ACDC Dynamics PBU-1000W-UPS User manual

PORTABLE
POWER STATION
USER MANUAL
Recommended to fully charge PBU-1000W-UPS before use
PBU-1000W-UPS
www.acdc.co.za
National Sales Centre - 010 202 3400 | Technical - 010 202 3500 www.acdc.co.za THINK ELECTRICAL

GENERAL SPECIFICATIONS
The is a portable battery pack with the ability to supply 1000W of pure
sine wave AC power via the onboard AC output. Additionally, The PBU-1000W-UPS is able
to support USB quick charging via the onboard 1 x USB PD port and 3 x USB A ports.
Overall storage capacity is 999Wh of energy.
Rated Output Power
1000W
Rated capacity
999Wh
Standard capacity
3.7V/270000mAh
Peak AC output
2000W
AC continuous output
1000W
Output waveform
pure sine wave
USB output
QC3.0/18W * 3
Output Type-C
PD100W * 1
Cigarette Lighter Socket Output
12V-14V/10A
DC 55*2.1 output
12V-14V/5A* 2
AC input
500W(184-264V 5.7A Max)
Anderson input
400W(12-75V 12A Max)
Working temperature
-
10-40°C
Weight (net weight)
9.3kg
Weight (including accessories)
11.2kg
Product size
328*221*263mm
Operating Temp
14 to 104°F (-10 to 40°C)
Charging Temp
32 to 104°F (0 to 40°C)
Storage Temp
-
4to 113°F (-20 to 45°C)
1
PBU-1000W-UPS

WARNINGS
To ensure safe operation and service , follow these
instructions. Failure to observe these warnings can result in
severe injury or death.
•DO NOT use in excess of its output rating. Overload outputs above
rating may result in a risk of fire or injury to persons, even though we have built-in
overload protection.
•DO NOT use , if it is damaged or has been modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire, explosion, or risk
of injury.
•DO NOT subject to vibration, impacts, or drops. Secure during transport.
The housing may not show signs of damage, but internal components may have been
compromised. It is advisable to replace it if any such severe events occur.
•DO NOT expose to moisture, rain, or snow.
•DO NOT charge, use or store in a bathroom or in an area exposed to rain
or moisture.
•DO NOT leave children or the persons, who with reduced physical/sensory or mental
capabilities/or lack of experience and knowledge, along with unless they
have been given supervision or instruction concerning use of it by a person responsible for
their safety.
•DO NOT attempt to repair . There are no user-serviceable
components inside.
•DO NOT handle with wet hands.
•DO NOT place on its side or upside down while in use or in storage.
•If rust, odor, overheating, or other abnormal circumstance are observed, stop using
and contact intelligentenergy customer service.
•Children should be supervised to ensure that they DO NOT play with the
alone.
• The is only used for emergency power station, it cannot replace
the standard AC or DC power of household appliances or digital products.
•Keep away from high voltage electrical fields.
• Risk of fire and burns, DO NOT open, crush, heat above 113°F (45°C) or
incinerate. Follow all instructions.
•Use of a power supply, charger, or cable not recommended or sold by portable
battery manufacturer may result in a risk of fire or injury to persons.
•Should fluid from inside of come in contact with your skin or clothing,
wash the affected areas with tap water.
•The accessories included in the box should only be used with the .
•KEEP THIS PRODUCT AWAY FROM PETS.
2
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS

BUTTON FEATURE
FEATURE DETAILS
1.SOS MODE & LED light2.Cigarette Lighter Output 3.Anti-collusion Strip
4.DC Output 5.1000W Rated AC Output 6. USB Output
7.LCD Screen Display 8. logo 9. Handle
10.straps hooks 11.Air Intake Vent with Cooling Fan
12.Solar Charging Input 13.AC input
Note: No user-serviceable parts inside.
Recommended to fully charge the before use.
1. Power ON/OFF Button 2.USB Output Power ON/OFF Button
3.SOS mode & LED light Button 4.AC Output Power ON/OFF Button
5.SOS mode & LED light Button 6. DC Output Power ON/OFF Button
3
PBU-1000W-UPS

A.Battery Level Indicator B. total Outputs Status C.LED Status
D.AC Outputs Status E.UPS Status F.abnormality Status
G.USB Outputs Status H.DC Outputs Status I.LED Status
J. Inputs Status
By solar panels
400W (12-75V 12A Max)
about 3-5 hours
depending on solar conditions
By Car Port 12V 10A
about 11-13 hours when car running
From Wall Charger 230V
2.5-3.5 hours
4
LCD FEATURES
HOW TO CHARGE

