AccuEnergy RIK V User manual

RIK V
0-5Vdc/0-10Vdc Rogowski Coil Integrator
Users Manual
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

Copyright © 2023 V: 1.0.2
This manual may not be altered or reproduced in whole or in part by any means without the
expressed written consent of Accuenergy.
The information contained in this document is believed to be accurate at the time of
publication, however, Accuenergy assumes no responsibility for any errors which may appear
here and reserves the right to make changes without notice. Please ask the local representative
for latest product speci󳆂cations before ordering.
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

SAFETY INFORMATION
Please read this manual carefully before installation, operation and maintenance of the
Rogowski Coil Integrator.
The following symbols in this manual are used to provide warning of danger or risk during the
installation and operation of the unit.
Electric Shock Symbol: Carries information about procedures which must be
followed to reduce the risk of electric shock and danger to personal health.
S afety Alert Symbol: Carries information about circumstances which if not
considered may result in injury or death.
This mark indicates that this product is UL listed.
Installation and maintenance of the Rogowski Coil Integrator should only be performed by
quali󳆂ed, competent professionals who have received training and should have experience
with high voltage and current devices.
Accuenergy shall not be responsible or liable for any damages caused by improper meter
installation and/or operation.
Product is protected by reinforced insulation
Application Around and removal from UNINSULATED
HAZARDOUS LIVE conductors is permited
WARNING: Disconnect power supply before making electrical connections.
WARNING: Current Transformers (CT’s) should be installed by trained electrician or technician.
WARNING: The secondary circuit of a CT should not be opened when current is flowing
through the primary circuit.
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

Table of Contents
Chapter 1: Overview...................................................................................................4
1.1 Overview.............................................................................................................................. 4
1.2 What's Included ..................................................................................................................4
Chapter 2: Overview...................................................................................................6
2.1 Hardware Overview............................................................................................................ 7
2.2 Installation ..........................................................................................................................7
2.3 Configuration ....................................................................................................................13
2.4 Measurements
...................................................................................................................................................14
Appendix: Key Specifications ..................................................................................15
SPECIFICATIONS ......................................................................................................................15
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

RIK V
0-5Vdc/0-10Vdc
Rogowski Coil Integrator
Chapter 1
1.1 Overview
1.2 What's Included
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
4
RIK V
0-5V/0-10V Rogowski Coil Integrator
Chapter 1: Overview
1.1 Overview
The Rogowski Integrator (RIK V) is designed to provide users with an easy to install, plug and
play, retro󳆂t solution that can be used with any power meter or equipment with either 0-5Vdc
and 0-10Vdc current input from a Current Transformer(CT). The flexibility of the Rogowski
Coil CT's reduces the complexity and allows it use to be used for a variety of applications and
con󳆂gurations where special constraints may limit the use of other CT solutions. The RIK is a
con󳆂gurable unit that can measure current from 2.5-60000A making it ideal for any system that
operates at both 50Hz and 60Hz further adding to its 󳆃exibility.
1.2 What's Included
The Rogowski Coil includes either the single channel or three channel integrator unit which
contains the seven con󳆂gurable CT ratios for each channel. The integrator unit can be surfaced
mounted or mounted on a standard DIN rail.
Rogowski coils that will measure the current and the 24Vdc power supply to power the
integrator are sold separately.
Three Phase Integrator
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
Chapter 1: Overview
5
1Rogowski Coil Input
Three Channels for 󳆃exible rope style CT
input.
20-5V/0-10V Output
Three Channels, 0-5V/0-10V Output.
3Power On Light
Indicates that the RIK is powered up.
4CT Con󳆂gurator
Seven individual 󳆂eld con󳆂gurable CT
ratios for each channel
5Rogowski Coil
CT sizes available from 16-47 inches
6Coil Input Lead
Input lead for connection with RIK
integrator.
Details:
Single Phase Integrator
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

RIK V
0-5Vdc/0-10Vdc
Rogowski Coil Integrator
Chapter 2
2.1 Hardware Overview
2.2 Installation
2.3 Con󳆂guration
2.4 Measurements
Chapter 2: Overview
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

