ACD M2Smart SE Reference guide

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 1 / 32
Brief Overview/Resumen breve/
Aperçu rapide
Accessories –M2Smart®SE
Accesorios –M2Smart®SE
Accessoires –M2Smart®SE
Version/ Versión: 1.02

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 2 / 32
U.S. Edition 2021/EE. UU. Edición 2021/Édition français 2021
© Copyright ACD Group
All Rights Reserved
This document may not be duplicated or made accessible to third parties without written permission by ACD.
Todos los derechos reservados
Este documento no se puede reproducir ni facilitar a terceros sin consentimiento por escrito de ACD.
Tous droits réservés
Ce document ne peut pas être dupliqué ou rendu accessible àtiers sans l'autorisation écrite d'ACD.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 3 / 32
Table of Contents/Índice/Table des matières
English
1Introduction ..................................................................................................4
2Transportation and Storage..........................................................................6
3Scope of Delivery.........................................................................................6
4Commissioning and Operation of M2Modules..............................................6
4.1 M2Modules................................................................................................................ 6
4.1.1 Intended Use........................................................................................................ 6
4.1.2 Security Advices ..................................................................................................6
4.1.3 Attaching and removing the modules ..................................................................8
4.2 M2UHF-RFID Shortrange ......................................................................................... 9
4.2.1 Security Advices ..................................................................................................9
4.2.2 Handling.............................................................................................................10
4.2.3 Technical Data M2UHF-RFID Shortrange.........................................................11
4.2.4 FCC Statement of Compliance..........................................................................11
4.2.5 IC Statement of Compliance..............................................................................11
4.2.6 RF Exposure......................................................................................................11
4.2.7 Security Advices ................................................................................................12
4.2.8 Handling.............................................................................................................13
4.2.9 Technical Data M2UHF-RFID Midrange............................................................14
4.2.10 FCC Statement of Compliance..........................................................................14
4.2.11 IC Statement of Compliance..............................................................................14
4.2.12 RF Exposure......................................................................................................14
4.3 Docking station DS2Smart®Charging and transmission box, DS2Smart®Charging box and
DS2Smart®Developer box .....................................................................................15
4.3.1 Security Advices ................................................................................................15
4.3.2 Inserting the Mobil Handheld Computer in and removing it from the docking station
........................................................................................................................... 15
4.3.3 Inserting the replacement rechargeable battery in and removing it from the docking
station ................................................................................................................16
4.3.4 Status LEDs.......................................................................................................17
4.3.5 Disposal of the DS2Smart®................................................................................18
4.4 Docking station DS2Battery 2-fold..........................................................................18
4.4.1 Security Advices ................................................................................................18
4.4.2 Inserting the replacement rechargeable battery in and removing it from the docking
station ................................................................................................................19
4.4.3 Status LEDs.......................................................................................................20
4.4.4 Disposal of the DS2Battery................................................................................20
4.5 M2Grip5 ..................................................................................................................21
4.5.1 Security Advices ................................................................................................21
4.5.2 Attaching M2Grip5 to the M2Smart®SE.............................................................21
4.5.3 Removing M2Grip5 from the M2Smart®SE ....................................................... 22
4.6 M2 logistics protective caps....................................................................................23
4.6.1 Security Advices ................................................................................................23
4.6.2 Attaching M2 logistics protective caps to the M2Smart®SE ..............................23
4.6.3 Removing M2 logistics protective caps from the M2Smart®SE.........................24
4.7 Replacement Battery .............................................................................................. 26
4.7.1 Security Advices ................................................................................................26
4.7.2 Rechargeable battery change............................................................................26
5Instructions for Cleaning and Care.............................................................28
5.1 Communication contacts.........................................................................................28
5.2 Keyboard/Keys........................................................................................................28
6Support.......................................................................................................29
7Service and Spare Parts ............................................................................29
8Manufacturer’s Representations and Warranties .......................................30