WHAT IT POWERS
Laptops (41.4Wh)
32" TV(60W)
CPAP without heated
Go pro (5.9Wh)
Floodlight(4W)
Around
Around
humidifier (15W)
Around
Around
19 Recharges
13 hours
53hours
135 Recharges
200 hours
+MORE
Mini Fridge(40W)
DJ Drone(89.2Wh)
Smartphone(10Wh)
Switch(16Wh)
Around
Around
Around
Around
20 hours
9 Recharges
80 Recharges
50 Recharges
Uninterruptible Power Supply (UPS)
5
This product supports an uninterruptible power supply (UPS) function. The unit's
battery will be bypassed while fully charged and connected to the grid via AC
charging cable. In other words, anything you plug into the AC port will pull directly
from the grid rather than the battery. In a power outage , this product can automati-
cally switch to the battery powered mode within 10ms.
Note: The function does not support 0ms switching. Therefore, it is not recommend-
ed to be used as a UPS for highly sensitive equipment, such as data services and
workstations without confirming compatibility or proper testing before use. It is also
recommend to only use the UPS function for one device at a time to avoid overload
protection, VIGOPROOL assumes no responsibility ans is therefore not lable for
data loss or damage caused by the use of this product in setups that it was not
intend for and the disregard of this recommendation.

FUNCTION BUTTONS
POWER ON/OFF
SOS MODE & LED LIGHT
DC OUTPUT POWER ON/OFF
USB OUTPUT POWER ON/OFF
6
Function available only when the Button ①activate .
Firstly, press Button one time ③or ⑤to turn on the LED light and get 3W;
Secondly, press button ③or ⑤again to make LED light brighter at 5W
Thirdly, press button ③or ⑤thirdly to turn on the SOS mode;
Fourthly, press Button ③or ⑤to turn on the sharp-flash, one more time again will
turn off the light.
If both LED lights have been activated, press button ③or just button ⑤can control
both LED light at the same time. If you want to power both LED off, needs to press
both buttons ③and ⑤.
The DC output port will NOT function until the appropriate Button ①&⑥are both
pressed to activate.Press Button ⑥to shut down the output(s)When not in use.
The USB output port will NOT function until the appropriate Button ①&②are both
pressed to activate.Press Button ②to shut down the output(s) When not in use.
The USB C output port will NOT function until the appropriate Button ①&②are both
pressed to activate.
The USB C cable of different devices need different endorsements of corresponding
protocols, if the USB C port didn't work, try to use the AC output port.
Button ①is the master switch. Press Button ①to activate all buttons.
Press Button ①to shut down the output(s)When not in use.
PBU-1000W-UPS

AC OUTPUT POWER ON/OFF
The AC output port will NOT function until the appropriate Button &are both
pressed to activate.
Press Button to shut down the output(s)When not in use.USB C OUTPUT(4)
COOLING FAN(12)
PORTABLE POWER STATION utilizes an internal cooling fan to
ensure the product is operating within the appropriate temperature range. PORTABLE
POWER STATION , when it experiences a higher output load, will
automatically turn on the fan. During discharge, and possibly charging, the fan may
operate intermittently to keep internal temperature within operating range. The fan will
likely start when the AC circuit is activated to ensure proper operation.
7
PBU-1000W-UPS
PBU-1000W-UPS

DETAILS DISPLAYED ON LCD
BATTERY LEVEL INDICATOR :
Thebattery level is showing by percentage ofbattery.
charge corresponding to the number of bars and percentage displayed. The
segments in the battery level correspond to the current state of charge, 0-10% one
segment, 11-20% two segments, 21-30% three segments, 31-40% four segments,
41-50% five segments, 51-60% six segments, and so on, all ten are lit when
charge level is above 91%.
Provides the user live telemetry data on time to completely charge, or deplete the
battery based upon the energy entering or leaving the battery.
Highly recommend to fully charge PORTABLE POWER STATION when
first use. Higher battery level indicator show, more precise data will indicate.
PLEASE BE AWARE thatthis value can adjust multiple times as the energy draw
changesfrom the connected devices. This is evident during initial activation of ports
with a connected device.
RECOMMENDED back to charge the PORTABLE POWER STATION
when battery indicate less than 20%. Note that when you first plug in a power
source, whether it's a solar panel or a wall charger, the PORTABLE POWER
STATION may take a minute to detect and adjust its charge
circuitry before it starts drawing power from the source.
INPUT Status J: The is capable of providing input energy in watts.
DC Output Status H: The display will provide output watts of the DC port on position of B.
AC Output Status D: The display will provide output watts of the AC port on position of B.
The output watts of USB port will display on the LCD Screen B position.
LCD Screen will enter sleep mode after 180 seconds of inactivity (no new output load
detected), and will "wake up" when inputting a charging cord or when any button is
pressed.
8
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS

