DHK Hobby 8136 Operator's manual

8136 Model :8137
1:10 Scale 4WD Monster Truck
(Brushed & Brushless Versions)

Thank you for choosing DHK’s R/C model! This model is designed in thorough research and
assembled with utmost craftsmanship. This high performance 1:10 scale 4WD monster truck can run
very fast. It is easy to drive and it uses quality parts to achieve its best performance. With proper and
regular maintenance, you will enjoy a lot of fun and joy when you drive this R/C kit.
Before you drive this model, kindly take some time to read through this instruction manual for a better
and safer operation. This instruction aims to provide a general guideline for end-users. Kindly note
that a good understanding of the model, its relevant parts and other accessories packed in the
consumer box will enable you to have fun when driving. Meanwhile, users are recommended to
conduct regular maintenance for high performance and durability. Failure to do so might shorten the
lifespan of the model. If you come across any problems or need any support, please contact us. We
will always be very happy to assist you.
Before you operate this R/C kit, kindly make sure that you understand the following.
1.Make sure that all screws and nuts are tightened securely.
2.Make sure that the battery(ries) are fresh or fully charged so the model won’t lose control.
3.Do not drive the model in the following places/areas to avoid injury of people and damage to the
public property.
i.On public streets or in parks, causing injury or death of pedestrians, young children, animals and
pets.
ii.On highways, leading to accidents or damage of the model.
iii.In water, resulting in damage to electronic components and parts, or direct failure of the model.
Drive your model in open areas.
4. Check all signals and electronic parts are working properly.
After driving, battery(ries), ESC, and motor can be very hot. Please do not touch them with bare
hands.
Warning:
This high performance R/C kit can run very fast. It is designed and produced for people of 14+ years
of age to operate. Players under this age should be guided by adult supervision. Entry level players
should seek guidance and supervision from experienced model players. Players are responsible for
any/all accidental occurrences (human or animal injury, damage to property and possessions,
breakage of the model itself) due to improper operation of this model.

Brushed Truck Model Specifications
Length: 455mm(17.9”) (incl. F/R bumpers)
Width: 366mm(14.4”)
Height: 225mm(8.8”) (incl. body shell)
Wheelbase: 290mm(11.4”)
Front track/rear track: 293mm/298mm(11.5”/11.7”)
Tire size: Ф122*68mm(Ф4.8”/2.7”)
Wheel size: Ф72*48mm(Ф2.8”/1.9”)
Ground clearance: 74mm(2.9”)
Gear ratio: 10.97:1
Steering servo: 6kg
Brushless Truck Model Specifications
Length: 455mm(17.9”) (incl. F/R bumpers)
Width: 366mm(14.4”)
Height: 225mm(8.8”) (incl. body shell)
Wheelbase: 290mm(11.4”)
Front track/rear track: 293mm/298mm(11.5”/11.7”)
Tire size: Ф122*68mm(Ф4.8”/2.7”)
Wheel size: Ф72*48mm(Ф2.8”/1.9”)
Ground clearance: 76mm(3.0”)
Gear ratio: 15.19:1
Steering servo: 6kg
Radio System
A 2-channel radio system is required for the model. This includes 2.4GHz transmitter and receiver.
Please refer to 2.4GHz Transmitter Manual.
Battery and ESC information for brushed truck
The brushed truck comes with a 7-cell 8.4V SC type NiMh battery. The battery is with T-connector, so
does the battery charger. Besides, the ESC also has a T-connector to match it on the battery.
Below you may find the features and specifications of the high voltage ESC.
High Voltage ESC (Part# H126)
Features
1. Auto search throttle neutral point.
2. HF drive system
3. Over-heat protection (90C°)
4. Lipo battery low-voltage protection (2S Lipo-6.6V cutoff, 3S Lipo-9.9V shut down)
5. Low internal resistance & big capacity PCB board, providing great resistance to high current.
6. Forward, brake and reverse functions, good for both vehicles and boats.
Specifications
Forward current: 380A
Reverse current: 190A
Brake current: 250A
Voltage range: 4.8V-12.6V
PWM frequency: 1.5KHz
BEC voltage: 5V/2A
Operation
To obtain forward, brake and reverse functions and to switch battery types, kindly refer to the
2