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 4 / 32
Français
9Mise en service et fonctionnement des M2Modules...................................32
9.1 M2UHF-RFID Shortrange .......................................................................................32
9.1.1 Exposition aux RF..............................................................................................32
9.2 M2UHF-RFID Midrange.......................................................................................... 32
9.2.1 Exposition aux RF..............................................................................................32
Español
1 Introduction
Read all instructions first before using the Mobile Handheld
Computer!
Use Original Spare Parts Only.
There are several accessories for th M2Smart®SE available, which are explained below:
M2UHF-RFID Shortrange (Figure 1)
M2UHF-RFID Midrange (Figure 2)
Docking station DS2Smart®Charging and transmission box (Figure 3)
Docking station DS2Smart®Charging box (Figure 4)
Docking station DS2Smart®Developer box (Figure 5)
Docking station DS2Battery 2-fold (Figure 6)
M2Grip5 (Figure 7)
M2 logistics protective caps (Figure 8)
Replacement Battery (Figure 9)
Figure 1: M2UHF-RFID Shortrange Figure 2: M2UHF-RFID Midrange

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 5 / 32
Figure 3: DS2Smart®Charging and transmission box Figure 4: DS2Smart®Charging box
Figure 5: DS2Smart®Developer box Figure 6: DSBattery 2-fold
Figure 7: M2Grip5 Figure 8: M2 logistics protective caps
Figure 9: Replacement Battery

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 6 / 32
2 Transportation and Storage
ATTENTION
The rechargeable battery for the Mobile Handheld Computer is a
lithium ion rechargeable battery pack. Lithium ion rechargeable
batteries can explode if they are subjected to fire or heat. The
rechargeable battery pack may not be taken apart and subjected to
fire or heat (greater than 60 °C/140 °F).
ATTENTION
Do not set the Mobile Handheld Computer, battery, docking station
or power supply near heat sources (heater blowers, etc.) and never
subject it to direct solar radiation, excess quantities of dust or
shocks. Make sure that there is no stumbling hazard due to
connection cable or power supplies.
The maximum permissible ambient temperatures for the
M2Smart®SE with battery are listed below.
Operating temperature: -20 °C to 50 °C/-4 °F to 122 °F*
Storage temperature: -20 °C to 60 °C/-4 °F to 140 °F
Charging temperature: 5 °C to 35 °C/41 °F to 95 °F
* The device should only be used in the deep-freeze area after the
starting process.
3 Scope of Delivery
The scope of delivery described above can vary and depends on the corresponding PO.
Please check the package content directly after receipt to ensure that it is complete and undamaged. If a
shipment is incomplete or damaged, please report this immediately to the responsible office at your
company.
4 Commissioning and Operation of M2Modules
4.1 M2Modules
4.1.1 Intended Use
The modules of the Mobile Handheld Computer serve as accessories for the M2Smart®SE. The included
components are intended exclusively for use with the Mobile Handheld Computer.
4.1.2 Security Advices
Please read the following warning and safety notices. They are for your safety and to ensure that the various
modules are ready to use.
ATTENTION
Only ACD original power supplies may be used for operation of the
modules! The use of components that have not been approved can
cause the destruction of the modules or the main device.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 7 / 32
ATTENTION
Do not set the modules near heat sources (heater blowers, etc.)
and never subject them to direct solar radiation, excess quantities
of dust or shocks. Make sure that there is no stumbling hazard due
to connection cable or power supplies.
ATTENTION
The modules may not be used in areas subject to explosion.
ATTENTION
Before using the modules, any connection cables must be
checked for damage. Damaged parts must be replaced. For this,
please contact ACD Elektronik GmbH.
ATTENTION
Before use, the contacts of the modules and the contacts of any
plugs present must be checked for dirt and cleaned if necessary.
ATTENTION
Unintended use of the interfaces is forbidden.
ATTENTION
To prevent overheating, the modules may not be covered during
operation.
ATTENTION
The modules may only be opened by trained specialized
personnel.
ATTENTION
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.

