Accessible Technologies PROCHARGER 2014+ C7 Corvette User manual

2014+ C7 Corvette
Competition Race Kit
Installation Guide

© 2020 Accessible Technologies, Inc.
Accessible Technologies, Inc.
14801 W. 114th Terrace
Lenexa, KS 66215
Phone: [phone]
Fax: [phone]
[e-mail]
All rights reserved. Accessible Technologies Inc. hereby grants permission to use and reproduce this
document for personal use, provided that all copyright information be retained. Reproduction of this
document for unauthorized commercial use is strictly prohibited.
Information in this document is subject to change without notice.
ProCharger is a registered trademark and The Intercooled Supercharging Experts!TM and Designed to
Blow Away the CompetitionTM are trademarks of Accessible Technologies, Inc. and may not be used
without express permission.
Revised 8/20 Part Number PMGU1A-007 Rev. F Printed in the USA
You should also have the following gauges available to properly check the finished installation and monitor
your vehicle’s performance (especially for testing):
• Manifold Boost Pressure Gauge • Fuel Pressure Gauge • Wide Band Oxygen Sensor and Gauge
Gauges should be of a type that can be read from the cockpit while performing a wide-open throttle road
test. Cockpit or hood-mounted gauges are preferable. In order to obtain usable readings, the gauges should
measure pressure at the intake manifold and fuel rail. IF VEHICLE DOES NOT MAINTAIN PROPER FUEL
PRESSURE (50-65 PSI), DECREASE THROTTLE APPLICATION IMMEDIATELY. In some cases, extra vehicle
modifications can strain the stock fuel pump. If your vehicle has difficulty retaining adequate fuel pressure,
contact ATI ProCharger about the availability of an upgraded fuel system.
The engine on which the ProCharger®is to be installed should retain the factory compression ratio. If it
has been modified in any way, please consult ProCharger staff before proceeding with the installation. This
supercharger system is intended for use on STOCK, strong, well-maintained engines/transmissions. Installation
on a worn or troublesome powertrain should be reconsidered. ATI PROCHARGER WILL NOT BE HELD
RESPONSIBLE FOR DAMAGE TO A VEHICLE’S POWERTRAIN. ATI ProCharger is not responsible for ECM
tuning/programming on non-stock vehicles. ATI PROCHARGER recommends verifying that your vehicle has
current ECM updates from the vehicle manufacturer before installation.
For best performance and reliability, always use premium grade fuel (91 octane or higher) and listen closely
for signs of detonation, which might sound like ball bearings rolling around in a tin can. IF DETONATION
SHOULD OCCUR, OR IF YOU ARE UNSURE WHETHER WHAT YOU’RE HEARING IS DETONATION,
DECREASE THROTTLE APPLICATION IMMEDIATELY and please consult ATI ProCharger staff. Detonation
should not be an issue with a properly installed intercooled supercharger system, though OEM factory-shipped
engine and parts inconsistencies are possible on any vehicle.

2014+ C7 Corvette Competition Race Installation Guide i
Introduction
Congratulations on purchasing your
ProCharger®2014+ C7 Corvette Competition
Race Kit. Read this entire manual before you
attempt to install your ProCharger kit. It is
imperative that you follow all of the instructions
in the order they appear in this installation
guide. If you have any questions regarding any
aspect of this installation, call us at (913) 338-
2886.
For best results, we recommend reviewing
the installation instructions beforehand, and
following the installation instructions closely
and in sequence. A detailed packing list has
been provided to assist you in identifying the
components of your ProCharger system.
Tech Tip: Installing spark plugs that
are one heat ranger colder than stock
and gapping your plugs to .035” is
recommended.
Warning: Read and understand all
safety precautions in this manual
before installation. Failure to comply
with instructions in this manual could
result in personal injury, property
damage, and/or voiding your warranty.
Required Tools and Supplies
• Open End Wrench Set (standard & metric)
• 3/8” & 1/2” Socket Sets (standard & metric)
• 3/8” Hex Bit Set (standard & metric)
• 7mm & 8mm nut driver
•T15, T20, T25, T30 Torx driver
• Inch-Pound Torque Wrench
• Flat & Phillips Screwdrivers
• Plier Set
• Drill & Drill Bits
• Hack Saw
• Recipricating Saw
Warning: Your supercharged Corvette
must always be run on 91 octane or
better gas. The best way to insure
this is to run the tank near empty
(below 1/4) and fill with 91 octane for
several tanks prior to installing the
supercharger.
IntroductIon