CHARGING PORTABLE POWER STATION
Connect the provided AC power cord to Input, and allow PORTABLE POWER
STATION to fully charge prior to use, approx. 2.5 - 3.5 hours.
When charging, the LCD Screen will be illuminated, and the LCD display will
provide Battery level Indicator A , PORTABLE POWER STATION
is fully charged when the level is 100%. It is recommended to fully
charge PORTABLE POWER STATION every 3 months to
maintain the health of the battery pack.
9
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS

POWERING / CHARGING DEVICES WITH PBU-1000W-UPS
Select the type of outlet required by pressing the Output ON/OFF Button . The
output port will NOT function until the appropriate button is pressed to activate the
port. When activated, the indicator on the button will illuminate blue, indicating that the
output(s) are active, and the LCD display will turn on and provide details on the
charging output. The LCD Screen will automatically shut down when no outputs are
activated.
PORTABLE POWER STATION will enter sleep mode after 180
seconds of inactivity (no new output load detected), and will "wake up" when inputting a
charging cord or when any button is pressed. Press the ON/OFF button(s) to shut
down the output(s) when not in use.
PASS-THROUGH CHARGING
The advanced battery management system of the PORTABLE POWER STATION
allows it to charge a connected device via DC output & USB output while
charge the PORTABLE POWER STATION
support AC output during AC power cord charging itself.
OVERLOAD CONDITION
If an overload condition occurs on the OUTPUT port, PORTABLE POWER STATION
will:
Automatically turn off AC Output power.
Theindicator of LCD Screen willbe illuminated.
Do following:
Check the input charge cable. The port will be efficient when the input charge cable meets
the specification outlined in the GENERAL SPECIFICATIONS section.
Only charge PORTABLE POWER STATION with provided AC
power cord.
PBU-1000W-UPS ACCESSORY LIST
AC power cord Car Charger to Anderson Cable User Manual
Recommend to use Solar panel (not included)
10
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS

CLEANING
Be sure that PORTABLE POWER STATION is disconnected from all
input power sources and output devices. Use a clean, dry, soft-lint-free cloth to wipe
down it. Remove any debris, dirt, or other blockages on both side vents. When
cleaning debris from the side vents, do not allow the debris, dirt, or other blockages to
enter the body of PORTABLE POWER STATION .
DO NOT use abrasive cleaners or solvents.
DO NOT use compressed air to clean side cooling vents, as this will force foreign
particles into the internal circuitry.
To avoid the risk of electrical shock, DO NOT use metal objects to clean ports.
STORAGE
If storing for more than 1 month, charge completely before storage and recharge
approximately every 3 months to avoid full discharge and possible damage. Store
indoors, in cool temperatures, mild humidity, and away from direct sunlight (See
GENERAL SPECIFICATIONS section). Leaving in a vehicle or other confined spaces
in extreme hot temperatures can lead to decreased service life, overheating, and fire.
Extreme cold conditions below specific storage range can also harm
PORTABLE POWER STATION performance and service life. Keep away
from corrosion chemicals and gases.
After taking out of storage, visually inspect to make sure PORTABLE POWER STATION
and all accessories look satisfactory. This increase review the intake and
exhaust side vents to ensure they are clear of debris. Allow
PORTABLE POWER STATION to return to ambient conditions
before recharging, or charging other devices.
ATTENTION
Transportation:PORTABLE POWER STATION complies with all legal
requirements for transport of dangerous goods. The capacity of the lithium battery pack
exceeds 100Wh. Based on international standards, if PORTABLE POWER STATION
is transported by airplane, it must be transported in accordance with
IATA standard packaging. IATA instructions and labeling requirements and the relevant
declarations must be completed.
Not Permitted On Air crafts
To Preserve The Battery Lifespans, Please Use
And Recharge At Least Once Every 3 Months
Use Original Or Certified Charger And Cables
Avoid Extreme Temperature
Avoid Dropping
Do Not Disassemble
It's Not Waterproof,do Not Expose To Liquids
Please Dispose Of Batteries And Electronic
GoodsIn Accordance With Local Regulations
11
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS

TROUBLESHOOTING
PORTABLE POWER STATION WILL NOT
CHARGE OR OPERATE connected devices:
Ensure that the DC/USB/AC output ports are activated by pressing the Button(s)
/ / for the port(s) in use.
Confirm the connected device is suitable for the PORTABLE POWER STATION
by reviewing the output specifications provided in the GENERAL
SPECIFICATIONS section.
Confirm PORTABLE POWER STATION is charged by reviewing
the Battery Level Indicator A.
PORTABLE POWER STATION DO NOT CHARGE:
Confirm thatthe AC power cord is inserted fully into the AC Input(13). Confirm thatthe AC
power cord or charger cable is the charger provided with .
If the input does not comply with the requirements located in the GENERAL
SPECIFICATIONS section, the Low Watt range 0 to 10 may be displayed on.
INPUT STATUS I ofLCD screen(1).
MAINTENANCE
Recharge as needed. There are no predesignated intervals at which to recharge as long
as the PORTABLE POWER STATION is being used regularly. It needs
to wait 1-2hours to recharge again after AC discharging from 100% to 0%
uninterruptedly. Avoid discharging completed on a regular basis, as this can impact
overall life.
Regularly inspect all ports and chargerfor any debris, dirt, damage and corrosion.
DO NOT attempt to fix.
DO NOT cover the PORTABLE POWER STATION with towels,
clothing or other items. Regularly observe if the side vents are collecting dirt or dust,
and clean following cleaning procedures noted in manual.
DISPOSAL/RECYCLE
Do notplace equipment and its accessories in the trash. Items must be
properly disposed of in accordance with local regulations. See
www.epa.gov for additional information.
STATEMENT
Second Edition: Mar 2023. This user guide describes features that are common to
most models.
12
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS
PBU-1000W-UPS

WARRANTY
Limited Warranty
Warranty to the original consumer purchaser that the PORTABLE POWER
STATION will be free from defects in workmanship and material under normal
consumer use during the applicable warranty period identified in the 'Warranty
Period' section below, subject to the exclusions set forth below. This warranty
statement sets forth our total and exclusive warranty obligation. We will not assume,
nor authorize any person to assume for us, any other liability in connection with the
sale of our products.
WARRANTY PERIOD
The warranty period is 12 months. In each case, the warranty period is measured
starting on the date of purchase by the original consumer purchaser. The sales
receipt from the first consumer purchase, or other reasonable documentary proof, is
required in order to establish the start date of the warranty period.
A replacement product assumes the remaining warranty of the original product or ninety
(90) days from the date of replacement, whichever is greater. Customer is responsible
for the return shipping costs.
Limited to Original Consumer Buyer
The warranty on our product is limited to the original consumer purchaser and to
any subsequent owner.
EXCLUSIONS
PORTABLE POWER Station's warranty does not apply to (i) any product that is misused,
abused, modified, damaged by accident, or used for anything otherthan normal
consumer use as authorized in our current product literature, or (ii) any product
purchased through an online auction house. Our warranty does not apply to the battery
cell unless the battery cell is fully charged by you within seven days after you purchase
the product and at least every 3 months thereafter.
13

WARNING
(A) Read all the instructions before using the product.
(B) To reduce the risk of injury, close supervision is necessary when the product is used
near children.
(C) Do not put fingers or hands into the product.
(D) Use of an attachment not recommended or sold by power pack manufacturer may
result in a risk of fire, electric shock, or injury to persons.
(E) To reduce risk of damage to the electric plug and cord, pull the plug ratherthan the
cord when disconnecting the power pack.
(F) Do not use a battery pack or appliance that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire, explosion or
risk of injury.
(G) Do not operate the power pack with a damaged cord or plug, or a damaged
output cable.
(H) Do not disassemble the power pack, take it to a qualified service person when
service or repair is required. Incorrect reassembly may result in a risk of fire or
electric shock.
(I ) To reduce the risk of electric shock, unplug the power pack form the outlet
before attempting any instructed servicing.
(J ) WARNING – RISK OF EXPLOSIVE GASES.
(1) WORKING IN VICINITY OF A LEAD ACID BATTERY IS DANGEROUS.
BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL BATTERY
OPERATION. FOR THIS REASON, ITIS OF THE UTMOST IMORTANCE THAT
YOU FOLLOW THE INSTRUCTIONS EACH TIME YOU USE THE POWER PACK.
(2) To reduce risk of battery explosion, follow these instructions and those
published by battery manufacturer and manufacturer of any equipment you
intend to use in vicinity of the battery. Review cautionary marking on these
products and on engine.
When charging the internal battery, work in a well ventilated area and do
not restrict ventilation in any way.(m) Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.(n) Do not expose a power pack tofire or
excessive temperature.
FCC Caution:
This device complies with part 15 of the FCC Rules. Operation is subject tothe following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested andfound to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
14

installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation.
If this equipment does cause harmful interference to radio or television reception,which
can be determined by turning the equipment off and on, the user is encouraged totry to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC RF Exposure guidelines, This equipment should be
installed and operated with minimum distance between 20cm the radiator your body:
Use only the supplied antenna.
NOTES
15
