AC-FIX PEX-A User manual

MAX
POWER
INSTRUCTIONS
SET ELECTRIC EXPANDER
FOR PEX-A PIPES
(Expansion ring system)
Self-rotatory expanding head
5,0Ah

DESCRIPCIÓN
1. Expander cone
2. Trigger
3. Lock of trigger
4. 2 batteries: 12V 5,0Ah 60Wh
5. Expanding heads
6. Charger 220V 50Hz
7. Lubricant
8. Digital display screen
(disabled)
1
2
73
48
5
6
5,0Ah
WARNINGS
 Remove the battery pack
before starting any work
on the machine.
 When the battery is charging,
keep it away from the water
and the humidity.
 Do not use the tool in an

gases, explosive or dust.
!

ASSEMBLY STEPS
To achieve a good result, it is
essential to cut the pipe as clean
and perpendicular as possible
to its axis.
The pipe ends should be dry and
without grease, so that the plastic ring
will not slide on the pipe during expansion.
The size of the used expansion head must be the one corresponding to the pipe.
1
3
✓✓



2
PEX-a ring without stop edge
Fit the plastic ring onto the pipe so that a
very small part of it (max. 1mm) is outside


loosely, expand the pipe end slightly without
the plastic ring.
Then put the ring back on
the end of the pipe sticking out
a bit (max. 1 mm).
PEX-a ring with stop edge or EVO-PLUS ring
Place the ring on the end of the pipe until the
pipe reaches the stop edge of the ring.
90º
Before pulling the trigger, make sure the
trigger safety is unlocked. Press the button,
on the side of the tool that has a picture of
the open padlock.
View image.
ASSEMBLY STEPS

ASSEMBLY STEPS
Keep the head of expansion and the cone always clean

that does not loose lint, then apply a thin layer of grease on it.
Do not lubricate it too much.

into the pipe.



expand once more.
5
6
Screw in the expander head of the appropriate
measure on the tool. 
into the pipe, then push the trigger; the expander
head will expand and retract continuously while
the trigger is pressed. Each time the segments
retract, repeatedly and gently push the pipe inward
on the expander head several times (*) until the pipe
and ring are at level with the shoulder of the expan-
sion head. The expander head must not be pushed
inwardly of the pipe so as not to block the move-
ment auto-rotation. Finally, remove the pipe when
the segments retract and then release the trigger.
󰀨
4
✓
www.ac-x.com
The joint can be pressurized after 30 minutes with
temperatures up to + 5 °. At lower temperatures, this
time increases according to the table below. The
maximum test pressure, which must not be excee-
ded, is 20 bar (2.0 MPa). At room temperature, after
about 6 hours, the joint will be as strong as the tube.
(*) The approximate number of expansions depends on the diameter of the pipe:
16 x 1,8: 4 16 x 2,2: 6 25 x 2,3: 8 25 x 3,5: 20
20 x 1,9: 6 20 x 2,8: 12 32 x 2,9: 12 32 x 4,4: DO NOT USE
DO NOT USE WITH PIPES 32 x 4,4!

temperatures
Time to
test pressure
+5ºC — +1ºC 1,5 hours
±0ºC — -4ºC 3 hours
-5ºC — -9ºC 4 hours
-10ºC — -15ºC 10 hours
✓
Carry out the tightness test according to
test procedure A of the standard

Leak test
