Access Lighting SLANT DLC 20786LED User manual

IMPORTANT
Before assembling your access lighting fixture, please make sure that
you carefully read through these instruction sheets. Consider having
your fixture installed by a qualified licensed electrician.
NOTE: The important safeguards and instructions that appear in this
manual are not meant to cover all possible conditions and situations
that may occur. It must be understood that common sense, caution and
care, are factors that can’t be built into any product. These factors must
be supplied by the person(s) caring for and operating the fixture.
STEP BY STEP INSTRUCTIONS
Before starting your installation disconnect the Power by turning off the
Circuit Breaker or by removing the fuse at the fuse box. Just turning the
light off at the light switch is not sufficient to prevent electrical shock.
PREPARE FIXTURE
If there is an existing fixture remove it.
Loosen the bottom screw at the back and open the
housing.
1
GENERAL INFORMATION
All electrical connections must be in accordance with all ordinances,
Local and National Electrical Codes. These fixtures are intended for
mounting to a standard 4” x 2 1/2”metal octagon outlet box. The box
must be directly supported by the building structure and U.L. Recognized.
WHAT YOU NEED
• Screwdriver
• Wire Cutters
• Wiring Supplies as Specified
by Electrical Code
INSTALLATION INSTRUCTIONS
WHAT WE PROVIDE
• Mounting Hardware
• LED
COLLECTION
1
CERTIFICATION: ETL WET NO. 20786LED
20786LED
APPLICATION MODEL NO.
OUTDOOR
SLANT DLC

2
4
2
CERTIFICATION: ETL WET NO. 20786LED
3
MOUNT THE MOUNTING BOX
Expose the supply wiresfrom the J-box.
Mount the mounting box to the J-box with the supplied
screws.
MAKE WIRE CONNECTIONS
Gently pull the supply wires through the hole in the
back housing. Connect the black supply wire to the black
fixture wire. Secure with the supplied wire nuts.
Connect the white supply wire to the white
fixture wire. Secure with the supplied wire nuts. Either
wrap the green wire around one of the protruding screws
or connect it to the supply ground wire. Secure all wires
with electrical tape (not supplied).
Tuck all wires carefully into the mounting box.
Close and tighten the bottom screw
at the back
RESTORE THE ELECTRICITY AND
CHECK THE OPERATION OF YOUR
NEW ACCESS FIXTURE
