The Getac PS236 Fully Rugged Handheld

The Getac PS236 is the first fully rugged handheld built to meet

MIL-STD 810G with high-speed HSDPA wireless networking*.

The PS236 features a high sensitivity GPS receiver, E-Compass

and altimeter, making it perfect for GIS applications and a built-in

three megapixel auto-focus camera has been neatly integrated to

provide an all-in-one solution.

The PS236 includes 4GB of embedded memory and can be

expanded to a total of 20GB of memory using the external SDHC

card** The PS236 can be customized with either the standard

numeric keypad or a PDA keypad depending on the application

and need. The PS236 is preinstalled with Windows® Mobile 6.1

software for quick access to email, the Internet, texting and other

means of mobile communications.

Weighing a mere 18 ounces, the device can operate at full

capacity for up to 12-hours on a fully-charged battery and is MIL-

STD 810G compliant and IP67 compliant to operate without failure

under the most extreme weather conditions, environments and

everyday abuse associated with its user base.

MIL-STD 810G and IP67 Compliance

Microsoft Windows Mobile® 6.1

3.5G WWAN

RS232 Serial Port, USB OTG & SDIO / SDHC Slot

Field Swappable Long Life Li-Ion Battery

Embedded High Sensitivity GPS Receiver

3 Megapixel Pixels Auto-focus Camera

Getac PS236

Fully Rugged Handheld

Chipset: SiRF Star III

Receiver type: L1 (C/A)

Channels: 20 channel all-in-view tracking

Update rate: 1 Hz

Autonomous: 5 m

DGPS: 1~3 m

Cold start time: 45 sec average

Warm start time: 30 sec average

Hot start time: 1 sec average

Reacquisition: 0.1 sec average

Battery type: 3.72V, 5600 mAh

Li-Ion battery pack

7” x 3.5” x 1.18”

(178 x 89 x 30 mm)

17.64 oz (500g)**

Operating temp:

-22°F to 140°F (-30°C to 60°C)

Storage temp:

-40°F to 158°F (-40°C to 70°C)

Humidity: 5% ~ 95% (non-condensing)

SDIO / SDHC x 1

DC x 1

USB OTG x 1

RS232 x 1

Ofﬁce docking port x 1

Speaker x 1

Camera x 1

Battery cover x 1

Stylus pen x 1

3 Year limited warranty standard†

Water & dust resistance: IP67

Drop spec:

1.52 m (5 ft) drop on all faces, edges and

corners on steel per MIL-STD-810G

Electrostatic discharge:

+/- 15kVdc air discharge,

+/- 8kVdc contact discharge

Tumble spec:

1,000 1.6 ft/0.5m tumbles (2,000 drops)

Genuine Windows®Mobile 6.1 Classic

Genuine Windows®Mobile 6.1 Professional

Marvell PXA310 806MHz

128MB MDDR

256MB NAND Flash and 4GB iNAND*

SDIO and SDHC

(up to 16GB SDHC memory card*)

3.5” VGA (480 x 640 pixel)

Transﬂective sunlight readable display

Pressure sensitive touchscreen

Soft input panel (SIP) on screen keyboard

Transcriber handwriting recognition

Optional numeric or PDA keypad

WLAN 802.11 b/g

Bluetooth (v2.0 +EDR Class 2)

3 Megapixel auto-focus

E-Compass

Altimeter

Microsoft getting started disc

AC adaptor

USB cable

Protective ﬁlm

Hand strap

Quick start guide

Battery

Sylus pen

Ruggedness

Operating System

Microprocessor

Memory

Storage

SD Card Slot

Display

Keypad

Communications

Camera

Special Features

Included Accessories

GPS Sensor

Speciﬁcations

Power

Dimensions and

Weight

Temperature

I/O Interfaces

Warranty

tionject to change without notice. Battery life testing conducted under in the United States and/or other countries. Microsoft and Windows are registered trademarks of

Microsoft Corporation in the United States and in other countries. All other trademarks are the property of their respective owners.

Specication subject to change without notice. Battery performance will vary based on software applications, wireless settings, power management settings, LCD brightness, customized modules

and environmental conditions. As with all batteries, maximum capacity decreases with time and use and may eventually need to be replaced by a Getac service provider. Battery life and charge

cycles vary by use and settings. Battery life may be reduced in subzero applications.

* For storage, 1GB = 1 billion bytes; actual formatted capacity less.

** Weight is without 3G module. Weight varies by conguration and manufacturing process.

† For warranty terms and conditions visit www.getac.com