ii 2014+ C7 Corvette Competition Race Installation Guide
Introduction
table of contents
Introduction .................................................................................................................................. i
Table of Contents..........................................................................................................................ii
Getting Started............................................................................................................................ 1
Crank Pulley............................................................................................................................... 10
Intercooler Component Install ................................................................................................... 14
Cooling System Modifications.................................................................................................... 19
Optional Intake Manifold........................................................................................................... 21
Intercooler and Tubing............................................................................................................... 26
ProCharger Installation .............................................................................................................. 31
Intercooler Water Routing ......................................................................................................... 34
Air Inlet...................................................................................................................................... 38
PCV System................................................................................................................................ 39
Surge System............................................................................................................................. 42
Intercooler Pump Wiring............................................................................................................ 45
Final Assembly ........................................................................................................................... 46
Operation and Maintenance ...................................................................................................... 48
Limited Warranty ....................................................................................................................... 50

2014+ C7 Corvette Competition Race Installation Guide 1
Getting Started
GettInG started
Read and understand all safety precautions in this manual before installation. Failure to
comply with instructions in this manual could result in personal injury, property damage, and/
or voiding your warranty.
(A) Factory Air Filter Box
(B) Mass Airflow (MAF) sensor
(C) Factory Air Inlet
(D) Plastic Coil Covers
Completion of this section will configure the
vehicle for system installation:
A
B
C
D

22014+ C7 Corvette Competition Race Installation Guide
Getting Started
1Disconnect the negative battery cable
from the battery.
2Use a 7mm to remove the (4) screws
holding the air scoop to the radiator.
3Disconnect the MAF (Mass Air Flow)
sensor.
4Remove the coil covers on both sides.
5Disconnect the PCV hose on the driver’s
side valve cover by squeezing the clip
and pulling up.
6
Wet sump vehicles: Remove the PCV
hose on the passenger’s side that goes
from the passenger’s valve cover to the
air inlet box.
7
All Dry sump vehicles: Remove the PCV
hose on the passenger’s side that goes
from the dry sump oil reservoir to the air
inlet box.
MAF Connector
Disconnect MAF Harness From Intake Tube
Remove PCV Hose (All Dry Sump)
Remove-
PCV Line
Remove Air Scoop Screws
Remove (4) 7mm Screws

2014+ C7 Corvette Competition Race Installation Guide 3
Getting Started
8
2017+ Dry sump vehicles only:
Disconnect the hose connection near the
dry sump oil reservoir.
9
2017+ Dry sump vehicles only: Remove
the line that goes from the driver’s side
valve cover to the oil reservoir that was
disconnected in the previous step.
10
2017+ Dry sump vehicles only: Remove
the line from the oil reservoir that runs
from the passenger valve cover to the
dry sump tank.
11
2017+ Dry sump vehicles only: Place
the supplied rubber cap over the open
bung on the oil reservoir. Secure with a
hose clamp.
12
2017+ Dry sump vehicles only: Connect
the line removed from the oil reservoir
in step 10 to the loose hose removed in
step 8 above.
Disconnect Hose (2017+ Dry Sump)
Remove Line (2017+ Dry Sump)
Cap Oil Reservoir (2017+ Dry Sump)

42014+ C7 Corvette Competition Race Installation Guide
Getting Started
13 Use an 8mm to loosen the hose clamps
at the throttle body and at the MAF
tube. Remove the air inlet assembly.
14 Use a T20 Torx to remove the (2) screws
holding the MAF tube to the air filter
box.
15 Use a 10mm to remove the (2) bolts
holding the air box to the fender.
Remove the air filter box from the car.
16 Ensure the parking brake is fully
engaged. Raise the front of the vehicle.
Support with jack stands
17 Remove the front wheels from the
vehicle.
18 Use a 10mm to remove the (7) screws
and (1) plastic push-pin that hold the
rubber panel under the car.
19 Use a 7mm to remove the 10 screws on
the bottom of the front fascia. Remove
the hard plastic skid panel.
Loosen Clamps and Remove Fasteners
Loosen Clamps
Remove fasteners
Front Fascia Lower Screws (x10)
Remove x10
Rubber Panel Screws
Push Pin

