SwitcHub-7s
&INO<GG<ODJI*<IP<G

Installation Manual
SwitcHub-7s
Smart Ethernet Switch
with 610BASE-T Ports and
110BASE-T/100BASE-TX Port

Copyright (c) 1996 by Accton Technology Corporation. All rights reserved.
No part of this document may be copied or reproduced in any form or by any means without the
prior written consent of Accton Technology Corporation.
Accton makes no warranties with respect to this documentation and disclaims any implied
warranties of merchantability, quality, or fitness for any particular purpose. The information in this
document is subject to change without notice. Accton reserves the right to make revisions to this
publication without obligation to notify any person or entity of any such changes.
International Headquarters
No. 1 Creation Road III,
Science-based Industrial Park
Hsinchu 300, Taiwan, R.O.C.
Phone: [phone]
FAX: [phone]
BBS: 886-3-5770-654
Internet: [email protected]
USA Headquarters
1962 Zanker Road
San Jose, CA 95112
Phone: [phone]
FAX: [phone]
BBS: 408-452-8828
FAST FAX: [phone]
Accton, SwitcHub and SmartWatch are trademarks or registered trademarks of Accton Technology
Corporation. Other trademarks or brand names mentioned herein are trademarks or registered
trademarks of their respective companies.
ES2007-TX
E1296-R02
150667-101

Package Contents i
Package Contents
Carefully unpack the contents of the package and verify them against the
checklist given below.
Package Checklist
æSwitcHub-7s (Model No. ES2007-TX)
æAC power cord
æFour rubber foot pads
æInstallation manual
æOwner registration card
Please inform your dealer immediately should there be any wrong, missing, or
damaged parts.
If possible, retain the carton, including the original packing materials. Use
them again to repack the unit in case there is a need to return it for repair.
To qualify for product updates and product warranty registration, fill in the
Owner Registration Card and return it to Accton Technology Corporation.

Quick Installation iii
Quick Installation
The SwitcHub-7s contains six 10BASE-T RJ-45 Ethernet ports, and one RJ-45
port for either 10BASE-T or 100BASE-TX connection (detected by auto-
sensing). Each of these ports support full-duplex or half-duplex operation.
The smart design built into the front display panel and configure options
provides a friendly interface that simplifies installation and network
troubleshooting. If you are already familiar with basic network operations, you
should be able to install this switch as described below:
1. Unpack the SwitcHub-7s.
2. Find a location close to the network devices you need to connect, and within
easy reach of an electrical outlet.
3. Mount the switch on a desktop or any other flat surface.
4. Ports 1 - 6 operate at 10 Mbps; while Port 7 automatically adjusts to 10
Mbps or 100 Mbps, depending on the transmission speed of the connected
device. Connect servers or workstations to the RJ-45 station ports. To
connect to another switch or hub, run cable from the daisy-chain port on this
switch (Port 7MDI) to a station port on the other device. Otherwise, run
cable in the opposite direction –from a daisy-chain port on the other device
to a station port on this switch.
Use 100Ωcable for all connections, Category 3 or greater for 10 Mbps
Ethernet and Category 5 for 100 Mbps Ethernet. For standard connections,
use straight-through twisted-pair cable. However, if you must make a direct
connection between MDI or MDI-X ports (i.e., MDI to MDI, or MDI-X to
MDI-X), then use crossover cable. Be sure the length of any twisted-pair
connection does not exceed 100 meters.

SwitcHub-7s User’s Guide
iv Quick Installation
For integrating legacy networks, Port 7 provides for connection via either
100BASE-TX or 10BASE-T. It uses auto-sensing to dynamically set the
required transmission speed at 10 or 100 Mbps.
5. The SwitcHub-7s can serve as a collapsed backbone, or can be connected to
any other network interconnection device via one of the 10 Mbps ports or the
100 Mbps port. (Refer to Chapter 3 for sample applications.)
6. Set the transmission mode for each port to full duplex or half duplex using
the Configure button. (Refer to Full/Half Duplex Mode Selection in Chapter 2.)
Full-duplex communications can only be supported for a dedicated link (i.e.,
set communications to half duplex if you are connecting to a shared collision
domain). Remember that the selected mode must correspond to that
supported by the connected device.
7. Verify network communications by ensuring that -
• you have made all the necessary connections
• you can access any connected resources
• the hub’s indicator LEDs are functioning properly
Note: For devices connected to Port 7, the system will automatically detect
transmission speed (10/100 Mbps). However, note that unless connected
devices are operating at half duplex (i.e., system default), you will have to
manually set the transmission mode via the Configure button. (Refer to Full/Half
Duplex Mode Selection in Chapter 2).
If you encounter any problems in installing the SwitcHub-7s, refer to Chapter 2
for a detailed description of installation procedures, or to Appendix A for help
in troubleshooting.

About this Guide v
About this Guide
This guide is designed for the experienced network installer. It describes how
to install and operate Accton’s SwitcHub-7s Smart Ethernet switch. After
reading this manual, you should be able to use the front display panel and
configure options to manage all your network connections.
This manual covers the following topics:
Chapter 1 - Product Overview
Brief description of switching technology, followed by a description of this
switch and a summary of its important features and specifications.
Chapter 2 - Setup and Configuration
Installing a SwitcHub-7s and making basic network connections. Shows
sample network configurations for a local area network.
Chapter 3 - Network Applications
Provides a brief description of several common network configurations.
Chapter 4 - Hardware Reference
Detailed description of indicator panel and ports.
Appendices - Troubleshooting, cable assignments, and product specifications.