NOTE
This is a Class A device (EN55032). This device can cause radio
interference in residential areas.
In this case, the operator can be asked to take appropriate actions.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 8 / 32
4.1.3 Attaching and removing the modules
The upper plug-in module and the lower plug-in module can be attached and removed as shown in the
following figures.
Figure 10: Attaching and removing the upper plug-in module
Figure 11: Attaching and removing the lower plug-in module
When attaching and removing the modules, please do not reach into the area of the plug-in sliding
mechanism, as there is a risk of injury due to jamming during sliding.
ATTENTION
When attaching and removing the modules, please do not reach
into the area of the plug-in sliding mechanism, as there is a risk of
injury due to jamming during sliding.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 9 / 32
4.2 M2UHF-RFID Shortrange
The M2UHF-RFID Shortrange is described below. It is a plug-in module for reading UHF-RFID tags, which
can be used for the upper plug-in sliding mechanism.
Figure 12: M2UHF-RFID Shortrange
4.2.1 Security Advices
ATTENTION
The M2UHF-RFID Shortrange is designt for occupational use only.
ATTENTION
Removal of the plug-in module on the upper plug-slide mechanism
of the device:
Please do not reach into the area around the scanner glass; there
is a risk of injury due to pinching when sliding.
The scanner glass can also be soiled in the process.
ATTENTION
The maximum permissible ambient temperatures for the modules
are listed below.
Operating temperature: -20 °C to 50 °C/-4 °F to 122 °F
Storage temperature: -20 °C to 60 °C/-4 °F to 140 °F
ATTENTION
The device has the following radio system:
UHF-RFID
Frequency bands:
UHF-RFID Europe
865.7 to 867.5 MHz
UHF-RFID North America
902.75 to 927.25 MHz
Max. permissible transmission power on the frequency bands:
UHF-RFID 200 mW
ATTENTION
The M2UHF-RFID Shortrange attachable module can become very
hot during extended operation. To protect persons and the
module, the maximum time of a scan is limited to two minutes.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 10 / 32
4.2.2 Handling
After the M2UHF-RFID Shortrange attachable module has been plugged into the main device on the upper
plug-slide mechanism, it can be used for reading UHF-RFID tags.
To do this, start a software application to initialize the module. Then the read process can be carried out with
the software application.
Figure 13: M2UHF-RFID Shortrange Antenna and Radiation
The red box represents where the antenna is palced and the red lines indicate the radiation of HF signal.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 11 / 32
4.2.3 Technical Data M2UHF-RFID Shortrange
The table below includes the technical data for the M2UHF-RFID Shortrange plug-in module.
Technical Data
Housing
ABS/PC
Protection class
IP54
Operating
temperature
-20 °C to 50 °C/-4 °F to 122 °F
Condensation of the device must be avoided.
Storage temperature
-20 °C to 60 °C/-4 °F to 140 °F
Rel. humidity
5 % - 90 % non-condensing
Device dimensions
52 x 85 x 27 mm (L x W x H)
Weight
58 g
Interfaces
Plug for connection to the main device
Frequency range EU
865.7 to 867.5 MHz
Frequency range
USA and Canada
902.75 to 927.25 MHz
Read range
Up to 1.5 meters
Antenna type
Integrated Linear Polarized
RFID protocols
EPCglobal UHF Class 1 Gen 2
ISO 18000-63 (formerly 18000-6C)
DRM (Dense Reader Mode) support
Output power
0 dBm until +23 dBm
4.2.4 FCC Statement of Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device should accept any interference, including interference that may cause undesired operation of
the device.
4.2.5 IC Statement of Compliance
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference
(2) This device must accept any interference, including interference that may cause undesired operation of
the device.
4.2.6 RF Exposure
This equipment complies with FCC and IC SAR exemption limits at a minimum separation distance of
50 mm from the Antenna of this module.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 12 / 32
M2UHF-RFID Midrange
The M2UHF-RFID Midrange is described below. It is a plug-in module for reading UHF-RFID tags, which can
be used for the upper plug-in sliding mechanism.
Figure 14: M2UHF-RFID Midrange
4.2.7 Security Advices
ATTENTION
The M2UHF-RFID Midrange is designt for occupational use only.
ATTENTION
Removal of the plug-in module on the upper plug-slide mechanism
