Accurate Technology VALIANT User manual

VALIANT
TWIN DRAG REEL
OWNERS
MANUAL
®

2
Contents
Getting Acquainted ................................3
Drag Variance, Filling the Spool, Rod Mounting ......4
Operation..........................................5
Line Capacities .....................................6
Twin Drag System ..................................7
Maintenance .......................................8
Warranty...........................................9

3
Getting Acquainted
Frame
Handle
Sideplate
T-6 Torx Screws
Clicker Button
Preset Drag
Strike Position
High Speed
Retrieve
Button
Low Speed
Retrieve
Button
Main Drag Lever
SUPERIOR LIGHTWEIGHT DESIGN
SIX CLASS 5 ABEC STAINLESS
STEEL BEARINGS
PATENTED TWINDRAG®FEATURE
CVX®TECHNOLOGY
STAINLESS STEEL ARB
174 HEAT TREATED STAINLESS STEEL GEARS
AND SHAFT
LARGER, STRONGER GEAR SHAFT FOR
INCREASED TORQUE
SLEEVED SPOOL FOR INCREASED CASTABILITY
PATENTED DIRECSHIFT 2SPEED MECHANISM
FOR INSTANT ENGAGEMENT 2SPEED
MODELS
2 YEAR FREE SERVICE PROGRAM
PROUDLY DESIGNED, MANUFACTURED AND
ASSEMBLED IN AMERICA
TWIN
DRAG
®

4
Thanks to the Valiant's exclusive TwinDrag technology, the drag tension you set will vary no more than one pound when
line is pulled off the reel at any speed! Unfortunately, there is another factor which causes drag variance that needs to
be accounted for. This factor is based on how full the reel is with line. When the spool is filled, the line is being pulled off
a high point on the spool. As the amount of line on the spool reduces, the line is pulled from a lower area on the spool.
There is less leverage used when the line is pulled at a lower level, which means the line needs more force to move the
spool against the drag. The drag setting has not been decreased, but the line will encounter increased tension. Account
for the drag pressure to approximately double when 25% of the line has been removed from a full spool.
Begin filling the Valiant reel by attaching the line securely to the reel spool. With tension applied to the line, fill the spool
to approximately 1/4” from the spool edge.
NOTE: Filling the spool too close to the spool edge means you will have to level wind perfectly to prevent a high spot from
occurring. If a high spot occurs, the reel will not allow you to retrieve all of the line. Leave room on the spool to level wind
comfortably while fighting a fish.
Because of mono compaction when using ultra light line, we recommend first filling the spool with at least 2/3 spectra
line. Mono Compaction - Mono compaction is a problem that happens with light line. The smaller the mono line
diameter, the more elasticity the line will have. The elasticity is multiplied by the amount of line put on the spool
which creates pressure on the spool. When too much light line is added,
the pressure can expand the spool. This could cause the reel to
perform with inconsistent drag pressure or, if enough pressure
is built up, break the spool in half.Always put the least amount
of ultra-light line on the reel as needed.
Mount the reel on the rod with its rod clamp.
If your reel is a right-handed model, be sure to
mount the reel with the handle on the right.
Drag
Variance
Filling
the Spool
Rod
Mounting
Rod Clamp
ATD
VALIANT

5
Operation
Strike Position Free Spool Full Drag
Basic operation of your Valiant reel is no different from operating any other fishing reel except for setting the lever
drag. The most popular drag setting is to set your drag so when the Main Drag Lever is in the strike position it is
at approximately 25 to 30% of your line strength. To obtain this setting, start by adjusting the Main Drag Lever so it
is in the Free Spool position. NOTE: The Preset knob cannot be adjusted unless the Main Lever is in the free spool
position. Then adjust the Preset knob by moving it clockwise or counter clockwise. Move your Main Drag Lever to the
strike position. If the drag is too light or heavy, repeate the process until you’ve reached your desired drag pressure.
For a more Accurate drag setting, have your reel mounted to the rod with line going through the guides where you can
pull line using a spring or digital scale to see the exact reading.
ATD
VALIANT