following Skipping Needles Matrix for detail. This matrix provides clear information for operation.
Skipping Needles Matrix
Needles placement and corresponding functions
550 brushed motor parameters (For brushed truck)
3
1, 2
2, 3 Forward, brake, no reverse
4, 5 Lipo battery
5, 6 NiMh battery
Needles Functions
Forward, brake, reverse
①②③
④ ⑤ ⑥
Motor 3650 KV(RPM): 3970
Power: 21.0V
Empty load current: 2.0A (10V)
Resistance(Ω): 11Ω
Length (including motor shaft): 70mm
Diameter: 36mm
Weight : 170g
Shaft diameter: 3.175mm
Features: 6kg
Gears: Plastic gears, ball bearings
Working voltage: 4.8-6.0V
Speed (seconds/60°): 0.18-0.16 sec/60°
Torque: 6kg/cm
Net weight: 40g
Size(LxWxH): 40.8*20.1*38mm
Constant voltage: 7.4V Direction: CCW
Brushless electric motor (For brushless truck)
Servo (For both trucks)
The brushless truck comes with a 7.4V 2S Lipo battery. It runs over 80A brushless ESC. Please refer to
the ESC information below.
Note: When the motor temperature is over 120℃(248℉), please add a fan over the motor for better
ventlation. Please refer to the parts list foroptional part motor cooling fan and heat sink.

8381-102 Diff outdrive/pins (Ф2*10mm)
8381-103 Pins(Ф2*10mm) (16 pcs)
8381-104 Flathead screw-coarse
thread(KB2.6*10mm) (16 pcs)
8381-106 Diff case set/diff case cover/gasket
8381-107 Washer-A/B (8 pcs each)
8381-108 Gear-18T (2 pcs)/gear-12T (4 pcs)
8381-109 O Ring(Ф8*Ф2mm) (16 pcs)
8381-110 Ball bearing(Ф10*Ф15*4mm) (2 pcs)
8381-111 Diff pins(Ф4*25.8mm) (4 pcs)
8381-113 Flathead screw(KM2.6X6mm) (16 pcs)
8381-114 Ball bearing(Ф8*Ф14*4mm) (2 pcs)
8381-115 Pins(Ф2*8mm) (16 pcs)
8381-116 Pinion gear outdrive/pins(Ф2*8mm)
8381-117 Ball bearing(Ф5*Ф11*4mm) (2 pcs)
8381-118 Diff gear case cover-F/R
8381-119 B head screw-coarse
thread(BB3*16mm) (16 pcs)
8136-200 Assembly of reduction gearbox
8136-201 Reduction connecting axle/pins
(Ф2*10mm)
8136-202 E-type clamping spring(4 pcs)
8136-203 Reduction mounting plate A/B
8131-204 Spur gear-53T(plastic) (2 pcs)
8131-205 Center diff outdrive/lock nut(M4*4mm)
8381-204 Set screws (M4*4mm) (16 pcs)
8136-300 Shock absorber complete (2 pcs)
8136-302 Shock spring (4 pcs)
8381-305 Shock ball (8 pcs)
8381-306 M3 nylon nut (8 pcs)
8381-309 Shock shaft (4 pcs)
8381-50L Assembly of upper sus.arm-Left
8381-50R Assembly of upper sus.arm-Right
8381-501 Upper sus.arm ball (4 pcs)
8381-502 Upper sus.arm/rod end (2 sets)
8381-503 Upper sus.arm linkage (2 pcs)
8136-600 Servo saver assembly-complete
8131-601 Servo saver spring (4 pcs)
8131-602 Steering plate
8382-601 Servo saver sus. Arm-
upper/lower/steering sus. Arm
8381-601 Brass washer (4 pcs)
8381-602 Servo saver bushing/adjustment ring
8381-605 B head screw-coarse
thread(BB3*12mm) (16 pcs)
8381-606 Screw bushing (16 pcs)
4
8381-608 Shaft (2 pcs)
8136-6Z0 Assembly of steering linkage (2 pcs)
8136-6Z1 Steering linkage (2 pcs)
8381-6Z2 Plastic rod end (8 pcs)
8381-6Z3 Double way ball end (8 pcs)
8381-701 Upper sus.arm mount-rear/suspension
mount
8381-702 B head screw-coarse
thread(BB3*14mm) (16 pcs)
8381-703 B head screw-coarse
thread(BB3*10mm) (16 pcs)
8381-706 Lower sus.arm-front (2 pcs)
8381-707 Drive shaft set/revolving shaft (2 sets)
8381-710 Ball bearing(Ф6*Ф12*4mm) (2 pcs)
8381-714 C-hub (2 pcs)
8381-717 Shock tower (2 pcs)
8381-718 Pivot ball mount (4 pcs)
8381-719 Upper sus.arm shaft (4 pcs)
8381-721 Lower sus.arm plate-front
8381-723 C-hub screw bushing (16 pcs)
8381-724 T head screw(TM4*12mm) (16 pcs)
8381-725 T head screw(TM4*22mm) (16 pcs)
8381-726 B head screw-coarse
thread(BB3*18mm) (16 pcs)
8381-727 B head screw(BM3*56mm) (8 pcs)
8381-728 B head screw(BM3*43mm) (8 pcs)
8382-703 Body post holder/body post
8382-705 B head screw(BM3*24mm) (16 pcs)
8135-701 Wheel axle (2 pcs)
8135-702 Steering arm (2 pcs)
8135-703 Hex adapter (4 pcs)
8135-704 Set screws-M4 (4 pcs)
8382-702 Front bumper/upper sus.arm mount-
front
8381-801 Lower sus.arm-rear (2 pcs)
8381-802 Rear hub-L/R
8381-803 B head screw(BM3*18mm) (16 pcs)
8381-805 B head screw(BM3*10mm) (16 pcs)
8381-807 Pin-A(Ф1.5mm) (16 pcs)
8136-9M1 Motor moun
8381-9S1 Servo mount
8381-9S4 Servo arm-D (2 pcs)
8131-9S2 B head screw(BM2.6*6mm) (12 pcs)
8381-9Z0 Assembly of steering tie rod
8381-9Z1 Steering tie rod (2 pcs)
8136-001 Chassis
Part No. Description Part No. Description