of the device:
Please do not reach into the area around the scanner glass; there
is a risk of injury due to pinching when sliding.
The scanner glass can also be soiled in the process.
ATTENTION
The maximum permissible ambient temperatures for the modules
are listed below.
Operating temperature: -20 °C to 50 °C/-4 °F to 122 °F
Storage temperature: -20 °C to 60 °C/-4 °F to 140 °F
ATTENTION
The device has the following radio system:
UHF-RFID
Frequency bands:
UHF-RFID Europe
865.7 to 867.5 MHz
UHF-RFID North America
902.75 to 927.25 MHz
Max. permissible transmission power on the frequency bands:
UHF-RFID 500 mW
ATTENTION
The M2UHF-RFID Midrange attachable module can become very
hot during extended operation. To protect persons and the
module, the maximum time of a scan is limited to two minutes.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 13 / 32
4.2.8 Handling
After the M2UHF-RFID Midrange attachable module has been plugged into the main device on the upper
plug-slide mechanism, it can be used for reading UHF-RFID tags.
To do this, start a software application to initialize the module. Then the read process can be carried out with
the software application.
Figure 15: M2UHF-RFID Shortrange Antenna and Radiation
The red box represents where the antenna is palced and the red lines indicate the radiation of HF signal.
.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 14 / 32
4.2.9 Technical Data M2UHF-RFID Midrange
The table below includes the technical data for the M2UHF-RFID Midrange plug-in module.
Technical Data
Housing
ABS/PC
Protection class
IP54
Operating
temperature
-20 °C to 50 °C/-4 °F to 122 °F
Condensation of the device must be avoided.
Storage temperature
-20 °C to 60 °C/-4 °F to 140 °F
Rel. humidity
5 % - 90 % non-condensing
Device dimensions
52 x 85 x 27 mm (L x W x H)
Weight
58 g
Interfaces
Plug for connection to the main device
Frequency range EU
865.7 to 867.5 MHz
Frequency range
USA and Canada
902.75 to 927.25 MHz
Read range
Up to 6 meters
Antenna type
Integrated Linear Polarized
RFID protocols
EPCglobal UHF Class 1 Gen 2
ISO 18000-63 (formerly 18000-6C)
DRM (Dense Reader Mode) support
Output power EU
0 dBm until +27 dBm
Output power
USA and Canada
0 dBm until +26.5 dBm
4.2.10 FCC Statement of Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device should accept any interference, including interference that may cause undesired operation of
the device.
4.2.11 IC Statement of Compliance
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference
(2) This device must accept any interference, including interference that may cause undesired operation of
the device.
4.2.12 RF Exposure
This equipment complies with FCC and IC SAR exemption limits at a minimum separation distance of
50 mm from the Antenna of this module.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 15 / 32
Commissioning and Operation of Accessories
4.3 Docking station DS2Smart®Charging and transmission box, DS2Smart®
Charging box and DS2Smart®Developer box
4.3.1 Security Advices
ATTENTION
Only ACD original power supplies and rechargeable batteries
approved by ACD may be used for the operation of the Mobile
Handheld Computer and docking station! The use of components
that have not been approved can cause the destruction of the
backhand scanner or docking station. Do not use the ACD-
approved components with a third-party device.
ATTENTION
Before use, the Mobile Handheld Computer incl. battery, docking
station, power supply, and any connection cables should be
checked for damage. Damaged parts should be replaced. Please
contact ACD Elektronik GmbH to do this.
ATTENTION
For indoor use only.
ATTENTION
To prevent overheating, the Mobile Handheld Computer incl.
battery, docking station, and the power supply should not be
covered while they are in operation.
ATTENTION
Never position the Mobile Handheld Computer incl. battery in close
proximity to heat sources (heating fans or similar equipment) and
never expose it to direct sunlight, excessive dust sources or
shocks.
4.3.2 Inserting the Mobil Handheld Computer in and removing it from the docking station
To insert the Mobile Handheld Computer in the docking station, put it in vertically downward. To remove the
Mobile Handheld Computer from the docking station, pull it vertically upward out of the docking station.
Figure 16: Inserting Mobile Handheld Computer in and removing it from the docking station