6
Line
Capacities
MODEL WEIGHT (oz) GEAR RATIO LINE CAPACITY-BRAID INCHES PER CRANK MAX DRAG
BV2-300 15.7 6:1 / 3:1 325 yds / 30 lbs 38″ / 19" 24
BV2-400 16 6:1 / 3:1 400 yds / 50 lbs 38″ / 19" 26
BV2-500N 17 6:1 / 3:1 300 yds / 50 lbs 45″ / 23" 30
BV2-500 18 6:1 / 3:1 475 yds / 50 lbs 45″ / 23" 30
BV2-600NN 19 5:1 / 2.2:1 300 yds / 65 lbs 44″ / 19″ 32
BV2-600N 19 5:1 / 2.2:1 400 yds / 65 lbs 44″ / 19″ 32
BV2-600 20 5:1 / 2.2:1 500 yds / 65 lbs 44″ / 19″ 32
BV2-800N 24 5:1 / 2.2:1 600 yds / 80 lbs 47″ / 21″ 36
BV2-800 25 5:1 / 2.2:1 800 yds / 80 lbs 47″ / 21″ 36
BV2-1000 29 5:1 / 2.2:1 1000 yds / 100 lbs 52″ / 23″ 40
VALIANT®(BV2) TWO SPEED REELS
MODEL WEIGHT (oz) GEAR RATIO LINE CAPACITY-BRAID INCHES PER CRANK MAX DRAG
BV-300 9.9 6:1 325 yds / 30 lbs 38″ 24
BV-400 14 6:1 400 yds / 50 lbs 38" 26
BV-500N 15 6:1 300 yds / 50 lbs 45″ 30
BV-500 16 6:1 475 yds / 50 lbs 45″ 30
BV-600NN 18 6:1 300 yds / 65 lbs 53″ 32
BV-600N 18 6:1 400 yds / 65 lbs 53″ 32
BV-600 18 6:1 500 yds / 65 lbs 53″ 32
BV-600PNN 18 4:1 300 yds / 65 lbs 35″ 32
BV-600PN 18 4:1 400 yds / 65 lbs 35″ 32
BV-600P 19 4:1 500 yds / 65 lbs 35″ 32
VALIANT®(BV) SINGLE SPEED REELS
MODEL WEIGHT (oz) GEAR RATIO LINE CAPACITY-BRAID LINE CAPACITY-MONO INCHES PER CRANK MAX DRAG
BVL-600S 19 7:1 NA 650 yds / 20 lbs 62 20
BVL-600SW 20 7:1 NA 750 yds / 20 lbs 62 20
BVL-800S 24 6:1 NA 800 yds / 30 lbs 56 26
VALIANT®LIGHT LINE (BVL) SINGLE SPEED REELS
ATD
VALIANT

7
TWIN
DRAG
Our patented TwinDrag
TM
technology utilizes carbon fiber drag washers
and stainless-steel friction washers on both sides of the gear to create
the strongest smoothest drag possible.
TwinDrag
TM
SYSTEM
 PATENTED TWINDRAG™ SYSTEM
 BILLET 6061  T6 ALUMINUM
 6 CLASS5 ABEC STAINLESS STEEL BEARINGS
 2 DRAG FRICTION WASHERS
 UNHINDERED FREESPOOL AT EVERY
DRAG SETTING
 GREASED ACCUDRAGS
 STAINLESSSTEEL GEARS, SPRINGS,
HARNESS LUG, HEAD SCREWS
 OVERSIZED RUBBER HANDLE
 1 YEAR WARRANTY
 PROUDLY DESIGNED AND MANUFACTURED
IN THE USA
 LEFTHANDED MODELS AVAILABLE
TwinDrag
TM
SYSTEM
EVEN DRAG PRESSURE
Drag
Pressure
Drag
Pressure
Friction Washers Drag Washers
Traditional fishing reel design applies the drag pressure to only one side of the spool — resulting in uneven pressure placed on reel components
and excessive heat buildup. The TwinDrag™ system applies equal pressure
to both sides of the spool which distributes the drag friction over the
surface of two drag plates instead of one. That’s 50% of the total drag
pressure on each side, resulting in a smoother drag with less heat build-
up and a balanced load on reel bearings and spool. TwinDrag reels also
have extremely accurate drag settings with very little fluctuation. In fact,
Valiant reels will fluctuate less than 1-pound in total drag when line is
drawn at any speed. For example: when the drag is set to 20 pounds on
a Valiant reel, drag pressure will only vary between 19.5 and 20.5 pounds,
or less!