The following parts are suitable for cars
only where there are √
Optional parts
8136
8137
5
Part No. Description
8133-100 Assembly of diff gear box
8133-101 Diff set
8133-102 Crown gear-41T (large)/pinion
gear-11T (small)
8133-103 Assembly of the pinion gear
8131-9M2 Motor gear-18T/Lock nut(M3*3)
8136-007 Printed truck body (PVC)
8136-008 Clear truck body (PVC) with
body decals and window cutout
H126 55A Brushed ESC
H112 550 Brushed motor
H125 7-cell (8.4V) SC 1800mAh NiMh
battery(T-connector)
H131 7-cell NiMh battery charger
(T-connector)-800mAh output
8381-100 Assembly of diff gear box
8381-101 Diff set
8381-105 Crown gear-41T (large)/pinion
gear-11T (small)
8381-112 Assembly of the pinion gear
8137-001 Printed truck body (PVC)
8137-002 Clear truck body (PVC) with
body decals and window cutout
8137-9M1 Motor gear-13T/Lock nut(M3*3)
H132 1/10 Brushless ESC (80A)
H109 3650 Brushless motor (KV:3970)
H110 LiPo battery (7.4V, 20C, 2300mAh)
8136-011 Wheelie bar assembly
8381-400 Anti-roll bar assembly
8381-40L Assembly of anti-roll bar linkage-Left
8381-40R Assembly of anti-roll bar linkage-Right
8381-401 Anti-roll bar rod end (8 pcs)
8381-402 Anti-roll bar linkage (4 pcs)
8381-403 Anti-roll bar pivot ball-upper/lower (4 sets)
8381-404 Set screws (M3*3mm) (8 pcs)
8381-405 Anti-roll bar(Ф2.2mm) (2 pcs)
8381-607 Steering plate
8381-709 Steering arm (2 pcs)
8381-716 Set screws (M4*12mm) (16 pcs)
8136-002 Upper deck mount
8136-003 Central drive shaft-F
8136-004 Tire complete (chrome wheels) (2 pcs)
8136-005 Tire with foam (unglued) (2 pcs)
8136-006 Chrome wheels (2 pcs)
8136-010 Chassis cover
8135-005 Battery mount-C/D
8331-003 Body spacer (Ф18*Ф8*2mm) (4 pcs)
8381-008 Antenna tube (3 pcs)
8381-009 Pin-B(dia 1.2mm) (16 pcs)
8381-010 Screw washer (4 pcs)
8381-011 Flathead screw(KM3X10mm) (16 pcs)
8381-012 Flathead screw-coarsethread(KB3*10mm)
(16 pcs)
8381-024 Flathead screw(KB4X11.5mm) (12 pcs)
D303 Servo (6kg)
D302T 2.4GHz transmitter
D302S 2.4GHz receiver
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√

