USA Trains EXTENDED VISION CABOOSE User manual

This product is built with pride by USA Trains and is covered by
a limited warranty. (See limited warranty terms). Please follow these
instructions carefully before returning:
1. Return caboose in its original blue/red box with the proper foam inserts
and then pack the original box in a proper shipping carton so it is well
protected in shipment. The package must be fully insured and prepaid.
USA Trains is not responsible for damage or loss during shipment.
2. Include a note explaining the problem and servicing you need
performed. Be sure to include your name, street address, (NO P.O. BOXES
PLEASE) City, State, Country (if outside U.S.A) and zip code along with a
daytime phone number including area code. If the service is not covered
by warranty, a reasonable service fee will be charged. For any caboose
to be returned outside the continental U.S.A., please include $20.00 U.S.
currency to cover return postage. Any cabooses returned to customers in
the continental U.S.A. will be pre-paid by USA Trains.
3. Ship your item to:
USA TRAINS
662 CROSS STREET
ALDEN, A. 02148
SERVICING
E TENDED VISION
CABOOSE
INSTRUCTIONS
This USA Trains caboose is warranted for one year from the date of
purchase against defects in material or workmanship. We will repair or
replace (at our option) the defective part without charge for parts or
labor within one year of the original date of purchase. This warranty does
not cover items that have been abused or damaged by careless
handling or improper operation such as a train derailment, modification
or repair by non-factory technicians. Parts that “wear out” due to
excessive use are also not covered under warranty. USA Trains reserves
the right to determine “excessive use”. Transportation costs incurred by
the customer are not covered under this warranty.
LIMITED ONE YEAR WARRANTY
USA TRAINS
USA TRAINS
662 CROSS STREET
MALDEN, MA 02148, USA
www.usatrains.com
781-322-6084
KNUCKLE COUPLER INSTALLATION
•
•
•
Remove Hook & Loop coupler.
Clip tab "A" from end of tongue
and file smooth.
Attach USA knuckle coupler "B"
with #4 screw (C) provided. A
B
C

Dear Customer,
Congratulations on your purchase of this
highly detailed, high quality G scale caboose. This
unit is equipped with a rechargeable battery
circuit which will allow the rear ETD light to remain
illuminated while the caboose remains stopped
in your freight yard. This feature is unique to
USA Trains and shows that we are committed to providing you with the best
possible product at a reasonable price.
We thank you for your support and hope you enjoy our products.
Happy Railroading
USA TRAINS
Rechargeable battery installation is necessary for ETD to flash without
track power.
(1) Slide bottom of roof ladder away from caboose and them push the
ladder up so it detaches from catwalk.
(2) Grab end of platform (both ends) and slide away from caboose so it
is slightly detached from caboose. Slide complete handrail assembly
down so handrails detach from the roof.
(3) Remove the three screws underneath caboose. Remove the two
screws from underside of roof on each end. A Chapman wratchet
set is recommended for this due to the angle at which the screws
must be removed. Drop down the roof panels to access roof screws
on each end of caboose remove screws and lift roof off.
(4) Open battery compartment on inside of caboose and install a 9 volt
nicad rechargeable battery. ake sure (+) and (-) are correctly
matched.
(5) Reassemble caboose - make sure to put the handrails in roof first
and then slide handrail assembly back on to caboose underframe.
NOTE:
Roof will only fit on one way with rear light toward rear of caboose.
Do not force roof on - it is keyed and should fit on without difficulty.
(6) Use the three position switch on the bottom of the caboose to select
your light operation.
RECHARGEABLE BATTERY INSTRUCTIONS
The battery must be charged in an external battery charger for 12 hours
before installation in caboose.
NOTE: RECHARGEABLE BATTERY INSTALLATION IS NECESSARY FOR ETD
LIGHT TO STAY ON.
RECHARGEABLE BATTERY
THREE POSITION SWITCH
ALL
LIGHTS
ON
REAR
LIGHT
ON
ALL
LIGHTS
OFF
Interior light and
rear ETD light on
from track power
rear ETD light
only from
battery power
(1) (2)
(3)