8
Bearing Maintenance - The Class 6 A.B.E.C. bearings in the Valiant reels are teflon impregnated in the ball bearing race;
thus, no lubrication is needed for these bearings.
NOTE: Do not lubricate the two small weep holes on the bottom of the reel. These holes are for water to drain out of the
reel.
Wash down your Valiant reel with fresh water after each use. We recommend lightly spraying it to prevent water from
being forced inside. If heavy pressure is needed put the reel in the “Full” drag position. Do not completely submerge the
reel into water. Wipe the exterior parts with an anti-corrosion lubricant. Use a good quality reel oil to lubricate all the parts
indicated with the oil* symbol. We recommend Clenzoil Lube.
Periodically, check all exterior screws to make sure they are tight. Screws may loosen over time with boat vibrations.
We recommend yearly maintenance of your Valiant reel with a service professional. Preventative maintenance of your
Valiant reel will keep the internal parts in proper working condition and prolong the life of the reel.
Storage - When storing your Valiant reel, put the reel in “Free Spool” and the clicker in the on position.
Maintenance
Engagement
Lever,
Grease
or Oil
Grease
Torx Screws
Oil
Drop of Oil on
Threads of knob
Oil
Oil
Clicker Button
Oil
ATD
VALIANT
Check out the
Accurate YouTube channel
(Accurate Fishing)
for our reel
maintenance videos

9
How Long Does The Limited Warranty Coverage Last? This limited warranty runs for a period of one (1) year starting from
the date that the Valiant reel was first purchased by the consumer. Coverage terminates if you sell or otherwise transfer the reel.
What Does The Limited Warranty Cover? Accurate Fishing Products warrants to the original purchaser that its Valiant
fishing reels are free from defects in material and workmanship with the exceptions stated below.
What Is Not Covered By This Limited Warranty? This limited warranty does not cover damage or problems caused by
misuse, abuse, neglect, accident, installation, alterations or failure to properly maintain the reel.
What Will Accurate Fishing Products Do? Accurate Fishing Products will repair or replace any reel which is defective in
material or workmanship covered by this limited warranty at no charge.
How Do You Get Service? If something goes wrong with your reel, or you want to receive the annual lubrication service, send
it to Accurate Fishing Products, postage pre-paid, along with a sales receipt or other proof of the date of purchase. Be sure your
reel has been registered through our website and include a filled-out service form or a note explaining the problem. Send the
Valiant reel to Accurate Fishing Products at:
Accurate Fishing Products 807 E. Parkridge Avenue, Corona, California 92879.
You can find the service form and reel registration on our website at https://accuratefishing.com/help
You can also check out this link for an authorized service center near you: https://accuratefishing.com/accurate-service-centers/
Please pack your reel with any parts that have been removed securely in a sturdy box. Be certain that your package is
adequately insured and mailed with a shipping company that has tracking capabilities and include the service form or note.
Accurate Fishing Products will inspect your reel and contact you within a timely matter of receipt to inform you whether the
problem is covered by this limited warranty. There is no charge for the inspection.
What Are The Warranty Limitations And Limitations Of Liability? There are no other express warranties. Any warranty of
merchantability or fitness for a particular purpose is limited to the duration of this limited warranty. Accurate Fishing Products
shall NOT be liable for any loss of use, loss of time, inconvenience, commercial loss, or other incidental or consequential damages.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or
consequential damages, so the above limitations and exclusions may not apply to you. This limited warranty gives you specific
legal rights, you may have additional rights which vary from state to state.
Accurate Fishing Products One Year Limited Warranty VALIANT Reels
Warranty
VALIANT

For More Information
Visit Accurate Fishing Online At:
Additional Reel Information
Reel Service And Maintenance Tips
Additional Accessories
Charters, Trips, And Lodges
www.ACCURATEFISHING.com
@ACCURATEFISHING