8381-105
8381-112
8133-101
8136-6Z0 Assembly of
steering linkage
8381-6Z3
8381-6Z2
8131-205
8381-204
8136-202
8136-600 Assembly of the
servo saver
8381-606
8381-606
8381-601
8381-605
8381-601 8381-608
8381-608
8381-601 8382-601
8131-602 8381-605
8381-601 8381-602 8382-601 8382-601 8131-601 8381-602
8131-204
8136-201
8381-117
8136-203
8136-203
8136-201
8381-117
8381-103
8136-200 Assembly of the
center diff gear box
8136-6Z1
8381-6Z3
8381-6Z2
8133-112
8133-103
8133-102
8133-102
8381-101
8133-100 Assembly of the
diff gear box
8381-117
8381-118
8381-118
8381-119
8381-110
8381-110
8381-115
8381-116
8381-107
8381-114
8381-113
8381-107
8381-108
8381-102
8381-111
8381-103
8381-106
8381-108
8381-107
8381-108
8381-109
8381-107
8381-101
8381-108
8381-107
8381-106
8381-105
8381-103
8381-109
8381-102
8381-104
8381-50R
8381-50L
8381-501
8381-501
8381-502
8381-503
8381-502
8381-502
8381-503
8381-502
8381-50L Assembly of upper sus.arm-Left 8381-50L Assembly of upper sus.arm-Right
8136-300 Assembly of the
shocks
8381-400 Assembly of the
sway bar
8381-405
8381-404 8381-403
8381-403
8381-402 8381-402 8381-401
8381-403
8381-401 8381-402 8381-401
8381-40R
8381-40L
8381-309 8381-306
8381-501
8136-301
8381-305
8381-305
6

8136-9M1
8381-9S3
8137 Assembly of
the motor gear
8381-9S3
8137-9M1
8381-404
H109
8381-100
8381-726
8381-703
8381-703
8382-702
8381-119
8135-704
8136-9M1
8381-9S3
8136 Assembly of
the motor gear
8381-9S3
8131-9M2
8381-404
H112
8381-306
8381-306
8381-727
8381-727
8381-306
8381-306
8381-728
8381-728
8382-703
8381-009
8381-009
8381-807
8381-807
8381-306
8381-306
8381-725
8381-724
8381-725
8381-724
Assembly of the
front sus.arm system
8381-726
8381-400
8381-726
8133-100 8136-300
8136-300
8381-50L
8381-50R
8381-719
8381-726
8381-721
8382-705
8382-705
8382-702
8381-718
8381-718
8381-717
8381-726
8381-716
8381-716
8381-714
8381-714
8381-703
8381-702
8381-119
8381-119
8381-103
8381-708
8381-707
8381-707 8381-103
8381-707
8381-706
8381-706
8381-701
8381-701
8381-723
8381-710
8381-723
8381-723
8135-701
8135-701
8381-710
8135-704
8135-703
8381-103
8135-702
8381-110
8381-103
8135-703
8381-710
8135-702
8381-110
7

8137-002 8137-001
8136-008 8136-007
8136-006
8136-005
8136-004
8

8133-100
8381-9Z0 Assembly of
steering tie rod
8381-703
8381-726
8381-119
8381-703
8382-702
8382-702
8135-704
8135-704
8381-306
8381-306
8381-727
8381-727
8381-306
8381-728
8381-728
8135-703
8382-703
8382-703
8381-807
8381-807
8381-009
8381-009
8381-306
8381-306
8381-717
8381-718
Assembly of the
rear sus.arm system
8381-103
8382-705
8381-726
8381-721
8381-726
8136-300
8382-705
8136-300
8381-103
8381-103
8135-701
8135-701
8381-400
8381-110
8381-802
8381-710
8135-703
8381-100
8381-707
8381-707
8381-716
8381-119
8381-719
8381-50R
8381-726
8381-103
8381-50L
8381-726
8381-802
8381-702
8381-702
8381-119
8381-801
8381-110
8381-710
8381-726
8381-716
8381-719
8381-701
8381-701
8381-9Z1
8381-6Z3
8381-6Z3
8381-6Z2
8381-6Z2
9