Contents
Contents vii
Chapter 1: Product Overview.................................................1-1
Switching Technology...............................................................................................1-1
Accton’s SwitcHub-7s...............................................................................................1-2
Switching Methods...............................................................................................1-3
Basic Features.......................................................................................................1-4
Chapter 2: Setup and Configuration......................................2-1
Pre-Installation Requirements ...................................................................................2-1
Connecting the Switch System..................................................................................2-1
Server/Workstation Connection............................................................................2-2
Daisy-Chain Connection.......................................................................................2-2
Providing Power to the SwitcHub.............................................................................2-3
Diagnostic Tests........................................................................................................2-4
Upon Power On ..............................................................................................2-4
During Normal Operation...............................................................................2-4
Setting the Display Mode..........................................................................................2-4
Selections Available.............................................................................................2-5
Demonstration.................................................................................................2-5
Diagnostic Function........................................................................................2-6
Port Status Display..........................................................................................2-6
Bandwidth Utilization.....................................................................................2-6
Packet Forwarding Ratio.................................................................................2-6
Packet Filtering Ratio .....................................................................................2-7
Full/Half Duplex Mode Selection...................................................................2-7
Verifying Port Status.................................................................................................2-8
Verifying System Operation......................................................................................2-8
Chapter 3: Network Applications...........................................3-1
Switch Used as Collapsed Backbone for Starter Network ......................................3-1
Multiport Bridge with High-Bandwidth Backbone.................................................3-2
High-Bandwidth File Server ...................................................................................3-3
High-Speed Link between Switches........................................................................3-4

SwitcHub-7s User’s Guide
viii Contents
Chapter 4: Hardware Reference.............................................4-1
Indicator Panel ..........................................................................................................4-2
Configure Button..................................................................................................4-3
CPU Activity Indicator.........................................................................................4-4
Port Speed Indicator.............................................................................................4-4
Demonstration Display Mode...............................................................................4-5
Diagnostics Display Mode....................................................................................4-6
System Diagnostic Test...................................................................................4-6
Port Diagnostic Test .......................................................................................4-7
Port Status Display Mode.....................................................................................4-8
Collision Ratio (Port Status Display Mode)....................................................4-9
Transmit (Port Status Display Mode) .............................................................4-10
Receive (Port Status Display Mode)...............................................................4-10
Link (Port Status Display Mode) ....................................................................4-10
Statistical Display for System Performance..........................................................4-12
Port Utilization Rate (System Performance Display).....................................4-13
Port Forwarding Ratio (System Performance Display)..................................4-14
Port Filtering Ratio (System Performance Display).......................................4-14
Setting the Communication Mode (Full/Half Duplex) .........................................4-16
Ethernet Ports............................................................................................................4-17
Power Socket.............................................................................................................4-18
Appendix A: Troubleshooting................................................A-1
Diagnosing Switch Indicators....................................................................................A-1
System Diagnostics ...................................................................................................A-2
Installation............................................................................................................A-2
Configuration........................................................................................................A-2
Switch Integrity....................................................................................................A-3
Appendix B: Port and Cable Assignments ...........................B-1
RJ-45 Port ...............................................................................................................B-1

SwitcHub-7s User’s Guide
Contents ix
Appendix C: Specifications....................................................C-1
Product Specifications...............................................................................................C-1
Appendix D: Standards Compliance .....................................D-1
EMI Certification ......................................................................................................D-1
FCC Class A.........................................................................................................D-1
Canada Department of Communications - Class A...............................................D-1
Voluntary Control Council for Interference (VCCI-2).........................................D-2
CE Mark Declaration of Conformance (for EMI and Safety)...............................D-2
Safety Compliance.....................................................................................................D-3
Underwriters Laboratories Inc..............................................................................D-3
Sicherheitshinweise..............................................................................................D-4
Appendix E: Product Support Services ................................E-1
Product Registration..................................................................................................E-1
Problem Report .........................................................................................................E-1
Hardware Repair Service...........................................................................................E-1
Software Update and Upgrade Service......................................................................E-2
Bulletin Board Service (BBS) ...................................................................................E-2
Interactive Fast Fax (U.S.A. office) ..........................................................................E-3
Technical Support .....................................................................................................E-3
Limited Warranty......................................................................................................E-4
Customer Remedies..............................................................................................E-4
Return Process......................................................................................................E-5
Accton Offices...........................................................................................................E-6
Ordering Information ................................................................................................E-6
Glossary
Index

SwitcHub-7s User’s Guide
x Contents
List of Figures
Figure 3.1 SwitcHub Used as Simple Backbone.....................................................3-1
Figure 3.2 SwitcHub Used as Multiport Bridge......................................................3-2
Figure 3.3 SwitcHub Used to Link High-Bandwidth File Servers...........................3-3
Figure 3.4 High-Speed Link between Switches.......................................................3-4
Figure 4.1 The SwitcHub-7s Front Panel................................................................4-1
Figure 4.2 SmartWatch LED Panel for the SwitcHub-7s........................................4-2
Figure 4.3 Ethernet Ports on the Front Panel...........................................................4-17
Figure B-1 RJ-45 Connector (on the Switch Side)...................................................B-1