2014+ C7 Corvette Competition Race Installation Guide 5
Getting Started
20 Use a T15 Torx to remove the screws
that attach the wheel liner to the fascia
(3 per side).
21 Reach through the opening in the
bottom of the wheel liner to gain access
to the turn signal harness. Unlock the
safety clip and unplug the connector on
each side.
22 Use a 7mm to remove the 5 screws that
hold the plastic shroud to the fascia.
23 Unclip and remove the plastic covers in
the corner of the fascia and fender on
each side.
Wheel Liner Screws (3 Per Side)
Fascia to Shroud Screws (x5)
Fascia Shroud ScrewFascia Shroud Screw
Plastic Corner Covers

62014+ C7 Corvette Competition Race Installation Guide
Getting Started
24 Remove the 2 plastic clips and (4) T30
Torx screws at the top of the fascia.
25 Pull up on the fascia near the headlights
to unclip. Remove the fascia.
26 Use a 10mm to remove the bolt that
attaches the wheel liner to the cradle
(each side).
27 If equipped with brake cooling ducts,
use a 10mm to remove the bolts that
hold the duct to the cradle (each side).
Brake Cooling Duct Bolt (x2)
Brake Duct BoltBrake Duct Bolt
Top Fascia Fasteners
Wheel Liner to Cradle Bolt (x2)
Wheel Liner BoltWheel Liner Bolt

2014+ C7 Corvette Competition Race Installation Guide 7
Getting Started
28 Use zip ties to hold the radiator in place
before removing the cradle. Leave the
zip ties very loose to allow for radiator
movement in later steps.
29 Use a 13mm to remove the (2) radiator
to plastic shroud bolts.
30 Use a 10mm to remove the (2) cooling
fan bolts. Detach the (2) radiator hose
clips and wiring harness clips from the
fan.
31 Remove the fan.
32 Use a 10mm to remove the (2) bolts that
hold the plastic shroud to the cradle
from the back side.
Zip Tie Radiator
Shroud to Cradle Bolt (x2)
Radiator and Fan Bolts (x2)
Radiator to Plastic
Shroud Bolt
Cooling Fan Bolt

82014+ C7 Corvette Competition Race Installation Guide
Getting Started
33 Detach the wiring harness from the
cradle on the passenger’s side. Use a
13mm to remove the (4) cradle bolts and
remove the cradle.
34 Remove the (4) plastic push-clips that
hold the plastic shroud to the bottom of
the front bumper support.
35 From the top, use a 13mm to remove
the (3) bolts holding the shroud to the
bumper support.
36 Remove the ambient air temperature
sensor from the plastic shroud.
37 Push the radiator up and towards the
engine. Maneuver the plastic shroud
down and out of the car. It will not be
reused.
Cradle Bolts (x4)
Cradle Bolt
Shroud to Bumper Support Bolts
Shroud Bolts
Ambient Air Temperature Sensor Removed

2014+ C7 Corvette Competition Race Installation Guide 9
Getting Started
38 Use a T15 torx to remove the (2) screws
holding the air scoop.
39 Pull the air scoop away from the hood in
order to remove it.
40 Using a 15mm socket rotate the
tensioner to the passenger side to
remove the factory belt.
Remove Air Scoop Screws
Tensioner Bolt

10 2014+ C7 Corvette Competition Race Installation Guide
Crank Pulley
crank Pulley
1Use a 13mm to remove the (2) ABS
bracket bolts.
2Use an 18mm to remove the (2) steering
rack bolts.
3Use an 18mm to remove the (2) bolts
that hold the sway bar bracket to the
frame.
4Use a 21mm to loosen the (4) K-member
bolts. Back the bolts as far out as
possible, leaving only a few threads
engaged.
5Use a pry bar to separate the k-member
from the frame. While separated, insert
the supplied 1” spacer in between the
k-member and the frame at the front
bolt. Repeat for the other side.
K-member Bolt (x4)
K-Member Bolt
ABS and Steering Rack Bolts
ABS Bracket Bolts
Steering Rack Bolt
Sway Bar
Bracket Bolt
Spacer Between K-member and Frame
Insert Spacer