8136-011
H110
8136-010
H125
8136-001
8381-011
1
1
1
1
1
1
1
1
1
1
1
1
1
1
8381-011
8131-005
8381-009
8131-005
D302R
8135-005
8135-005
8381-024
1
8381-012
8381-024
8381-024
8136-600
H132
8136-003
8131-9S2
8381-9S4
8381-703
8381-703
D303
8381-9S1
H126
10

8136-002
8381-703
8381-703
8381-703
8381-805
8381-805
8381-119
8381-119
8381-008
8381-702
8381-702
8381-702
11

12
8381-102 Diff outdrive/pins
(Ф2*10mm)
8381-103 Pins
(Ф2*10mm) (16 pcs)
8381-104 Flathead screw-coarse
thread(KB2.6*10mm) (16 pcs) 8381-106 Diff case set/diff case
cover/gasket
8381-107 Washer-A/B (8 pcs each) 8381-109 O Ring(Ф8*Ф2mm)
(16 pcs)
8381-110 Ball bearing(Ф10*Ф15*
4mm) (2 pcs)
8381-111 Diff pins(Ф4*25.8mm)
(4 pcs) 8381-114 Ball bearing(Ф8*
Ф14*4mm) (2 pcs) 8381-115 Pins(Ф2*8mm) (16 pcs)
8381-116 Pinion gear outdrive/
pins(Ф2*8mm)
8381-117 Ball bearing(Ф5*Ф11*
4mm) (2 pcs) 8381-118 Diff gear case cover-F/R 8381-119B head screw-coarse
thread(BB3*16mm) (16 pcs)
8136-200 Assembly of reduction
gearbox
8136-201 Reduction connecting
axle/pins (Ф2*10mm)
8136-202 E-type clamping spring
(4 pcs)
8136-203 Reduction mounting
plate A/B
8131-204 Spur gear-53T(plastic)
(2 pcs)
8131-205 Center diff outdrive/lock
nut(M4*4mm)
8381-204 Set screws (M4*4mm)
(16 pcs)
8136-300 Shock absorber
complete (2 pcs)

13
8136-302 Shock spring (4 pcs) 8381-305 Shock ball (8 pcs) 8381-306 M3 nylon nut (8 pcs) 8381-309 Shock shaft (4 pcs)
8381-50L Assembly of upper
sus.arm-Left
8381-50R Assembly of upper
sus.arm-Right
8381-501 Upper sus.arm ball
(4 pcs)
8381-502 Upper sus.arm/rod
end (2 sets)
8381-503 Upper sus.arm linkage
(2 pcs)
8136-600 Servo saver assembly-
complete
8131-601 Servo saver spring
(4 pcs) 8131-602 Steering plate
8382-601 Servo saver sus. Arm-
upper/lower/steering sus. Arm 8381-601 Brass washer (4 pcs) 8381-602 Servo saver bushing/ adjustment ring
8381-605 B head screw-coarse
thread(BB3*12mm) (16 pcs)
8136-6Z1 Steering linkage (2 pcs)
8381-606 Screw bushing (16 pcs) 8381-608 Shaft (2 pcs) 8136-6Z0 Assembly of steering
linkage (2 pcs)
8381-6Z2 Plastic rod end (8 pcs) 8381-6Z3 Double way ball end
(8 pcs)
8381-701 Upper sus.arm mount-
rear/suspension mount
8381-702B head screw-coarse
thread(BB3*14mm) (16 pcs)

