Acclaim Lighting RBE Manual

Rebel Band 600 ( DMX-512 )
Model: RBE
Outdoor Fixtures
ACCLAIM
LIGHTING YOUR SOURCE FOR ADVANCED LED LIGHTING SOLUTIONS
www.acclaimlighting.eu

Control:
2 = DMX
Rebel Band 600 (IP65)
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
LED Current
Light Source
Power Consumption
Weight
Housing
Listing
Source Life
Operating Temp.
Storage Temp.
Including
100-240Vac + DMX
4 pcs @ 100Vac and 8 pcs @ 240Vac
3-Pin IP67 Waterproof Conn. Power in/out
5-Pin IP67 Waterproof Conn. DMX in/out
Direct DMX-512, Manual, Stand Alone
3 for RGB and SC and 4 for RGBA
XB-R1 Setup Tool
100-240Vac
600mA
104 x Rebel LED (3W)
270W
35 kg
Extruded alu with paint finish (grey)
Extruded alu with powder coating (black)
CE, cETLus Pending
50.000 hours at 70% lumen maintenance
-20 °C ~ +50 °C
-20 °C ~ +70 °C
-
-xxx-xxxx Version:
N = Normal
Color:
A
C
E
G
H
J
K
L
M
N
P
Q
R
= WW 2700k
= WW 3200k
= NW 4000k
= CW 6000k
= RGB
= RGB-A
= RGB-WW
= RGB-CW
= WW-CW-WW
= Red
= Green
= Blue
= Amber
Beam angle:
B
C
F
H
K
L
= 5°
= 10°
= 25°
= 40°
= 60°
= 5 x 20°
LED Config:
C = 104 LEDs
Cover:
1= Clear
Housing:
1= Black Color
2= Grey
RBE
Outdoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
ACCLAIM
LIGHTING
93mm [3.7"]
551mm [1'-9.7"]
684mm [2'-2.9"]
450mm [1'-5.7"]
189mm [7.4"]
600mm [1'-11.6"]
658mm [2'-1.9"]
93mm [3.7"]
685mm [2'-3.0"]
326mm [1'-0.8"]
551mm [1'-9.7"]
240V AC
128
DMX-512
max. 8pcs. in a chain
DMX-512 First cable
Rebel Band 600
Power link cable
DMX link cable
240V AC First cable
Wiring diagram