2014+ C7 Corvette Competition Race Installation Guide 11
Crank Pulley
6Use a 13mm to remove the (4) bolts that
hold the caps on the sway bar bushings.
Push the sway bar up and toward the
front of the car.
7Prop the hood up. Remove the hood
struts where they mount to the sway bar
bracket by prying back the locking clip.
Use a 15mm to remove the sway bar
bracket bolt on each side. Remove the
sway bar bracket.
8Push the steering rack up to gain access
to the crankshaft balancer bolt.
9Use a 24mm socket and an impact gun
to remove the balancer bolt.
Tech Tip: Using a torch to heat the
crank balancer bolt makes removal
easier. If an impact gun won’t remove
the balancer bolt, put the car in a
high gear and have someone apply
the brakes. Use a breaker bar and
extension to loosen the balancer bolt.
Tech Tip: For vehicles utilizing the
ATI Performance Products balancer,
refer to manufacturer’s instructions for
proper installation.
Crankshaft Balancer Bolt
Sway Bar Bolts
Sway Bar Bolts
Sway Bar
Bracket Bolt
Hood Strut

12 2014+ C7 Corvette Competition Race Installation Guide
Crank Pulley
Tech Tip: Inspect the outer edge of
the machined washer surface on the
factory balancer. This surface is critical
for centering the drive pulley. Use a file
and sandpaper to removed any burs or
sharp edges.
10 Insert the (6) 5/16 bolts and washers
through the supplied crank pulley. Apply
Loctite 272 to the bolts and thread the
(6) supplied cam locks onto the threads
from behind the pulley.
11 Use a 1/2” socket to lightly tighten the
cam locks with the lobe end facing away
from the center of the pulley and slightly
towards an adjacent cam lock(as shown).
This will provide clearance between the
cam locks and the balancer webs.
12 Insert the crank pulley over the balancer.
Rotate the pulley until it sits up against
the balancer.
13 Insert the supplied crankshaft bolt and
washer. Thread the bolt in until hand
tight.
14 Back the cam lock bolts off
approximately 1 turn. Rotate the crank
pulley counterclockwise until the cam
locks stop the pulley.
Clean Factory Balancer Edge
Cam Lock Assembly Direction
Crank Pulley and Cam Lock Assembly

2014+ C7 Corvette Competition Race Installation Guide 13
Crank Pulley
15 Use a 24mm to tighten the crank bolt
to 240 ft-lbs. Compare spacing to the
image at the right to ensure the pulley is
properly seated against the balancer.
16 Use a 1/2” socket to tighten the cam
lock bolts.
17 Insert the supplied 8 rib belt over the
crank pulley.
18 Reinstall the sway bar brackets to the
k-member. Reinstall the hood struts.
19 Put the sway bar back into place and
reinstall the sway bar caps.
20 Use a pry bar to separate the k-member
from the frame and remove the spacer
from each side.
21 Tighten the (4) k-member bolts.
22 Reinstall the (2) sway bar bracket bolts.
23 Reinstall the (2) steering rack bolts.
24 Reinstall the (2) ABS bracket bolts.
Crank Pulley Installed

14 2014+ C7 Corvette Competition Race Installation Guide
Intercooler Component Install
Intercooler comPonent Install
Heat Exchanger Install:
1Maneuver the new air dam into place of
the old one. Secure the (3) top bolts with
a 13mm. Secure the (2) engine bay bolts
with a 10mm.
2Slide the supplied heat exchanger into
the new air dam such that the threaded
studs go to the passenger side.
3Secure the heat exchanger to the plastic
air dam on the passenger side using the
(2) M6 nuts.
4Insert the ambient air temperature
sensor into its designated hole in the air
dam. Plug it in.
Heat Exchanger Install
Ambient Air Temp Sensor Location
New Air Dam Install

2014+ C7 Corvette Competition Race Installation Guide 15
Intercooler Component Install
5If equipped with a factory transmission
cooler, route the cooler and lines through
the cradle before mounting the cradle.
6Use a 13mm to reinstall the cradle using
the (4) factory bolts.
Expansion Tank Install (Passenger Side):
7Install the provided fittings into the
expansion tank as shown.
Transmission Cooler Lines
Cradle Reinstall
Cradle Bolt
Expansion Tank Fittings Installed

16 2014+ C7 Corvette Competition Race Installation Guide
Intercooler Component Install
Expansion Tank Rear Mount
8If equipped, lay the passenger side brake
duct over the expansion tank as shown.
9Using a 10mm insert the provided (1)
M6-1.0 x 20mm bolt into the cradle
as shown to secure the front of the
expansion tank.
10 Using a 10mm insert the other provided
(1) M6-1.0 x 20mm bolt into the cradle
as shown to secure the back of the
expansion tank.
Expansion Tank
Expansion Tank Front Mount