Chapter 2: Hardware Overview
7
V: 1.0.2 Revised: Jun 2023
The installation method is introduced in this chapter. Please read this chapter carefully before
beginning installation.
2.1 Hardware Overview
The RIK V is composed of the integrator and the optional power supply which can all be
mounted on a DIN rail along with one or three Rogowski coils. Rogowski coil and power supply
sold separately.
2.2 Installation
Single Phase Integrator
Three Phase Integrator
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
8
RIK V
0-5V/0-10V Rogowski Coil Integrator
45
42.3
106.3
50.650.6
103.7
Dimensions:
Figure 1: Top View
Figure 2: Side View
A
A
42.3
90.5
25.5
48.3
62
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
9
Chapter 2: Hardware Overview
Figure 4: Side view of Power Supply unit
3.5” (90mm)
3.9” (100mm)
Figure 3: Front view
A-A ( 1 : 1 )
48.3
103.3
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
10
RIK V
0-5V/0-10V Rogowski Coil Integrator
The installation of the RIK V integrator requires the user to simply connect the Rogowski coil CT
(sold separately) to the integrator and wire the 0-5/0-10V output to the power meter or electrical
equipment which will receive the signal. If the system is single phase or there are two phases
only the phases that need the CT will need to be connected to the input of the integrator.
Figure 5: Single Phase Integrator
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
11
Chapter 2: Hardware Overview
GND NL
V+ V+ V- V-
24Vdc Output
Power Supply
100-240Vac Input
Power Supply
100-240Vac-24Vdc Power Supply
AcuCT RIK
Rogowski Integrator
S 24V- 24V+
S IN- IN+
CH3
S IN- IN+
CH2
S IN- IN+
CH1
SUM+ SUM- Out+ Out-
CH3
Out+ Out-
CH2
Out+ Out-
CH1
ABCN
Source
Load
-OUT +OUT
AcuCT
Rogowski
Integrator
Output
-RCT +RCTS
A N
-24V +24VGnd
BOTTOM
GNDN L
V+ V+ V- V-
24Vdc Output
Power Supply
100-240Vac Input
Power Supply
100-240Vac-24Vdc Power Supply
Load
TOP
white
brown
Source
Single Phase Integrator
Three Phase Integrator
The diagram below illustrates how to connect the integrator.
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
12
RIK V
0-5V/0-10V Rogowski Coil Integrator
Input:
The provided Rogowski coils are the input to the integrator. Connect the Rogowski coil leads
to the input channel on the integrator. The white leads of the CT are the positive wire and the
brown lead is the negative wire.
• Connect the white lead to ‘IN+’ or ‘RCT+’ and the brown lead to ‘IN-’ or ‘RCT-’. The Shield of
the Rogowski coil should be left 󳆃oating. Open the coil by pulling apart the black connector
of the CT.
• Open the coil by pulling apart the black connector of the CT.
• Install the CT around the conductor to be measured. Arrow on the Rogowski coil connector
should be point to load.
• Re-attach the coil together.
• Repeat above steps if using more than one CT.
Ensure that the CT connected to each channel of the integrator is around the correct phase/line
voltage.
Output:
Connect each output channel to the meter or equipment with 0-5V/0-10V input.
• 'OUT+' is to be connected to the positive input terminal of meter.
• 'OUT-' is to be connected to the negative input terminal of meter.
Power Supply: (Sold Separately)
The RIK V requires 24Vdc power to operate. There is a 100-240Vac (50/60Hz) power adapter that
is included to provide this power.
• Connect the input power supply that is between 100-240Vac to the 'L' and 'N' terminals of
the power supply.
• Connect the DC output of power supply to the RIK's '24V+' and '24V-' terminals.
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
13
Chapter 2: Hardware Overview
2.3 Conguration
One or three sets of dip switches are used to con󳆂gure corresponding current ranges with
output ratings.
When the dip switch is in the up position the dip switch is considered to be O󳆁. When the dip
switch is in the down position the dip switch is considered as On.
Con󳆂gure each channels dip switches to output the desired range. Dip Switches 1 and 2 will
determine the output signal of that channel.
Note: Dip Switch #3 is not used.
For example to measure current rated for 1000A with a 0-5V output signal dip switches 1 and
2 will be con󳆂gured in the 'ON' position whiles dip switches 4 through 8 for the three channels
must be con󳆂gured to be 'OFF', 'ON', 'OFF', 'ON' and 'OFF' respectively.
• Enter this current ratio into the meter or equipment so it can read accurately from the
integrator.
Table 1: Three Phase Integrator Current Ratio Table
Output 1 2
0-5V ON ON
0-10V OFF OFF
4567 8
500A OFF OFF ON ON OFF
1000A OFF ON OFF ON OFF
2500A ON OFF OFF ON OFF
5000A OFF OFF ON OFF OFF
10000A OFF ON OFF OFF OFF
25000A ON OFF OFF OFF OFF
50000A ON OFF OFF OFF ON
Table 2 - Three Phase Integrator Sum Output Con󳆂guration
Output 1 2
0-5V ON ON
0-10V OFF OFF
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
14
RIK V
0-5V/0-10V Rogowski Coil Integrator
Table 3 - Single Phase Integrator Current Ratio Table
12345
500A OFF OFF ON ON OFF
1000A OFF ON OFF ON OFF
2500A ON OFF OFF ON OFF
5000A OFF OFF ON OFF OFF
10000A OFF ON OFF OFF OFF
25000A ON OFF OFF OFF OFF
50000A ON OFF OFF OFF ON
Output Options
67
0-5V ON ON
0-10V OFF OFF
2.4 Measurements
For each current range the integrator will be able to measure the current from 0.5% up to 120%
of the rated current. That is when the integrator is con󳆂gured to measure a current rated for
1000A it will measure the current from 5A to 1200A. The integrator will output 5A at the rated
current of 1000A and will output its maximum of 6A at 1200A.
The table below provides all the ranges of current that can be measured for each range.
Primary INput (ARMS) Sensing Range (A) Output
500 2.5 to 600 0-5V or 0-10V @500A
1000 5 to 1200 0-5V or 0-10V @1000A
2500 12.5 to 3000 0-5V or 0-10V @2500A
5000 25 to 6000 0-5V or 0-10V @5000A
10000 50 to 12000 0-5V or 0-10V @10000A
25000 125 to 30000 0-5V or 0-10V @25000A
50000 250 to 60000 0-5V or 0-10V @50000A
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca

V: 1.0.2 Revision Date: Jun 2023
15
Chapter 2: Hardware Overview
Appendix: Key Specications
SPECIFICATIONS
Specications Measurements
Current Measurement Range 2.5A - 60000A
Output Current 0-5V/0-10V (Field Con󳆂gurable)
Sensing Range 500A, 1000A, 2500A, 5000A, 10000A, 25000A and 50000A (Field Con󳆂gurable)
Measurement Channels 1 or 3 Channel
Frequency 45Hz to 65Hz
Accuracy +1% Full Scale Error
Channel Cross Talk <-60dB
Maximum Operating Temparature 55oC (131oF)
Shop for Power Metering products online at: 1.800.561.8187
www.PowerMeterStore.ca
