.
STEP 2B
TO FULLY TIGHTEN UPRIGHT, PLACE
INCLUDED WRENCH INTO PIPE SLOTS AS
SHOWN. TIGHTEN FULLY
SHEET 1 OF 3 PSBBCB1ADJ, PSBBCB2ADJ
1
2

SET SCREW
P
TIGHTEN
LOOSEN
TIGHTEN SET SCREW USING
THE ALLEN KEY TO LOCK
ADJUSTABLE CONNECTOR IN
PLACE.
BY HAND, SCREW
ADJUSTABLE CONNECTOR
TO BOTTOM UPRIGHTS.
ADJUST SO THAT HAND
WHEELS ALIGN TO THE
OUTSIDE (AS SHOWN ON
THE LEFT.)
WITH ALLEN KEY, SLIGHTLY BACK OUT
SET SCREWS ON ADJUSTABLE
CONNECTOR.
BY HAND, SCREW TOP
UPRIGHTS TO HANGBAR.
LOOSEN HAND WHEEL ON BOTH SIDES •
DROP HANGBAR INTO DESIRED HEIGHT •
LOCK IN POSITION BY TIGHTENING THE •
HAND WHEEL ON BOTH SIDES
SHEET 2 OF 3 PSBBCB1ADJ, PSBBCB2ADJ
4
5
3

FACEOUT FACEOUT
SHEET 3 OF 3 PSBBCB1ADJ, PSBBCB2ADJ
PSBBCB2ADJ
COMPLETE ASSEMBLY BY SCREWING IN FACEOUTS
PSBBCB1ADJ