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 16 / 32
ATTENTION
Place the docking station correctly on a smooth and clean
underground, which is not exposed to direct sunlight.
ATTENTION
The charging and communication contacts are very sensitive! The
Mobile Handheld Computer and the replacement rechargeable
battery may only be inserted in and removed from the docking
station as described above. Do not touch the contact with your
fingers or with objects such as pens, screwdrivers, etc.
ATTENTION
Do not leave the battery in the charger or docking station for an
unnecessarily long time.
4.3.3 Inserting the replacement rechargeable battery in and removing it from the docking
station
To insert the replacement rechargeable battery in the device, tip it diagonally downward and place it in the
rechargeable battery compartment. Insert the rechargeable battery so that the contacts are aligned with the
contacts of the docking station. Press the rechargeable battery into the rechargeable battery compartment
until it snaps in audibly.
Figure 17: Inserting replacement rechargeable battery in the docking station
To remove the replacement rechargeable battery from the docking station, first open the lock by pressing
toward the surface of the rechargeable battery. Remove the rechargeable battery upward.
Figure 18: Removing replacement rechargeable battery in the docking station

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 17 / 32
ATTENTION
Place the docking station correctly on a smooth and clean
underground, which is not exposed to direct sunlight.
ATTENTION
The charging and communication contacts are very sensitive! The
Mobile Handheld Computer and the replacement rechargeable
battery may only be inserted in and removed from the docking
station as described above. Do not touch the contact with your
fingers or with objects such as pens, screwdrivers, etc.
ATTENTION
Do not leave the battery in the charger or docking station for an
unnecessarily long time.
4.3.4 Status LEDs
The status LEDs of the DS2Smart®docking station will be described below.
Figure 19: Status LEDs of the DS2Smart®
Charging cradle for M2Smart®SE
Speed CHARGE LED lit red:
The rechargeable battery in the M2Smart®SE is being
charged
Speed CHARGE LED lit green:
The rechargeable battery in the M2Smart®SE is fully
charged
Speed CHARGE LED not lit:
No M2Smart®SE is inserted in the docking station
Charging cradle for replacement rechargeable battery
CHARGE LED lit red:
Replacement battery is being charged
CHARGE LED lit green:
Replacement battery is fully charged
CHARGE LED not lit:
There is no replacement battery inserted in the docking
station
The charging time of a battery of the M2Smart®SE is approx. 4.5 hours at room temperature.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 18 / 32
4.3.5 Disposal of the DS2Smart®
ATTENTION
All components should be disposed of properly at the end of their
technical lifetime.
4.4 Docking station DS2Battery 2-fold
4.4.1 Security Advices
ATTENTION
Only ACD original power supplies and rechargeable batteries
approved by ACD may be used for the operation of the Mobile
Handheld Computer and docking station! The use of components
that have not been approved can cause the destruction of the
backhand scanner or docking station. Do not use the ACD-
approved components with a third-party device.
ATTENTION
Before use, the Mobile Handheld Computer incl. battery, docking
station, power supply, and any connection cables should be
checked for damage. Damaged parts should be replaced. Please
contact ACD Elektronik GmbH to do this.
ATTENTION
For indoor use only.
ATTENTION
To prevent overheating, the Mobile Handheld Computer incl.
battery, docking station, and the power supply should not be
covered while they are in operation.
ATTENTION
Never position the Mobile Handheld Computer incl. battery in close
proximity to heat sources (heating fans or similar equipment) and
never expose it to direct sunlight, excessive dust sources or
shocks.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 19 / 32
4.4.2 Inserting the replacement rechargeable battery in and removing it from the docking
station
To insert the replacement rechargeable battery in the device, tip it diagonally downward and place it in the
rechargeable battery compartment. Insert the rechargeable battery so that the contacts are aligned with the
contacts of the docking station. Press the rechargeable battery into the rechargeable battery compartment
until it snaps in audibly.
Figure 20: Inserting replacement rechargeable battery in the docking station
To remove the replacement rechargeable battery from the docking station, first open the lock by pressing
toward the surface of the rechargeable battery. Remove the rechargeable battery upward.
Figure 21: Removing replacement rechargeable battery in the docking station
ATTENTION
Place the docking station correctly on a smooth and clean
underground, which is not exposed to direct sunlight.
ATTENTION
The charging and communication contacts are very sensitive! The
Mobile Handheld Computer and the replacement rechargeable
battery may only be inserted in and removed from the docking
station as described above. Do not touch the contact with your
fingers or with objects such as pens, screwdrivers, etc.
ATTENTION
Do not leave the battery in the charger or docking station for an
unnecessarily long time.

M2Smart®SE_Set_Brief Overview_V1.02_en_es_fr 20 / 32
4.4.3 Status LEDs
The status LEDs of the DS2Battery docking station will be described below.
Figure 22: Status LEDs of the DS2Battery
Charging cradle for replacement rechargeable battery
CHARGE LED lit red:
Replacement battery is being charged
CHARGE LED lit green:
Replacement battery is fully charged
CHARGE LED not lit:
There is no replacement battery inserted in the docking
station
The charging time of a battery of the M2Smart®SE is approx. 4.5 hours at room temperature.
4.4.4 Disposal of the DS2Battery
ATTENTION
All components should be disposed of properly at the end of their
technical lifetime.