14
8381-703 B head screw-coarse
thread(BB3*10mm) (16 pcs) 8381-706 Lower sus.arm-front
(2 pcs)
8381-707 Drive shaft set/revolving
shaft (2 sets)
8381-710 Ball bearing(Ф6*Ф12*
4mm) (2 pcs)
8381-714 C-hub (2 pcs) 8381-717 Shock tower (2 pcs) 8381-718 Pivot ball mount (4 pcs) 8381-719 Upper sus.arm shaft
(4 pcs)
8381-721 Lower sus.arm plate-
front
8381-723 C-hub screw bushing
(16 pcs)
8381-724 T head screw(TM4*
12mm) (16 pcs)
8381-725T head screw(TM4*
22mm) (16 pcs)
8381-726 B head screw-coarse
thread(BB3*18mm) (16 pcs)
8381-727 B head screw(BM3*
56mm) (8 pcs)
8381-728 B head screw(BM3*
43mm) (8 pcs)
8382-703 Body post holder/
body post
8382-705 B head screw(BM3*
24mm) (16 pcs) 8135-701Wheel axle (2 pcs) 8135-702 Steering arm (2 pcs) 8135-703 Hex adapter (4 pcs)
8135-704 Set screws-M4 (4 pcs) 8382-702 Front bumper/upper
sus.arm mount-front
8381-801 Lower sus.arm-rear
(2 pcs) 8381-802 Rear hub-L/R

15
8381-803 B head screw(BM3*
18mm) (16 pcs)
8381-805 B head screw(BM3*
10mm) (16 pcs) 8381-807 Pin-A(Ф1.5mm) (16 pcs) 8136-9M1 Motor moun
8381-9S1 Servo mount 8381-9S4 Servo arm-D (2 pcs)
8131-9S2 B head screw(BM2.6*
6mm) (12 pcs)
8381-9Z0 Assembly of steering
tie rod
8381-9Z1 Steering tie rod (2 pcs) 8136-001 Chassis 8136-002 Upper deck mount 8136-003 Central drive shaft-F
8136-004 Tire complete (chrome
wheels) (2 pcs)
8136-005 Tire with foam
(unglued) (2 pcs) 8136-006 Chrome wheels (2 pcs) 8136-010 Chassis cover
8135-005 Battery mount-C/D 8331-003 Body spacer (Ф18*
Ф8*2mm) (4 pcs) 8381-008 Antenna tube (3 pcs) 8381-009 Pin-B(dia 1.2mm) (16 pcs)
8381-010 Screw washer (4 pcs) 8381-011 Flathead screw
(KM3X10mm) (16 pcs)
8381-012 Flathead screw-coarse
thread(KB3*10mm) (16 pcs)
8381-024 Flathead screw
(KB4X11.5mm) (12 pcs)

16
D303 Servo (6kg) D302T 2.4GHz transmitter D302S 2.4GHz receiver 8133-100 Assembly of diff gear box
8133-101 Diff set 8133-102 Crown gear-41T
(large)/pinion gear-11T (small)
8133-103 Assembly of the
pinion gear
8131-9M2 Motor gear-18T/
Lock nut(M3*3)
8136-007 Printed truck body (PVC) 8136-008 Clear truck body (PVC)
with body decals and window cutout H126 55A Brushed ESC H112 550 Brushed motor
H125 7-cell(8.4V) SC 1800mAh
NiMh battery(T-connector)
H131 7-cell NiMh battery charger
(T-connector)-800mAh output 8381-100 Assembly of diff gear box 8381-101 Diff set
8381-105 Crown gear-41T (large)/
pinion gear-11T (small)
8381-112 Assembly of the pinion
gear 8137-001 Printed truck body (PVC)
8137-002 Clear truck body (PVC)
with body decals and window cutout
8137-9M1 Motor gear-13T/Lock
nut(M3*3) H132 1/10 Brushless ESC (80A) H109 3650 Brushless motor
(KV:3970)
H110 LiPo battery (7.4V, 20C,
2300mAh)

Optional parts
17
8136-011 Wheelie bar assembly 8381-400 Anti-roll bar assembly 8381-40L Assembly of anti-roll
bar linkage-Left
8381-40R Assembly of anti-roll
bar linkage-Right
8381-401 Anti-roll bar rod end
(8 pcs)
8381-402 Anti-roll bar linkage
(4 pcs)
8381-403 Anti-roll bar pivot ball-
upper/lower (4 sets)
8381-404 Set screws (M3*3mm)
(8 pcs)
8381-405 Anti-roll bar(Ф2.2mm)
(2 pcs) 8381-607 Steering plate 8381-709 Steering arm (2 pcs) 8381-716 Set screws (M4*12mm) (16 pcs)

18

Parts Diagrams
Receiver Functions
3
19
Frequency range
2.4GHz modulation
Sensitivity
Working voltage
Working current
Size
Weight
: 2.4GHz
: AFHDS
: -100dbm
: DC4.8-6.0V
: 5.7*26*15.2mm
: 11.2g
