Access Lighting 20370MG Installation instructions

(4) PREPARE THE FIXTURE
1. If you are replacing an existing fixture, disconnect and
remove the old fixture. Expose the supply wiring from the
outlet box.
2. Place the supplied long screws through the holes in the
crossbar and facing outward.
3. Secure crossbar to outlet box with the supplied short
screws. (The long screws should be facing out from the
wall).
4. Connect the Black wire from the fixture to the Black supply
wire and the White fixture wire to the White supply wire,
fasten securely with supplied wire nuts and secure wire
nuts with UL listed electrical tape (not supplied). Tuck the
wires carefully into the Junction box.
5. Connect the ground wire from the fixture to the electrical
supply ground wire, or attach the ground wire directly to
the ground screw on the crossbar. Fasten securely with
supplied wire nuts and secure wire nuts with UL listed
electrical tape (not supplied). Tuck the wires carefully into
the Junction box.
6. Put the long screws through the 2 holes allocated in the
fixture back plate. Secure the fixture against the wall by
screwing on the supplied nut caps.
7. Insert the bulbs. DO NOT EXCEED THE WATTAGE AS
INDICATED ON THE WARNING LABEL.
8. Place the metal frame over the glass diffuser (5) onto the
fixture back plate and secure by screws at corners. Place
fixture cover on top of metal frame and aligning the two
holes on the left and right hand side of the fixture. Secure
with the supplied screws.
9. It is strongly recommended that you caulk this fixture
around the back plate, where it makes contact with the
wall.
CAUTION:
Ensure that the Fitting is Cool and Switched off,
Before Changing Bulbs.
Do Not use Bulbs Exceeding Maximum Wattage as Per
Caution Label.
Do Not Touch the Bulb while fixture is in operation.
Do Not place fixture in close proximity to any
combustible material.
***READ & SAVE THESE INSTRUCTIONS ***
MODEL 20370MG
INSTALLATION & OPERATION INSTRUCTIONS
1) TOOLS AND MATERIALS REQUIRED
Blade Screwdriver
Adjustable Wrench
Wire Cutters
2 x 60W/E-26/Bulbs
Attention:
Before assembling your lighting fixture, please read
the following instructions.
(2) GENERAL
1. To ensure the success of the installation, be sure to read these
instructions thoroughly before beginning.
2. All electrical connections must be in accordance with local codes,
ordinances, or the National Electrical Code. If you are unfamiliar
with methods of installing electrical wiring, secure the services of a
qualified licensed electrician.
3. These fixtures are intended for mounting to a standard 4” x 2 ¼ ”
deep metal octagon outlet box. The box must be directly supported
by the building structure and must be U.L. Recognized
4. Before commencing with the installation, disconnect the power
by turning off the circuit breaker or by removing the fuse at the
fuse box. Turning the power off using the light switch is not
sufficient to prevent electrical shock.
NOTE:
The important safeguards and instructions appearing in
this manual are not meant to cover all possible conditions
and situations that may occur. It must be understood that
common sense, caution and care, are factors that cannot
be built into any product. The person(s) caring for and
operating the fixture must supply these factors.
(3) UNPACKING THE FIXTURE
On checking the contents of the box you will find;
1. Universal Crossbar
2. Fixture Assembly
3. Mounting Hardware packet
4. 1x Glass Diffusers

MODEL 20370MG
WALL
Junction box
1
Crossbar set
Wire nuts
2
Nuts &
washers
Bulbs Max.2x60W
4
waterproof gasket
glass diffuser
Metal frame
Screws x 6
Screws x 4
Top cover
